ADLINK Technology MVP-6000 Series User manual

Leading EDGE COMPUTING
MVP-6000 Series
High Performance 6th Generation Intel®Core™
i7/i5/i3 Fanless Computer
MVP-6001/MVP-6002/MVP-6003
User’s Manual
Manual Rev.: 4.0
Revision Date: May 6, 2019
Part No: 50-1Z214-2020

ii
Leading EDGE COMPUTING
Revision History
Revision Release Date Description of Change(s)
2.00 July 22, 2016 Initial Release
3.0 Dec. 6, 2018 Rev. to accommodate I\O changes
4.0 May 6, 2019 Spec revised & errata resolved

Preface iii
MVP-6000
Preface
Copyright 2019 ADLINK Technology Inc.
This document contains proprietary information protected by copy-
right. All rights are reserved. No part of this manual may be repro-
duced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior
notice in order to improve reliability, design, and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, spe-
cial, incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of
the possibility of such damages.
Environmental Responsibility
ADLINK is committed to fulfill its social responsi-
bility to global environmental preservation
through compliance with the European Union's
Restriction of Hazardous Substances (RoHS)
directive and Waste Electrical and Electronic
Equipment (WEEE) directive. Environmental pro-
tection is a top priority for ADLINK. We have
enforced measures to ensure that our products,
manufacturing processes, components, and raw
materials have as little impact on the environment as possible.
When products are at their end of life, our customers are encour-
aged to dispose of them in accordance with the product disposal
and/or recovery programs prescribed by their nation or company.

iv Preface
Leading EDGE COMPUTING
Battery Labels (for products with battery)
California Proposition 65 Warning
WARNING: This product can expose you to chemicals
including acrylamide, arsenic, benzene, cadmium,
Tris(1,3-dichloro-2-propyl) phosphate (TDCPP), 1,4-
Dioxane, formaldehyde, lead, DEHP, styrene, DINP, BBP, PVC,
and vinyl materials, which are known to the State of California to
cause cancer, and acrylamide, benzene, cadmium, lead, mercury,
phthalates, toluene, DEHP, DIDP, DnHP, DBP, BBP, PVC, and
vinyl materials, which are known to the State of California to cause
birth defects or other reproductive harm. For more information go
to www.P65Warnings.ca.gov.
Trademarks
Product names mentioned herein are used for identification pur-
poses only and may be trademarks and/or registered trademarks
of their respective companies.
Conventions
Take note of the following conventions used throughout this
manual to make sure that users perform certain tasks and
instructions properly.
NOTE:
NOTE:
Additional information, aids, and tips that help users perform
tasks.
ᘄ㟁ụㄳᅇᨲ

Preface v
MVP-6000
CAUTION:
Information to prevent minor physical injury, component dam-
age, data loss, and/or program corruption when trying to com-
plete a task.
WARNING:
Information to prevent serious physical injury, component
damage, data loss, and/or program corruption when trying to
complete a specific task.

vi Preface
Leading EDGE COMPUTING
This page intentionally left blank.

Table of Contents vii
MVP-6000
Table of Contents
Preface.................................................................................... iii
List of Tables........................................................................ xiii
List of Figures....................................................................... xv
1 Introduction ........................................................................ 1
1.1 Overview.............................................................................. 1
1.2 Features............................................................................... 1
1.3 Specifications....................................................................... 2
1.4 Schematics and Dimensions ............................................... 5
1.5 Front Panel I/O Connectors ................................................. 9
1.5.1 Power Button ............................................................ 10
1.5.2 LED Indicators .......................................................... 10
1.5.3 PCI Slot .................................................................... 10
1.5.4 PCI Express x16 Slot................................................ 10
1.5.5 Reset Button............................................................. 10
1.5.6 DisplayPort Connectors............................................ 11
Display Options ............................................................. 12
1.5.7 Digital I/O Connector ................................................ 12
8-channel Digital Input .................................................. 12
8-channel Digital Output ............................................... 12
1.5.8 DVI-D Connector ...................................................... 15
1.5.9 VGA Connector ........................................................ 15
1.5.10 USB 2.0 Ports........................................................... 16
1.5.11 Gigabit Ethernet Ports .............................................. 16
1.5.12 USB 3.0 Ports........................................................... 18
1.5.13 DC Power Connector................................................ 18
1.5.14 COM Port Connectors .............................................. 19
1.6 Rear-Mounted CFast Host Connector ............................... 19
1.7 Internal I/O Connectors...................................................... 21

viii Table of Contents
Leading EDGE COMPUTING
1.7.1 GPS Module Power Headers.................................... 22
1.7.2 USB 2.0 Connector................................................... 23
1.7.3 Mini-PCIe Connector ................................................ 23
1.7.4 SATA Connector....................................................... 23
1.7.5 9V Fan Connector..................................................... 23
1.7.6 Clear CMOS Jumper ................................................ 24
1.7.7 Extended PWR/RESET header ................................ 25
1.7.8 USIM Slot.................................................................. 25
1.7.9 12V Power for Add-on Card...................................... 25
1.7.10 Backboard to System PCB Connector...................... 26
1.7.11 12V DC Fan Connector ............................................ 26
2 Getting Started.................................................................. 29
2.1 Unpacking Checklist .......................................................... 29
2.2 Installing Hard Disk Drives................................................. 29
2.3 Installing CFast Cards........................................................ 34
2.4 Wall-mounting the MVP-6000 ............................................ 36
2.5 Driver Installation ............................................................... 39
A Appendix: Power Consumption .......................................41
A.1 Power Consumption Reference ......................................... 41
A.2 Power Supply Reference ................................................... 42
A.3 Accessory Cabling ............................................................. 42
B Appendix: BIOS Setup.......................................................43
B.1 Main ................................................................................... 43
BIOS Information .......................................................... 44
Platform Information ..................................................... 44
FW Information ............................................................. 44
System Time/System Date ........................................... 45
B.2 Advanced ........................................................................... 45
B.2.1 CPU Configuration.................................................... 46
Hyper-Threading ........................................................... 47

Table of Contents ix
MVP-6000
Active Processor Cores ................................................ 47
Intel Virtualization Technology ...................................... 47
CPU AES ...................................................................... 47
Intel(R) SpeedStep(tm) ................................................. 47
CPU C States ............................................................... 47
Intel TXT(LT) Support ................................................... 47
TCC Activation Offset ................................................... 47
B.2.2 Memory Configuration .............................................. 48
B.2.3 System Agent (SA) Configuration............................. 49
VT-d .............................................................................. 49
B.2.4 Graphics Configuration............................................. 50
Primary Display ............................................................. 50
GTT Size ....................................................................... 50
Aperture Size ................................................................ 50
DVMT Pre-Allocated ..................................................... 51
DVMT Total Gfx Mem ................................................... 51
B.2.5 Onboard Device Configuration ................................. 51
Serial Port 1 to 4 Configuration ..................................... 51
LAN #1 (Intel I211AT) ................................................... 52
LAN #1(I211AT) Launch PXE OpROM ......................... 52
LAN #2 (Intel I211AT) ................................................... 52
LAN #2(I211AT) Launch PXE OpROM ......................... 52
LAN #3 (Intel I211AT) ................................................... 52
LAN #3(I211AT) Launch PXE OpROM ......................... 52
Serial Port Console Redirection .................................... 53
B.2.6 Advanced Power Management ................................ 54
State After G3 ............................................................... 54
State After G3 ............................................................... 54
RTC Wake system from S5 .......................................... 55
BIOS POST Watchdog ................................................. 55
B.2.7 USB Configuration.................................................... 55
Legacy USB Support .................................................... 55

xTableofContents
Leading EDGE COMPUTING
XHCI Hand-off .............................................................. 56
USB Mass Storage Driver Support ............................... 56
Port 60/64 Emulation .................................................... 56
USB transfer time-out ................................................... 56
Device reset time-out .................................................... 56
Device power-up delay ................................................. 56
B.2.8 SATA Configuration .................................................. 57
SATA Port and CFast Card .......................................... 57
B.2.9 CSM Configuration ................................................... 58
CSM Support ................................................................ 58
GateA20 Active ............................................................. 58
Option ROM Messages ................................................ 58
Boot option filter ............................................................ 58
Network ......................................................................... 59
Storage ......................................................................... 59
Video ............................................................................. 59
Other PCI devices ......................................................... 59
B.3 Security.............................................................................. 60
Administrator Password ................................................ 60
User Password ............................................................. 60
RTC Lock ...................................................................... 60
BIOS Lock ..................................................................... 61
B.4 Boot ................................................................................... 61
Setup Prompt Timeout .................................................. 61
Bootup Num-Lock State ................................................ 61
Quiet Boot .................................................................... 62
Fast Boot ..................................................................... 62
Boot Option Priorities .................................................... 62
B.5 Save & Exit ........................................................................ 64
Discard Changes and Exit ............................................ 64
Save Changes and Reset ............................................. 64
Discard Changes .......................................................... 64

Table of Contents xi
MVP-6000
Restore Defaults ........................................................... 65
Save as User Defaults .................................................. 65
Restore User Defaults .................................................. 65
Launch EFI Shell from filesystem device ...................... 65
C Appendix: Watchdog Timer (WDT)
Function Library.....................................................................67
C.1 WDT with API/Windows..................................................... 67
InitWDT ......................................................................... 67
SetWDT ........................................................................ 68
C.2 WDT with DOS/Linux......................................................... 70
D Appendix: Digital Input/Output
Function Library.....................................................................73
DI/O with API/Windows ................................................. 73
Important Safety Instructions.............................................. 75
Getting Service...................................................................... 79

xii Table of Contents
Leading EDGE COMPUTING
This page intentionally left blank.

List of Tables xiii
MVP-6000
List of Tables
Table 1-1: General Specifications................................................ 2
Table 1-2: Power Recommendations .......................................... 4
Table 1-3: Front Panel I/O Connector Legend............................. 9
Table 1-4: LED Indicators .......................................................... 10
Table 1-5: DisplayPort Pin Assignments ................................... 11
Table 1-6: Applicable Cable Types............................................ 11
Table 1-7: Maximum Available Resolutions
with 2-Display Configuration..................................... 12
Table 1-8: Digital Input Connector Pin Legend.......................... 13
Table 1-9: Digital Output Connector Pin Legend ....................... 14
Table 1-10: DVI-D Connector Pin Legend ................................... 15
Table 1-11: VGA Connector Pin Legend ..................................... 16
Table 1-12: Active/Link LED Indicators........................................ 17
Table 1-13: Speed LED Indicators............................................... 17
Table 1-14: DC Power Supply Connector Signals....................... 18
Table 1-15: D-Sub 9p Signal Function of COM Ports.................. 19
Table 1-16: Mainboard Connector Legend .................................. 21
Table 1-17: Backplane Board Connector Legend........................ 22
Table A-1: Power Consumption ................................................. 41
Table A-2: Power Supply ........................................................... 42

xiv List of Tables
Leading EDGE COMPUTING
This page intentionally left blank.

List of Figures xv
MVP-6000
List of Figures
Figure 1-1: MVP-6000 Functional Block Diagram.............................. 4
Figure 1-2: Left Side View.................................................................. 5
Figure 1-3: Top View.......................................................................... 6
Figure 1-4: Front View........................................................................ 7
Figure 1-5: Rear View ........................................................................ 7
Figure 1-6: Underside View................................................................ 8
Figure 1-7: Front Panel I/O Connectors ............................................. 9
Figure 1-8: DisplayPort Connector................................................... 11
Figure 1-9: Digital I/O Connector Pin Assignment ........................... 13
Figure 1-10: Digital Input Circuit......................................................... 14
Figure 1-11: Digital Output Circuit...................................................... 14
Figure 1-12: DVI-D Connector Pin Assignment ................................. 15
Figure 1-13: VGA Connector Pin Assignment.................................... 15
Figure 1-14: Ethernet Port and LED Legend...................................... 17
Figure 1-15: DC Power Connector..................................................... 18
Figure 1-16: COM Port....................................................................... 19
Figure 1-17: CFast Host Connector (on rear panel)........................... 20
Figure 1-18: Mainboard I/O Connectors............................................. 21
Figure 1-19: Backplane Board PCB ................................................... 22
Figure 1-20: Clear CMOS Jumper Setting ......................................... 24

xvi List of Figures
Leading EDGE COMPUTING
This page intentionally left blank.

Introduction 1
MVP-6000
1 Introduction
1.1 Overview
ADLINK’s MVP-6000 Series of value line fanless embedded com-
puting platforms, incorporating the 6th Generation Intel®Core™
processor, provides one PCIe x16 and one PCI slot, one mini-
PCIe slot and single-side access for I/O ports, optimizing easy
maintenance in industrial automation environments. The series
retains the robust design of all ADLINK MXC/MXE lines, at a new
extremely cost-effective price point. The MVP-6000 series sup-
ports DDR4 memory for more powerful computing and the Intel®
HD Graphics 530 speeds graphics performance. Along with a ver-
satile I/O array and flexible expansion capacity, the MVP-6000
Series fully satisfies all the needs of industrial automation with the
performance demanded by vision inspection, motion control, and
surveillance applications. Fanless construction not only over-
comes contaminant and noise challenges presented by harsh IA
environments, the elimination of problematic structural elements
that negatively affect MTBF greatly increases lifecycle expecta-
tions for the platform.
1.2 Features
6th Generation Intel®Core™i7/i5/i3 Skylake FCLGA1151
processor + H110 chipset
2 x DDR4 SO-DIMM socket, supporting up to 32GB DDR4
2133 SO-DIMM Module
1x PCIex16 + 1x PCI slots available, supporting Gen3 PCIe
cards
Supports 2 independent displays with on-board 2x Display-
Port, 1x DVI-D, and 1x VGA ports onboard
6 External USB ports (4x USB 3.0, 2x USB 2.0), 1 internal
USB 2.0 port
3 Intel GbE LAN ports with teaming function
Built-in 8CH DI and 8CH DO, 2 software-programmable RS-
232/422/485 + 2 RS-232 ports

2Introduction
Leading EDGE COMPUTING
CFast socket, onboard SATA III port for 2.5” HDD/SSD
installation, and SATA 6Gb/s
Built-in wide-range 12V DC to 24V DC power input
Fanless operation from 0°C to 50°C (w/ industrial SSD)
1.3 Specifications
NOTE:
NOTE:
This option guarantees cold boot of the system at 0°c
and operation with 100% loading at 50° without add-on
cards. The industrial solid-state drive storage option is
required.
MVP-6001 MVP-6002 MVP-6003
System Core
Processor
Intel®Core™i7-
6700TE Quad
Core, 2.4GHZ, 8M
cache
(Max Turbo
Frequency up to
3.40 GHz)
Intel®Core™i5-
6500TE Quad
Core, 2.3GHZ, 6M
cache (Max Turbo
Frequency up to
3.30 GHz)
Intel®Core™i3-
6100TE Dual
Core, 2.7GHZ, 4M
cache
Chipset Intel®Mobile Platform Controller Hub (H110)
Video
2x DisplayPort (Resolution up to 4096x2304)
1x DVI-D (Resolution up to 4096x2160)
1x VGA up to 1920x1200
Memory 4GB DDR4 2133MHz SODIMM module (Max. capacity
32GB with 2x SODIMM socket option)
I/O Interface
Expansion
slots
1x PCIex16
1x PCI
Supports Gen3 PCIe cards (174mm)
PCI/PCIe combined power consumption: 50W
Ethernet 3x Intel®GbE ports (3x Intel®Ethernet controller I211-AT)
Supports teaming, Wake On LAN
Serial Ports
2 software-programmable RS-232/422/485 (COM1 &
COM2) with auto flow control
2 RS-232 (COM3 & COM4)
Table 1-1: General Specifications

Introduction 3
MVP-6000
USB
4x USB 3.0
2x USB 2.0 (external)****
1x internal USB 2.0 (optional)
DI/O 8CH DI
8CH DO
Audio 1 Mic-in and 1 Line-out
Power Supply
DC Input Built-in wide-range 12 to 24V DC input
3P pluggable connectors with latch (GND, V-, V+)
AC Input Optional 160 W external AC-DC adapter for AC input
Storage
2.5" SATA 1x internal SATA-III port for 2.5" HDD/SSD installation
SATA RAID 0,1 & high speed SATA 6 Gb/s support
CFast CFast (external,), supporting PI/O and DMA modes
Mechanical
Fan Module Optional fan module for dissipating heat from PCI/PCIe
card, Smart Fan Control
Dimensions 220(W) x 210(D) x 170(H) mm (8.67 x 8.27 x 6.69 in.)
Weight 4.5 kg (9.92lb)
Mounting Wall-mount kit
Environmental
Operating
Temperature
(Ambient w/o
airflow)
0°C to 50°C
Storage
Temperature
-40°C to 85°C (-40 to 185°F)
excl. HDD/SDD/CFast
Humidity Approx. 95% @ 40°C (non-condensing)
ESD Contact +/-4 KV and Air +/-8 KV
Shock Operating, 100G, half sine 11 ms duration (w/ CFast or
SSD)
EMC CE and FCC Class A
MVP-6001 MVP-6002 MVP-6003
Table 1-1: General Specifications

4Introduction
Leading EDGE COMPUTING
*Under Windows 7 desktop with no application programs exe-
cuted
**Under Windows 7 with 100% CPU utilization and simultaneous
access to all I/O devices
***Additional power supply required if add-on cards are installed
and in use
****All external USB ports support up to 1.6A
Figure 1-1: MVP-6000 Functional Block Diagram
Power
Supply
(24VDC) Power Off System Idle* System Full
Load**
Recommended
Power
Supply***
Integrated Embedded Computer
MVP-6001 2.9 W 19.68 W 53.52 W 160W
MVP-6002 2.9 W 18.26 W 52.18 W 160W
MVP-6003 2.9 W 17.9 W 50.66 W 160W
Table 1-2: Power Recommendations
Intel Core
i7-6700TE 2.4GHz
i5-6500TE 2.3GHz
I3-6100TE 2.7GHz
Processor
Intel H110
Plaƞorm Controller Hub
DMI
Gen3(8GT/s)
NCT6016D
PCIe x1
GBE I/F GbE controller
Intel WGI211AT
PCIe x1
GBE I/F GbE controller
Intel WGI211AT
PCIe x1GBE I/F GbE controller
Intel WGI211AT
USB3.0
USB2.0
HDA
Audio ALC262
LPC
COM x 4
Line out &
MIC in
connector
RJ45 &
USB3.0 x 2
Connector
RJ45 &
USB3.0 x 2
Connector
RJ45 &
USB2.0 x 2
Connector
Dsub -
Channel B DDR4
260 pin SODIMM
DDR4
2133MHz
EDP
VGA NXP
PTN3355D
DDPB
DVI NXP
PTN3360D
DDPC
DDPD
Display Port1
Display Port2
PCIE
GPO
CFAST
USB2.0
Mini PCIE
With USIM
PCIE
IT8892E PCI slot
PCI
SATA SATA port
USB2.0 USB dongle
PCIE x16 Gen3 PCIE x 16
slot
Intel Core
i7-6700TE 2.4GHz
i5-6500TE 2.3GHz
I3-6100TE 2.7GHz
Processor
Intel H110
Plaƞorm Controller Hub
DMI
Gen3(8GT/s)
NCT6016D
GbE controller
Intel WGI211AT
GbE controller
Intel WGI211AT
GbE controller
Intel WGI211AT
ALC262
Line out &
MIC in
connector
RJ45 &
USB3.0 x 2
Connector
RJ45 &
USB3.0 x 2
Connector
RJ45 &
USB2.0 x 2
Connector
Dsub - 9 x4
Channel B DDR4
260 pin SODIMM
NXP
PTN3355D
DDPB
NXP
PTN3360D
DisplayPort 1
DisplayPort 2
CFAST
Mini PCIE
With USIM
IT8892E PCI slot
SATA port
USB dongle
PCIE x 16
slot
DVI-D
connector
VGA
GPI
8DI connector
8DO connector
Channel A DDR4
260 pin SODIMM
SATA
DDR4
2133MHz
connector
USB3.0
