ADJ D4 BRANCH RM User manual

User Manual
D4 BRANCH RMD4 BRANCH RM

©2021 ADJ Products, LLC all rights reserved. Information, specications, diagrams, images, and
instructions herein are subject to change without notice. ADJ Products, LLC logo and identifying
product names and numbers herein are trademarks of ADJ Products, LLC. Copyright protection
claimed includes all forms and matters of copyrightable materials and information now allowed by
statutory or judicial law or hereinafter granted. Product names used in this document may be trade-
marks or registered trademarks of their respective companies and are hereby acknowledged. All
non-ADJ Products, LLC brands and product names are trademarks or registered trademarks of their
respective companies.
ADJ Products, LLC and all aliated companies hereby disclaim any and all liabilities for property,
equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic
loss associated with the use or reliance of any information contained within this document, and/or as
a result of the improper, unsafe, insucient and negligent assembly, installation, rigging, and opera-
tion of this product.
Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the enviroment. Please turn o all electrical products when
they are not in use. To avoid power consumption in idle mode, disconnect all electrical equipment from power
when not in use. Thank you!
ADJ Products, LLC - www.adj.com - D4 Branch RM User Manual Page 2
DOCUMENT VERSION
Please check www.adj.com for the latest revision/update of this guide.
Date Document
Version
Software
Version >
DMX
Channel
Mode
Notes
03/30/21 1 N/A N/A Initial Release
04/20/21 2 N/A N/A Updated Dimensional Drawings and Technical
Specications

D4 Branch RM Contents
General Information 4
General Instructions | Warranty Registration | Handling Precautions 5
Safety Precautions 6
Overview 7
Installation Guidelines 8
Dimensional Drawings 9
Technical Specications 10
ADJ Products, LLC - www.adj.com - D4 Branch RM User Manual Page 3

D4 Branch RM General Information
ADJ Products, LLC - www.adj.com - D4 Branch RM User Manual Page 4
Unpacking: Every device has been thoroughly tested and has been shipped in perfect operating con-
dition. Carefully check the shipping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your device for damage and be sure all accessories
necessary to operate the device have arrived intact. In the event damage has been found or parts are
missing, please contact our customer support team for further instructions. Please do not return this
device to your dealer without rst contacting customer support at the number listed below. Please do
not discard the shipping carton in the trash. Please recycle whenever possible.
Introduction: This single rack space, 4-way distributor/booster has been designed to perform reliably
for years when the guidelines in this booklet are followed. Please read and understand the instructions
in this manual carefully and thoroughly before attempting to operate this device. These instructions
contain important information regarding safety during use and maintenance.
Box Contents:
• (2) Rack Mount Brackets & (4) Screws
• (4) Rubber Pads
• Manual & Warranty Card
Customer Support: ADJ Products, LLC provides a customer support line, to provide set up help and
to answer any questions that may arise during initial set up or operation. You may also visit us on the
web at www.adj.com for any comments or suggestions. Service Hours are Monday through Friday
8:00 a.m. to 4:30 p.m. Pacic Standard Time.
Voice: [phone]
Fax: [phone]
E-mail: [email protected]
Warning! To prevent or reduce the risk of electrical shock or re, do not expose this unit to rain or
moisture.
Warning! This device can cause severe eye damage. Avoid looking directly into the light source for
any reason!

ADJ Products, LLC - www.adj.com - D4 Branch RM User Manual Page 5
D4 Branch RM Warranty Registration
Please fill out the enclosed warranty card to validate your purchase and warranty. You may also reg-
ister your product at www.adj.com. All returned service items, whether under warranty or not, must
be freight pre-paid and accompanied by a return authorization (R.A.) number. If the unit is under war-
ranty, you must provide a copy of your proof of purchase invoice. Please contact ADJ Products, LLC
customer support for an R.A. number.
D4 Branch RM General Instructions
To optimize the performance of this product, please read these operating instructions carefully to
familiarize yourself with the basic operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please keep this manual with the unit, for
future reference.
D4 Branch RM Handling Precautions
Caution! There are no user serviceable parts inside this unit. Do not attempt any repairs yourself, as
doing so will void your manufacturer’s warranty. In the unlikely event your unit may require service,
please contact ADJ Products, LLC.
ADJ Products, LLC will not accept any liability for any resulting damages caused by the non-obser-
vance of this manual or any unauthorized modifications to this unit.

ADJ Products, LLC - www.adj.com - D4 Branch RM User Manual Page 6
D4 Branch RM Safety Precautions
For Your Own Personal Safety, Please Read and Understand This Manual Completely Before
You Attempt To Install Or Operate This Unit!
• To reduce the risk of electrical shock or re, do not expose this unit to rain or moisture.
• Do not spill water or other liquids into or on to your unit.
• Be sure that the power outlet being used matches the required voltage for your unit.
• Do not attempt to operate this unit if the power cord is frayed or broken.
• Do not attempt to remove or break off the ground prong from the electrical cord. This prong is
used to reduce the risk of electrical shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not plug the device into a dimmer pack.
• Do not remove the cover for any reason. There are no user serviceable parts inside.
• Never operate this unit with the cover removed.
• Always be sure to mount this unit in an area that will allow proper ventilation. Allow about 6”
(15cm) between this device and a wall.
• Do not attempt to operate this unit if it has been damaged in any way.
• This unit is intended for indoor use only. Use of this product outdoors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to be walked on or pinched by
items placed upon or against them, paying particular attention to the point at which they exit from
the unit.
• Heat - The appliance should be situated away from heat sources such as radiators, heat registers,
stoves, or other appliances (including amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen onto, or liquid has been spilled into, the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a marked change in perfor-
mance.

D4 Branch RM Overview
ADJ Products, LLC - www.adj.com - D4 Branch RM User Manual Page 7
1. Power Switch
2. Link Out / Terminate Selector
3. DMX Input
4. DMX Output
5. DMX Output with Driver
6. Fuse
7. Power Input
LINK OUT / TERMINATE SELECTOR: When set to “Terminate”, this selector will disable the DMX
Outputs with Driver (labeled 1-4 on the device). When set to “Link Out”, signal to these outputs is
enabled and additional devices can be linked. This switch is primarily used for troubleshooting.
FUSE: The fuse is rated F0.5A 250V 5x20mm. When replacing the fuse, be sure to use only a fuse
with the same rating.

ADJ Products, LLC - www.adj.com - D4 Branch RM User Manual Page 8
D4 Branch RM Installation Guidelines
FLAMMABLE MATERIAL WARNING - Keep device at least 5.0 feet (1.5 meters) away from any
flammable materials, decorations, pyrotechnics, etc.
ELECTRICAL CONNECTIONS - A qualified electrician should be used for all electrical connec-
tions and/or installations.
The device can be placed on any flat surface when the included four (4) rubber feet are attached to
the bottom of the device.
The device can also be installed in a standard 19-inch 1-U rack space using standard rack screws
(not included).

D4 Branch RM Dimensional Drawings
ADJ Products, LLC - www.adj.com - D4 Branch RM User Manual Page 9

ADJ Products, LLC - www.adj.com - D4 Branch RM User Manual Page 10
FEATURES
• 4-Way DMX Data Splitter / Fully DMX 512 (1990) Compliant Link / Terminate Button for Easy
Troubleshooting
• DMX Status LED Indicator
• (1) 3pin + (1) 5pin XLR Isolated Input
• (1) 3pin + (1) 5pin XLR Passive Loop Output
• (4) 3pin + (4) 5pin XLR Isolated Outputs
SIZE / WEIGHT
• Length: 19.0” (482mm)
• Width: 5.5” (139.8mm)
• Vertical Height: 1.7” (44mm)
• Weight: 5.3 lbs. (2.4 kg)
ELECTRICAL
• AC 120V - 60Hz 0.5A
APPROVALS
• CE
• ETL Pending
• UKCA Pending
Please note: Specifications and improvements in the design of this unit and this manual are subject
to change without any prior written notice.
D4 Branch RM Technical Specifications
