CHAPTER 1 INTRODUCTION
1.1 Key features
¾Support four 3.5” SAS and/or SATA II hard disk drives (HDD) on 3 ODD Bays space.
¾Enclosure management controller chip on board
¾SFF8448 compliance SGPIO interface Support through one SFF8087 mini SAS 4i
connector
¾Support direct HDD Activity/Fault LEDs signal input
¾Support HDD Activity LEDs directly from SAS/SATA II HDD
¾Support buzzer alarm
¾Support buzzer-mute button
¾Support Power on, FAN fail, Over temperature LED indicator
¾Support Fan Control automatic by temperature

2
1.2 Unpacking list
Before removing the subsystem from the shipping carton, visually inspect the physical
condition of the shipping carton. Exterior damage to the shipping carton may indicate that the
contents of the carton are damaged. If any damage is found, do not remove the components；
contact the dealer where the subsystem was purchased for further instructions. Before
continuing, first unpack the subsystem and verify that the contents of the shipping carton are
all there and in good condition.
The package contains the following items：
■ One set with HDD tray x 4 (Shipping without HDD installed)
■ Mounting screws x 16
■ Jumper x 2
Note：Inspect the shipping cartons for evidence of physical damage. If a shipping carton
appears damaged, request that the carrier’s agent be present when the carton is opened.
Keep all contents and packing material for the agent’s inspection.
3
1.3 Front Panel Features
1.3.1 front view of 3 to 4 canister
nBuzzer mute oPower LED pOver Temperature LED
qFan Fail LED rDrive tray
LED indicators
LED NAME Color definition Behavior
Power LED Blue On：when system is powered on
Off：when system is powered off
Over Temperature LED Red
On：when system temperature exceeds
threshold temperature
Off：when system temperature is normal.
Fan fail LED Red On：when system detected fan abnormality
Off：when fan is normal operation
HDD Activity/Ready：
Blue color
On：when HDD is inserted and detected.
Flash：when accessing HDD
Off：when there is no HDD or no detection.
HDD Failure：
Red color
On：when HDD is detected as failure by host
Flash：RAID rebuilding
Off：when there is no HDD or normal
(only supported on HBA)

4
1.4 Rear Panel Features
1.4.1 rear view of 3 to 4 canister
nminiSAS host connector oPower input connectors
pOver-Temp Threshold ,Buzzer Setting and HDD Fail LED Input
qFan rFan connector
More details as below
MiniSAS Host Connector
A 36-pin Mini SAS connector is used for 4 SAS channels and sideband signals.
Signal Connector Pins
Rx 0+ A2
Rx 0- A3
Rx 1+ A5
Rx 1- A6
Sideband 0 A8
Sideband 1 A9
Sideband 2 A10
5
Side band 6 A11
Rx 2+ A13
Rx 2- A14
Rx 3+ A16
Rx 3- A17
Tx 0+ B2
Tx 0- B3
Tx 1+ B5
Tx 1- B6
Sideband 7 B8
Sideband 3 B9
Sideband 4 B10
Sideband 5 B11
Tx 2+ B13
Tx 2- B14
Tx 3+ B16
Tx 3- B17
SIGNAL GROUND A1,A4,A7,A12,A15,A18,
B1,B4,B7,B12,B15,B18
N/C = not connected
Power input connectors
Four-pin standard power connectors for +12V/+5V/GND
HDD Activity / Fail LED Input
(1) For some HBAs supporting HDD Fail signal output: If used, this
connector should be connected with HDD Fault signal from
HBA by external cable.
(2) For some HBAs supporting HDD Activity output: If used, this
connector should be connected with HDD Activity signal
from HBA external cable.
(3) It’s left to open, as default, when HBA doesn’t support it.

6
Fan Connectors
※A 3-pin fan connector with failure detection
※The canister also supports to be managed by IPMI interface
Pin Status Description
Open Disable External Access LED input
1,2 Close Enable External Access LED input
Open Access LED from HDD Pin P11
3,4 Close Access LED from SGPIO
Open SGPIO Bit2 is HDD Fail, Bit3 is HDD ID ex. ARECA
5,6 Close SGPIO Bit2 is HDD ID, Bit3 is HDD Fail ex. LSI
Open Disable SGPIO
7,8 Close Enable SGPIO
Pin Number Description Pin Number Description
1 GND 2 GND
3 HDD 0 Fail Input 4 HDD 0 Activity Input
5 HDD 1 Fail Input 6 HDD 1 Activity Input
7 HDD 2 Fail Input 8 HDD 2 Activity Input
9 HDD 3 Fail Input 10 HDD 3 Activity Input
Pin Number Description
1.2 Mute
3.4 45℃
5.6 50℃
Pin Number Description
1 GND
2 +12V
3 Tach
7
1.5 SGPIO and SES II Support via Sideband Signals of 36-pin mini SAS
The backplane is designed with one 36-pin mini SAS 4i connector which includes
sideband input for LED control. See Table 3 for the pin assignment of the sideband inputs.
The sideband on this product supports SGPIO (SFF8485).
SGPIO
SGPIO currently supports the behavior of HDD Activity and Fault LEDs. The
implementation of SGPIO is vender specific its SGPIO behavior. The HBA, RAID card, or
M/B has to implement SGPIO following SFF8448 pin assignment.
Please check with your HBA/RAID card/MB vendor for details.
Please check with your AIC/Xtore contact window for the latest support of HBA.
(Some HBAs do not supportActivity LED even they use SGPIO)
The pin assignment of the Sideband inputs follows SFF-8448 specifications.
Signal SGPIO
Sideband 0 SClock
Sideband 1 SLoad
Sideband 2 Ground
Sideband 3 Ground
Sideband 4 SDataOut
Sideband 5 SDataIn
Sideband 6 Controller Type
Sideband 7 Backplane Type
JP1 is used to configure the type.

8
CHAPTER 2 INSTALLATION OVERVIEW
Warning：Before you remove or install the unit, make sure the unit is not turned on or
connected to the AC power.
2.1 Removing the HDD Tray from the enclosure
1. Press the latch to the right by the thumb.
2. Pull the tray door outward by the forefinger at the same time.
3. Remove the HDD tray from the enclosure
4. Install the four mounting screws to secure the drive in the disk tray.
Bottom view of HDD tray
5. Slide the tray into a slot. Press the tray handle until the latch is closed and locks into
place.
