Advanced Bionics CI-5551 User manual

M Batteries and M Charger
CI-5551, CI-5552, CI-5553, CI-5555, CI-5607
(Small, Medium, Large, Standard, Charger)
instructions for use
English, Français, Español

1
SYMBOLS TABLE
Labeling symbols and their meanings
Date of Manufacture
Manufacturer
Model number
LOT number
Unique Device Identifier
Type of Protection: BF
Suitable temperature range for transport
and storage
See Instructions for Use
Fragile
Do not get wet
Suitable relative humidity range for transport
and storage
XXXX-XX-XX

2
Caution (refer to “Cautions & Warnings”
section for further information)
Dispose of in accordance with applicable
national and local regulations
MR Unsafe
Limitations and Contraindications
There are no known limitations or contraindications for the
M Batteries or M Battery Charger.
Precautions, Cautions, and Warnings
• This device should be used only by the individual for
whom it is prescribed.
• It is recommended that you charge the M Batteries
fully prior to first use, as M Batteries shipped from
Advanced Bionics are not fully charged.
• The M Battery Charger comes with a power supply de-
signed for the specifications of the M Battery Charger.
Do not use any other power supply unless it is sup-
plied by Advanced Bionics. If needed, call Advanced
Bionics for a power supply replacement.
• The M Battery Charger and power supply should be
operated in an open area to ensure adequate airflow.
While no injury cases have resulted, components may
become hot during normal use or a fault condition.
If the device’s temperature results in discomfort or
pain when touched, disconnect the power source and

3
contact your cochlear implant professional.
• CHOKING HAZARD: Contains small parts that pose
a hazard of inhalation, choking, or ingestion. If any
parts are swallowed or inhaled, consult a physician or
hospital immediately.
• Do not leave children unattended with or allow children
to play with the M Battery Charger or M Battery.
• Do not allow children to place the M Battery Charger or
M Battery in the mouth.
• Remove your sound processor and consult your coch-
lear implant professional if uncomfortable sounds are
heard or in case of discomfort, pain or skin irritation.
• Do not dispose of M Batteries in fire, as they may
explode.
• To prevent injury or burns, do not allow metal objects,
such as keys or coins, to contact or short circuit the
battery terminals. M Batteries may present risk of fire
or chemical burn if mistreated. Do not disassemble.
Do not heat above 100˚C/212˚F or incinerate.
• Remove M Batteries from your sound processor when
they are discharged to prevent damage from possible
leaking.
• If an M Battery shows visible signs of leakage, dispose
of it in accordance with local regulations, as detailed in
the “Disposal” section of this document.
• Do not allow leaking battery fluid to come into contact
with skin, mouth, or eyes.

4
• Do not expose M Batteries to heat (e.g., do not store in
direct sunlight or in a hot car).
• Carry M Batteries in the carrying case provided or in
a sealed plastic bag. M Batteries can short circuit if
they come into contact with metallic objects such as
coins or keys.
• Do not immerse the M Batteries or M Battery Charger
directly in water.
• High levels of static electricity may damage electronic
components of your sound processor or implant. Care
should be taken to avoid exposure of the system to
static electricity.
• Only charge M Batteries using the charger(s) recom-
mended by the manufacturer.
• Do not recharge disposable batteries.
• Although electromagnetic emissions of the M Battery
Charger has been confirmed within safe limits, some
other devices could be sensitive to such emissions. If
you notice other devices do not behave as expected
when your M Battery Charger is nearby, separate the
devices.
• In the event that you experience any issues with your
product, please contact your cochlear implant profes-
sional or the manufacturer. Do not attempt to service
or modify the Naída CI M, Sky CI M, or its accessories.
Doing so may compromise system performance and
will void the manufacturer’s warranty. Products should
be serviced only at Advanced Bionics and damaged
products should be returned to Advanced Bionics.

5
Undesirable Side Effects
Undesirable side eects of your Naída CI M or Sky CI M
system may include skin irritation and discomfort from
pressure on the ear, device overheating, or overly loud
sounds.
Product Description and Performance
Characteristics
The M Batteries are Lithium Ion rechargeable batteries.
There are four M Batteries: Small, Medium, Large, and
Standard.
The M Battery Charger contains three M Battery charging
bays. The charging system consists of the charger and
micro USB power supply cable. The wall adapter is
shipped separately from Advanced Bionics.
Small StandardLargeMedium

6
charging bay
Light Emitting
Diode (LED)
indicators
Battery Capacity
Product Battery caPacity (mah)
M Battery Small 90
M Battery Medium 150
M Battery Large 220
M Battery Standard 170
Charger Information
rated dc inPut Voltage rated dc inPut current
5V 500mA

7
Intended Use
M Batteries are intended to power the Advanced Bionics
Naída CI M and Sky CI M Sound Processors. The M Bat-
tery Charger is intended to recharge only the M Batteries.
Placing a charged M Battery on the sound processor will
power on the sound processor. Removing the M Battery
will power o the sound processor.
The intended users of the M Batteries and M Battery
Charger are users of the Naída CI M or Sky CI M Sound
Processors. The intended use environments of the M
Batteries and M Battery Charger are healthcare and daily
living environments.
Compatibility
Naída CI M Batteries are compatible with Naída CI M and
Sky CI M Sound Processors from Advanced Bionics. The
M Battery Charger is compatible with only M Batteries.
Operating Instructions
General Charging Information for M Batteries
• The M Battery Charger provided with the sound
processor is designed to recharge up to three M
Batteries simultaneously. Using the supplied power
adapter, it takes approximately 3 to 4 hours to fully
recharge a depleted M Battery. If the M Battery is
stored for prolonged periods of time, it may take ap-
proximately 5 to 6 hours to fully recharge the battery.
This will vary slightly for different M Battery types.
• M Batteries do not need to be fully depleted before
charging. A partially charged M Battery may be fully

8
charged in a shorter time period.
• You can remove the M Battery from the charger at
any time.
• You will not damage the M Batteries if they remain
on the charger longer than the required charging
time or overnight.
• It is recommended to use and recharge the M Batter-
ies at least once every 3 months. Please note that M
Batteries will decrease in capacity with age, even if
not in use. This is normal behavior for all rechargea-
ble batteries and should not be considered a defect.
Setting up the charger
To use the M Battery Charger with a wall outlet for
charging:
Place the M Battery Charger on a flat surface.
Connect the micro USB end of the power supply cable
into the charger.
Connect the power supply cable to the USB wall adapter.
Plug the wall adapter into the wall outlet.
To use the M Battery Charger with a USB port for
charging:
Place the M Battery Charger on a flat surface.
Connect the micro USB end of the power supply cable
into the M Battery Charger.

9
Insert the USB jack into a USB port (on a computer, in a
car, etc.).
Understanding M Battery Charger LED (light-emitting
diode) indicators
The M Battery Charger has dierent indicator lights that
are located at the base of each charging port, as well as
where the power cable enters the charger. If the light near
the power jack is lit and green in color, it means the charg-
er is connected to a power source and ready to charge
the M Batteries. If the light near the power jack is lit and
red in color, this indicates a fault condition.*
The LEDs located at the base of each charging port have
3 color options:
• Blue: M Battery is charging.
• Green: M Battery is fully charged.
• Red: Fault condition.*
*Try to reinsert the power cable or M Battery. If the red
LED illuminates again, contact your cochlear implant
professional.
The charger has an automatic dimmer. The brightness
of the LEDs may vary depending on the brightness of the
room in which the charger is placed.
Inserting the M Batteries into the charger
Locate the slide tracks on the charger. Position the M
Battery so that the battery contact is facing down toward

10
the base of the charger and aligned with the tracks on the
charger.
Slide the M Battery along the tracks until it engages.
The charger is designed so the M Batteries can only be
inserted in one direction.
Removing the M Batteries from the charger
Gently slide the M Battery out of the slide tracks of the
charger, toward the front edge of the charger. Do not pull
directly up on the battery.

11
Using the M Batteries with the Naída CI M and Sky CI
M Sound Processors
Putting the M Batteries on the sound processor
Hold the sound processor in one hand. Rotate headpiece
cable upward in order to avoid bumping it upon battery
placement.
Align the M Battery connector with the sound processor
housing side of the connector.

12
Slide the M battery onto the sound processor until it clicks
into place. The sound processor will be powered on as
soon as a charged M Battery is fully attached.
NOTE: Do not force the M Battery onto the sound proces-
sor. The M Battery is designed to be inserted in only one
direction; applying force may damage the equipment.
Removing the M Batteries from the sound processor
Rotate headpiece cable upward in order to avoid bumping
it upon M Battery removal.
Hold the sound processor in one hand. In the other hand
hold the M Battery. Firmly slide the M Battery cartridge

13
towards the back of the sound processor, away from any
earhook accessory.
The sound processor is powered o when the M Battery
is removed.
CARE AND MAINTENANCE
Storing the M Batteries and M Battery Charger
When not in use, store M Batteries and the M Battery
Charger in the equipment case provided.
Cleaning and Maintenance
Wipe the outside of the M Batteries with a soft, dry cloth.
To prevent intermittent operation of the sound processor,
the battery contacts on the M Battery Charger, M Battery,
and on the sound processor should be kept free from dirt
and dust. Gently clean the area with a hearing aid brush
or dry cotton swab at least once a month. If the M Battery
is exposed to moisture, place the it in a drying system
before charging and before next use. If the M Battery is
dropped, inspect it for evidence of damage or cracking.

14
If any evidence of damage is seen, the M Battery should
be replaced.
Recommended Operating and Storage Temperature
Ranges
condition minimum maximum
Operating Temperature 0˚C (32˚F) 45˚C (115˚F)
Storage Temperature -20˚C (-13˚F) 55˚C (131˚F)
Relative Humidity 0% 95%
Ingress Protection (IP) Ratings
The following product configurations have an IP rating of
54 (protection against dust; protection against failure due
to water splashes from all directions):
• The Naída™ CI M90 sound processor with an M
Battery or M Zn-Air Battery Pak, an M T-Mic™ micro-
phone or M Acoustic Earhook, and a Slim HP, Slim
HP Mic, or Slim HP Standard.
The following product configuration has an IP rating of 57
(protection against dust; protection against failure due
to one-time immersion for 30 minutes to a depth up to 1
meter and after drying overnight in a drying system):
• The Naída CI M90 sound processor with an M Bat-
tery, an M Earhook, and a Slim HP, Slim HP Mic, or
Slim HP Standard.

15
DISPOSAL AND HAZARDOUS MATERIALS:
For proper disposal of rechargeable batteries in Europe,
please return depleted M Batteries to the nearest AB
location or the designated programming/follow-up center.
Hazardous materials: not applicable to this product.
In the United States and Canada, please call the
Rechargeable Battery Recycling Corporation hotline at
877.273.2925 or visit their website at www.call2recycle.
org.
AVAILABLE PRODUCT OPTIONS AND MODEL
NUMBERS:
M Battery Charger
Product oPtion model numBer
M Battery Charger CI-5607
M Battery Small
Product oPtion model numBer
Sand Beige CI-5551-120
Chestnut CI-5551-130
Silver Grey CI-5551-140
Velvet Black CI-5551-150

16
Product oPtion model numBer
Alpine White CI-5551-110
Lava Red CI-5551-280
Blue Ocean CI-5551-260
Majesty Purple CI-5551-270
Caribbean Pirate CI-5551-190
Precious Pink CI-5551-250
Resin Beige CI-5551-240
M Battery Medium
Product oPtion model numBer
Sand Beige CI-5552-120
Chestnut CI-5552-130
Silver Grey CI-5552-140
Velvet Black CI-5552-150
Alpine White CI-5552-110
Lava Red CI-5552-280
Blue Ocean CI-5552-260

17
Product oPtion model numBer
Majesty Purple CI-5552-270
Caribbean Pirate CI-5552-190
Precious Pink CI-5552-250
Resin Beige CI-5552-240
M Battery Large
Product oPtion model numBer
Sand Beige CI-5553-120
Chestnut CI-5553-130
Silver Grey CI-5553-140
Velvet Black CI-5553-150
Alpine White CI-5553-110
Lava Red CI-5553-280
Blue Ocean CI-5553-260
Majesty Purple CI-5553-270
Caribbean Pirate CI-5553-190
Precious Pink CI-5553-250

18
Product oPtion model numBer
Resin Beige CI-5553-240
M Battery Standard
Product oPtion model numBer
Sand Beige CI-5555-120
Chestnut CI-5555-130
Silver Grey CI-5555-140
Velvet Black CI-5555-150
Resin Beige CI-5555-240
CLINICAL BENEFITS:
The M Batteries and the M Battery Charger provide no
clinical benefit; these products are intended to be used
with the Naída CI M and Sky CI M sound processors.
www.advancedbionics.com/clinicalandsafetyper-
formance/
Users of the M Batteries and M Battery Charger in the
European Union should report any serious incident
to their local competent authority.
