BETCO GS15 User manual





G
G
S
S

S
S
1
1
5
5
5
5
E890
0
00
‐0
0
A
15” G
r
A
uto
m
r
out
m
atic
S
S
crubber

1
1.0 NOTES FOR THE CLIENT
This manual provides information concerning use, maintenance and safety of Dirt Dragon machine designed and
constructed to guarantee maximum performance, comfort and ease of use in a variety of circumstances.
We invite you to read it with attention in order to avoid mistakes and obtain the best results.
In addition, we suggest you refer to it if problems should arise.
Before delivery, your Dirt Dragon machine was tested both in the factory and by our dealer to guarantee perfect
functioning. To maintain the machine in this condition and assure trouble-free use, it is necessary to perform
periodic maintenance as described in the manual (See page 11).
2.0 MODIFICATIONS AND IMPROVEMENTS
We reserve the right to carry out, when necessary, modifications and improvements without granting these
improvements to previously sold machines.
3.0 CONVENTIONS AND LEGEND
Indications such as RIGHT or LEFT, CLOCKWISE or COUNTER-CLOCKWISE used in this booklet relate to the
forward movements of the machine.
The paragraphs preceded by this symbol concern instructions which, if not followed, can cause
damage to the machine.
The paragraphs preceded by this symbol concern instructions which, if not followed, can cause
damage to people.
The paragraphs preceded by this symbol concern instructions which must be read very carefully.
Use this manual to get acquainted with the characteristics of the machine and better understand how to make the
best use of them.
4.0 SAFETY RULES
Most accidents at work happen because of failure to adhere to the most simple safety regulations. Accident
prevention information will only be effective if the operator collaborates actively and carefully. In particular, take
account of the following rules:
1. Read the instructions in this manual carefully before using the machine.
2. Forbid the use of the machine by people who are not authorized and instructed by qualified personnel.
3. Pay attention to other people, especially children, who are present while the machine is in use.
4. Check that the power supply sockets are properly grounded and protected by thermal magnetic and
differential switches.
5. Make sure that the electrical features of the mains fulfill the power supply requirements of the machine
(voltage, frequency, power draw), given on the machine name plate.
6. Avoid exposing the machine to inflammable materials or fumes (fuels, solvents, etc.) which could cause
explosions.
7. Repairs must be performed only by our qualified personnel.
8. Pull the plug of the power supply cord out of the socket during maintenance operations.
9. Take care that the power supply cord for connection to the mains is not crushed or torn during use.
10. Do not use the machine when its power supply cord is crushed or torn.
!
NOTE

11. After you have replaced a component, make sure all electrical connections are fixed in order to ensure
sufficient resistance to cable pulling.
12. Do not leave the machine unattended when it is plugged in.
13. DO NOT ALLOW THE SOLUTION PUMP TO RUN DRY for more than 5 minutes.
5.0 MACHINE IDENTIFICATION DATA
6.0 SERIAL NUMBER AND EC MARK
Make sure the machine is fitted with its serial number and CE
mark plate, located as illustrated in figure 1. If not, contact your
dealer.
2
Fig. 1

7.0 TECHNICAL SPECIFICATIONS
Cleaning width . . . . . . . . . . . . . . . . . . .14.8 in.
Floor wiper length . . . . . . . . . . . . . . . . .16.9 in.
Brush diameter . . . . . . . . . . . . . . . . . . .4 in.
Brush rotation . . . . . . . . . . . . . . . . . . . .800 rpm
Brush pressure . . . . . . . . . . . . . . . . . . .17.5-35 lbs.
Brush motor power . . . . . . . . . . . . . . . .370 watts
Suction motor power . . . . . . . . . . . . . . .100 watts
Suction vacuum . . . . . . . . . . . . . . . . . .90.5 in. H2O
Solution tank capacity . . . . . . . . . . . . . .3.7 gal.
Waste water tank capacity . . . . . . . . . .3.9 gal.
Accessory tank capacity . . . . . . . . . . . .1.8 gal.
Wheels (diameter) . . . . . . . . . . . . . . . .5.9 in.
Weight (with empty tanks) . . . . . . . . . . .79.4 lbs.
Overall dimensions w/o handlebar . . . .30.5 x 17.5 x 14.6 in.
Equivalent level . . . . . . . . . . . . . . . . . .78.5 dbA
Maximum level . . . . . . . . . . . . . . . . . . .80.7 dbA
Minimum level . . . . . . . . . . . . . . . . . . .76.5 dbA
The equivalent noise measurements refer to a machine operating in standard conditions of use. No operating
method or time of use calls for the operator of the machine to take particular measures.
3
Fig. 2 Fig. 3
1. Control panel
2. Hand grip
3. Handle release
4. Water tank
5. Waste water tank
6. Chassis
7. Rear squeegee
8. Front squeegee
9. Front bonnet
11. Snap coupling *
12. Bonnet
13. Tanks cover
14. Power supply cord
15. Cord hook
16. Pressure adj. device
17. Brush
18. Lifting device
19. Serial number label
20. Filter
21. Suction inlet *
22. Float
24. Accessory tank
* Optional

8.0 TRANSPORT
8.1 UNPACKING
Unpack the machine taking care to avoid any movements which could damage it. Check that all parts are integral.
If this is not the case, DO NOT use the machine and consult your dealer.
8.2 CONTENTS OF THE PACKAGE
• 1 Machine
• 1 Use and maintenance booklet and Declaration of Conformity
• 1 Spare parts booklet
• 1 Guarantee coupon
If you notice any parts are missing, contact your dealer immediately.
Do not forget to place packing materials (bags, cardboard, pallet, ganci, and so on) out of the reach of
children.
9.0 RANGE OF USES
MACHINE USE
Your machine is suitable for washing and drying floors and surfaces in general by exerting a vigorous brushing
action and sucking up the washing water.
Any other use is prohibited as it may cause damage to things or persons.
The manufacturer cannot be held responsible for damage caused by the machine when used inappropriately.
The machine must not be tampered with: in such cases the manufacturer cannot be
responsible for any damage caused by use of the machine.
REMEMBER TO KEEP THE MACHINE OUT OF THE REACH OF CHILDREN
4
!
!
!
NOTE

10.0 PREPARATION OF THE MACHINE
10.1 LIFTING
a. Your machine should have the handle in T position (see FIG. 4).
b. Grip both arms of the handle at the middle (A) (see FIG. 4).
c. Lift the machine after checking that the articulation coupler is firmly fastened (try lifting the machine a few
times).
d. Push the handle to position R (FIG. 4).
10.2 TRANSFER
a. The machine should have the handle in R position (see FIG.4)
b. The power supply cord (14 FIG. 3) should be disconnected from the mains and wound onto the
corresponding support (15 FIG. 3) of the handle.
c. Lift the front part of the machine a little, using the handgrip of the handle, to push the machine forward.
5
Fig. 4

11.0 CONTROLS AND FUNCTIONAL PARTS
11.1 CONTROLS (FIG. 5)
1. Main switch
Start/Stop switch for the current input.
2. Mains light
Light that comes on when the plug is connected to the socket.
3. Handle release
Operates the releasing of the handle articulation
(give half a turn counter-clockwise).
4. Fuse
Protects the electrical equipment.
5. Brush switch
On/Off switch for operating the motor of the brush.
6. Suction switch
On/Off switch for the suction motor.
7. Water pump switch
On/Off switch for the pump.
8. Water pump button
Button: as above (to operate the pump non-stop).
11.2 HANDLE
The handle (2 FIG. 3) of your machine can assume four different positions.
To release, turn the lever (3 FIG. 3) counter-clockwise as far as it will go; this operation releases the two articulated
joints simultaneously. The handle can adopt the following positions (FIG.4):
T=Transport In this position the machine is less bulky and can be lifted by gripping the handle in the
midline (A).
R=Rest A special spring lifting device (18 FIG. 2) lifts the brush from the floor and therefore reduces
the pressure exerted on the rubber .pads of the squeegee, in order to avoid damage. In this
position, the machine can be moved from room to room and stored.
L=Work In this position the lifting device is disconnected and the machine is ready for use.
LB=Low work To facilitate cleaning under tables, benches, furniture, etc., the handle can be released from
its Work position and bent as far as desired.
The machine must be put away with the handle in T or R position after use.
11.3 FLOOR WIPER (SQUEEGEE)
Squeegees are devices that enable drying of the damp floor. If the machine is not drying effectively, check for any
dirt or foreign matters on the squeegee. In this case, you will have to remove the squeegee to clean it.
11.3.1 DISASSEMBLY
1) Set the handle in R position (FIG. 4).
2) Remove the side lock of the squeegee support by pulling it upwards.
3) Remove the floor wiper by pulling it out as if it were a drawer from the opposite side of the locking.
ATTENTION: The lock on the rear squeegee is on the right of the machine, while that of the front squeegee is on
the left.
6
Fig. 5
NOTE

11.3.2 ASSEMBLY
1) Put the floor wiper back by pushing it into its guides.
2) Insert the lateral lock in the special swallow tailed slide of the squeegee support and press it down.
N.B. refit the squeegees back in the same position.
11.4 BRUSH
The brush ensures removal of dirt thanks to its mechanical action on the floor.
If you are using the machine in particularly dirty environments, the self-cleaning system of the brushes may not be
sufficient. In this event, we recommend you to remove the brush and wash it by hand.
11.4.1 DISASSEMBLY
1) Remove the front bonnet ( 1 FIG. 6) by grasping its side and pulling outward.
2) Turn the brush (3 FIG. 6) so that its coupling lever (2 FIG. 6), located on its right hand side, is facing
upwards.
3) Push the roll coupling lever axially (2 FIG. 6) in such a way as to release it and, at the same time, press
the roll down and pull it out crosswise.
11.4.2 ASSEMBLY (FIG. 7)
To refit the brush, carry out the above operations in reverse order.
7
Fig. 6 Fig. 7

11.5 SQUEEGEE ADJUSTMENT
The floor wipers are fitted with pressure adjustment
devices so as to suit different types of surface.
To regulate the pressure of the rubber lips turn
the adjustment device (1 FIG. 8) clockwise to
increase pressure or counter-clockwise to
reduce it.
11.6 FRESH WATER TANK (SOLUTION)
This contains the detergent solution (3.7 gal.) and is filled in the following way:
1. Lift the cover (13 FlG. 3) and tip it onto the front part of the machine.
2. Fill the fresh water tank (4 FIG. 3).
The maximum water level is 1.5 in. from the top of the tank.
3. Add detergent according to the instructions given by the detergent manufacturer.
4. Lower the cover.
11.7 WASTE WATER TANK
1. Lift the cover and tip it onto the front part of the machine.
2. Pull out the waste water tank by gripping it by the handles positioned at the sides of the opening and pulling
it upwards.
3. Pour the waste water into a wash basin or drain and rinse it with fresh water.
4. Put the tank back on the machine and lower the cover. Make sure it is firmly shut before starting your work.
Staff up the suction system and try lifting the cover: difficulty lifting the cover means that it is firmly shut.
11.8 ACCESSORY TANK
This contains the detergent solution (1.8 gal.) and is filled in the following way:
1. Lift the cover (13 FIG. 3) and tip it onto the front part of the machine.
2. Fill the fresh water tank (24 FIG. 3).
11.9 SUCTION SYSTEM FLOAT
When the level of dirty water in the tank has reached its maximum level, a safety system (float) stops
the machine’s suction system.
When the float is activated, you will notice that the noise of the suction motor changes immediately. This
means you must take the necessary corrective measures.
Stop the machine immediately and empty the tank as described in the previous paragraph.
8
NOTE
Fig. 8
NOTE

12.0 ACCESSORIES
THIS OPERATION MUST BE CARRIED OUT WITH THE MACHINE OFF.
1. Connect the accessory pipe (1) to the relevant fitting (2).
2. Turn the suction inlet (2) counter-clockwise to activate suction.
3. Fit the water pipe (3) with the snap coupling (4).
4. Shut off the valve (5).
5. Turn on the machine using controls 1-6-7 (see FIG. 5). The
accessory will wash and dry. At the end of your work, turn off
the machine. To disconnect the accessory, open up the valve
(5), release any residual pressure and disconnect the pipe.
Shut off the suction inlet before turning on the machine.
IT IS STRICTLY PROHIBITED to touch moving parts of the
machine and to remove the front bonnet while the machine is
operating.
13.0 ELECTRICAL CONNECTIONS
The electrical features of the machine are printed on the serial number label (1 FIG. 1): check that the frequency
and voltage correspond exactly to those of the electric system of the room where you are working.
Make sure the mains is effectively grounded and that the sockets and adapters used guarantee the
continuity of the grounding wires.
Failure to observe these instructions may cause severe damage or injuries, apart from forfeiting the
guarantee.
14.0 PREPARING THE MACHINE FOR WORK
1. Empty out the waste water tank.
2. If necessary, wipe the filter (20 FIG. 2), which is located inside the solution tank (4 FIG. 3), clean.
3. Fill the solution tank with a suitable mixture of water and detergent.
This operation must be carried out after checking that the waste water tank has been completely emptied
to avoid damage to the suction motor.
9
Fig. 9
!
!
!
!
NOTE
NOTE
