ADTRAN NetVanta ActivReach User manual

Quick Start Guide, 61702595F17-13A, March 2015 Support - Phone: [phone], Email: [e-mail] Copyright © 2015 ADTRAN, Inc. All Rights Reserved.
NetVanta ActivReach Wall Plate Media Converter P/N 1702595F17
SPECIFICATIONS
Conversion 1-pair or 4-pair ActivReach Ethernet to standard
10/100Base-T
Compliance EN 60950-1, IEC 60950-1, AS/NZS 60950-1, UL/CUL 60950-1
FCC Part 15 Class B, EN 300 386, ICES 003 Class B
RoHS compliant
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) This device may not cause harmful interference. 2) This
device must accept any interference received, including
interference that may cause undesired operation.
Physical Dimensions: 3.50-inch W x 2.00-inch H x 1.12-inch D
Operating Temperature: 0°C to 40°C
Storage Temperature: -20°C to 70°C
Relative Humidity: Up to 95 percent, noncondensing
• The NetVanta ActivReach Wall Plate Media
Converter is intended for intrabuilding use only.
• Ensure that the Wall Plate Media Converter wiring
is installed in accordance with all national, state,
and local electrical codes.
• The Wall Plate Media Converter is intended for use
only in low-voltage, communication-level junction
boxes only. It must not be used in a junction box
containing AC power.
• PoE cables are intended for intrabuilding use only.
Connecting an ADTRAN PoE unit directly to PoE
cables that run outside the building in which the unit
is housed will void the user's warranty and could
create a fire or shock hazard.
• Ethernet cables are intended for intrabuilding use
only. Connecting an ADTRAN unit directly to
Ethernet cables that run outside the building in
which the unit is housed will void the user's
warranty and could create a fire or shock hazard.
ACTIVREACH PIN CONNECTIONS
DESCRIPTION
The NetVanta ActivReach Wall Plate Media Converter is designed to be
mounted to data junction boxes in a building’s existing infrastructure. It converts
ADTRAN’s ActivReach Ethernet to standard 10/100Base-T over varying cable
types and cable distances well beyond the standard Ethernet limitation of
100 meters. The NetVanta ActivReach Wall Plate Media Converter has no input
power supply, rather it draws power from an upstream ActivReach Ethernet
Switch (NetVanta 1535P, P/N 1702595G10 or NetVanta 1235P,
P/N 1700595G10). The optional Access Point (AP) Mounting Kit for NetVanta
ActivReach Wall Plate Media Converter (P/N 1702595F21) can be used to easily
mount an AP directly to the Media Converter. Refer to the quick start guide that
ships with the AP mounting kit for mounting instructions.
The NetVanta ActivReach Wall Plate Media Converter can be used in the
following configurations: 1-pair ActivReach over legacy copper/Cat 3/5/6 cable
and 4-pair ActivReach over Cat 3/5/6 cable. There is also an optional voice
passthrough configuration that will allow a legacy POTS line to pass through the
unit. For a description of ActivReach pin connections, see the ActivReach Pin
Connections illustrations below. For instructions on installing the Media
Converter for each configuration, refer to the Installation Instructions for
ActivReach Ethernet on page 2.
• The NetVanta ActivReach Wall Plate Media Converter has
only one mode. It always provides PoE to the downstream
device. Caution must be taken when connecting the Wall
Plate Media Converter. It should not be used with a
downstream device that does not support PoE.
• The NetVanta ActivReach Wall Plate Media Converter
intended for use only with the NetVanta 1535P
(P/N 1702595G10) and the NetVanta 1235P
(P/N 1700595G10) ActivReach Ethernet Switches.
AB
C
D
POTS
34567812
1-pair ActivReach
connect pair A only.
Optional Voice Passthrough
connect pins 3 and 4.
4-pair ActivReach
connect pairs A, B, C, D.
RJ-45
345612
RJ-11

Quick Start Guide, 61702595F17-13A, March 2015 Support - Phone: [phone], Email: [e-mail] Copyright © 2015 ADTRAN, Inc. All Rights Reserved.
QUICK START
NetVanta ActivReach Wall Plate Media Converter P/N 1702595F17
INSTALLATION INSTRUCTIONS FOR ACTIVREACH ETHERNET
1. Ensure that the NetVanta 1235P/1535P lines and any voice/POTS lines
are disconnected from the source prior to configuring and installing any
jacks inside the junction box.
2. Configure the network cable on both the Media Converter end and the
NetVanta 1235P/1535P end in accordance with your installation
requirements for 1-pair or 4-pair operation as illustrated in ActivReach
Pin Connections on page 1. Make sure both ends of the network cable
are configured in the same manner.
3. Plug the RJ-45 connector of the configured cable into one of the
network ports of the NetVanta 1235P/1535P.
4. Plug the configured junction box cable into the RJ-45 connector labeled
To Network on the back of the Media Converter. After a few minutes,
the Media Converter power LED will light.
5. Mount the Media Converter to junction box using the screws provided
(see the illustration on the first page).
6. Insert a 10/100 Ethernet cable into the RJ-45 connector on the front
panel of the Media Converter labeled To Device.
7. Insert the other end of the Ethernet cable into the downstream device.
INSTALLATION INSTRUCTIONS FOR ACTIVREACH ETHERNET
AND OPTIONAL VOICE PASSTHROUGH
1. Ensure that the NetVanta 1235P/1535P lines and any voice/POTS lines
are disconnected from the source prior to configuring and installing any
jacks inside the junction box.
2. Configure the network cable on both the Media Converter end and the
NetVanta 1235P/1535P end in accordance with your installation
requirements 1-pair ActivReach and optional voice passthrough as
illustrated in ActivReach Pin Connections on page 1. Make sure both
ends of the network cable are configured in the same manner.
3. Plug the RJ-45 connector of the configured cable into one of the
network ports of the NetVanta 1235P/1535P.
4. Plug the RJ-11 connector of the configured cable into an RJ-11
connector on the PBX.
5. On the Media Converter end, plug the configured cable’s RJ-45
connector into the connector on the Media Converter labeled To
Network and the RJ-11 connector in to the connector labeled POTS on
the back of the Media Converter. After a few minutes, the Media
Converter power LED will light.
6. Mount the Media Converter to junction box using the screws provided
(see the illustration on the first page).
7. Insert a 10/100 Ethernet cable into an appropriate connector on the
front panel of the Media Converter labeled To Device.
8. Insert the other end of the Ethernet cable into the downstream device.
9. Insert a phone cable into the RJ-11 connector on the bottom of the
Media Converter.
10. Insert the other end of the phone cable into the downstream POTS
phone.
NetVanta 1535P
25 26 27 28
VCID
PoE
LINK/ACT
EPS
RPS
STAT
12 34 56 78 91011 12 13 14 15 16 17 18 19 20 21 22 23 24
ActivReach
10/100Base-T
Downstream
PoE
Device
POTS
POTS
Phone
NetVanta 1535P
PBX Phone System
ActivReach
RJ-45
RJ-11
RJ-45
RJ-11
Wall
Plate
MC
Optional Voice Passthrough
