Biamp VOCIA VI-6 User manual

VI-6
OPERATION MANUAL
585.0247.90C
JANUARY 2016

VI-6 Product Description
The VI-6 is a networked audio input expansion device allowing the user to add six channels of
background music or user-defined audio to a Vocia system.
As part of the Vocia system, the VI-6 meets paging requirements for facilities of all sizes.
VI-6 –сетевой модуль аналоговых аудиовходов, позволяющий подключать до 6 каналов фоновой
музыки или любого другого источника звука к системе Vocia. VI-6 как часть системы Vocia
соответствует всем стандартам пейджинговых систем.

VI-6 Setup and Installation
Setup and Use
The Vocia software provides an intuitive interface for configuration, DSP equalization, and programming
of the VI-6. The information supplied by this manual relates to physical connections and assignment. For
more details on software setup, please consult the Vocia Help File.
Installation
Install the unit away from heat sources, such as vents and radiators, and in rooms with adequate
ventilation. Ensure that air can circulate freely behind, beside, and above the unit. Do not exceed the
maximum ambient operating temperature of 32° - 108° F (0° - 42°C). Be aware of conditions in an
enclosed rack that may cause the temperature to exceed ambient room conditions.
The unit requires one 1.75 inch (44.45 mm) high and 19 inch wide rack space with 17 inch (432 mm)
depth. Mounting the unit using four screws with washers will prevent marring of the front panel. PVC or
nylon washers are appropriate.

VI-6 Front
Power Indicator LED
The Unit features one power indication LED on the front panel:
1. Not illuminated: The device is not powered.
2. Flashing green: The unit is receiving power but not data, or the unit has not been configured
correctly.
3. Solid green: The unit is operational. Power supply and network traffic are functional.
Signal LED
Six LEDs located in the center of the front panel act as audio signal identifiers for the six input channels
and are useful for setting optimum signal levels. Each LED has four states. Please see the table below for
the signal mapping to each of the LEDs. Detailed metering of current output levels can be obtained in real
time via the Vocia software interface.
Red
Amber
Green
Dark
Signal above clip threshold>
-2dbFS
Signal above nominal but below
clip threshold
> -18dBFS
< -3dBFS
Signal above minimum but below
nominal threshold
> -48dBFS
< -19dBFS
Signal below minimum
threshold
< -48dBFS
Control LEDs
The control LEDs signal the current state of the control I/Os. The first four are input status indicators, and
the second four are output status indicators.
Amber
Green
Dark
Relays are energized
Above input threshold
Not active

VI-6 Rear
Ground Screw
This screw provides a connection point to ground the chassis of the device. The power supply to the unit
is sourced from PoE, which may have no connection to ground. The chassis of the unit should be
connected to a safety ground (main power supply ground) using the grounding screw.
Network Connection
PoE-enabled network switches or PoE midspan adapters must be used to power the unit. These must be
802.3at Type 1 compliant. The maximum cable distance between any unit and an Ethernet switch is 328
feet (100 meters) when using copper cabling. Additional Ethernet switches and/or fiber-optic cable can be
used to further extend distances between units on a network. Please note that CobraNet limits network
extensions to seven hops (one-way transmissions) within a 100Mb network. If other network traffic shares
an Ethernet switch with the Vocia network, a managed switch should be used with separate VLANs.
The connector provides two LEDs that indicate Ethernet link and network activity.
Left LED
Right LED
Description
None
None
No power or data connectivity. Please check the PoE network connection.
Amber
Flashing Green
Link established and CobraNet activity detected (normal operation).
Flashing
Amber
Flashing Green
Link established and CobraNet activity detected (normal operation). Unit is operating as CobraNet
Conductor.
Flashing
Amber
None
CobraNet Fault. Check cabling and configuration for errors.
Device ID
The rotary ID switches give the unit a unique Device ID. The switches are in hexadecimal format. All units
of the same device type must have a unique Device ID to function properly within a Vocia Paging World.
The Factory Default Device ID is 01. A Device ID of 00 is invalid and cannot be used.

To assign a Device ID of hex 07, leave the MSB switch on 0 and turn the LSB switch to 7. Device ID
switches should be set using a 0.1 inch (2.5mm) to 0.12 inch (3.0mm) flat blade screwdriver.
NOTE
Changes made to the Device ID while connected to the network require a power cycle of the device in order to take effect.
Control Outputs
The Control Outputs, labeled 1 through 4, are isolated, voltage-free, software-configurable relay outputs.
The individual pins are labeled as follows:
1. (C): common/ground pin
2. (NC): normally closed (connected to C when relay is not energized)
3. (NO): normally open (connected to C when relay is energized)
Control Inputs
The Control Inputs are labeled as follows:
1. (Ground symbol): logic common/ground input pin
2. (1–4): individual logic inputs
3. (10V): 10V reference voltage (when used as a switch input, a switch must be connected
between the input and logic common terminal)
Audio Inputs
Two sets of plug-in barrier strip and RCA connectors provide analog audio signal input. Inputs 1 through 4
are designed for line-level input. The RCA and plug-in barrier strip connectors are resistively summed
internally so that a stereo source can be conveniently converted to mono audio. Inputs 5 and 6 are
designed for microphone or line-level inputs and include phantom power. All plug-in barrier strip
connectors should be wired from left to right as follows:
1. High
2. Low
3. Ground
Paging Ports
The VI-6 has four Paging Ports on the rear of the unit which facilitate connection of either a Vocia Paging
Stations Interface 1 (VPSI-1) or a Vocia Auxiliary Microphone 1 (VAM-1), or a combination of both. The
Paging Ports when used in conjunction with these devices allow a balanced audio input, external Push-to-
Talk and LED feedback of Zone and Paging states.
When the VI-6 audio input path is configured to use the Paging Ports the associated line inputs of the VI-
6 will be disabled. The Audio Channel Signal Presence LEDs on the front of the VI-6 chassis will continue
to operate when the input channel is configured for Paging. It will function as it normally would when
configured as a Background or a User Input. The LEDs will function regardless of whether the associated
ancillary paging devices PTT is pressed.

VI-6 Specifications
Specification Table
Connection:
RJ45 with shielded Ethernet
cable (CAT5, 5e, 6 or 7)
Power:
PoE:
PoE 802.3at Type 1 Class 3 (12.95 Watt)
Overall Dimensions:
Height:
1.75 inches (44.5 mm)
Width:
19 inches (483 mm)
Depth:
10 inches (254 mm)
Weight:
Approx. 6.4lbs. (2.9kg)
Environment:
Ambient Operating Temperature:
32-113°F
(0-42°C)
Humidity:
0 - 95%
Altitude:
0 - 10000 Feet MSL
(0 - 3000 Meters MSL)
Compliance:
UL Listed- USA and Canada E215636
FCC Part 15 Subpart B class B
CE Marked
RoHS Compliant
RCM Marked
EAC Marked
Audio Specification
Frequency Response
Line Inputs:
+ or –1dB, 20Hz-20kHz
Mic/Line Inputs
+ or –1dB 35Hz to 20kHz
THD + N (20Hz to 8kHz):
Line Inputs:
<0.02%
Mic/Line Inputs
<0.05%
Line Inputs Signal to Noise Ratio:
>84dB
Mic Inputs Equivalent Input Noise:
<-126dBu
Dynamic Range:
>100dB
Input Impedance:
Line Inputs:
>10kΩ
Mic/Line Inputs:
>1kΩ
Mic Inputs Phantom Power:
18V behind 3.3kΩ/leg
A/D Converters:
24-bit (48kHz sampling)
Control Specifications
Control Inputs
Type:
Digital, variable threshold
Max Input Threshold::
10V
Max Input Voltage::
12V
Min Input Threshold:
150mV
Input Impedance:
100kΩ
Control Outputs
Type:
Form C Voltage
free change over contact
Max Operating Voltage:
125VAC, 60VDC
Max Switching Capacity:
37VA
Min Operating Load:
10μA @ 10mV DC
Block Diagram
