WHITEPAPER
Using the Open Toolkit plug-in
for FrameMaker
With the Darwin Information Typing Architecture (DITA) emerging as the de facto stan-
dard for creating topic-based content, Adobe® FrameMaker® 9 provides extensive support
for authoring DITA content. In addition, you can use the DITA Open Toolkit with
FrameMaker to obtain deliverable outputs. This document describes how to use the DITA
Open Toolkit with FrameMaker 9.
You are expected to know how to use DITA in FrameMaker. For information on installing
DITA Open Toolkit, see “Appendix 1: Installing the DITA Open Toolkit” on page 9, and
“Appendix 2: Installing the Open Toolkit plug-in for FrameMaker” on page 13.
Overview of DITA Open Toolkit
DITA Open Toolkit is a set of software tools, originally developed by IBM®, for publishing
DITA to various formats, including HTML, Microsoft HTML Help (.CHM) and Java™
Help. If your content conforms to the DITA structure, you can use the DITA Open Toolkit
to generate a wide variety of outputs.
The DITA Open Toolkit—an Open Source tool chain for multichannel publishing
DITA Open Toolkit is available for free distribution on the Organization for the Advance-
ment of Structured Information Standards (OASIS) website at http://www.oasis-open.org/
committees/tc_home.php?wg_abbrev=dita. OASIS maintains the DITA specification.
Working with the Open Toolkit plug-in for FrameMaker
The Open Toolkit plug-in for FrameMaker lets you manage publishing through the
FrameMaker user interface. The plug-in provides a DITA menu for publishing multiple
outputs through the DITA Open Toolkit, using the default options or your customized
builds.
HTML
Compiled Help
Java Help
XML conforming to
DITA Structure
DITA Open
ToolKit
XML
TABLE OF CONTENTS
1 Over view of DITA Open Toolkit
1 Working with the Open Toolkit plug-in for
FrameMaker
3 Advanced features
9 Appendix 1: Installing the DITA Open Toolkit
13 Appendix 2: Installing the Open Toolkit plug-
in for FrameMaker
14 Next steps
14 Resources

Using the Open Toolkit plug-in for FrameMaker 2
The Open Toolkit plug-in for FrameMaker
Generating output from the current file
After installation, you can run the DITA Open Toolkit processes from within FrameMaker. There
are two ways to do this, corresponding to the two options, Current File and Selected Target in the
DITA Generate Output dialog box:
The DITA Generate Output dialog box offers two forms of DITA Open Toolkit processing.
•Current File uses a pre-configured Ant script: This Ant script is the ditafm-ant.xml file that you
copied to your DITA-open toolkit folder on installation. This script generates output from a topic
that is currently open or from the map file to a sub folder of the folder containing the topic. On a
configured system, you can generate output without having to modify the Ant script. However,
you can edit the ditafm-ant.xml file to customize the processing of output. You must specify the
path where you installed the DITA Open Toolkit.
•Selected Target lets you specify an Ant script you’ve created. You must set up your own Ant script
and reference the script in the ditafm.ini file. The list of selected targets does not appear until you
define them in the Ant script and reference them in the ditafm.ini file.
• Most users may require only the Current File method starting the DITA open toolkit. Most
FrameMaker users may use the Current File method for running the DITA Open Toolkit pro-
cesses.
You can use Current File to process the map file or DITA topics that are open.
In the Selected Target method, the Ant scripts referenced in your DITA initialization file are run.
This method indicates the following:
• Files to process
• Applications and processes to run
• Destination folders and filenames

Using the Open Toolkit plug-in for FrameMaker 3
Thus, the Selected Target method is more appropriate for calling publishing processes that generate
output from source files in the locations specified in your custom Ant scripts.
Current File Method
Make the following changes in fminit\ditafm\ditafm.ini
To process a topic file that is open, change the ditafm.ini file as follows:
[BuildFile]
AntCommand=ant
AntScript=ditafm-ant.xml
Count=2
DitaDir=C:\DITA-OT1.4.2.1
1=chm
2=html
To generate output from the example Help file DITA map, using the Current File option:
1 Open a ditamap file.
2 If prompted, select the structured application DITA-Map-HTML, and click Continue.
Use the Structured Application dialog box.
3 Select the path where the DITA Open Toolkit is installed.
4 Select the Current File option.
5 Select .html.
6 Select the output folder, and click Build.
On a fully configured system, the example DITA content is saved in HTML.
HTML output
To view the HTML output, double-click the index.html file, which is located in the output folder.
Compiled Help (.chm) output
You can generate compiled Help (.CHM) easily. This process is similar to generating HTML output.
Open the .ditamap file, and choose DITA-->Generate CHM Output. A folder named CHM is cre-
ated in the output folder. The CHM folder contains the CHM file.
When you use the Current File option to generate output using the DITA Open Toolkit, you do not
need to modify any of the Ant, XSLT, or initialization files.
PDF output
The recommended way to generate a PDF for DITA files is through the Save As PDF option in
FrameMaker.
However, to generate PDFs using the DITA Open Toolkit:
1 Install a FO processor that helps in converting FO files to PDF. (Apache FOP is free.)
2 With Apache FOP installed, add fop.jar, batik.jar, avalon-framework-cvs-20020806.jar file path to
the CLASSPATH environment variable.
3 Update ditafm.ini to add an entry for PDF.
The route to generate PDFs through DITA Open Toolkit is added to the DITA Generate Output dia-
log box.
Advanced features
The publishing capabilities of Adobe FrameMaker are enhanced by the Open Toolkit plug-in for
FrameMaker. To take advantage of these features, you must have knowledge of the following:

Using the Open Toolkit plug-in for FrameMaker 4
• The settings in the DITA initialization file (ditafm.ini), which determine the Apache Ant file to be
used for different target outputs.
• Apache Ant scripts, in general, and their role in defining publishing processes that generate
output from the DITA Open Toolkit.
• The XSLT style sheets that are used to generate HTML and other forms of output with the
DITA Open Toolkit, as well as the other files that control the format of output, such as
cascading style sheets.
Using the Selected Target option
A user can customize using the selected target option. The ditafm.ini file provides users with entry
points from where they can run various Ant scripts. Also, for customizing Ant scripts, the user also
needs to have a basic understanding of these scripts.
When you use the Selected Target option, rather than starting an Ant script that is preset to process
the currently open file, you start an Ant script without parameters. The Ant script must contain
explicit instructions about the following:
• Files to process
• Folders to be used for different forms of output
• Publishing methods and processes
While the Selected Target option requires more setup than the Current File option, it offers more
fine-grained control.
About Ant scripts
Apache Ant, a Java™ application installed with the DITA Open Toolkit, is used for automating soft-
ware build processes. For example, the following types of publishing processes can be automated:
1 Transform specified XML files, such as DITA map files or associated topic files, with XSLT style
sheets, to generate XHTML output.
2 Run a subsequent process to place these files into specific folders for deployment to a website.
With Ant, such processes are completely controlled by an Ant script or XML build file, which
defines the following:
• All steps of the publishing process, including the processes or applications called, the target and
destination folders and files
• Processing sequence
Example custom Ant script
If the DITA Open Toolkit is properly installed, you should see a file named PROJECT.xml in your
DITA_OT folder, such as C:\dita-ot1.2.\PROJECT.xml. You can define any custom publishing pro-
cesses by copying, renaming, and modifying the PROJECT.xml file. In addition, you must modify
the DITA initialization file.
For example, to process DITA files located in the C:\Projects\Test folder, do the following:
1 Create a folder named C:\Projects\Test and copy all .dita and .xml files from the source folder to it.
Source refers to the location where you extracted the OpenToolkit.zip file. See Appendix 2 for
details.
2 Copy PROJECT.xml to your Open Toolkit (typically, C:\dita-ot1.4.2.1) folder and rename
PROJECT. xml to Test.xml.
3 Open Test.xml in Windows® Notepad® (Start > Programs > Accessories > Notepad). In steps 4
through 9, you will set the main properties indicated in the comments, which appear at the begin-
ning of the file.

Using the Open Toolkit plug-in for FrameMaker 5
Test.xml open in Windows Notepad
4 Set the property value for dita.dir to your Open Toolkit path (for example, C:\DITA-OT1.4.2.1).
Property name and value settings for dita.dir
5 Set the property value for project.ditamap to the name of your DITA map file, and the value for
project.dir to the path of your project folder (in this case, C:\Projects\Test). If necessary, you can
change the output folder. In the initial configuration of PROJECT.xml, the default output folder is
the sub folder, out, in the folder defined as project.dir.
Property name and value settings for project.dita
6 Set the property value for dita.extname to the extension of your referenced topic files (in this
case, .xml).
Property name and value settings for dita.extname
7 Save and close Test.xml.
At this stage, Test.xml must include all parameters required for running builds that target the
specific test folders and files. However, such Ant scripts must be referenced in the initialization file
before their targets show as options in the DITA Generate Output dialog box.
Editing the DITA initialization file
To complete the process of adding the selected targets, edit the DITA initialization file.
Note: Take a backup of the DITA initialization file before changing anything.
1 Using Windows Notepad, open ditafm.ini from the fminit\ditafm folder.
2 Add the following lines at the end of the file:

Using the Open Toolkit plug-in for FrameMaker 6
[AntBuild]
AntCommand=ant
Count=2
1=Test - CHM
2=Test - HTML
[ANT:Test - CHM]
BuildFile=C:\DITA-OT1.4.2.1\Test.xml
Target=chm
OutputDir=C:\Projects\Test\out\chm
Logfile=C:\Projects\Test\ant-buildlog-chm.txt
[ANT:Test - HTML]
BuildFile=C:\DITA-OT1.4.2.1\Test.xml
Target=html
OutputDir=C:\Projects\Test\out\html
Logfile=C:\Projects\Test\ant-buildlog-html.txt
3 Save and close ditafm.ini.
Now you can run the selected targets. Note that Test.xml is a single script that contains multiple tar-
gets, such as CHM and HTML.
To run the selected targets you have defined (formats like CHM, PDF, and so on):
4 In FrameMaker, select DITA > Generate Output.
5 Click Selected Target. The list of targets specified in the .ini file appears.
DITA Generate Output dialog box with Selected Target option selected
6 Select one of the targets and click Build.
You can review the output, which is similar to the output generated using the Current File option.

Using the Open Toolkit plug-in for FrameMaker 7
Customizing Ant
You can customize Ant scripts to automate a wide range of publishing processes.
For example, you might use an Ant script to copy files from one location to another. You can either
create a script or add a target to an existing script, as shown in the following figure:
Customizing the Text.xml Ant script
To add this target as an option in FrameMaker, you can modify the DITA initialization file to refer-
ence and define the new target, as shown in the following examples:
Modifying the ditafm.ini file
When the ditafm.ini file is updated, the new form of output is listed as a target in the DITA Gener-
ate Output dialog box.
New target available in DITA Generate Output dialog box

Using the Open Toolkit plug-in for FrameMaker 8
Customizing DITA Open Toolkit files
In addition to customizing Ant scripts, you can customize other components of the DITA Open
Toolkit publishing process. The DITA-OT contains the files you can modify. Ant processing can
include files in any location, and processes and applications not included in the DITA Open Toolkit
distribution.
Main files of the DITA Open Toolkit
You can modify some of the following files to customize the output generated using the Open Tool-
kit plug-in for FrameMaker.
• XSLT style sheets that control HTM and other forms of published output. You can change the
XSLT style sheet to customize HTML design, or you can use XSLT to generate XML in a different
structure from your core DITA structure to interface with specific systems.
• CSS style sheets that are used in HTML output
•Antscripts
• Any other tools used in new targets
This customization must be separated from the core toolkit processing. For example, you can cus-
tomize the XSLT that generates XHTML to accommodate a specialized structure by doing the fol-
lowing:
1 In the xsl sub folder in your DITA Open Toolkit folder, rename dita2xhtml.xsl to
dita2xhtml_original.xsl.
2 Create a file named dita2xhtml.xsl that imports both the renamed .xsl file, and a second .xsl file
where you add your custom processing:
<xsl:stylesheet version="1.0"
xmlns:xsl="http://www.w3.org/1999/XSL/Transform">
<xsl:import href="dita2xhtml_original.xsl"/>
<xsl:import href="/path/to/custom2xhtml.xsl"/>
</xsl:stylesheet>
3 Create the XSLT for custom processing, and save it in a folder outside the DITA Open Toolkit
folder. By doing this, you can manage Open Toolkit updates, without losing any customization.
You must install a new version of the Open Toolkit and then do steps 1 and 2 above.

Using the Open Toolkit plug-in for FrameMaker 9
Appendix 1: Installing the DITA Open Toolkit
The DITA Open Toolkit includes the basic document type definitions (DTDs) associated with DITA,
as well as some XSLT style sheets for processing DITA into various output formats. The toolkit
depends on several freely available software applications, such as the following:
• The Java Development Kit, required for core processing of published output
• Apache Ant, required to define different forms of output, including location of source and
destination files
• JavaHelp, used when you are publishing your content as Help for Java applications
• SAXON, an XSLT processor used for HTML publishing
• Microsoft® HTML Help, used to generate compiled HTML Help (.chm) files
• XML-Resolver - xml-resolver-1.2.jar file required for DITA-OT1.4.2.1. (Located in the path con-
taining openToolkit.dll)
A complete installation includes installing these applications and Open Toolkit, then setting the
Environment Variables on the computer on which you’ve installed these so that the various applica-
tions can work together. To run the DITA Open Toolkit from FrameMaker, you will also need to
install the Open Toolkit plug-in for FrameMaker. For information on downloading and installing
the plug-in, see “Appendix 2: Installing the Open Toolkit plug-in for FrameMaker” on page 13.
Installing the Java Development Kit
At the core of the DITA Open Toolkit is the Java Development Kit (JDK), which provides the base
Java functionality on which most other toolkit programs depend. To install the JDK:
1Gotohttp://java.sun.com/javase/downloads/index.jsp.
2 Click the Download J2SE SDK link to download the JDK. Check for JDK 6 Update 3.
3 Accept the license agreement, and click Windows Offline Installation.
4 Click Save to save the file to your hard disk; note where you saved the file.
5 Open Windows Explorer again by right-clicking the Windows Start menu and choosing Explore
from the pop-up menu. Navigate to the folder where you saved the file, and double-click the
executable file.
6 Click Run and accept the default installation options.
7 Open Windows Explorer again. Look in the root folder to see where the JDK was installed, for
example, C:\Program Files\Java\jdk1.6.0_10 (the precise name depends on the version of the JDK
you installed).
Installing Apache Ant
Apache Ant is a build tool used by the DITA Open Toolkit for defining different processing steps
for generating published output. To install Apache Ant:
1Gotohttp://ant.apache.org/bindownload.cgi.
2 Click the .zip archive link to download the current version of Apache Ant (for example,
apache-ant-1.7.1-bin.zip [PGP] [SHA1] [MD5]).
3 Click Save to save the archive file to your hard disk; note where you saved the file.
4 Open Windows Explorer by right-clicking the Windows Start menu and choosing Explore from
the pop-up menu. Navigate to the folder where you saved the archive file.
5 Extract the contents of the archive file to the C:\ folder.

Using the Open Toolkit plug-in for FrameMaker 10
Installing JavaHelp
JavaHelp creates Help for use in Java-based applications. To install JavaHelp:
1Gotohttp://java.sun.com/products/javahelp/download_binary.html.
2 Download the latest version of JavaHelp (for example, JavaHelp 2.0_02 [Zip]), accepting the
license agreements.
3 Click Save to save the archive file to your hard disk; note where you saved the file.
4 Open Windows Explorer by right-clicking the Windows Start menu and choosing Explore from
the pop-up menu. Navigate to the folder where you saved the archive file.
5 Extract the contents of the archive file to the C:\ folder.
Installing the SAXON XSLT Processor
The SAXON XSLT Processor is an Open Source XSLT processor built by Michael Kay, used to
transform source XML conforming to the DITA architecture to HTML. To install the SAXON
XSLT Processor:
1Gotohttp://saxon.sourceforge.net/.
2 Click the download link under the heading Saxon 6.5.5.
3 Click one of the download options on the SourceForge.net page.
4 Click Save to save the archive file to your hard disk; note where you saved the file.
5 Open Windows Explorer by right-clicking the Windows Start menu and choosing Explore from
the pop-up menu. Create a folder within the root folder called Saxon (for example, C:\Saxon).
6 In Windows Explorer, navigate to the folder where you saved the archive file.
7 Extract the contents of the archive file to the C:\Saxon folder that you created.
Installing Microsoft HTML Help
Microsoft HTML Help is a tool for authoring online Help, which is used by the Open Toolkit to
create compiled Help (.chm) files. To install Microsoft HTML Help:
1Gotohttp://msdn.microsoft.com/library/default.asp?url=/library/en-us/htmlhelp/
html/hwMicrosoftHTMLHelpDownloads.asp (make sure this is a single line).
2 Click Download Htmlhelp.exe and click Save to save the executable file to your hard disk; note
where you saved the file.
3 Open Windows Explorer by right-clicking on the Windows Start menu, and choosing Explore
from the pop-up menu. Double-click the Htmlhelp.exe file and follow the steps in the HTML
Help installation wizard to complete the installation.
Installing the DITA Open Toolkit
The DITA Open Toolkit itself provides files that control the dependent applications, such as the
JDK, Ant, and SAXON, to generate published output. To install the DITA Open Toolkit:
1Gotohttp://dita-ot.sourceforge.net/.
2 Click Download in the left pane, and click Download DITA Open Toolkit.
3 Select and download the most recent DITA Open Toolkit .zip archive (for example,
DITA-OT1.4.2.1_full_easy_install_bin.zip), selecting a mirror site for your download.
4 Click Save to save the archive file to your hard disk; note where you saved the file.
5 Open Windows Explorer by right-clicking the Windows Start menu and choosing Explore from
the pop-up menu. Navigate to the folder where you saved the archive file.
6 Extract the contents of the archive file to the C:\ folder.
Technical skill required
Note that installing the DITA Open Toolkit requires con-
siderable expertise, and may not be appropriate for
those without at least some programming background.
Time allocation
This process can be time-consuming, as you will be
installing multiple Open Source applications that sup-
port the toolkit, as well as the toolkit itself. Allocate sev-
eral hours for installation and testing.

Using the Open Toolkit plug-in for FrameMaker 11
Setting environment variables
Before you can use the DITA Open Toolkit, you need to set various environment variables, so the
applications can work together. To set environmental variables in Windows XP:
1 Click the Windows Start Menu, right-click on My Computer, and then choose Properties from the
pop-up menu.
2 Select the Advanced tab and click Environment Variables to open the Environment Variables
dialog box. For the DITA Open Toolkit, modify only the System Variables.
3 Edit existing System Variables by selecting them from the list and clicking Edit.
Note: Do not overwrite path values; instead, add additional paths to variables by delimiting paths
with semicolons.
v
When editing System Variables, be sure to add a semicolon at the end of existing values, followed by the additional
value you want to add.
4 Add new System Variables by clicking New instead of Edit, and setting the variable value.
Follow the instructions in the table below for each environment variable listed. Before adding new
variables, check the System Variables list to see if they are already present. If so, first add a semico-
lon after the existing value, then add the new path.

Using the Open Toolkit plug-in for FrameMaker 12
Overview of environment variables and instructions
Verifying the installation
To verify that you have installed the DITA Open Toolkit correctly, including its dependencies
and configuration:
1 Go to the command prompt by choosing Run from the Windows Start menu, and then typing
cmd and clicking OK.
2Typecd \ at the command prompt to move to the root folder.
ENVIRONMENT VARIABLE INSTRUCTION
Set the ANT_Home variable to the location where
you installed Apache Ant.
Click New under System Variables and set the
variable name to ANT_HOME, and the variable
value to the path created by the Apache Ant
installation (for example, C:\apache-ant-1.6.5).
Set the ANT_OPTS variable to allow sufficient
memory to run the test Ant script.
Click New under System Variables and set the
variable name to ANT_OPTS, and the variable
value to -Xmx256M.
Set the Classpath variable to include the Open
Toolkit dost.jar file.
If you already have a Classpath variable in your list
of System Variables, select the Classpath variable
in the list of System Variables and click Edit. Add a
semicolon (no spaces before or after) to the end of
the current Classpath value, followed by the path
of your Open Toolkit dost.jar file (for example,
C:\dita-ot1.4.2.1\dost.jar).
If you don’t have a Classpath variable, create one
by clicking New and setting the variable name
to Classpath, and the variable value to the path
of your Open Toolkit dost.jar file (for example,
C:\dita-ot1.4.2.1\dost.jar).
Set the Classpath variable to include the
SAXON .jar file.
Select the Classpath variable in the list of system
variables and click Edit—add a semicolon (no
spaces before or after) to the end of the current
Classpath value, followed by the path of your
SAXON .jar file (for example, C:\Saxon\saxon.jar).
Set the JAVA_Home variable to the folder where
you installed the JDK.
Click New under System Variables and set the
variable name to JAVA_HOME, and the variable
value to the path created by the JDK installation
(for example, C:\j2sdk1.4.2_12).
Set the JHHome variable to the folder where you
installed JavaHelp.
Click New under System Variables and set the
variable name to JHHOME, and the variable value
to the path created by the JavaHelp installation
(for example, C:\jh2.0).
Set the Path variable to the folder where you
installed the Apache Ant bin folder.
Select the Path variable in the list of System
Variables and click Edit. Add a semicolon (no
spaces) followed by the path of your Apache Ant
bin folder (for example, C:\apache-ant-1.6.5\bin).
Set the Classpath variable to include the xml-
resolver-1.2.jar file.
If you already have a Classpath variable in your list
of System Variables, select the Classpath variable
in the list of System Variables and click Edit. Add a
semicolon (no spaces before or after) to the end of
the current Classpath value, followed by the path of
xml-resolver-1.2.jar file (for example, C:\xml-
resolver-1.2.jar).
If you don’t have a Classpath variable, create one
by clicking New and setting the variable name
to Classpath, and the variable value to the path of
xml-resolver-1.2.jar file (for example, C:\xml-
resolver-1.2.jar).

Using the Open Toolkit plug-in for FrameMaker 13
Moving to DITA Open Toolkit folder in command window
3 Navigate to the DITA Open Toolkit folder (for example, by typing CD dicta-ot1.4.2.1).
Note: This folder name must exactly match the folder where you installed the DITA Open Toolkit.
4 At the command prompt, type ant all
If your toolkit is properly installed, you should see text scrolling through the command window
for several minutes, as the DITA Open Toolkit generates test output, completing with the text
“BUILD SUCCESSFUL.”
Successful build reported in command window
If you receive an error, double-check the installation instructions above, or see the DITA Open
Toolkit documentation.
Appendix 2: Installing the Open Toolkit plug-in for FrameMaker
This section guides you through installing the Open Toolkit plug-in for FrameMaker and its associ-
ated components. The various sets of files you need are contained in the openToolkit.zip archive.
Follow the directions for expanding and extracting each set of files to their proper locations.
Installation overview
There are only two main steps to setting up the Open Toolkit plug-in for FrameMaker:
1 Extract all the files from the .zip archive to specified areas in FrameMaker installation folder (for
example, C:\Program Files\Adobe\FrameMaker9).
2 Make the corresponding entry in maker.ini.
Extracting and placing the archive files
1 Download and save the OpenToolkit .zip archive to a work area on your computer (for example, a
downloads or temporary files folder).
2 Extract the contents of the OpenToolkit .zip file.
3 Copy openToolkit.dll into fminit folder.
4 Copy the two xml files: PROJECT.xml and ditafm-ant.xml into fminit\ditafm sub folder.
5 Open maker.ini file located in the FrameMaker installation folder. Navigate to the APIClients sec-
tion. Add the following entry at the end of this section:
ditaOpenToolkit=Standard, DITA Open Toolkit, fminit\openTool-
kit.dll, structured

Adobe Systems Incorporated • 345 Park Avenue, San Jose, CA
95110-2704 USA • www.adobe.com
Adobe, the Adobe logo, and FrameMaker are either registered trade-
marks or trademarks of Adobe Systems Incorporated in the United
States and/or other countries. IBM is a trademark of International
Business Machines Corporation in the United States, other countries,
or both. Java is a trademark or registered trademark of Sun Microsys-
tems, Inc. in the United States and other countries. Microsoft and
Windows are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries.
All other trademarks are the property of their respective owners.
© 2009 Adobe Systems Incorporated. All rights reserved.
6 Check the final file locations. When complete, the extracted files should be in the fol-
lowing locations in your FrameMaker9 installation folder:
Table of file types and final file locations in FrameMaker installation folder
7 Close the .zip archive if your extracting application does not close it automatically.
8 Now launch FrameMaker 9. Navigate to the DITA menu. A new submenu: Generate
Output has been added.
Moving the DITA Open Toolkit Files
There are two files that are used for working with the DITA Open Toolkit, which have to
be copied into the fminit\ditafm folder in your initial installation.
1 In Windows Explorer, navigate to the ditafm folder in your FrameMaker installation
folder (for example, C:\Program Files\Adobe\FrameMaker9\fminit\ditafm), and copy
ditafm-ant.xml and PROJECT.xml.
2 Navigate to your DITA-OT folder (for example, C:\dita-ot1.4.2.1), and paste the two
files.
Next steps
Now that you’ve seen the power of publishing with the Open Toolkit plug-in for
FrameMaker, you may want to learn more about the DITA Open Toolkit itself, the tech-
nologies associated with specific forms of output, such as the XSLT and CSS style sheets
that generate and format HTML.
Different users will have different degrees of interest in customization. To some, it will be
enough to get the DITA Open Toolkit and the Open Toolkit plug-in for FrameMaker
installed, and to gain the benefit of automatic output of formats, such as compiled Help
without any customization.
It should be noted that the DITA Open Toolkit is in a work-in-progress state. Some of the
information in this paper may become obsolete as the toolkit evolves, so it is a good idea to
check with the official DITA Open Toolkit project page for definitive, up-to-the-minute
information.
Resources
FILE TYPES FINAL FILE LOCATIONS IN FRAMEMAKER INSTALLATION FOLDER
Core plug-ins fminit\openToolkit.dll
Files for use with the
DITA Open Toolkit
fminit\ditafm\ (Ant-related files with .xml extensions: these should be copied
to your DITA-OT folder if you are using the DITA Open Toolkit)
http://sourceforge.net/projects/dita-ot/ The DITA Open Toolkit project site
www.oasis-open.org/committees/dita DITA technical committee at OASIS
http://docs.oasis-open.org/dita/ Core DITA documentation DITA
http://ant.apache.org/ Apache Ant project site
http://ant.apache.org/resources.html Apache Ant resources
http://groups.yahoo.com/group/dita-users/ DITA users Yahoo group
http://groups.yahoo.com/group/framemaker-dita FrameMaker DITA Yahoo group
