Advanced Industrial Computer XI2000 Series XI-316R User manual

Ethernet
Switch
Servers
XI-316R
Storage System
XI2000 Series IP-SAN iSCSI Storage System
High Performance. Low Cost. Ease of Maintenance
The XI2000 series solution is an enterprise-level IP-SAN iSCSI storage solution that provides
cost-effective, high-performance, feature rich, energy efcient (“Green”) iSCSI RAID storage
solutions for IP Storage Area Networks (IP-SANs).
XI-316R is the industry’s most advanced iSCSI storage system at entry level pricing. The core
of the XI-316R storage system is the GigaStor technology, comprising a next generation “Storage
System on a Chip” designed to accelerate iSCSI RAID, with advanced storage virtualization
rmware, and embedded IP-based management graphical user interface (GUI). XI-316R is easy
to install, congure, and maintain.
XI-316R is an integrated storage system with a choice of drives. This solution also includes
a simple management GUI with an easy “4-click” installation that greatly reduces conguration
time so IT managers can focus their valuable resources on supporting their users instead of
maintaining equipments. XI-316R storage system provides up to 10Gbps performance —
signicantly exceeding the speed of any Fibre Channel product. XI2000 high level of integration
provides a complete scalable solution at an attractive total cost of ownership (TCO).
www.xtore.com
Model 4Gbe Mo d e l 8Gbe Mo d e l 10Gbe
Bandwidth* 450MB/Sec 890MB/Sec 1160 MB/Sec
IOPs > 80,000 IOPs/sec
Applications
Disk to Disk backup
Content delivery —
Web servers,
Video streaming
Imaging
Video Surveillance
Data archiving
Content management
E-mail servers
Data Base Applications
Online Transactional
Processing (OLTP)
Any High-Speed SAN Storage
• QuickInstallationwithFlexibleConguration
• InvestmentProtectionwithScalableCapacity
• “EaseofUse”LowersITOverhead
• AcceleratesApplications
Enabling Your Server and Storage Solutions
Key Features
Adaptive and Persistent
Cache Management
• Write Back, Write Through,
Write Coalescing, and
Read Ahead
Volume Virtualization
• Online Capacity Expansion
• RAID Level Migration
• Free Space Reclamation
• Auto Rebuild
• Micro Rebuilds
iSCSI Performance
• Jumbo Frames Support
• Full TCP/IP Hardware
Off-load Engine (TOE)
Standards Based Platform
• iSNS Discovery Support
• Microsoft VDS Support
• CHAP Authentication
Security Support
• Enclosure Management
Services Ready

*Performance depends on conguration of different devices and are shown here for a reference
Common Technical Specifications
© 2008 Xtore Extreme Storage. All rights reserved worldwide. Xtore Extreme Storage is a registered trademark and the Xtore Extreme Storage
logo is a trademark of Xtore Extreme Storage. All other product or company names are the property of their respective owners. 06/2008
PUB-00044-A
iSCSI Network Interface XI-316R-ISN-04A XI-316R-ISN-08A XI-316R-ISN-10A
• Host Connectivity 4x 1GbE ports, RJ45 connectors
included
8x 1GbE ports, RJ45 connectors
included
1x 10GbE port, optional standard
connector for XFP Transceiver
• Connections1,024
• CHAP Authentications Yes
• Access Control of Management Yes
• iSCSI/TCP/IP Full HW Ofoad Yes
• Jumbo Frames Support Yes
Volume and RAID Support
• RAID Controller GigaStorATX 1GbE GigaStorATX 1GbE GigaStorATX 10GbE
• RAID Support RAID Levels 0, 1, 1+0, 5 and JBOD (Striped sets, mirrored sets, parity sets, striped mirrored sets, and JBOD)
• Volumes / Target Nodes 1,024 Virtual Volumes (256 available per initiator) / 1,024
• VLANs Supported Up to Eight VLANs Supported (1-to-1 mapping between IP subnet and VLAN.
Multiple VLANs per physical port with VLAN tag. — 1GbE Only: All physical ports in LAG belong to the same VLAN.)
• Online Capacity Expansion / Hot Swappable Drives Yes / Yes
• Instant Volume Access Yes
• Free Space Defragmentation Yes
• Auto-Detection Failed Drive / Auto-Rebuild / Global Spare Yes / Yes / Yes
• RAID Level Migration Yes
• Drive Roaming in Power Off Yes
• Micro Rebuilds Yes
Storage Management
• Embedded IP-Based Managment GUI Create, manage, expand, and monitor storage pool, volumes and RAID. Event manager to view and persist events.
• Firmware Field Upgradeable / Remote Upgrade Yes / Yes
OS and HBA Support
• Operating System Supported Microsoft® Windows® 2000 Advanced Server SP4 and Server SP4; Windows 2003 (x64) Enterprise Edition R2 and
Standard Edition R2; Windows 2003 (x86) Enterprise Edition R2, SP1 and Standard Edition R2, SP1; Red Hat, Red
Hat Advanced Server, SuSE Professional and Linux; Mac® OS 10.3 and 10.4; emboot winboot/1; VMware 3.5.x
• iSCSI Ethernet Host Bus Adapters Supported QLogic® QLA4010C iSCSI PCI-X; Adaptec® 7211C 1 Gb iSCSI PCI-X; ATTO iSCSI Mac Initiator - Xtend SAN; Intel®
PRO/100T IP Storage; Alacritech® iSCSI Accelerator; 3COM 00-0337-000 Rev. B; Neterion 10Gbe (10GbE Only)
• Switches Dell Power Connect 3424 24 Port 1GbE; Raptor ER 1010 24 Port 1GbE/10GbE; Fujitsu XG0801A 10GbE Optical;
D-Link DXS 3250 48 Port 1GbE 2 Port 10GbE Upllink; Extreme Summit 400-48T
Power
• Supply Type Redundant 500 watt
• Input Voltage / Input Frequency 100-240 VAC (auto-switching) / 50-60 Hz
• Input Current 8A maximum at 100 VAC and 4A maximum at 240 VAC
(maximum amps vs voltage varies linearly throughout this voltage range)
• Power Factor Correction 95%@110V, Full Load
Environmental
• Operating / Storage Temperature — English (Metric) 32º to 95º F (0º to 35º C) / -4º to 158º F (-20º to 70º C)
• Operating / Storage Humidity 20 to 90% non-condensing / 10 to 95% non-condensing
Physical
• Form Factor 3U industry-standard 19” rack
• Height x Width x Depth x Weight — English (Metric) 5.2” x 17” x 21.5” x 37 lbs full conguration (13.2 cm x 44 cm x 54.8 cm x 16.8 kg)
Standards
• Compliance / Certication RoHS / UL, CE, FCC
