ADT 927 User manual

P/N 90927-SPPM-000-00
Dec 2018
ADT Model 927 Water
Recycling System
Preventing maintenance manual

Advanced Dicing Technologies Ltd.
ii
Advanced Dicing Technologies Ltd. —www.adt-dicing.com
5 Hamada St., Hi-Tech Park (South), P.O.Box 87, Yokneam 20692, Israel
Tel.: [phone], Fax: [phone]
Confidential
This information is the property of ADT Ltd.
Any reproduction, publication or distribution to a third party is strictly forbidden, unless written
permission is given by an authorized agent of Advanced Dicing Technologies Ltd.

ADT Model 927 Water Recycling System
Safety First
P/N 90927-SPPM-000-00
iii
SAFETY FIRST
ADT believes that the safety of personnel working with and around our
systems is the most important consideration. Read the safety information
before operating the System or perform any maintenance function.
Warnings
Obey and follow all warnings and cautions given in this manual.
Comply with all approved and established precautions for operating
electrical equipment.
Only qualified and authorized personnel should perform maintenance
or repair tasks.
Verify the power, air and water facilities are turned off before
beginning any maintenance procedure, part replacement, or repairs.
Danger: Electrical Shock Hazard. High voltage ispresent at points throughout the
System. Contact with high voltagecan result in injury or death. Before openinganycover,
make sure that there is no voltagepresent byswitching off the Circuit Breaker. Switching off
the Main Power Switch does not cut off power to the system.When performing maintenance,
disconnect the mainspower plug from the wall outlet.
Danger: High PressureWater and Air Hazards.Observe standard operating
procedures toavoid contact with High Pressure Air andWater, whichcan present hazards,
especiallyto eyes.
Danger: Bodily Injury Hazard. Becareful not to drop anyof the system parts. Dropping
certainparts mightcause bodily injuryor damage to the parts.
Safety Features
The ADT Model 927 Water Recycling System is equipped with the
following safety features. Look at them and get to know them.
EMERGENCY STOP BUTTON: Pressing the red EMERGENCY STOP BUTTON
stops ALL activities in the System. The Emergency Stop Button is
located on the system front panel.
CIRCUIT BREAKER SWITCH: switching down the CIRCUIT BREAKER SWITCH
immediately cuts off power to the System. The Circuit Breaker Switch
is located on the system right side.
FRONT LOWER COVER SAFETY SWITCH: when opening the Front Lower
Cover, the FRONT LOWER COVER SAFETY SWITCH puts the system in a
Standby mode. The Front Lower Cover Safety Switch is located behind
the lower front door, on the upper left corner.
COVERS LOCK: all of the system COVERS (except the front main door)
require a metric Allen wrench for opening and removing the cover.

Table of Contents
Advanced Dicing Technologies Ltd.
iv
TABLE OF CONTENTS
1. Overview _____________________________________________1
2. SPPM kit parts list received ______________________________2
3. Preventing maintenance procedure _______________________3
3.1 Water tanks cleaning______________________________________________ 3
3.2 Cleaning the pre-filter _____________________________________________ 5
3.3 Replacing the slurry bag filter ______________________________________ 6
3.4 Replacing the filter modules________________________________________ 7
3.5 Cleaning the Air Regulator Filter ___________________________________ 10
3.6 Setup the machine _______________________________________________ 10
3.6.1 Powering OFF__________________________________________________ 11
4. Preparing the System __________________________________12
4.1 Inspecting Valves Orientation______________________________________ 12
4.2 Filling the Bottom Water Tank _____________________________________ 13
4.3 Bleeding Air from Pumps _________________________________________ 13
4.4 Checking for Water Leaks_________________________________________ 13
4.5 Operating parameters ____________________________________________ 13

ADT Model 927 Water Recycling System
P/N 90927-SPPM-000-00
v
LIST OF FIGURES
Figure 3-1. Clean water tanks ________________________________________________ 3
Figure 3-2. Clean water level sensors __________________________________________ 4
Figure 3-3. Water level sensors screen_________________________________________ 4
Figure 3-4. Pre-filter (F1) ____________________________________________________ 5
Figure 3-5. Pre-filter element_________________________________________________ 5
Figure 3-6. Slurry bag-filter (F2)_______________________________________________ 6
Figure 3-7. Bag-filter _______________________________________________________ 7
Figure 3-8. Filter locker _____________________________________________________ 7
Figure 3-9. Filter holding ring_________________________________________________ 8
Figure 3-10. Filter top cover (and removed) _____________________________________ 8
Figure 3-11. Tube with O-rings _______________________________________________ 9
Figure 3-12. Filter element-extracting tool _______________________________________ 9
Figure 3-13. Main circuit breaker_____________________________________________ 10
Figure 3-14. Standby screen ________________________________________________ 11
Figure 4-1. Pump air bleed screw ____________________________________________ 13

List of Tables
Advanced Dicing Technologies Ltd.
vi
LIST OF TABLES
Table 2-1. Parts and Accessories _____________________________________________ 2

ADT Model 927 Water Recycling System
P/N 90927-SPPM-000-00
i
1. OVERVIEW
The ADT Model 927 Water Recycling System provides a closed-loop
uniform supply of water, which is used for dicing machines.
The system recycles the saw drain water through a number of filters, cools
the water to a set temperature, and delivers a steady flow of water to the
dicing machine.
The 927 preventing maintenance procedure is recommended to be
performed every 6 months under regular conditions. The preventing
maintenance procedure is done in addition to the maintenance tasks that
are performed routinely on a periodic basis, and maintenance performed
because of warnings displayed by the PLC. For further information regard
routinely maintenance, see 927 full operation and maintenance manual at
section 6.

ADT Model 927 Water Recycling System
P/N 90927-SPPM-000-00
ii
2. SPPM KIT PARTS LIST RECEIVED
The 927 SPPM kit is supplied with the following items and parts:
Table 2-1. Parts and Accessories
#
Part Description
ADT Part Number
Qty
1
Membrane - Ultra Filtration Elements
23100-0017-001
2
2
Membrane Connectors + O-rings
23100-0017-003
2
3
Membrane Pressure Housing O-ring
23100-0017-004
4
4
Big Blue O-Ring
23100-0020-011
1
5
O-RING ID=13/16" OD=3.34" W=3/16"
BUNA-N
61400-0002-012
4
6
927 Prevent maintenance manual
90927-SPPM-000-00
1

ADT Model 927 Water Recycling System
P/N 90927-SPPM-000-00
iii
3. PREVENTING MAINTENANCE PROCEDURE
Caution: Cleaning and replacing the water filters may cause water to spill on the
system and on the floor. Place cloths or other absorbent material under the
cleaned/replaced filter to absorb the water.
Note: Cleaning and replacing the filters requires putting the system in standby
mode or powering down.
3.1 Water tanks cleaning
After working with the System for a long period, dicing debris
accumulates in the sediment water tank.
To empty the water tank:
Power down the System.
Remove the rear lower cover.
Put a bucket or a vacuum cleaner near the sediment water tank cork,
and open the cork.
Do the same for the supply water tank.
Use a piece of cleaning cloth or cleaning paper towel to remove all
sediments of sediment water tank. Clean the inside of the tank. In
addition clean the water level sensors.
Do the same for supply water tank.
Figure 3-1. Clean water tanks

ADT Model 927 Water Recycling System
P/N 90927-SPPM-000-00
iv
Figure 3-2. Clean water level sensors
After water tanks cleaned, check all water level sensors function well,
check at water level sensors screen at setup screens. See 927 full
manual at section 4.7.1
Figure 3-3. Water level sensors screen

ADT Model 927 Water Recycling System
P/N 90927-SPPM-000-00
v
3.2 Cleaning the pre-filter
Remove the System bottom side cover.
Figure 3-4. Pre-filter (F1)
Place a bucket/pail under the filter drain valve.
Open the filter drain valve, and let the water drain into the
bucket/pail.
Rotate the filter body in a counter-clockwise direction, and remove it.
Figure 3-5. Pre-filter element
Remove the filter element and clean it or replace it.
Inspect the filter element and filter body O-rings.
If they are damaged or dry–replace them.
Insert the filter element back into the filter body, pushing it all the
way in.
Re-assemble the filter body to the filter base.
Rotate the filter drain valve to its closed orientation.
Filter drain
valve
Filter body
Filter element

ADT Model 927 Water Recycling System
P/N 90927-SPPM-000-00
vi
3.3 Replacing the slurry bag filter
Open the lower front and side covers.
Connect an elbow fitting for a 12 mm tube to the filter drain.
Figure 3-6. Slurry bag-filter (F2)
Connect a drain tube from the filter to an external drain.
Open the filter drain valve, and let the water drain out.
Use the supplied filter opening tool to remove the filter body, in a
counter-clockwise direction.
Remove the dirty bag-filter, and clean it or replace it.
Filter body
Filter drain
valve
Filter drain
Filter opening
tool

ADT Model 927 Water Recycling System
P/N 90927-SPPM-000-00
vii
Figure 3-7. Bag-filter
Inspect the filter O-rings.
If they are damaged or dry–replace them.
If not–apply some grease or other lubricant to ensure good sealing.
Insert the bag-filter into the filter body.
Re-assemble the filter body to the filter base.
Rotate the filter drain valve to its closed orientation.
3.4 Replacing the filter modules
Disconnect the light-tower cable.
Open the 12 screws connecting the System top cover, and remove it.
Perform the following procedure on both filter modules.
To remove the filter element:
Open the screw connecting the yellow locker, and remove the locker.
Figure 3-8. Filter locker
Open and release the pipes connected to the filters.
Using a large flathead screwdriver, remove the white holding ring.

ADT Model 927 Water Recycling System
P/N 90927-SPPM-000-00
viii
Figure 3-9. Filter holding ring
Pull off the filter top cover (wiggling upwards motion).
Figure 3-10. Filter top cover (and removed)
Filter cover
White tube
with O-rings

ADT Model 927 Water Recycling System
P/N 90927-SPPM-000-00
ix
Note: For the next action it is recommended your hand are dry (not slippery),
or use a piece of cloth or paper.
Pull out the white tube with O-rings.
Figure 3-11. Tube with O-rings
Push the provided filter element-extracting tool into the filter
element, and close its nut until the tool catches the filter element.
Figure 3-12. Filter element-extracting tool
Pull the filter element up an out.
Release the tool from the filter element by releasing its nut.
Remove the while tube with O-rings from the bottom of the filter
element.
To close the filter:
Inspect the O-rings of the white tube and of the filter body.
Tool nut

ADT Model 927 Water Recycling System
P/N 90927-SPPM-000-00
x
If any are damaged or dry–replace.
If not–apply some grease or other lubricant to ensure good sealing.
Attach the white tube with O-rings to the replaced filter element.
Insert the replaced filter element into the filter body.
Insert the second white tube with O-rings into the replaced filter
element top opening.
Place the filter cover, and push down.
Re-assemble the white holding ring.
Rotate the holding ring to an angle the yellow locker can be connected
to the filter cover.
Re-connect the yellow locker to the filter.
3.5 Cleaning the Air Regulator Filter
Inspect the air filter, if it is dirty or filled with water, empty it and clean
it.
3.6 Setup the machine
Before powering on, verify that the EMO button is not pushed in.
To power-on the system:
Toggle the main circuit breaker to the ON position.
Figure 3-13. Main circuit breaker
a. The system goes through an initialization process, of 5 seconds,
and displays the Standby screen.

ADT Model 927 Water Recycling System
P/N 90927-SPPM-000-00
xi
Figure 3-14. Standby screen
Note: The front lower door has a sensor. When the door is open, the System
goes into standby mode.
3.6.1 Powering OFF
Powering OFF is performed when the system is not in use, or before
performing maintenance and service procedures.
Note: This should be done only after stopping the dicer cutting process.
To power down the system:
Press the Run/Standby button to go into Standby mode.
Toggle the system Main Circuit Breaker to its OFF position.

ADT Model 927 Water Recycling System
P/N 90927-SPPM-000-00
xii
4. PREPARING THE SYSTEM
The 927 Water Recycling System is used for recycling the dicing saw
cutting water. Therefore, preparing the System requires connecting the
927 System to a dicing saw.
Preparing and setting the system includes the following actions:
Inspecting the valves orientation (section 4.1)
Filling the water tank with fresh water (section 4.2)
Bleeding air from the pumps (section 4.3)
Checking to ensure there are no water leaks (section 4.4)
Placing the System (section Error! Reference source not found.)
4.1 Inspecting Valves Orientation
Before operating the System, verify the manual (orange) valves are in the
required orientation.
Remove the upper and lower front covers on both sides of the System.
Verify the valves are oriented as follows:
Pump 1(P1):
In: open
Out: open
Pump 2(P2):
In: open
Out: open
Pump 3(P3):
In: open
Out: open
Filter 1(F1) (pre-filter):
In: open
Out: open
Manual drain: closed
Filter 2(F2) (slurry bag-filter):
In: open
To sink tank: open
To external drain: closed

ADT Model 927 Water Recycling System
P/N 90927-SPPM-000-00
xiii
4.2 Filling the Bottom Water Tank
Open the valve for the Water Fill. The bottom tank starts filling, until the
water level reaches the second level-sensor.
4.3 Bleeding Air from Pumps
The pumps have trapped air which needs to be removed from the pump.
This is done by operating the system and opening the bleed screw until
the air is removed.
Caution: Thebleeding air from pumps procedure may cause some water spillage.
Place cloths or other absorbent material under the pump to absorb the water.
To bleed air from the pumps:
Power on the System.
Open the bleed screw of pump P1, just until water start coming out.
Figure 4-1. Pump air bleed screw
Close and tighten the screw.
Repeat the air bleeding procedure for supply pump P3.
4.4 Checking for Water Leaks
Press the Run button, and visually inspect to ensure there are no water
leaks. Carefully inspect all pipe connections and valves.
4.5 Operating parameters
After preventing maintenance procedure is finished and machine is setup
and running, make sure that the following parameters values are in the
correct range:
Filtration flow rate = 25 LPM (Liter per minute)
Filtration pressure = 0.81.3 Bar
Supply flow rate = 520 LPM
Backwash flow rate = 25 (or above) LPM
Bleed screw
