ADIATEK ruby Series User guide

ruby
06 2018
Use and maintenance
Warning! Please read the instructions before use.

3
INTRODUCTORY COMMENT
Thank you for having chosen our machine. This floor cleaning machine is used for the industrial and civil cleaning and is able to clean any type of
floor. During its advance movement, the combined action of the brush and the detergent solution removes the dirt which is aspirated through the
rear suction assembly, giving a perfectly dry surface.
The machine must be used only for such purpose. It gives the best performance if it is used correctly and maintained in perfect efficiency. We
therefore ask you to read this instruction booklet carefully whenever difficulties arise in the course of the machine’s use. In case of need, we ask you
to contact our service department for all advice and servicing as may prove necessary.
SUMMARY
INTRODUCTORY COMMENT 3
TECHNICAL DESCRIPTION 4
GENERAL RULES OF SAFETY 6
Transfer 6
Storage and disposal 6
Correct use 6
Maintenance 6
GENERAL RULES OF THE BATTERIES 6
SYMBOLOGY ON THE MACHINE 7
SYMBOLOGY ON THE MANUAL 7
INSTRUMENT BOARD AND CONTROLS LEGEND 8
LEGEND MACHINE 8
OPTIONAL ACCESSORIES 9
BEFORE USE 10
Handling of the packed machine 10
Unpacking of the machine 10
Battery installation and setting of the battery type 10
Battery charger 10
Batteries charging 11
On-board battery recharger (optional) 11
Batteries charging with on-board battery charger (optional) 11
Batteries charge level indicator 11
Hour meter (if equipped with a display) 11
Squeegee assembling 11
Adjusting the squeegee height 12
Adjusting the squeegee inclination 12
Splash guard assembling 12
Brush/es assembly and disassembly 12
Automatic brush release 13
Recovery tank 13
Detergent solution tank 13
FLOOR CLEANING 14
Starting of the machine 14
3S System “Solution Saving System” (optional) 14
Overflow device 14
Emptying detergent solution 14
Forward movement (if equipped with traction) 14
Stop (if equipped with traction) 15
Adjustment of the brush/es pressure present on some models 15
Brush/es motor overload protection device (optional) 15
Signal detergent solution reserve (H2O on the display) 15
STOP OF THE MACHINE AFTER CLEANING OPERATION 15
Emptying device detergent solution (optional) 15
DAILY MAINTENANCE 17
Recovery tank cleaning 17
Suction filter cleaning 17
Brush/es cleaning 17
Squeegee cleaning 17
WEEKLY MAINTENANCE 17
Rear squeegee rubber replacement 17
Squeegee hose cleaning 17
Cleaning of solution tank and filter 18
TWO-MONTHLY MAINTENANCE 18
Front squeegee rubber replacement 18
SIX-MONTHLY MAINTENANCE 18
Splash guard replacement 18
TROUBLESHOOTING GUIDE 19
Signals on the display (if present) 19
The suction motor does not work 19
The brush motor does not work 19
Insufficient water on the brush 20
The machine does not clean properly 20
The squeegee does not dry perfectly 20
Excessive foam production 20
PROGRAMMED MAINTENANCE 21
Periodic ordinary maintenance chart 21

TECHNICAL DESCRIPTION ruby 45 light ruby 55 light ruby 48bl ruby 48blt
Cleaning width
mm
450
550
485
508
in
18
19
20
Squeegee width
mm
770
770
770
770
in
30
30
30
30
Working capacity, up to
m2/h
1575
1925
1700
1700
sqft/h
16.954
20.722
18.300
18.300
Brushes diameter
mm
2x235
2x285
1 x 485
1 x 508
in
2x9
2x11
1 x 19
1 x 20
Brushes rpm rpm 325 260 155 155
Pressure on the brushes
kg
22,5
24.5
20
30
lbs.
50
54
44
66
Brushes motor
W
420
420
350
450
A
17.5
17.5
14.6
18.5
Suction motor
W
450
450
450
450
A
18.8
18.8
18.8
18.8
Suction vacuum
mbar
120
120
120
120
water lift
48
48
48
48
Traction motor
W
/ / /
120
A
48
Type of drive semi-automatic semi-automatic semi-automatic automatic
Movement speed
km/h
/ / /
4
mph
2.5
Maximum gradient % 2 2 2 2
Solution tank
l
33
33
40
40
gal
8.8
8.8
10.6
10.6
Recovery tank
l
45
45
45
45
gal
12
12
12
12
Machine length
mm
1102
1140
1195
1195
in
43
45
47
47
Machine height
mm
1053
1053
1053
1053
in
41.5
41.5
41.5
41.5
Machine width (without squeegee)
mm
527
586
530
530
in
21
23
21
21
Weight of the machine (empty and without
batteries )
kg
67
71
66
76
lbs.
147.7
156.5
145.5
167.6
Gross weight of the machine
(in conformity with EN 60335-2-72 art. 5.z102)
kg
180
188
185
190
lbs.
397
414
408
419
Tension of the batteries V 24 24 24 24
Capacity of the batteries Ah5110 110 110 110
Weight of the batteries
kg
74
74
74
74
lbs.
163
163
163
163
Compartment of the batteries
mm
342x340x295
342x340x295
342x340x295
342x340x295
in
13.5x13.4x11.6
13.5x13.4x11.6
13.5x13.4x11.6
13.5x13.4x11.6
Acoustic pressure level (in conformity with
EN 60704-1) Lpa dB (A) <70 <70 <70 <70
Level of vibration left m/s20.72 0.72 1.15 0.75
Uncertainty k m/s2/ / 0.43 0.27
Max. level of the electromagnetic field (recharger) µT/ / / /
Max. level of the electromagnetic field (machine) µT/ / / /
Class
Protection level IP 23 23 23 23
Weight packed machine
kg
95
95
95
105
lbs.
209,5
209,5
209,5
231,5
Packing dimensions (LxDxH)
cm
118x67x119
118x67x119
118x67x119
118x67x119
in
46.5x26.4x47
46.5x26.4x47
46.5x26.4x47
46.5x26.4x47
III III III III

ruby 48 bh ruby 45 ruby 50 ruby 55 ruby 45t ruby 50t ruby 55t
485
450
500
550
450
500
550
19
18
20
22
18
20
22
770
770
770
770
790
790
790
30
30
30
30
31
31
31
1700
1575
1750
1925
1800
2000
2200
18.300
16.964
18.837
20.722
19.375
21.528
23.681
1 x 508
2x235
1x508
2x285
2x235
1x508
2x285
1 x 20
2x9
1x20
2x11
2x9
1x20
2x11
155 350 182 280 350 182 280
30
22,5
30
24,5
22,5
30
24,5
66
50
66
54
50
66
54
450
420
600
420
420
600
420
18.5
17.5
25
17.5
17.5
25
17.5
450
570
570
570
570
570
570
18.8
237.5
237.5
237.5
237.5
237.5
237.5
120
120
120
120
120
120
120
5
48
48
48
48
48
48
120
/ / /
120
120
120
48
5
5
5
automatic semi-automatic semi-automatic semi-automatic automatic automatic automatic
4
/ / /
4
4
4
2.5
2.5
2.5
2.5
2 2 2 2 2 2 2
40
40
40
40
40
40
40
10.6
11
11
11
11
11
11
45
45
45
45
45
45
45
12
12
12
12
12
12
12
1195
1102
1205
1140
1102
1205
1140
47
43
47
45
43
47
45
1053
1053
1053
1053
1053
1053
1053
41.5
42
42
42
42
42
42
530
527
535
586
527
535
586
21
21
22
23
21
22
23
76
71
75
74
81
85
84
167.6
156.5
165.4
163.1
179
187
185
190
180
185
188
187
195
190
419
397
408
414
412
430
419
24 24 24 24 24 24 24
110 110 110 110 110 110 110
74
74
74
74
74
74
74
163
163
163
163
163
163
163
342x340x295
342x350x300
342x350x300
342x350x300
342x350x300
342x350x300
342x350x300
13.5x13.4x11.6
13.5x13.5x12
13.5x13.5x12
13.5x13.5x12
13.5x13.5x12
13.5x13.5x12
13.5x13.5x12
<70 67,3 67,3 66,2 67,6 / 67,6
0.75 0.72 / 0,75 0,37 0.62 0,37
0.27 / / / / 0.23 /
/ 1,1031 / 1,1031 0,8685 / 0,8685
/ 6,3157 / 6,3157 0,5102 / 0,5102
23 X3 X3 X3 X3 X3 X3
105
95
95
95
105
105
105
231,5
209,5
209,5
209,5
231,5
231,5
231,5
118x67x119
118x67x119
118x67x119
118x67x119
118x67x119
118x67x119
118x67x119
46.5x26.4x47
46.5x26.4x47
46.5x26.4x47
46.5x26.4x47
46.5x26.4x47
46.5x26.4x47
46.5x26.4x47
III III III III III III III

6
GENERAL RULES OF SAFETY
The rules below have to be followed carefully in order to avoid injury
to the operator and damage to the machine.
−Read the labels carefully on the machine. Do not cover them for
any reason and replace them immediately if damaged.
−ATTENTION: The machine must be used exclusively by authorized
staff that have been instructed on its correct and proper use.
−ATTENTION: Do not use the machine on areas having a higher
gradient than the one stated on the number plate.
−ATTENTION: The machine is not to be used by persons, children
included, with reduced physical, sensorial or mental capabilities, or
with lack of experience or knowledge, unless they could benefit,
through the intermediation of a responsible person for their safety,
by a supervision or instructions concerning to its use.
−During the operation of the machine, pay attention to other people
and especially to the children.
−Children shall not play with the machine.
−Children cannot carry out cleaning and maintenance of the
machine.
TRANSFER
−Do not strike shelvings or scaffoldings where there is danger of
falling objects.
−Do not use the machine as a means of transport.
−Adapt the working speed to the adhesion conditions: particularly,
slow down before narrow curves have to be faced.
STORAGE AND DISPOSAL
−Storage temperature: between 0°C and +55°C (32°F and 131°F).
−Perfect operating temperature: between 0°C and +40°C (32°F and
104°F).
−The humidity should not exceed 95%.
−Provide for the scrapping of the material of normal wear following
strictly the respective rules.
When your machine has to stop activity, provide for the appropriate
waste disposal of its materials, especially oils, batteries and electronic
components, and considering that the machine itself has been, where
possible, constructed using recyclable materials.
CORRECT USE
−Do not use the machine on surfaces covered with inflammable
liquids or dusts (for example hydrocarbons, ashes or soot).
−In case of fire, use a powder-based fire-extinguisher. Do not use
water.
−Do not use the machine in explosive atmosphere.
−The machine has to carry out simultaneously the operations of
washing and drying. Different operations must be carried out in
restricted areas prohibited to non-authorized personnel and the
operator has to wear suitable shoes.
−Signal the areas of moist floors with suitable signs.
−Do not mix different detergents, avoiding harmful odours.
−Avoid brush operation when the machine is standing still in order
to prevent floor damages.
−Before lifting the recovery tank, make sure that it is empty.
MAINTENANCE
−If the machine does not work properly, check by conducting simple
maintenance procedures. Otherwise, as for technical advice from
an authorized assistance centre.
−For any cleaning and/or maintenance operation take off the power
supply from the machine.
−Where parts are required, ask for ORIGINAL spare parts from the
distributor and/or from an authorized dealer.
−Use only ORIGINAL brushes.
−Do not take off the protections which require the use of tools for
their removal.
−Do not wash the machine with direct water, jets or with high water
pressure nor with corrosive material.
−Every 200 working hours have a machine check by an authorized
service department.
−Before using the machine, check that all panels and coverings are
in their position as indicated in this use and maintenance
catalogue.
−Restore all electrical connections after any maintenance operation.
GENERAL RULES OF THE BATTERIES
−At any intervention on the batteries, use suitable acid-proof gloves
and glasses.
−Do not smoke near the batteries and do not approach them with
free flames.
−Check that a fire-extinguisher is available on site.
−Be very careful in case of leakages or liquid outlets because
corrosive.
−Do not place any metallic tools onto the batteries. Risk of short
circuit!
−It is compulsory to hand over exhaust batteries, classified as
dangerous waste, to an authorized institution according to the
current laws.

7
SYMBOLOGY ON THE MACHINE
Symbol denoting the solution valve.
Indicates the switch or signal lamp solenoid
valve on the instrument board.
Indicates the solution valve lever.
Indication of the maximum temperature of the
solution detergent.
It is placed near the charging hole of the
solution tank.
Symbol denoting the lifting of the squeegee.
Symbol denoting the charge level of the
batteries (if the display is not present).
Symbol denoting the lowering of the squeegee.
Symbol denoting the brush.
Indicates the switch of the brush motor.
Symbol denoting the suction motor.
Indicates the switch of the suction motor.
Symbol denoting the crossed bin.
Indicates that at the end of its activity, the
machine has to be disposed conforming to the
laws in force.
Symbol denoting switching on.
Indicates the general switch of the machine.
SYMBOLOGY ON THE MANUAL
Symbol denoting the open book.
Indicates that the operator has to read the
manual before the use of the machine.
Symbol that indicates the obligation of wearing
safety glasses.
Symbol denoting the open book.
For the good functioning of the battery
charger, read the manual of the constructor.
Symbol that indicates the obligation of wearing
safety gloves.
Warning symbol.
Read carefully the sections marked with this
symbol, for the security of both the operator
and the machine.
Symbol that precedes an important information
about the proper use of the machine.
Symbol that indicates the obligations of
disconnecting the system from the batteries by
disconnecting the connector before operating
on the machine.
Symbol that indicates operations that have to
be carried out only by qualified personnel.
Icon indicating the part of the manual related
to the unboxing, preparation and start of the
machine.
Icon indicating the part of the manual related
to the machine use.
Icon indicating the part of the manual related
to the maintenance of the machine.

8
INSTRUMENT BOARD AND CONTROLS LEGEND
1. IGNITION SWITCH
2. BATTERIES CHARGE LEVEL SIGNAL
3. BRUSH MOTOR SWITCH
4. SUCTION MOTOR SWITCH
5. SOLENOID VALVE SWITCH
6. LEVERS DRIVE CONTROL
7. LEVER SOLUTION VALVE
8. LEVER SQUEEGEE LIFTING
9. PEDAL BRUSH BASE GROUP LIFTING
1. DISPLAY
2. BRUSH RELEASE (ONLY ON BRUSH BASE 50)
LEGEND MACHINE
1. BRUSH BASE GROUP
2. PLUG EXHAUST HOSE RECOVERY TANK
3. RECOVERY TANK
4. INSTRUMENT BOARD
5. LEVERS DRIVE CONTROL
6. SCREW CAP FOR INLET DETERGENT SOLUTION
7. GUIDE SPRING SQUEEGEE HOSE SQUEEGEE HOSE
8. SQUEEGEE HOSE
9. BATTERIES
10. INLET OPENING SQUEEGEE HOSE
11. SUCTION COVER
12. SOLUTION TANK
13. WHEELS
14. SQUEEGEE ASSEMBLY
15. CASTOR WHEELS

9
OPTIONAL ACCESSORIES
The optional accessories are:
Switch with key (1);
Brush/es motor overload protection device (2);
3S – Solution Saving System assembly (3);
Emptying device of the solution tank (4):
On-board battery charger (5).

10
BEFORE USE
HANDLING OF THE PACKED MACHINE
The machine is supplied with suitable packing foreseen for fork lift
truck handling.
For the package dimensions please look at the “TECHNICAL
DESCRIPTION” table.
Do not place more than 2 packings on top of each other.
UNPACKING OF THE MACHINE
1. Remove the external packing.
2. Unscrew the brackets that secure the machine to the pallet.
3. Move the machine backwards, as indicated in figure, avoiding
heavy contacts to mechanical parts.
4. Keep the pallet for eventual transport.
The portable slope is not included in the packaging.
BATTERY INSTALLATION AND SETTING OF THE BATTERY TYPE
This machine is equipped with two batteries at 12V in serial
connection, placed in its appropriate compartment under the
recovery tank and must be handled using suitable lifting equipment
(due to weight and coupling system).
The batteries must be in accordance with CEI 21-5 Norms.
The connection of the batteries' cables has to be carried out by
specialized staff, because the inversion of polarity causes the damage
of the electrical components.
Before the machine is supplied with power, check that the red cable
is connected to the + pole of the battery.
For batteries installation proceed as follows:
1. Take off the squeegee hose (1).
2. Take off the suction cover (2) after turning the blocking levers
(3).
3. Take off the recovery tank (4).
4. Place the batteries in its compartment.
5. Connect the terminals, respecting the polarities, avoiding
contact with tools that could create short circuit.
6. Reassemble all parts.
The machine and the signal lamp of the battery charge level foresee
the use of traditional lead batteries.
If the machine is equipped with the display, check the battery
setting on it (1).
In case of GEL batteries installation, it is necessary to carry out a
specific adjustment. Please contact the authorized technical
assistance.
BATTERY CHARGER
Be sure that the battery recharger is suitable for the installed
batteries both for their capacities and type (lead/acid or GEL and
equivalent).
In the plastic bag containing the use and maintenance you will find
the coupling connector for the recharger. It must be assembled onto
the cables of your recharger, following the instructions given by the
manufacturer.

11
BATTERIES CHARGING
Take the machine to a levelled surface.
Plug in batteries connector (1) placed in the rear part of the machine,
to connector (2) of the battery recharger.
ON-BOARD BATTERY RECHARGER (OPTIONAL)
If the machine is equipped with the on-board battery recharger (see
under "OPTIONAL ACCESSORIES”) please refer to the instructions of
the constructor of this accessory what the recharging operations
concern.
The battery recharger is connected directly to the battery poles.
During the recharging operations a device is activated which does not
permit the machine's functioning.
The main cable of the battery recharger has a maximum length of
two meters (6.5 ft.) and must be connected to a single-phase socket
type CEE 7/7.
BATTERIES CHARGING WITH ON-BOARD BATTERY CHARGER
(OPTIONAL)
Bring the machine on a leveled surface near to a single-phase socket
(within 2m, 6.5 ft.) with tension 230V, frequency 50Hz (for USA 120V,
60Hz), nominal current 10A.
Switch off the switches of the brushes motor, suction motor and of
the solenoid valve.
Insert the plug into the mains socket.
At the end of the recharging, take off the plug from the mains
socket.
BATTERIES CHARGE LEVEL INDICATOR
If the machine is not provided with a display, when switching on
the signal lamp of the battery charge level (2) will come on.
When the signal lamp is in green colour it means that the battery
charge level is sufficient for the functioning of the machine.
If the signal lamp is in red colour it means that the battery charge
level is insufficient for the functioning of the machine and it is
necessary to recharge immediately the batteries (see under
"BATTERIES CHARGING”).
If the machine is equipped with a display, on the display (1) the
following indication of the battery charge level is digital and
indicates the percentage of the battery charge. 100 is the maximum
charge, down to a minimum of 10, indicating every 10% decrease.
When the charge level reaches 20%, the display starts blinking
indicating the end of the battery charge.
After a few seconds from the four blinking ‘’----’’ dashes, the brushes
motor stops automatically. With the remaining charge it is anyhow
possible to finish the drying operation before proceeding to the
recharge.
HOUR METER (IF EQUIPPED WITH A DISPLAY)
The machine is equipped with an hour meter located on the same
display of the battery charge level indicator (1). Keeping the button
(2) pressed for more than 3 seconds, the first data indicates the
working hours and after a few seconds the working minutes are
shown.
SQUEEGEE ASSEMBLING
With the squeegee support lowered, slide the two stud bolts (1)
placed on the upper part of the squeegee inside the slots on the
support. Block the squeegee by rotating the lever (2) clockwise.
Insert the squeegee hose (3) into its coupling, respecting its position
as indicated in the figure.

12
ADJUSTING THE SQUEEGEE HEIGHT
The squeegee must be adjusted in height depending on the rubber
wear. In order to guarantee a perfect drying during the operation, the
lower blade of the rear squeegee rubber (4) must work slightly bent
backwards (operator side) in uniformed way in all its length.
Acting clockwise upon the two registers (5) it is possible to increase
the bending of the rubber. Acting counterclockwise it is possible to
decrease the rubber bending.
A label placed near the two registers (5) indicates rotation sense to
increase or reduce the height.
Note: The wheels of the squeegee support must be adjusted through
the registers (5) at the same height so that the squeegee works
parallel to the floor.
ADJUSTING THE SQUEEGEE INCLINATION
In case of need, to increase the rubber bending in the central part, it
is necessary to tilt the squeegee rotating counterclockwise the
register (6). To increase the rubber bending on the squeegee
extremities, rotate the register clockwise.
SPLASH GUARD ASSEMBLING
SPRING-LOCKING TYPE
The two splash guards have to be assembled onto the brushes base
group. Insert the metal strips inside the suitable slots present on the
rubber. Place the round hole at the flat extremity of the strip onto
the screw placed in the front part of the brushes base group. Secure
the strips through the nut blocking it.
Hook the coupling in the rear part of the brushes base group to the
slot placed at the extremity of the metal strip still free. Please act as
above for both the splash guard rubbers, paying attention to reduce
to the minimum the gap between the two rubbers in the front part of
the brushes base group.
With brushes assembled, the splash guard must slightly touch the
floor.
KNOB-LOCKING TYPE
The two splash guards have to be assembled onto the brush base
group. Insert the metal strips inside the suitable slots present on the
rubber. Place the round hole at the flat extremity of the strip onto
the screw placed in the front part of the brush base group. Secure the
strips through the nut blocking it.
Screw down the knobs in the rear part of the cover in the free
extremity of the metal strips. The operation has to be carried out for
both splash guards.
With the brush assembled, the splash guard must slightly touch the
floor.
BRUSH/ES ASSEMBLY AND DISASSEMBLY
1. Take off the electric supply to the brush motor unplugging the
batteries connector.
2. Acting upon the pedal lift the brush base group.
3. With the brush base group in lifted position, insert the brush
into its plate seat underneath the brush base turning it until the
three metal buttons are properly seated in their slots; rotate
energically the brush to push the button towards the coupling
spring until it gets blocked.
The figure shows the rotating sense for the brush coupling.
SINGLE BRUSH VERSION

13
TWO-BRUSHES VERSION
To unlock the brush, perform the same operations and rotate the
brush the opposite way as for the locking.
For a longer life of the brushes we suggest to invert daily their
position. Whenever brushes were deformed we suggest to reassemble
them in the same position, avoiding that the different inclination of
the bristles causes excessive motor overload or troublesome
vibrations.
AUTOMATIC BRUSH RELEASE
Only for the models with the 50 brush base it is possible to release
the brush as follows:
1. Lift the brush base by pressing the pedal (10).
2. Turn on the brush switch (3).
3. Press the drive control levers (7).
4. Press the release button (11).
5. Release the drive control levers (7).
In this way the brush automatically releases itself from the brush
base.
RECOVERY TANK
Check that the cover of the suction filter (1) is correctly secured, after
rotating the levers and that the suction motor hose (2) is correctly
connected.
Verify also that the squeegee hose is correctly inserted into the seats
(3 and 4) and that the exhaust hose plug (5) placed in the front part
of the machine, is closed.
DETERGENT SOLUTION TANK
The solution tank is provided with an inspection opening. This permits
to clean the exit point of the detergent solution.
Be sure that the cap is well tightened after the cleaning.
The capacity of the detergent solution tank is indicated in the
technical data.
Open the screw plug (1) placed in the rear left part of the machine
and fill the detergent solution tank with clean water at a maximum
temperature of 50°C. Add the liquid detergent in the percentage and
conditions foreseen by the manufacturer. To avoid excessive foam
presence, which could cause problems to the suction motor, use the
minimum percentage of detergent. Screw down the plug to close the
tank.

14
FLOOR CLEANING
STARTING OF THE MACHINE
1. Press the key switch (OPT).
2. If present, press the switch ignition 1/0 (1).
3. Check the charge level on the display or on the signal lamp
battery charge level.
4. Press the brush motor switch (3).
5. Press the suction motor switch (4).
6. Press the solenoid valve switch (5).
7. Acting upon the brush base lifting pedal (9) lower the brush
base.
8. Acting upon the solution valve lever (7) open and adjust the
solution detergent flow.
The water starts to flow automatically when the brush motor is
activated.
On the instrument board the indicator of the solenoid valve
switch (5) will turn on.
9. Activating the levers drive control (6) the machine will start
moving, the brush starts to rotate, the solenoid valve activates
the water flow and the squeegee will start drying the floor.
10. During the first meters check that the detergent solution flow is
appropriate and that the squeegee adjustment guarantees a
perfect drying action.
3S SYSTEM “SOLUTION SAVING SYSTEM” (OPTIONAL)
The need of an increasing carefulness to the environment, and to the
abuse of polluting elements, such as detergents in the floor cleaning
machines, has brought us to the realization of a device which,
regardless from the capacity to use the machine by the operator,
keeps the minimum flow of the detergent solution constant, having
been properly calibrated by an expert technician. The best detergent
solution amount with this system will be the one which realizes the
minimum flow of detergent solution sufficient to clean correctly the
floor. For this reason the system is called “Solution Saving System”
abbreviated to “3S” system.
The system is composed by a hydraulic circuit parallel to the
traditional one which can be enabled or disabled directly from the
instrument board through a 3-position switch with the following
functions:
(1) = Position solution valve with traditional functioning with
variable water flow that differs by the opening of the solution valve.
(2) = Position STOP with functioning without flow (drying only).
(3) = Position 3S with functioning with optimal fixed flow.
The hydraulic circuit of the 3S system is independent and it is
provided with a proper filter which has to be cleaned regularly.
For the cleaning it is necessary to unscrew the plug as shown in the
figure and clean the inside filter with a water jet.
OVERFLOW DEVICE
In order to avoid serious damages to the suction motor, the machine
is equipped with a float that intervenes when the recovery tank is
full, closing the suction hose and stopping the suction.
When this happens, it is necessary to empty the recovery tank.
1. Hold the exhaust hose placed in the front part of the machine.
2. Take off the exhaust plug acting upon its lever and empty the
recovery tank into appropriate containers, according to the
standard norms for the liquid disposal.
EMPTYING DETERGENT SOLUTION
To empty the detergent solution remained in the solution tank:
1. Bring the machine to an appropriate place for tanks draining.
2. Unscrew the solution tank cap (1).
3. Unscrew the exhaust plug (2).
FORWARD MOVEMENT (IF EQUIPPED WITH TRACTION)
The traction of this machine is given through an electronically
controlled motor.

15
To move the machine, act upon the switch (1), then rotate the levers
drive control placed on the handle bar, in forward you obtain the
forward drive, in reverse the backwards movement is obtained. The
control acts in a progressive way, therefore it is possible to graduate
the speed depending on each requirement rotating the lever
whatever it is necessary. During reverse motion the speed is reduced.
STOP (IF EQUIPPED WITH TRACTION)
Releasing the levers drive control, the machine and the brush will
stop.
Moving the machine backwards, make sure that the squeegee is
lifted.
ADJUSTMENT OF THE BRUSH/ES PRESSURE PRESENT ON SOME
MODELS
Through the register (1) placed on the internal part of the front right
wheel, it is possible to adjust the brush/es pressure on the cleaned
surface.
By turning the wing nut clockwise the pressure increases, rotating the
wing nut counterclockwise, the pressure decreases.
This device allows a more efficient cleaning action also on very
difficult and dirty surfaces.
BRUSH/ES MOTOR OVERLOAD PROTECTION DEVICE (OPTIONAL)
If the machine is equipped with the amperemetric protection device
(see under "OPTIONAL ACCESSORIES"), this, in case of extended
overload of the brush/es motor, intervenes shutting it off.
Furthermore, on the display (1) appears an alarm ”AL01”. In case of
intervention of this device, check the brush/es pressure adjustment in
connection with the type of floor to be cleaned and if necessary,
reduce it.
To reset the brush/es motor, turn off the brush/es motor switch (5)
for a few seconds and turn it on again.
SIGNAL DETERGENT SOLUTION RESERVE (H2O ON THE DISPLAY)
When the indication H2O on the display appears, this means that the
detergent is getting low corresponding to 10% of the maximum
capacity of the solution tank.
STOP OF THE MACHINE AFTER CLEANING OPERATION
Before executing any type of maintenance:
1. Lift the brushes base acting upon the pedal (9).
2. Lift the squeegee acting upon the lever (8).
3. Turn off the brush motor, the suction motor and the solenoid
valve acting upon its switches.
4. Bring the machine to an appropriate place for tanks draining.
The machine is not equipped with a parking brake, therefore do not
leave it on slopes.
EMPTYING DEVICE DETERGENT SOLUTION (OPTIONAL)
To recover the detergent solution, it is necessary to use the emptying
device provided for the purpose and proceed as follows:

16
1. Unhook the hose.
2. Open the solution valve directing the jet into a collecting
container.
3. When the operation has been completed, close the solution valve.
4. Put the hose back into its position, placing it into the spring.

17
DAILY MAINTENANCE
RECOVERY TANK CLEANING
1. Hold the exhaust hose placed in the front part of the machine.
2. Take off the exhaust plug acting upon its lever and empty the
recovery tank into appropriate containers (see under
"OVERFLOW DEVICE").
3. Take off the suction cover (1) after rotating the blocking levers
(2).
4. Take off the filter and filter protection.
5. Rinse the tank with a water jet.
SUCTION FILTER CLEANING
1. Take off suction cover (1) after rotating the blocking levers (2).
2. Take off the filter and filter protection.
3. Clean all parts with a water jet especially inside surfaces and
filter bottom.
4. Carry out carefully the cleaning operations.
5. Reassemble all parts.
BRUSH/ES CLEANING
Disassemble the brush/es and clean it/them with a water jet (for the
brush disassembly see under “BRUSH ASSEMBLY AND DISASSEMBLY”).
SQUEEGEE CLEANING
Keeping the squeegee clean guarantees always the best drying action.
For the cleaning it is necessary to:
1. Take off the squeegee hose (3) from its coupling.
2. Disassemble the squeegee from its support by rotating the lever
(2) counterclockwise and making slide the stud bolts (1) in their
slots up to their release.
3. Clean with care the internal part of the squeegee inlet
eliminating eventual dirt residuals.
4. Clean with care the squeegee rubbers.
5. Reassemble all parts.
WEEKLY MAINTENANCE
REAR SQUEEGEE RUBBER REPLACEMENT
Check the squeegee rubber wear and eventually turn or replace it.
For the replacement it is necessary to:
1. Lift the squeegee acting upon the lever.
2. Uncouple the hook (1) of the rubber holder blade, release the
extremities (2) from the squeegee body and take off the rubber
(4).
3. Turn the rubber (4) to a new side or replace it.
To reassemble the squeegee repeat reverse the operations above-
mentioned, inserting the rubber (4) on the guides (3), couple the
extremities (2) of the rubber holder blade onto the squeegee body
and finally block the hook (1).
SQUEEGEE HOSE CLEANING
Weekly or in case of insufficient suction, it is necessary to check that
the squeegee hose is not obstructed. Eventually, to clean it, proceed
as follows:

18
1. Take off the hose from the squeegee coupling (1) and release the
guide spring of the suction hose (2).
2. Wash the inside of the hose with a water jet, from the squeegee
hose side.
3. To reassemble the hose repeat reverse the operations above-
mentioned.
CLEANING OF SOLUTION TANK AND FILTER
1. Bring the machine to an appropriate place for tanks draining.
2. Unscrew the solution tank cap (1).
3. Unscrew the exhaust plug (2) being careful not to lose or to
damage the gasket.
4. Rinse with a water jet the solution tank.
5. Rinse the solution tank filter placed inside the exhaust plug,
under the machine.
TWO-MONTHLY MAINTENANCE
FRONT SQUEEGEE RUBBER REPLACEMENT
Check the wear of the squeegee rubber and eventually replace it.
For the replacement it is necessary to:
1. Take off the squeegee hose (3) from its coupling.
2. Disassemble the squeegee from the support rotating the lever (2)
counterclockwise and sliding the stud bolts (1) in their slots.
3. Uncouple the hook (1) of the rubber holder blade, release the
extremities (2) from the squeegee body and take off the rubber
(4).
4. Unscrew the wing nuts (5) in the upper part of the squeegee.
5. Slip off the lower part (6) of the squeegee body, so to take off
the front rubber (7).
6. Replace the front rubber.
7. To reassemble the squeegee repeat reverse the operations above-
mentioned.
SIX-MONTHLY MAINTENANCE
SPLASH GUARD REPLACEMENT
SPRING-LOCK SYSTEM
1. Release the coupling in the rear part of the brushes base group
from the slot placed at the extremity of the metal strip.
2. Unscrew the nut on the front part of the brushes base group
and take off the metal strips.

19
3. Replace the splash guard rubbers and follow assembling
instructions at “SPLASH GUARD ASSEMBLY” paragraph.
With brushes assembled, the splash guard must slightly touch the
floor.
KNOBS-LOCK SYSTEM
1. Unscrew the knobs in the rear part of the brush base group from
the extremity of the metal strips. The operation has to be carried
out on both splash guards.
2. Unscrew the nut on the front part of the brush base group and
take off the metal strips.
3. Replace the splash guard rubbers and follow the assembling
instructions at “SPLASH GUARD ASSEMBLY” paragraph.
With the brush assembled, the splash guard must slightly touch the
floor.
TROUBLESHOOTING GUIDE
The checking of all the other foreseen machine operations is left
to the authorized technical assistance.
SIGNALS ON THE DISPLAY (IF PRESENT)
A001: Indication of the version of the electronic check card (the last
number indicates the revision of the check card).
Pb24: Indication battery check card set for lead batteries.
GE24: Indication battery check card set for gel batteries.
AL01: Signal indicating an absorption of excessive current of the
brushes motor, only on machines equipped with the overload
protection device for the brushes pressure adjustment (see under
"OPTIONAL ACCESSORIES”).
---- (blinking): signal indicating the discharged batteries.
THE SUCTION MOTOR DOES NOT WORK
1. Verify that the key switch (see under "OPTIONAL ACCESSORIES”)
is in the correct position (clockwise).
2. Check that the suction motor switch is on.
3. Check the charge level of the batteries (see “BATTERIES
CHARGING”)
4. Check that the battery connector (1) is correctly plugged in.
If the problem persists, please contact the authorized technical
assistance.
THE BRUSH MOTOR DOES NOT WORK
1. Verify that the key switch (see under "OPTIONAL ACCESSORIES”)
is in the correct position (clockwise).
2. Verify that the brush motor switch is on.
3. Activate the levers movement.
4. Check the charge level of the batteries (see “BATTERIES
CHARGING”)
5. Check that the battery connector (1) is correctly plugged in.
6. On machines equipped with brush/es motor overload protection
device (see under "OPTIONAL ACCESSORIES”), check that on the
display (1) does not appear the alarm “AL01” (brush/es motor
overload alarm).
If the problem persists, please contact the authorized technical
assistance.
Never leave the batteries discharged for a long time.

20
INSUFFICIENT WATER ON THE BRUSH
1. Check that the solution valve lever (1) is open.
2. Check the level of the liquid in the solution tank.
3. Check that the solution filter (2) is clean.
If the problem persists, please contact the authorized technical
assistance.
THE MACHINE DOES NOT CLEAN PROPERLY
1. The brush/es do not have the suitable bristle dimension: use only
original brushes. For advice, contact the authorized technical
assistance.
2. The brush/es has/have got worn bristles. Check the brushes wear
condition and eventually replace them (the brush has to be
replaced when the bristles have reached a height of about
15mm).
To replace the brush/es, see instructions at paragraph “BRUSH/ES
DISASSEMBLY” and “BRUSH/ES ASSEMBLY”.
3. The solution detergent is insufficient: open more the solution
valve.
4. Check that the liquid detergent is in the recommended
percentage.
Contact the authorized technical assistance for advice.
THE SQUEEGEE DOES NOT DRY PERFECTLY
1. Check that the squeegee rubbers are clean.
2. Check the height and inclination of the squeegee (see under
“SQUEEGEE” in “BEFORE USE”).
3. Check that the suction hose is correctly inserted in the proper
seat on the recovery tank.
4. Clean the suction filter.
5. Replace the rubbers if worn out.
6. Check that the suction motor switch is on.
7. Check that the recovery tank is empty.
EXCESSIVE FOAM PRODUCTION
Check that low foam detergent has been used. Eventually add small
quantities of anti foam liquid into the recovery tank.
Please be aware that a bigger quantity of foam is produced when the
floor is not very dirty. In this case please dilute detergent solution.
