Introduction
This User’s Manual describes how to setup and install your USB-to-
Serial Adapter.
The QSU2-100 and ESU2-100, respectively, provide four and eight
independent RS-232 serial interfaces to the host PC via the Universal
Serial Bus (USB) port.
The QSU2-400 and ESU2-400, respectively, provide four and eight
independent asynchronous serial interfaces via the USB port. Each of
these interfaces can be used as desired for RS-232, RS-422 or RS-485
communications.
Table 1 - Device port and connection options
Device
Ports
Connection
Device
Ports
Connection
QSU2-100
4
RS-232
QSU2-400
4
RS-232/422/485
ESU2-100
8
RS-232
ESU2-400
8
RS-232/422/485
Each adapter uses high-speed UARTs and deep FIFOs, allowing each
channel to obtain data rates up to 921.6 kbps. The adapters are
powered over their USB connection (bus-powered), eliminating the
need for an external power supply. The adapters are Plug-and-Play
devices and require no hardware configuration.
System Requirements
The USB-to-Serial adapters are supported under the Windows 2000/XP
(and later) and Linux operating systems. One USB port is required to
connect the adapter to your computer. You can use either a built-in
USB port or an add-in USB host adapter. We recommend the use of a
USB 2.0 port for best performance. Contact our sales department for
details on current software offerings.
Note: These products comply
fully with USB Specification
version 2.0. They will also
operate over slower USB 1.1
connections at a slightly
reduced performance level.
Note: The “-400” designation
indicates an “MEI” device.
MEI is an acronym for
“Multiple Electrical Interface.”
The interface is software-
selectable for each serial port.

USB
to Serial Adapter
4
Features
Multiple Electrical Interface (MEI)
MEI adapters (model numbers ending with “-400”) are shipped with a
factory default of all serial ports set for RS-232 connections. Each
port can be individually configured for RS-232, RS-422/485 full-
duplex, or RS-422-485 half-duplex operation.
Understanding the LEDs
The LEDs inform you of the configuration of the adapter’s serial
ports. Each serial port has one associated LED located on the back
panel to the right of the port’s DB-9 connector. The following table
lists the possible states of the LEDs and their meaning.
Table 2 - LED codes
LED color Meaning
Red
Port is configured for RS-232.
Green
Port is configured for RS-422/485.
Installing the USB-to-Serial Adapter
This section explains how to install the USB-to-Serial adapter under
different operating systems. Please locate and follow the procedure
for your computer’s operating system.
The USB-to-Serial adapter includes Windows device drivers that
enable the serial ports to appear to Windows as standard COM ports.
Installing under Windows XP
Follow these steps to install the adapter under Windows XP.
Step
Procedure
Description

Step 1
Turn on the power to your computer
system.
This is the system in which the
device
is to
be installed.

Step 2
Plug t
he wide flat end of the USB cable
into the downstream connector.
This is the connector located on the back of
the computer or USB hub.

Step 3
Plug the square end of the USB cable into
the back of the
USB-to-Serial adapter.
Windows tells you that it has f
ound new
hardware and launches the Found New
Hardware Wizard.
Caution! Be sure to allow
the installation process to
finish without interruption.

USB
to Serial Adapter
5
Figure 1 - Windows XP Found new hardware prompt
Step
Procedure
Description
Step 4 Insert the installation CD into your CD-
ROM drive.
This is the CD that shipped with the
product.

Step 5
Select the “Advanced” option. Click the
Next button.
The Choose your search and installation
options prompt displays.
Figure 1 illustrates the
Windows XP Found new
hardware prompt. The Found
New Hardware Wizard
launches automatically when
you first plug in the USB-to-
Serial adapter.

USB
to Serial Adapter
6
Figure 2 - Windows XP Choose your search and installation options prompt
Step
Procedure
Description
Step 6 Select Search removable media (floppy,
CD-ROM).
If necessary, you can also select the
Include this location in the search:
option and browse to the location with
the USB-to-Serial drivers.
The complete path is E:\Serial Port
Adapters\Drivers\Windows 98, Me,
2000, XP for USB.
Replace E:\ with your CD-ROM
designation
Step 7 Click the Next button. Windows searches for drivers for the
adapter.
Figure 2 illustrates the
Windows XP Choose your
search and installation
prompt.

USB
to Serial Adapter
7
Figure 3 - Windows XP Searches drivers prompt
Step
Procedure
Description
Step 8 The Wizard locates and starts to install
the necessary software.
The Wizard installs the software prompt
displays, followed by the Finished
installing prompt.
Figure 3 illustrates the
Windows XP Searches for
drivers prompt. When the
Wizard finds the USB-to-
Serial drivers, this screen
disappears.

USB
to Serial Adapter
8
Figure 4 - Windows XP Wizard installs the software
Figure 5 - Windows XP Finished installing prompt
Step
Procedure
Description
Step 11 Press the Finish button to continue. The USB adapter installation is
complete.
Figure 5 shows the Windows
XP Finished installing
prompt. It indicates that the
adapter has been successfully
installed.

USB
to Serial Adapter
9
Installing under Windows 2000
Follow these steps to install the USB-to-Serial adapter under
Windows 2000.
Step
Procedure
Description

Step 1
Turn on the power to your computer
system.
This is the system in which the
device
is to
be installed.

Step 2
Plug the wide flat end of the USB cable
into the downs
tream connector.
This is the connector located on the back of
the computer of USB hub.

Step 3
Plug the square end of the USB cable into
the back of the
USB-to-Serial adapter.
Windows tells you that it has found new
hardware and launches the Add New
Hardwa
re Wizard. The Found new
hardware prompt displays.
Figure 6 - Windows 2000 Found new hardware prompt
Step
Procedure
Description
Step 4 Click the Next button. The Search for or display drivers
prompt displays.
Figure 6 illustrates the
Windows 2000 Found new
hardware prompt. The Found
New Hardware Wizard
launches automatically when
you first plug in the USB-to-
Serial adapter.

USB
to Serial Adapter
10
Figure 7 - Windows 2000 Search for or display drivers prompt
Step
Procedure
Description
Step 5 Insert the installation CD into your CD-
ROM drive.
This is the CD that shipped with the
adapter.
Step 6 Select Search for a suitable driver for
my device (recommended)
Step 7 Click the Next button. The Locate driver files prompt displays.
Figure 8 - Windows 2000 Locate driver files prompt
Figure 7 shows the Windows
2000 Search for or display
drivers prompt.
Figure 8 illustrates the
Windows
2000 Locate driver
files prompt.

USB
to Serial Adapter
11
Step
Procedure
Description
Step 8 Select CD-ROM drives. If necessary, you can also select Specify
a location: and browse to the desired
location with the USB-to-Serial drivers.
The complete path is E:\Serial Port
Adapters\Drivers\Windows 98, Me,
2000, XP for USB.
Replace E:\ with your CD-ROM drive
designation.
Step 9 Click the Next button. Windows searches for drivers for the
adapter. The Finished searching for
driver files prompt displays.
Figure 9 - Windows 2000 Finished searching for driver files prompt
Step
Procedure
Description
Step 10 Click the Next button.
Step 13 The Wizard proceeds with the
installation.
The Please wait while the Wizard
installs the software screen displays,
followed by the Finished installing
prompt.
Figure 9 illustrates the
Windows 2000 finished
searching for driver files
prompt.

USB
to Serial Adapter
12
Figure 10 - Windows 2000 Finished installing prompt
Step
Procedure
Description

Step 14
Press the Finish button to continue.
The USB-to-Serial adapter installation
is complete.
Figure 10 is the Windows 2000
finished installing prompt. It
indicates that the adapter has
been successfully installed.

USB
to Serial Adapter
13
Uninstalling under Windows 2000 or Windows XP
Follow these steps in the event that you need to uninstall or reinstall
the USB-to-Serial software.
1. From the Control Panel, select System.
2. Press the Hardware tab.
3. Click on Device Manager.
Figure 11 – Device Manager
4. Scroll down to Multi-port serial adapters and expand.
5. Highlight your USB-to-Serial adapter; for example, ESU2-400,
Eight RS-232/422/485 Serial Ports (Group ID14).
6. Select the Action menu option.
7. Select Uninstall from the drop down menu.
8. Click OK at the Confirmation screen. Note that this also removes
all the serial ports associated with your USB-to-Serial adapter.

USB
to Serial Adapter
14
Making external connections
The USB-to-Serial adapters are equipped with male DB-9 connectors.
The following figures and tables show the serial port pinouts for RS-
232 and RS-232/422/485 applications.
Figure 12 - DB-9 connector pinout
RS-232 serial connections
RS-232 devices are classified by their function as either Data
Terminal Equipment (DTE) or Data Communication Equipment
(DCE).
Figure 13 - Use of DTEs and DCEs in a communication link
The USB-to-Serial adapters are DTE devices that connect to
peripheral equipment through a male DB-9 connector. The following
table lists the serial port connector definitions.
Table 3 - RS-232 signals on DB-9 connector
RS-232 signal description DB-9
Data Carrier Detect (DCD)
1
Receive Data (RxD)
2
Transmit Data (TxD)
3
Data Terminal Ready (DTR)
4
Signal Ground (GND)
5
Data Set Ready (DSR)
6
Request To Send (RTS)
7
Clear To Send (CTS)
8
Ring Indicator (RI)
9
Note: A DTE device is the
communication source. A DCE
device provides a communication
channel between two DTE-type
devices.

USB
to Serial Adapter
15
DTE- and DCE-type devices have complementary pinouts that allow
terminals and modems to connect directly using a one-to-one cable as
shown in Figure 14. Two DTE-type devices can be connected by a
null modem cable. A typical null modem cable is also shown in the
figure.
Figure 14 - Cabling requirements for RS-232 devices
RS-422/485 serial connections
The USB-to-Serial adapters provide four differential communication
signals (either RS-422 or RS-485) per channel. Transmit Data (TxD)
and Auxiliary Output (AuxOut) are the two output signals. Receive
Data (RxD) and Auxiliary Input (AuxIn) are the two input signals.
The adapters also provide a ground signal.
The AuxOut pair can carry the UART’s RTS signal. The AuxIn pair
can carry the UART’s CTS signal. Alternatively, the AuxOut pair can
be configured to internally loopback to the AuxIn pair, with the
UART’s RTS signal also looped back to its CTS signal. The following
table shows the RS-422/485 connector definitions.
Table 4 - RS-422/485 signals on DB-9 connector
RS-422/485 signal description
four-wire mode
DB-9
RS
-422/485 signal description
two
-wire mode
Auxiliary Input (AuxIn–)
1
DNC
Receive Data (RxD+)
2
DNC
Transmit Data (TxD+)
3
Transmit/Receive Data (Data+)
Auxiliary Output (AuxOut–)
4
DNC
Signal Ground (GND)
5
Signal Ground (GND)
Receive Data (RxD–)
6
DNC
Auxiliary Output (AuxOut+)
7
DNC
Auxiliary Input (AuxIn+)
8
DNC
Transmit Data (TxD–)
9
Transmit/Receive Data (Data–)
Figure 14 illustrates the RS-
232 pinouts for typical DTE-
to-DCE and DTE-to-DTE
cables with 9-pin connectors.
Note: In many applications,
DCEs are unnecessary. This
allows you to use a null
modem
cable (modem eliminator cable)
to directly connect two DTE-
type devices.
Note: Pins labeled DNC (Do
Not Connect) are
indeterminate
in two-wire mode
and should be
left unconnected.
Note: Refer to Advanced
Options using Device Manager
for details on software-
selectable advanced options.

USB
to Serial Adapter
16
Testing DB-9 serial ports in HyperTerminal
This section explains how to test the functionality of your USB-to-
Serial adapter using Hyperterminal for RS-232 ports and RS-422/485
ports.
An RS-232 loopback connector is included with the USB-to-Serial
adapter. For MEI models, an RS-422/485 loopback is also included.
Running Hyperterminal
Step
Procedure
Description

Step 1
Attach the loopback connector to the DB-9
connector.
Be sure to use the correct loopback
connector for RS-232 or RS-422/485.
Step 2 Launch HyperTerminal. In Windows, select Programs/
Accessories/ Communications/
HyperTerminal.

Step 3
Create a new session.
When prompted, give the session any
name you wish.
Step 4 Select the COM # associated with port 1
from the drop down list.
You are now set up to test the first serial
port.
Note: Leave all settings at default.
Step 5 With the session open, type any text. If the text you type is echoed on the
screen, the port is functioning properly.
Step 6 Close the session.
Step 7 Repeat steps 3 through 6 for each serial
port.
If the text you type is echoed on the
screen, the port is functioning properly.

USB
to Serial Adapter
17
Using Device Manager
This section explains how to use Device Manager to view the
properties of the serial ports enumerated by the USB-to-Serial
adapter.
Accessing Device Manager
Step
Procedure
Description

Step 1
Select Start – Control Panel.
Step 2 Double click the System icon. The System Properties dialog box opens.
Step 3 Click the Hardware tab, and then press
the Device Manager button.
Device Manager lists all the hardware
devices that are registered inside the
Windows registry.
Exploring Device Manager screens
Windows XP and 2000
Device Manager provides two property dialogs that apply to the USB-
to-Serial adapter.
Ports (COM & LPT) device group property box
Multi-port serial adapters device group property box
Use the Ports (COM & LPT) device group property box to view and
set the port settings and to view device usage and driver information
for the serial ports. Use the Multi-port serial adapters device group
property box to view and set the advanced options and to view device
usage and driver information for the USB-to-Serial adapter.
Step
Procedure
Description
Step 1 With Device Manager open, expand the
Multi-port serial adapters device group.
Your USB-to-Serial adapter should
appear in the list – for example, ESU2-
400 Eight RS-232/422/485 Serial Ports
(Group ID14).
Step 2 Double click the USB-to-Serial adapter. The Properties dialog box opens and
displays the General tab.

USB
to Serial Adapter
18
Figure 15 - Windows XP/2000 Device Manager properties, General tab
Step
Procedure
Description
Step 3 Click the USB Serial Ports Advanced
Options tab to view the port setting
properties.
The Advanced Options dialog box
displays.
Figure 15 illustrates the
Windows XP/2000 General
Tab, which tells you whether
the USB-to-
Serial adapter is
working properly.
