Glyph DV-Project User manual

www.glyphtech.com
800.335.0345
When your non-linear editing workstation hungers for mass storage and
blazing speed, Glyph's DV Project FireWire RAID array is the only solution. DV
Project is specifically designed for videographers who need massive disk space
without sacrificing performance. Glyph's DV Project is optimized to achieve
maximum throughput on any FireWire ready system.
The DV Project internal transfer rates exceed 440 Mb/s enabling video
streaming rates over 40 MBytes/sec. Just plug into your FireWire port, & start
streaming.
No termination, ID’s or cable lengths to worry about.
DV Project Features:
•Capture, Playback, Render & Edit Full Broadcast Quality Video
•Fully Optimized solution for superior performance with your NLE
•Mass Storage in a small Tabletop footprint
•Available in Single, Double or Triple RAID Configurations
•Powerful enough for your Final Cut Pro, Matrox and Igniter,
Media 100i and Avid Express Plus Workstation
•Glyph’s DV RAID Toolkit Package included
•Comes complete with Glyph’s outstanding 24 hour advance
replace warranty at no additional charge, along with our
unrivaled tech support and service.
Scalable Capac ty
•Multiple DV Projects can be striped together enabling seamless
expansion up to a Terabyte
•Supports FireWire extended cable lengths (up to 4.5 meters)
DV Project™
FireWire RAID Array
© 2004Glyph Technologies. All rights reserved. Glyph and the
Glyph logo are registered trademarks of Glyph Technologies

Glyph Technolog es
227 Cherry Street
Ithaca, New York 14850
Sales: 800.335.0345
Fa : 607.275.9464
Tech Support: 607.275.0154
www.glyphtech.com
[email protected]
DV-Project - F rew re RAID Array
Glyph Technologies focuses on robust, high-speed RAID arrays for A/V professionals. All Glyph
RAID arrays are tested and optimized to work with the latest in NLE workstations to achieve
optimal performance and ensure maximum functionality and compatibility. Glyph's legendary
service and tech support is backed by an Overnight Advance Replacement warranty on all 80 GB
or larger DV-Project RAID arrays.
DV-Project RAID Spec f cat ons
Sustained transfer rate . . . . . . . . . 30 - 40 MB/sec
Interface. . . . . . . . . . . . . . . . . . . . . . . . IEEE 1394
Capacity. . . . . . . . . . . . . . . . . . . . . . . up to 240GB
Dr ve Spec f cat ons
Sector size. . . . . . . . . . . . . . . . . . . . . . . . 512 bytes
Max. areal density . . . . . . . . . 15.3 Gbits/sq. inch
Max. recording density . . . . . . . . . . . 449,000 BPI
Track density . . . . . . . . . . . . . . . . . . . . 34,000 TPI
Dr ve Performance (Per Dr ve)
Data buffer . . . . . . . . . . . . . . . . . . . . . . . . . . 2 MB
Rotational speed . . . . . . . . . . . . . . . . . . 7200 RPM
Average latency . . . . . . . . . . . . . . . . . . . . . 4.17 ms
Max media transfer rate . . . . . . . . . 494 Mbits/sec
Sustained transfer rate . . . . . . . . . . . > 30 MB/sec
Seek time (read)
Average . . . . . . . . . . . . . . . . . . . . . . . . . 8.5 ms
Track-to-track. . . . . . . . . . . . . . . . . . . . . 1.2 ms
Full-track . . . . . . . . . . . . . . . . . . . . . . . 15.0 ms
Included w th Glyph DV Project
(1) QuickStart User’s Manual
(1) Glyph’s DV RAID Toolkit
(1) 2 meter Firewire cable
(1) 1/2 ft. FireWire cable
(1) Base w/screws
(2) Rack ears w/screws
(4) Rubber feet
(4) Rack Mounting Screws
(1) Cable Strain Relief w/screw
(1) Power Cable
(1) Warranty Registration Card
Dr ve Rel ab l ty
MTBF (Projected Field). . . . . . . . . . . . . 1,000,000
Limited Warranty . . . . . . . . . . . . . Three (3) Years
Rel ab l ty
Nonrecoverable error rate . . . . . . . . . . 1 in 10E13
Start/stop cycles (load/unload). . . . . . . . . 40,000
Power Supply
Switching, 110 - 230V AC Input
Env ronmental
Operating Temperature (˙F/˙C) 41 to 122 / 5
to 55
Phys cal
H, W, D (in) - Tower . . . . . . . . . . . . . 14 x 5 x 9.25
H, W, D (in) - Tabletop . . . . . . . . 2 x 13.75 x 9.25
H, W, D (in) - Rackmount . . . . . . 1.75 x 19 x 9.25
Weight (lbs/kg). . . . . . . . . . . . . . . . . . . . 7.2 / 3.3
DV-Project D g tal, Non-l near
Ed tor Compat b l t es
Media 100 i/leDV, Media 100 i/lx, Media 100 i/xs
Media 100 i/xr (double DV Project configuration)
Apple G4
