ADT ATD-80102 User manual


 
ATD‐80102
MiniSaberLight
Owner’sManual

FeaturesAndSpecifications:
•18PremiumWhiteLEDbulbsprovide300Luxbrightness!
•Platedreflectorfocuseslightintensityonworkarea
•Testedtough‐NootherLEDlightistougher!
•Leaveitpluggedin‐Automaticoverchargeprotection
•2‐3hoursruntime
•Autodischargeshut‐offfunctionprolongsbatterylife
•Red&greenchargeindicatorlights
•3.6V,600mAhbattery
•Triplehexdesignpreventsrolling
•IncludesA/Cwallcharger&beltmountholster
•Worksbetterthanaflashlightforunderthedashortightareasoftheenginecompartment

Charginginstructions
Batteryisonly50%chargedbeforeshipment.Fullychargeunitfor3‐4hoursbeforeusebypluggingACadapterintoanyACpower
supplyandpluggingtheotherendintothechargingportlocatedonthebaseoftheunit.Unithasoverchargeprotection,plugitin
andleaveit.UnitisfullychargedwhengreenLEDison.

ToChangeLEDBoard:
•Removetopcap(1)andhandle(6).Youmayneedasmall,flatbladedscrewdriverorsimilartooltobreakthedotofglueloosebeforeremoving.
•UnscrewtwoPhillipsheadscrewsoneitherendofunit.
•PullLenshalves(2)&(3)aparttoexposetheLEDboard,batteryandothercomponents.
•Unscrewthereflectorboard(4)fromthebackoftheLEDboardandsavethereflectorboardandscrewsforre‐assembly.
•Unsolderthewiresatthebottomoftheboardnearthebatteryasshowninfig2.Besuretolabelthesewiresforre‐installation.
•SolderthewiresbackontothenewLEDboardinthesamewaytheycameoffoftheoldboard.
•Re‐assembleunitinreverseorderofhowyoudisassembledit.










Figure1Figure2

Cautions
•DoNOTservicethislightwhileitispluggedin.Itmaycauseelectricalshock
•DoNOTsubmergeinwater.–Itmaycauseelectricalshockand/orfires.Toclean,wipewithdampclothonly,donotusesolvents,andcleanonly
whentheunitisunpluggedfrompowersource.
•DoNOTusethislampinexplosiveatmosphere‐Nearflammableliquidsorwhereexplosionprooflampsarerequired.
•Thewarnings,cautions,andinstructionsdiscussedinthisinstructionmanualcannotcoverallpossibleconditionsandsituationsthatmayoccur.It
mustbeunderstoodbytheoperatorthatcommonsenseandcautionarefactorswhichcannotbebuiltintothisproduct,butmustbesuppliedby
theoperator.


MadeinChinatoATDTools,Inc.Specifications















