8 Way Input Card
Features
The Mxp-014 is an internal peripheral for use with the MxPro 4 multi-loop panels. The unit provides a cost
effective method of monitoring for up to 8 individual clean contact switch inputs.
Each input can be programmed to generate a specific user defined function from the control panel program
and can be assigned to an individual or common zone. The input functions can be either latched or non-
latched and includes Fire, Fault, Pre-alarm, Security, General Alarm, Group Disable, Control Signal, Level-2
access enable etc. together with any other programmable input option allowed within the MxPro 4 systems
DynamiX zoning facilities.
The unit connects directly to the panel and is ideal for class change or non-latching operation where a fast
input response is essential.

www.advancedco.com
Specifications & Ordering:
Models, Sales Order Parts:
Mxp-014: 8 Way Input Card
Mxp-014F: 8 Way Input Card fitted within a Mx-4100/L, Mx-4200, Mx-4400 or Mx-4800 control panel
Applications / Limitations:
All inputs can be individually programmed to any of the specific functions allowed in the control panel
programme: i.e. Fire, fault, pre-alarm, security, record, alarm-1, alarm-2, alarm-3, key-lock, silence, resound,
mute, reset, disable group, control signal and fire evacuate.
Only one 8 Way Input card can be fitted to an Mx-4100/L, Mx-4200 or Mx-4400 control panel.
Up to two 8 Way Input cards can be fitted to an Mx-4800 control panel.
Compatibility:
The Mxp-014 is fully compatible with the following Fire Alarm Control Panels.
Mx-4100/L, Mx-4200, Mx-4400 & Mx-4800
Mounting pillars are provided to mount this card as follows:
Mx-4200, Mx-4400 & Mx-4800 panel chassis
Mx-4100/L on the rear face of the back box.
Item
Specification Details
Switch Inputs
8 normally open inputs. (Can be inverted via software programming for normally closed
operation on an individual basis).
Each input fed from a 24v supply and optically isolated.
On board indication
8 on board Green LED indicators.
LED illuminates when the switch is closed.
Power Supply
24V DC
(E.G. Wired from panel 24V Aux Supply)
Supply Current
Open: –0mA
Closed: –2.2mA
Dimensions
(H x W x D)
55mm x 105mm x 18mm
As our policy is one of constant product improvement the right is therefore reserved to modify product specifications without prior notice

www.advancedco.com
3
Table of Contents Page
FEATURES .............................................................................................................................................................1
1INSTALLATION..............................................................................................................................................4
1.1 INSTALLING THE MXP-014 IN THE MX-4100/L............................................................................................4
1.1.1 Mounting the Card .............................................................................................................................4
1.1.2 Internal Wiring....................................................................................................................................4
1.2 INSTALLING THE MXP-014 IN THE MX-4200/MX-4400/MX-4800.................................................................4
1.3 MOUNTING THE CARD...............................................................................................................................4
1.4 INTERNAL WIRING ....................................................................................................................................5
1.5 EXTERNAL WIRING ...................................................................................................................................6
2PROGRAM THE SWITCH INPUTS................................................................................................................6

www.advancedco.com
1 Installation
1.1 Installing the Mxp-014 in the Mx-4100/L
1.1.1 Mounting the Card
Mxp-007
Base Card
DC 24V
M3 Fixing Points (x4)
PL
2
PL
5
Mxp-014
TB3
TB1
TB5
PL1
PL1
DC 24V
Ribbon Cable
Figure 1
The card mounts on 4 pillars in the rear of the enclosure. See
diagram opposite.
Remove the gear tray assembly and set aside in a safe
place.
Screw in the four spacers supplied into the threaded inserts
in the back box. Use the four M3 screws supplied to securely
affix the card to the spacers.
Figure 1 opposite shows the location.
1.1.2 Internal Wiring
Use the supplied 10-way single in line ribbon cable to connect the input card, via the latched header –PL1, to
the 10 way latched header on the back of the display card (see Figure 4 for location on the display card).
NOTE: It will be necessary to disassemble the base card from the gear tray assembly to obtain access to this
connector. M3 nylock nuts secure the base card to the assembly –keep these safe for re-assembly.
The 8-Way Input Card requires a 24VDC Supply.
Connect the DC Input (see figure 6 for polarity) to the 24V DC AUX Supply Output on the base card as shown
in Figure 1. Run the cable along the rear wall of the back box and tie in place with cable ties. OBSERVE
POLARITY OF CONNECTIONS.
1.2 Installing the Mxp-014 in the Mx-4200/Mx-4400/Mx-4800
1.3 Mounting the Card
Figure 2
The card mounts on 4 pillars in the bottom left hand corner
of the control panel chassis adjacent to the Mx4200/Mx
4400 base card.
See diagram opposite.
Use the four M3 screws supplied to securely affix the card to
the chassis (the supplied spacers are not required).
It is not possible to install the Mxp-014 in this position if the
Mxp-029 Shop Interface is already installed.
Cable
M3 Fixing Screws
Input Card

www.advancedco.com
5
1.4 Internal Wiring
Figure 3
Input Card
Base Card
Cable
Route the cable between the input card and the base card and
then beneath the base card along the bottom edge.
Figure 4
Display Card
Cable Clips
Route the cable around the hinge and along the display plate.
Positions for the plastic cable clips are shown
A 10 way single in line ribbon cable is used to
connect the input card, via the latched
header –PL1, to the 10 way latched header
on the back of the display card.
Route the cable as shown in the diagrams
opposite.
Adhesive ribbon cable clips are supplied with
the kit.
Affix these in the positions shown and clip the
ribbon cable into place to prevent undue
strain on the cable connections.
The 8-Way Input Card requires a 24VDC
Supply.
Connect the Inputs to the 24V DC AUX
Supply Output on the base card as shown in
the diagram opposite.
OBSERVE POLARITY OF CONNECTIONS.
Figure 5
Base Card
Input Card
AUX DC Power to Input Card

www.advancedco.com
1.5 External Wiring
The picture below shows the terminal block positions for
each switch input.
Install cables suitable for the application and degree of fire
protection required. These circuits are SELV type.
If additional knockouts are required, use the deeper back
box (Mxm-020) or use the Termination Enclosures (Mxm-
028 or Mxm-029) as appropriate.
Figure 6
SWITCH
I/P2
SWITCH
I/P3
SWITCH
I/P4
SWITCH
I/P5
SWITCH
I/P6
SWITCH
I/P7
SWITCH
I/P8
SWITCH
I/P1
24V DC
SUPPLY
+ –
PL1
All electrical wiring installation work should be
carried out in accordance with the code of
practice applicable in the country of installation.
To maintain electrical integrity of the SELV
wiring on the input lines all SELV wiring should
be segregated from the LV mains wiring and be
wired using cable with insulation suitable for the
application.
To minimise the effects of EMC interference all
data wiring circuits should be wired with a
twisted pair of conductors with a cross sectional
area suitable for the loading conditions.
In areas where cabling may come into contact
with high frequency interference, such as
portable radio transceivers etc. the input wiring
cable should be of a twisted pair construction
within an overall screen. The screen should be
terminated to one of the dedicated earth studs
available in the panel (refer to panel manual for
positions).
NB: Minimum / Maximum cable size for all
connections is limited to 0.35mm² / 2.5mm² (22-
14AWG).
2 Program the Switch Inputs.
Each input can be
independently
programmed in the
same way as other
inputs to the panel.
On the PC
configuration
software, the inputs
appear as “On-board”
devices and are
shown as Panel S/W-
1 through to Panel
S/W-8.
By default, the inputs
are assigned to the
same zone as
defined for this
control panel. This
can be changed if
required.
Click on the circuit icon
Adjust the “Point Details” as required. The input action, delay, etc. can then be defined.
For further information on PC programming, see document reference 680-021.

www.advancedco.com
