Advantech AIM-37AT User manual

User Manual
AIM-37AT
RISC All-in-One Light duty
Mobile Data Terminal

AIM-37AT User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2017
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
All other product names or trademarks are properties of their respective owners.
Declaration of Conformity
CE Conformity Statement
Radio products with the CE alert marking comply with the R&TTE Directive (1999/5/
EC) issued by the Commission of the European Community. Compliance with this
directive implies conformity to the following European Norms (in brackets are the
equivalent international standards).
EN 60950-1 (IEC60950-1) - Product Safety
EN 300 328 Technical requirement for radio equipment
ET S301 489 General EMC requirements for radio equipment
Products that contain the radio transmitter are labeled with CE alert marking and may
also carry the CE logo.
FCC Compliance Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly
approved by the party responsible for compliance could void the user's authority to
operate this equipment. (Example: use only shielded interface cables when connect-
ing to computer or peripheral devices).
Part No. Edition 1
Printed in Taiwan February 2017

iii AIM-37AT User Manual
This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference
that may cause undesired operation.
15.21
Any changes or modifications not expressly approved by the party responsible for
compliance could void the authority to operate equipment.
This device and its antenna must not be co-located or operating in conjunction with
any other antenna or transmitter.
End-users and installers must be provided with antenna installation instructions and
transmitter operating conditions for satisfying RF exposure compliance.
For product available in the USA/Canada market, only channel 1~11 can be oper-
ated. Selection of other channels is not possible.
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment for body-worn configuration in direct contact to the phan-
tom.
This device complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
IC warning statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is sub-
ject to the following two conditions: (1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appa-
reils radio exempts de licence. L'exploitation est autorisée aux deux conditions suiv-
antes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil
doit accepter tout brouillage radioélectrique subi, même si le brouillage est suscepti-
ble d'en compromettre le fonctionnement.
This radio transmitter has been approved by Industry Canada to operate with the
antenna types listed below with the maximum permissible gain and required
antenna impedance are strictly prohibited for use with this device.
Le present emetteur radio a ete approuve par Industrie Canada pour fonctionner
avec les types d'antenne enumeres ci-dessous et ayant un gain admissible maximal
et l'impedance requise pour chaque type d'antenne. Les types d'antenne non inclus
dans cette liste, ou dont le gain est superieur au gain maximal indique, sont
strictement interdits pour l'exploitation de l'emetteur.

AIM-37AT User Manual iv
IC Radiation Exposure Statement
This EUT is compliance with SAR for general population/uncontrolled exposure limits
in IC RSS-102. This equipment should be installed and operated with minimum dis-
tance 0 cm between the radiator & your body.
Cet EUT est la conformite avec SAR pour la population generale / les limites d'expo-
sition incontrolees dans IC RSS-102. Cet equipement doit etre installe et utilise a une
distance minimale de 0 cm entre le radiateur et votre corps.
NCC Warning Statement
Article 12
Without permission, any company, firm or user shall not alter the frequency, increase
the power, or change the characteristics and functions of the original design of the
certified lower power frequency electric machinery.
Article 14
The application of low power frequency electric machineries shall not affect the navi-
gation safety nor interfere a legal communication, if an interference is found, the ser-
vice will be suspended until improvement is made and the interference no longer
exists.
Technical Support and Assistance
1. Visit theAdvantech web site at http://support.advantech.com where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
Package List
Ensure all the following items are present when you receive your AIM-37AT. If any of
these items are missing, contact your dealer immediately.
AIM-37AT Computer
Startup Manual
AC power adaptor (micro USB connector)

v AIM-37AT User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. Keep this equipment away from humidity.
5. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
6. Do not leave this equipment in an environment unconditioned where the storage
temperature under -20° C (-4° F) or above 70° C (158° F), it may damage the
equipment.
7. Do not operate this equipment in an environment temperature may over 70° C
(158° F). The surface temperature of metal chassis may be scorch and hot.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord. The voltage and current rating of the cord should be
greater than the voltage and current rating marked on the product.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
13. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
14. This product is intended to be supplied by a Listed Power Adapter or DC power
source, rated 5Vdc, 3A minimum and Tma 50 degree C, if need further assis-
tance, please contact Advantech for further information.Ð_

AIM-37AT User Manual vi
Battery Safety
Mistreat the battery used in this device may present a risk of fire or chemical burn.
Do not attempt to disassemble the computer or its accessories.
Only qualified personal is allowed to replace the battery.
Do not dispose batteries in a fire and check with local authorities for disposal instruc-
tions.
AIM-37AT can only be equipped with standard battery pack with TCL PR-396698G
7,900 mAH Polymer Lithium Ion Battery. Use of another battery may present a risk of
fire or explosion.
Battery Charge Notice
It is important to consider the environment temperature whenever you are charging
the Lithium-Ion battery pack. The process is more efficient at normal room tempera-
ture or slightly cooler. It is essential that you charge batteries within the stated range
of 0°C to 40°C. Charging batteries outside of the specified range could damage the
batteries and shorten their charging life cycle.
Storage and Safety Notice
Although charge Lithium-Ion batteries may be left unused for several months, their
capacity may be depleted due to the buildup of internal resistance. If this happens
they will require recharging prior to use. Lithium Ion batteries may be stored at tem-
peratures between -10°C to 60°C, however they may be depleted more rapidly at the
high end of this range. It is recommended to store AIM-37AT within normal room tem-
perature ranges.MIT-W101 User Manual
Caution! Danger of explosion if battery is incorrectly replaced. Replace only with
the same type recommended by the manufacturer, discard used batter-
ies according to the manufacturer's instructions.
Danger d'explosion si la batterie est inexactement remplacée. Rem-
placez seulement avec la même chose ou le type recommandé par le
fabricant, jettent les batteries utilisées instructions de s selon fabricant
des'.

vii AIM-37AT User Manual
WEEE
EN
Following information is only for EU-member states:
The use of the symbol indicates that this product may not be treated as household
waste. By ensuring this product is disposed of correctly, you will help prevent poten-
tial negative consequences for the environment and human health, which could oth-
erwise be caused by inappropriate waste handling of this product. For more
information about recycling of this product, please contact your local city office, your
household waste disposal service or the shop where you purchased the product.
Warnings, Cautions and Notes
Warning! Warnings indicate conditions, which if not observed, can cause personal
injury!
Caution! Cautions are included to help you avoid damaging hardware or losing
data. e.g.
There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer's
instructions.
Note! Notes provide optional additional information.

AIM-37AT User Manual viii

ix AIM-37AT User Manual
Contents
Chapter 1 Information...........................................1
1.1 Introduction ...............................................................................................2
1.2 Product Features.......................................................................................2
1.3 Product Specifications...............................................................................3
1.3.1 Technical Specifications ...............................................................3
1.3.2 Product Outlook and Dimensions .................................................4
1.4 Exploring the AIM-37AT............................................................................5
1.4.1 Front View.....................................................................................5
1.4.2 Rear View .....................................................................................6
1.4.3 Right View.....................................................................................6
1.4.4 Left View.......................................................................................7
1.4.5 Top View.......................................................................................7
1.4.6 Bottom View..................................................................................8
Chapter 2 Getting Started.....................................9
2.1 Charge the Computer..............................................................................10
2.2 Turn on the Computer.............................................................................10
2.3 Sleep Mode.............................................................................................10
2.4 Operate the computer.............................................................................11
2.5 LED Indicator Status...............................................................................11
2.5.1 Power LED..................................................................................11
2.5.2 Barcode scanner status LED......................................................11
Chapter 3 Basic Setups......................................13
3.1 Windows 10 IoT Enterprise Basic Setups...............................................14
Figure 3.1 Windows 10 IoT Enterprise Home Screen ...............14
3.2 Android 6.0.1 Basic Settings...................................................................15
Figure 3.2 Android 6.0.1 Home Screen.....................................15
Chapter 4 Running applications........................17
4.1 Installing Applications..............................................................................18
4.1.1 Install applications with Windows 10 IoT ....................................18
4.1.2 Install applications with Android..................................................19
Chapter 5 Maintenance.......................................23
5.1 Maintaining the LCD Display...................................................................24
5.2 Cleaning the AIM-37AT...........................................................................24
5.3 Trouble Shooting.....................................................................................24
5.4 ENERGY STAR ......................................................................................24

AIM-37AT User Manual x

Chapter 1
1Information

AIM-37AT User Manual 2
1.1 Introduction
Congratulations on your purchase of the AIM-37AT Computer.
AIM-37AT has two variants and the difference is the optional peripherals at the right
side of the device.
This product combines stylish design with reliable performance and powerful func-
tionality to best suit all your needs, in a wide range of working conditions. This user
manual outlines all you need to know to set up and use your AIM-37AT. If you have
any further questions or queries, contact our technical support team via our website:
http://support.advantech.com.tw/
1.2 Product Features
Semi-rugged stylish design with only 17.4mm in thickness.
Low power Intel® ATOM ™ processor designed for mobile applications.
Rich Built-in WLAN/Bluetooth/NFC wireless communications.
10.1 “ WXGA TFT IPS LCD with 10-points multiple touch.
Durable and reliable Anti-Glare, Anti-Fingerprint Corning Gorilla Glass™ 3.
Dual USB 2.0 host connectors via Micro USB
Optional 2D barcode scanner with trigger button and status LED.
Comply with IP54 sealing for water and dust (AIM-37AT-S SERIES).
Built-in MSR and IC Card readers (AIM-37AT-M SERIES).
Can be configured to install either Android or Windows OS.
AIM-37AT-M SERIES:
MSR and IC Card Reader slots are
embedded at the right side.
AIM-37AT-S SERIES:
The card reader slots are sealed off and
replaced by volume keys.

3 AIM-37AT User Manual
Chapter 1 Information
1.3 Product Specifications
1.3.1 Technical Specifications
AIM-37AT-M AIM-37-S
Computing
System
CPU Intel® Atom™ x5-Z8350 Processor
Max. Speed 1.92GHz
On-board Mem-
ory 2GB DDR3L-RS
Operating Sys-
tem
Microsoft Windows 10 IoT
Enterprise
Android 6.0.1 Android 6.0.1
Storage On-board eMMC 32GB
Micro-SD Micro-SD Card Slot for Storage Expansion up to 128GB
Display
Display Type 10.1" TFT IPS LCD Panel
Max. Resolution WXGA, 1280x800, 350 nits
Touch Type Projected Capacitive Multi-Touch
Glass Type G/G Direct Bonding, Corning GG3 Glass
Communica-
tion
WIFI 802.11b/g/n
Bluetooth Bluetooth v4.0 CLASS II
NFC Read/ Write Device Compatible With ISO15693,
ISO14443A, ISO14443B, Mifare, Felica
Audio x1 80dB 1Watt SPK 0.5M, x1 Audio combo jack
Connectivity I/O Port Inter-
faces x1 Micro USB 2.0 (OTG & Charging) x1 AIM Dock 6-pin Pogo Connector: USB 2.0 + Power
Camera Front 2MP Fixed Focus
Rear 5MP Auto Focus with LED Flash
Sensor G-sensor + E-compass, Gyroscope, ALS
Security Kensington security slot
MSR
3-Track MSR with 3-DES
encryption; Triple DES and
AES Encryption; DUKPT
key management
N/A
IC Card 5V smart card; ISO/IEC
7816-1, 2, 3, 4; T=0 & T = 1; N/A
Barcode scan-
ner 1D/2D barcode scanner N/A
Hard Buttons x1 Power Button
x1 Functional Button
x1 Power Button
x2 Volume Control Button
x1 Functional Button
System Indica-
tors x1 Power / Battery Status x1 Barcode scanner Status
Power Input Micro USB DC 5V, Max 3A
6-Pin Pogo Con-
nector DC 5V, Max 3A
Battery Capacity Embedded Lithium-ion battery
Soft Pack (1S2P): 3.8V 7,900mAH (30 Watt)
Operating Temp 0°C ~+40 °C (Charging)
0°C ~+50 °C (Discharging)

AIM-37AT User Manual 4
1.3.2 Product Outlook and Dimensions
All AIM-37AT Series share the same dimension, the following illustration uses AIM-
37AT-M SERIES as example.
Environment Temperature Operating: 0°C ~ +50°C, Storage: -10°C ~ +60°C
Operating & Stor-
age Humidity 5% ~ 95%(non-condensing)
Ingress
Protection Dust/ Water Resistance IP-54 (Except MSR / IC Card slot) IP-54 compliant
Physical
Characteris-
tics
Dimensions (W x
H x D) 290 x176 x 17.4mm
Weight 915g 900g
Color Black + Orange / Black + Cool Gray
Certifications CE/FCC/CB/UL/NCC/BSMI/CCC
290
176
17.4 17.4

5 AIM-37AT User Manual
Chapter 1 Information
1.4 Exploring the AIM-37AT
1.4.1 Front View
No. Component
1 Front Camera
2 Barcode scanner status LED
3 Power LED
4NFC
5 Ambient Light Sensor
1 2 3
4
5

AIM-37AT User Manual 6
1.4.2 Rear View
1.4.3 Right View
1.4.3.1 AIM-37AT-M SERIES
No. Component
1 Barcode scanner trigger or programmable button
2 Rear Camera with LED Flash
3 Power button
4 M6 screw holes
5 Speaker
1 2 3
4
4
5
4
4
No. Component
1 MSR (Magnetic Swipe Reader)
2 IC Card Reader
1
2

7 AIM-37AT User Manual
Chapter 1 Information
1.4.3.2 AIM-37AT-S SERIES
1.4.4 Left View
1.4.5 Top View
1.4.5.1 AIM-37AT-M SERIES
No. Component
1 Volume Up
2 Volume Down
12
No. Component
1 Reserved screw
2 Audio Combo Jack
3 Kensington Lock connector
1 2 3
No. Component
1 Guide pin
2MicroSDslot
3 Barcode scanner
4MSRslot
1 2 3 4

AIM-37AT User Manual 8
1.4.5.2 AIM-37AT-S SERIES
1.4.6 Bottom View
1.4.6.1 AIM-37AT-M SERIES
1.4.6.2 AIM-37AT-S SERIES
No. Component
1 Guide pin
2MicroSDslot
3 (Optional) barcode scanner
1 2 3
No. Component
1 Guide pin
2 Pogo Pin (Reserved for future docking usage)
3MicroUSB
4MSRslot
1 2 1 3 4
No. Component
1 Guide pin
2 Pogo Pin (Reserved for future docking usage)
3MicroUSB
1 2 1 3

Chapter 2
2Getting Started

AIM-37AT User Manual 10
2.1 Charge the Computer
To charge the embedded battery in AIM-37AT, connect the Micro USB adaptor on the
AIM-37 computer.
2.2 Turn on the Computer
Push the Power Button (located at no. 3 of Section 1.5.2 Rear View.) for 3 seconds to
start the computer.
2.3 Sleep Mode
While the computer is running, push the Power Button for 1 second will move the
equipment into sleep mode for power saving. Push the Power Button again will
enable the backlight again.
Note! Please charge for at least one hour when you use this computer for the
first time.
Micro USB Connector
Power button
