ADLINK Technology MXC-6101D User manual

Advance Technologies; Automate the World.
Manual Rev.: 2.00
Revision Date: May 30, 2011
Part No: 50-1Z083-1000
MXC-6000
Fanless, Expandable Intel® Core™ i7-620LE
Processor 2.0 GHz Embedded Computer
User’s Manual

Revision History
Revision Release Date Description of Change(s)
2.00 May 30, 2011 Initial release

iii
MXC-6000
Preface
Copyright 2011 ADLINK Technology Inc.
This document contains proprietary information protected by copy-
right. All rights are reserved. No part of this manual may be repro-
duced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior
notice in order to improve reliability, design, and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, spe-
cial, incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of
the possibility of such damages.
Environmental Responsibility
ADLINK is committed to fulfill its social responsibility to global
environmental preservation through compliance with the Euro-
pean Union's Restriction of Hazardous Substances (RoHS) direc-
tive and Waste Electrical and Electronic Equipment (WEEE)
directive. Environmental protection is a top priority for ADLINK.
We have enforced measures to ensure that our products, manu-
facturing processes, components, and raw materials have as little
impact on the environment as possible. When products are at their
end of life, our customers are encouraged to dispose of them in
accordance with the product disposal and/or recovery programs
prescribed by their nation or company.
Trademarks
Product names mentioned herein are used for identification pur-
poses only and may be trademarks and/or registered trademarks
of their respective companies.

iv
Using this Manual
Audience and Scope
The MXC-6000 User’s Manual is intended for hardware
technicians and systems operators with knowledge of installing,
configuring and operating industrial grade single board computers.
Manual Organization
This manual is organized as follows:
Preface: Presents important copyright notifications, disclaimers,
trademarks, and associated information on the proper understand-
ing and usage of this document and its associated product(s).
Chapter 1, Introduction: Introduces the MXC-6000, and its fea-
tures and specifications.
Chapter 2, System Description: Provides information on con-
nectivity and interface function for the MXC-6000.
Chapter 3, Getting Started: Illustrates installation of components
on the MXC-6000 such as drives and storage devices, as well as
instructions on wall-mounting.
Chapter 4, Driver Installation: Provides information on how to
install the MXC-6000 device drivers.
Chapter 5, BIOS Setup: Describes basic navigation of the BIOS
setup utility.
Appendix A, Appendix: Presents information on implementing
the watchdog timer.
Important Safety Instructions: Presents safety instructions all
users must follow for the proper setup, installation and usage of
equipment and/or software.
Getting Service: Contact information for ADLINK’s worldwide
offices.

v
MXC-6000
Conventions
Take note of the following conventions used throughout this
manual to make sure that users perform certain tasks and
instructions properly.
NOTE:
NOTE:
Additional information, aids, and tips that help users perform
tasks.
CAUTION:
Information to prevent minor physical injury, component dam-
age, data loss, and/or program corruption when trying to com-
plete a task.
WARNING:
Information to prevent serious physical injury, component
damage, data loss, and/or program corruption when trying to
complete a specific task.

vi
This page intentionally left blank.

Table of Contents vii
MXC-6000
Table of Contents
Revision History...................................................................... ii
Preface.................................................................................... iii
List of Figures........................................................................ xi
List of Tables........................................................................ xiii
1 Introduction ........................................................................ 1
1.1 Overview.............................................................................. 1
1.2 Features............................................................................... 2
1.3 Specifications....................................................................... 3
1.4 Unpacking Checklist............................................................ 5
2 System Description............................................................ 7
2.1 Mechanical Drawings........................................................... 7
2.2 Front Panel I/O Connectors............................................... 10
2.2.1 Power Button............................................................11
2.2.2 LED Indicators..........................................................12
2.2.3 Reset Button.............................................................12
2.2.4 Digital I/O Connector ................................................13
2.2.5 USB 2.0 Connectors.................................................15
2.2.6 Dual Gigabit Ethernet Ports......................................15
2.2.7 CompactFlash Socket ..............................................16
2.2.8 COM Port connectors...............................................17
2.2.9 DVI-I connector.........................................................18
2.2.10 Audio Jacks..............................................................19
2.2.11 Keyboard & Mouse PS/2 connectors........................19
2.2.12 eSATA connector .....................................................20
2.2.13 DC Power connector ................................................20
2.2.14 PCI slot.....................................................................20

viii Table of Contents
2.2.15 PCI express x4 slot...................................................21
2.3 Internal I/O connectors....................................................... 21
2.3.1 Clear CMOS Jumper ................................................23
2.3.2 Internal Reserved +5V and +12V Connector............23
2.3.3 Internal CF Card Connector......................................24
2.3.4 LVDS Interface Connector........................................25
2.3.5 12V DC Fan Connector ............................................26
2.3.6 LVDS Panel Backlight Control Connector ................26
2.3.7 PCI Express x4 Slot..................................................26
2.3.8 PCI Slot ....................................................................26
2.3.9 Internal USB Connector............................................27
2.3.10 SATA Connectors.....................................................27
2.3.11 Backboard to System PCB Connector......................27
3 Getting Started.................................................................. 29
3.1 Installing hard disk drives................................................... 29
3.2 Installing a PCI/PCIe card.................................................. 34
3.3 Installing CF cards............................................................. 36
3.4 Connecting and using eSATA storage device ................... 41
3.5 Connecting DC power........................................................ 42
3.6 Wall-mounting the MXC-6000 series................................. 43
3.7 Cooling configuration......................................................... 46
4 Driver Installation.............................................................. 47
4.1 Installing the chipset driver ................................................ 47
4.2 Installing the graphics driver.............................................. 48
4.3 Installing the Ethernet driver.............................................. 49
4.4 Installing the audio driver................................................... 49
4.5 Installing the WDT driver.................................................... 49
5 BIOS Setup........................................................................ 51
5.1 Main................................................................................... 51
5.1.1 System Time/System Date.......................................51

Table of Contents ix
MXC-6000
5.2 Advanced........................................................................... 52
5.2.1 Intel PXE ROM.........................................................52
5.2.2 ACPI Settings...........................................................52
5.2.3 Intel IGD SWSCI OpRegion .....................................52
5.2.4 CPU Configuration....................................................53
5.2.5 SATA Configuration..................................................53
5.2.6 Serial Port Configuration ..........................................53
5.2.7 USB Configuration....................................................54
5.2.8 Watchdog Timer.......................................................54
5.2.9 H/W Monitor..............................................................54
5.3 Chipset............................................................................... 55
5.3.1 Northbridge configuration.........................................55
5.3.2 Southbridge configuration.........................................55
5.4 Security.............................................................................. 56
5.5 Boot ................................................................................... 56
5.5.1 Boot Settings Configuration......................................56
5.5.2 Boot Option Priorities................................................56
5.6 Exit..................................................................................... 57
A Appendix........................................................................... 59
A.1 Watchdog Timer (WDT) Function Reference .................... 59
Important Safety Instructions.............................................. 63
Getting Service...................................................................... 65

xTableofContents
This page intentionally left blank.

xi
MXC-6000
List of Figures
Figure 2-1: MXC-6000 Left Side View................................................7
Figure 2-2: MXC-6000 Right Side View.............................................7
Figure 2-3: MXC-6000 Top View........................................................8
Figure 2-4: MXC-6000 Front View .....................................................8
Figure 2-5: MXC-6000 Rear View......................................................9
Figure 2-6: MXC-6000 Bottom View ..................................................9
Figure 2-7: Front Panel I/O Connectors...........................................10
Figure 2-8: Mainboard PCB .............................................................21
Figure 2-9: Back Plane Board PCB..................................................22

xii
This page intentionally left blank.

List of Tables xiii
MXC-6000
List of Tables
Table 1-1: MXC-6000 General Specifications...................................4
Table 2-1: Front Panel I/O Connector Legend................................11
Table 2-2: LED Indicators...............................................................12
Table 2-3: Digital I/O Connector Pin Signals ..................................14
Table 2-4: Active/Link LED .............................................................16
Table 2-5: Speed LED ....................................................................16
Table 2-6: D-sub 9P signal function of COM ports .........................17
Table 2-7: DVI-I Connector Signals................................................18
Table 2-8: Audio Jack Signals ........................................................19
Table 2-9: PS/2 Connector Signals.................................................19
Table 2-10: DC Power Supply Connector Signals............................20
Table 2-11: Mainboard Connector Legend.......................................21
Table 2-12: Back Plane Board Connector Legend ...........................22
Table 2-13: Clear CMOS Jumper Settings .......................................23
Table 2-14: +5V and +12V Connector Pin Functions .......................23
Table 2-15: LVDS Connector Pin Functions.....................................25
Table 2-16: Backlight Connector Pin Functions................................26
Table 5-1: Restore On Power Loss.................................................55

xiv List of Tables
This page intentionally left blank.

Introduction 1
MXC-6000
1 Introduction
1.1 Overview
The Matrix MXC-6000 series provides powerful, fanless, expand-
able embedded computing using the new Intel® Core™ i7-620LE
Processor 2.0 GHz with improved computing performance. The
MXC-6000 continues the exceptional fanless and cable-free
design from the existing Matrix C series.
The MXC-6000 series features an Intel® Core™ i7-620LE Proces-
sor 2.0 GHz and Intel® QM57 chipset to boost performance, mak-
ing it ideal for image and vision measurement and automation
applications. Its PCI and PCIe slots allow integration of
off-the-shelf PCI/PCIe cards to develop a configurable application
platform. The built-in 16 isolated DIO channels are provided for
general industrial control. A DVI-I connector output on the front
panel allows direct connection to an LCD panel, and the
MXC-6000 series also provides one eSATA port to enable expan-
sion of current storage capacity or use of hot-swappable SATA
drives.
Leveraging a reliable fanless and durable cable-free design, the
MXC-6000 series exhibits excellent dependability in harsh envi-
ronments, where severe temperature variation and vibration may
occur. The MXC-6000 series provides an optional hot-pluggable
fan module to dissipate heat generated within the system when
high power consumption PCI/PCIe cards are installed. This inno-
vative mechanical design retains a cable-free structure which dra-
matically improves thermal stability when PCI/PCIe cards are
installed.
The MXC-6000 also provides a USB 2.0 port internally on riser
card. This function provides more reliable usage in security appli-
cations where license keys or password encryption through an
internal USB dongle dramatically improve the security of the
Matrix I/O controller. Combining a reliable design with more com-
puting power and innovative features, the Matrix MXC-6000 series
is the optimal choice on which to base any rugged application sys-
tem.

2Introduction
1.2 Features
XIntel® Core i7-620LE 2.0 GHz processor + Intel® QM57
chipset
XConfigurable PCI and PCIe x4 slots
XRugged, -10°C to 60°C fanless operation*
XBuilt-in 9 V DC to 32 V DC wide-range DC power input
XVGA+DVI-D display by DVI-I connector
XDual 1000/100/10 Mbps Ethernet ports
XTwo RS-232 and two software-selectable ports
XRS-232/422/485 ports
XUSB 2.0 port internally on riser card
XBuilt-in 16-CH isolated DI and 16-CH isolated DO
NOTE:
NOTE:
This option guarantees cold boot of the system at -10°c
and operation with 100% loading at 60°c. The industrial
solid-state drive storage option is required.

Introduction 3
MXC-6000
1.3 Specifications
MXC-6101D MXC-6201D
System Core
Processor Intel® Core i7-620LE 2.0 GHz CPU
Chipset Intel® QM57
Video VGA+DVI display by DVI-I connector
Analog CRT, supports QXGA (2048 x 1536) resolution
DVI-I 1.0 (DVI + VGA) (with external cable for connecting DVI-I
connector to DVI and VGA device)
Optional 48-bit LVDS (by internal box header)
Memory 1 socket slot with 2 GB DDR3 800/1066 MHz SODIMM module
(Max. Capacity 4GB)
I/O Interface
Ethernet 2x GbE port (2x Intel® 82574L)
Serial Port 2x software-programmable RS-232/422/485 (COM1 & COM2)
2x RS-232 (COM3 & COM4)
USB 4x USB 2.0 ports (external), 1xUSB 2.0 port (internally on riser
card)
Audio 1x Mic-in and 1x Speaker-out
KB/MS 1x PS/2 keyboard and 1x PS/2 mouse
Expansion 2* PCI slots 1* PCIex4 slot + 1* PCI slot
DI/O 16DI + 16DO
Power Supply
DC Input AT/ATX, Built-in 9-32 V DC wide-range DC input ,
3P pluggable connector with latch (V-, GND, V+)
AC Input Optional 100 W external AC-DC adapter for AC input

4Introduction
Table 1-1: MXC-6000 General Specifications
Storage Device
SATA HDD 2 x Onboard SATA port for 2.5" HDD/SSD installation
CF 1x external type I CompactFlash socket,
1x internal type I CompactFlash socket
eSATA 1x eSATA port
Mechanical
Fan Optional hot-pluggable fan module cooling PCI/PCIe card
Dimensions 130(W) x 225 (D) x 183(H) mm (5.12x8.86x7.2 in)
Weight 3.5 kg (7.71 lb)
Mounting Wall-mount kit
Environmental
Operating
Tempera-
ture
Standard: 0°C to 50°C (32 to 122°F) (w/ HDD)
Extended: -10°C to 60°C (-14 to 140°F) (w/o HDD or w/
Industrial SSD/CF)
Storage
Tempera-
ture
-40°C to 85°C (-40 to 185°F)
Humidity approx. 95% @ 40°C (non-condensing)
Vibration Operating, 5 Grms, 5-500 Hz, 3 axes (w/ CF or SSD)
Operating, 0.5 Grms, 5-500 Hz, 3 axes (w/ HDD)
EMC CE, FCC
Shock Operating, 50 G, half sine 11ms duration (w/ CF or SSD)

Introduction 5
MXC-6000
1.4 Unpacking Checklist
Before unpacking, check the shipping carton for any damage. If
the shipping carton and/or contents are damaged, inform your
dealer immediately. Retain the shipping carton and packing
materials for inspection. Obtain authorization from your dealer
before returning any product to ADLINK. Ensure that the fol-
lowing items are included in the package.
XMXC-6000 controller
XAccessory Box
XScrew pack for wall-mounting and HDD fixing
XUser’s manual
XADLINK All-in-One DVD
WARNING:
The MXC-6000 must be protected from static discharge and
physical shock. Never remove any of the socketed parts except
at a static-free workstation. Use the anti-static bag shipped with
the product to handle the board. Wear a grounded wrist strap
when installing and/or servicing.

6Introduction
This page intentionally left blank.
