MVP-5100/6100
SERVICE MANUAL ABOUT
GETTING STARTED
Rev.: 1.1

Leading EDGE COMPUTING adlinktech.com
Table of Contents
Getting Started
MVP-5100
Install HDD/SSD
Install CFast Card
Install M.2 module
Install Mini PCIe module
Wall mount
MVP-6120/6140
Install HDD/SSD
Install HDD/SSD (Option)
Install CFast Card
Install M.2 module
Install Mini PCIe module
Wall mount
Install Fan Kit (Option)
PCIe/PCI card’s max. dimension
MVP-5100-MXM
Install HDD/SSD
Install M.2 module
Install Mini PCIe module
Wall mount

Leading EDGE COMPUTING adlinktech.com
MVP-5100

Leading EDGE COMPUTING adlinktech.com
Install HDD/SSD
1. Remove the 6 bottom cover screws by screwdriver 2. Remove the bottom cover by lifting

Leading EDGE COMPUTING adlinktech.com
Install HDD/SSD
3. Release the hand screw to take the two bracket out. 4. Use 8 of the included M3 screws to fix two 2.5"
HDD or SSD unit to the Tray from the accessory pack.
Note: 2.5" HDD or SSD maximum thickness support to 15mm

Leading EDGE COMPUTING adlinktech.com
Install HDD/SSD
5. Gently seat the drive into the SATA connector on
the PCB and 4 hand screws are fix to the bracket.

Leading EDGE COMPUTING adlinktech.com
Install CFast card
1.Remove the screws fixing the CFast socket cover on
the front panel and remove the cover.
2. True the CFast card with the alignment guide.
3.Gently insert the CFast card until it is firmly seated in
the socket.

Leading EDGE COMPUTING adlinktech.com
Install M.2 module
1. Gently pull the drive out of the SATA connector on
the PCB after loosening the 4 hand screws.
2. Use the included M3 standoff screw to fix it on the
main board, The position depending on the size of
M.2.
M.2 size 2280
M.2 size 3042

Leading EDGE COMPUTING adlinktech.com
Install M.2 module
3. Install the M.2 module and lock the included screw.

Leading EDGE COMPUTING adlinktech.com
Install Mini PCIe module
3. Gently pull the drive out of the SATA connector on
the PCB after loosening the 4 hand screws.
4. Install the miniPCIe module and lock the included
2 M2.5 screws.

Leading EDGE COMPUTING adlinktech.com
Wall-mount
1.Remove the 6 bottom cover screws by screwdriver 2.Use the 6 M4 screws shipped with the controller to
fix the 2 wall-mount brackets, also included, to the
chassis, according to the spacing dimensions of the
screw holes and brackets, as shown.

Leading EDGE COMPUTING adlinktech.com
Wall mount
3.Once final assembly as shown is complete, mount
the MVP-5000 on the wall via screw holes.

Leading EDGE COMPUTING adlinktech.com
MVP-6120/6140

Leading EDGE COMPUTING adlinktech.com
Install HDD/SSD
1. Remove the top cover after loosening the hand
screw
2. Remove the 4 rear base case screws by screwdriver

Leading EDGE COMPUTING adlinktech.com
Install HDD/SSD
3. Remove the bracket by lifting 4. Use 8 of the included M3 screws to fix two 2.5" HDD or SSD
unit to the bracket.
Note: 2.5" HDD or SSD maximum thickness support to 9.5mm

Leading EDGE COMPUTING adlinktech.com
Install HDD/SSD
3. Gently seat the drive into the SATA connector on
the PCB.

Leading EDGE COMPUTING adlinktech.com
Install HDD/SSD (option)
Screw X 8
Bracket X 1
SATA/Power cable(short) X 1
SATA /Power cable(long) X 1
1. Combined with two 2.5" HDD or SSD
Note: 2.5" HDD or SSD maximum thickness support to 15mm

Leading EDGE COMPUTING adlinktech.com
Install HDD/SSD (option)
1. Remove the top cover after loosening the hand
screw.
2. Remove the 4 side base case screws by screwdriver.

Leading EDGE COMPUTING adlinktech.com
Install HDD/SSD (option)
3. Put the HDD or SSD assembly into the system and
lock the 4 side base case screws .
4. Connect the cables to the PCB in sequence.
SATA /Power cable(short)
1
2
3
4
SATA /Power cable(long)

Leading EDGE COMPUTING adlinktech.com
Install CFast card
1.Remove the screws fixing the CFast socket cover on
the front panel and remove the cover.
2. True the CFast card with the alignment guide.
3.Gently insert the CFast card until it is firmly seated in
the socket.
