Advantech MARS-1030 User manual

MARS-1030
WinCE. NET Rugged Portable
Data Terminal
User Manual

MARS-1030 User Manual ii
Copyright
The documentation and the software included with this product are copy-
righted 2006 by Advantech Co., Ltd. All rights are reserved. Advantech
Co., Ltd. reserves the right to make improvements in the products
described in this manual at any time without notice. No part of this man-
ual may be reproduced, copied, translated or transmitted in any form or
by any means without the prior written permission of Advantech Co., Ltd.
Information provided in this manual is intended to be accurate and reli-
able. However, Advantech Co., Ltd. assumes no responsibility for its use,
nor for any infringements of the rights of third parties, which may result
from its use.
Acknowledgements
Intel is a trademark of Intel Corporation.
Microsoft Windows is a registered trademark of Microsoft Corp.
All other product names or trademarks are properties of their respective
owners.
Part No. 2006103001 Edition 2
Printed in Taiwan January 2007

iii Table of Contents
Contents
Chapter 1 Introduction ..................................................... 2
1.1 About this Manual............................................................. 2
1.2 User and Product Safety.................................................... 3
1.3 Declaration of conformity ................................................. 5
1.4 Product Labeling ............................................................... 7
1.5 System Specifications ....................................................... 9
1.6 Environment Standard..................................................... 11
1.7 Warranty and after service .............................................. 12
1.8 Technical Support and Assistance................................... 12
1.9 Document Feedback........................................................ 12
Chapter 2 Getting Started .............................................. 14
2.1 Check the package........................................................... 14
2.2 General View of the PDT................................................ 15
2.2.1 PDT front side view ..................................................... 15
2.2.2 PDT back side view ..................................................... 15
2.3 Charging the Battery Pack............................................... 17
2.3.1 Installing the battery pack ............................................ 17
2.3.2 Charging the battery pack with a Power Adapter ........ 21
2.3.3 Charging the battery pack with a Single Dock ............ 22
2.4 Handling the PDT............................................................ 24
2.4.1 Starting the PDT .......................................................... 24
2.4.2 Power on/off ................................................................ 25
2.4.3 Calibration of the touch Screen ................ 25
2.4.4 Adjusting the brightness .............................................. 26
2.4.5 To mute the Sound ....................................................... 26
2.4.6 Using the Stylus ........................................................... 26
2.4.7 Using the Keypad ......................................................... 27
2.4.8 Using Earphones and a Microphone ............................ 41
2.5 Navigating the Display.................................................... 42
2.5.1 Setting Time and Date ................................................. 42
2.5.2 Entering the Data ......................................................... 43
2.5.3 The Command Bar ....................................................... 43
2.5.4 The Taskbar ................................................................. 44
2.5.5 The Soft Keypad .......................................................... 44
2.5.6 Setting Up a Wireless LAN ......................................... 45
2.5.7 Scanning Barcode ........................................................ 47
2.5.8 Help .............................................................................. 48
2.6 Power Management......................................................... 49
2.6.1 Suspend Mode .............................................................. 49
2.6.2 Resuming ..................................................................... 50
2.7 Resetting the PDT ........................................................... 51
2.7.1 Software (Warm) Reset ............................................... 51
2.7.2 Cold Reset .................................................................... 51

MARS-1030 User Manual iv
Chapter 3 Setting............................................................. 54
3.1 Introduction ..................................................................... 54
3.2 Control Panel................................................................... 54
3.2.1 Barcode Setting ............................................................ 55
3.2.2 Symbologies List ......................................................... 64
3.2.3 Bluetooth Device Properties ........................................ 83
3.2.4 Certificates ................................................................... 87
3.2.5 Control Center .............................................................. 89
3.2.6 Date/Time ................................. 94
3.2.7 Dialing Properties ........................... 94
3.2.8 Display Properties ........................... 96
3.2.9 Input Panel ................................................................... 98
3.2.10 Internet Options ........................................................... 99
3.2.11 Keyboard .................................................................... 101
3.2.12 Network and Dial-up Connections ............................ 102
3.2.13 Owner ......................................................................... 107
3.2.14 Password .................................................................... 108
3.2.15 PC Connection ........................................................... 109
3.2.16 Power ......................................................................... 110
3.2.17 Regional Settings ....................................................... 112
3.2.18 Remove Programs ...................................................... 113
3.2.19 Storage Manager ........................................................ 114
3.2.20 Stylus ......................................................................... 115
3.2.21 System ........................................................................ 117
3.2.22 Volume & Sounds Properties .................................... 119
3.3 Taskbar and Start Menu ................................................ 120
Chapter 4 Communication ........................................... 122
4.1 Installing & Setting Up Microsoft ActiveSync ............. 122
4.1.1 Installing Microsoft ActiveSync on the Host PC ....... 122
4.1.2 Connecting PDT to Host PC ...................................... 122
4.2 Using ActiveSync.......................................................... 123
4.2.1 Setting up a Partnership ............................................. 123
4.2.2 ActiveSync File Synchronization .............................. 124
4.3 Networking.................................................................... 124
Chapter 5 Software Applications................................. 126
5.1 Introduction ................................................................... 126
5.2 Software Applications ................................................... 126
5.2.1 Calculator ................................................................... 126
5.2.2 Inbox .......................................................................... 126
5.2.3 Internet Explorer ........................................................ 136
5.2.4 Media Player .............................................................. 140
5.2.5 Messenger .................................................................. 140
5.2.6 Microsoft WordPad .................................................... 141
5.2.7 Remote connection .................................................... 147
5.2.8 Windows Explorer ..................................................... 148

v Table of Contents
5.3 DiskOnChip .................................................................. 150
5.3.1 Saving to flash ........................................................... 150
5.3.2 DiskOnChip location ................................................. 150
5.3.3 DiskOnChip size ........................................................ 151
Appendix A Barcode Setting............................................ 154
A.1 Setup Tab....................................................................... 154
A.1.1 Symbology setup ........................................................ 156
A.1.2 Decoder setup ............................................................ 157
A.1.3 Options ....................................................................... 159
A.2 Update Tab .................................................................... 160
A.3 Symbologies List........................................................... 162
A.3.1 Aztec .......................................................................... 162
A.3.2 Codabar ...................................................................... 163
A.3.3 Code 11 ...................................................................... 164
A.3.4 Code 128 .................................................................... 165
A.3.5 Code 39 ...................................................................... 166
A.3.6 Code 49 ...................................................................... 168
A.3.7 Code 93 ...................................................................... 169
A.3.8 Composite Codes ....................................................... 170
A.3.9 Data Matrix ................................................................ 171
A.3.10 EAN-8 ........................................................................ 172
A.3.11 EAN-13 ...................................................................... 173
A.3.12 Interleaved 2 of 5 ....................................................... 174
A.3.13 MaxiCode ................................................................... 175
A.3.14 MicroPDF417 ............................................................ 176
A.3.15 OCR-A, OCR-B, US Currency .................................. 177
A.3.16 PDF417 ...................................................................... 189
A.3.17 Postnet ........................................................................ 190
A.3.18 QR Code .................................................................... 191
A.3.19 Reduced Space Symbology ....................................... 192
A.3.20 UPC-A ....................................................................... 193
A.3.21 UPC-E ........................................................................ 194
A.3.22 UPC-E1 ...................................................................... 195
A.3.23 ISBT ........................................................................... 196
A.3.24 British Post ................................................................. 197
A.3.25 Canadian Post ............................................................ 198
A.3.26 Australian Post ........................................................... 199
A.3.27 IATA 2 of 5 ................................................................ 200
A.3.28 Codablock F ............................................................... 201
A.3.29 Japanese Post ............................................................. 202
A.3.30 Planet Code ................................................................ 203
A.3.31 KIX (Netherlands) Post ............................................. 204
A.3.32 MSI ............................................................................ 205
A.3.33 TCIF Linked Code 39 ................................................ 206
A.3.34 Matrix 2 of 5 .............................................................. 207

MARS-1030 User Manual vi
A.3.35 Korean Post ................................................................ 208

1
CHAPTER
Introduction
This chapter presents general informa-
tion about the PDT.

MARS-1030 User Manual 2
Chapter 1 Introduction
Congratulations on purchasing the MARS-1030 Portable Data Terminal
(PDT), a Microsoft Windows® CE .Net rugged PDT. Its special combina-
tion of features makes it perfect for using in a wide range of applications.
These features are:
• Intel® XScale™ PXA255 400 MHz 32 bits RISC Processor
• Windows® CE .NET 4.2 Operating System
• 64/128/256 MB SDRAM & 64/128 MB Flash ROM
• Open Architecture: User Accessible SD/CF/PCMCIA Slot
• 240 x 320, 3.5" Color TFT Display with Touch Panel
• 1 Numeric Keyboards with LED backlight
• 802.11b Radio Support (Bluetooth Optional)
• Integrated 1D or 2D Barcode Scanner
1.1 About this Manual
The following chapters contained in this manual are:
Chapter 1: Introduction—Presents general information about the
PDT.
Chapter 2: Getting started—Describes the basic use of the PDT.
Chapter 3: Setting—Provides basic instructions for customizing the
PDT by adjusting settings.
Chapter 4: Communication—Describes how to use the communica-
tion features of the PDT.
Chapter 5: Software Application—Software implement procedures.
Appendix A: Barcode Setting—Provides instructions for customizing
the barcode engine.

3 Chapter1
1.2 User and Product Safety
• Do not stare into the laser beam directly or shine it into eyes.
• Never use strong pressure onto the screen or subject it to severe
impact, as the LCD panel could become cracked and possibly cause
personal injury. If the LCD panel is broken, never touch the liquid
inside, for such contact would irritate the skin.
• Although the MARS-1030 PDT has passed IP54 standard tests for
water and dust resistance, avoid prolonged exposure to rain or other
concentrated moisture. For these conditions exceed the IP54 stan-
dard, and could result in water or other contaminants entering the
PDT.
• Use only the approved AC Adapter with the PDT. Use of an unap-
proved AC Adapter could result in electrical problems, or even
cause a fire or electrical shock to the user.
• Be sure that only authorized suppliers are allowed to disassemble
and reassemble the device. If the device or parts has been damaged
due to wrong handling, the product and parts warranty shall be
void.
• Always make backup copies of all important data. This is easily
one by using a cable or Single Cradle (sold as an option) to transfer
data to the computer. The manufacturer is not liable for any data
damage or loss caused by deletion or corruption of data when using
this device or caused by a drained battery.
• Lithium-ion battery packs might get hot, explode, ignite and/or
cause serious injury abused. Please follow the safety warnings
listed as below:
– Do not place the battery pack in fire or heat the battery.
– Do not install the battery pack backwards so the polarity is
reversed.
– Do not connect the positive and negative terminals of the bat-
tery pack together with any electrically conductive object.
– Do not carry or store battery pack together with metal objects.
– Do not pierce the battery pack with nails, strike the battery pack
with a hammer, step on the battery pack or otherwise subject it
to strong impacts or shocks.
– Do not solder directly onto the battery pack.
– Do not expose battery pack to liquid, or allow the battery con-
tacts to get wet.

MARS-1030 User Manual 4
– Do not disassemble or modify the battery pack. The battery
pack contains safety and protection devices, which, if damaged,
may cause the battery pack to generate heat, explode or ignite.
– Do not discharge the battery pack using any device except for
the specified device. When it is used in devices other than the
specified devices, the battery pack can be damaged or its life
expectancy reduced. If the device causes any abnormal current
to flow, it may cause the battery pack to become hot, explode or
ignite and cause serious injury.
– In the event the battery pack leaks and the fluid gets into one’s
eye, do not rub the eye. Rinse well with water and immediately
seek medical care. If left untreated, the battery fluid could cause
damage to the eye.
Caution!
Achtung!
There is a danger of a new battery exploding if it is
incorrectly installed. Do not attempt to recharge,
force open, or heat the battery. Replace the battery
only with the same or equivalent type recommended
by the manufacturer. Discard used batteries accord-
ing to the manufacturer’s instructions.

5 Chapter1
1.3 Declaration of conformity
FCC Class B
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interfer-
ence in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accor-
dance with the instructions, may cause harmful interference to radio com-
munications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for
help.
FCC Caution: Any changes or modifications not expressly approved by
the party responsible for compliance could void the user's authority to
operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC RF radiation exposure limits set forth
for an uncontrolled environment. To maintain compliance with FCC RF
exposure compliance requirements, please avoid direct contact to the
transmitting antenna during transmitting.
This transmitter must not be co-located or operated in conjunction with
any other antenna or transmitter.

MARS-1030 User Manual 6
CE
This product has passed the CE test for environmental specifications. Test
conditions for passing included the equipment being operated within an
industrial enclosure. In order to protect the product from being damaged
by ESD (Electrostatic Discharge) and EMI leakage, we strongly recom-
mend the use of CE-compliant industrial enclosure products.
IMPORTANT FOR LASER PRODUCTS
1. Class II Laser Product
2. Caution - use of controls or adjustments or performance of proce-
dures other than those specified herein may result in hazardous
radiation exposure.
3. “Laser Radiation—Do not stare into beam”
4. Do not allow young children to use the product without adult super-
vision.
5. Do not replace/repair the LED/Laser. These are not user replace-
able.
6. Do not shine the LED/Laser on a reflective surface.
Caution: Advantech declares that MARS-1030 ID:M82-MARS-
1030 is limited in CH1~CH11 for 2.4GHz by specified firmware
controlled in U.S.A.
The FCC ID of MARS-1030 is M82-MARS-1030

7 Chapter1
1.4 Product Labeling
The PDT has several labels as shown in Figure 1-1 and 1-2.
Figure 1.1: Product Labeling (Front side view)

MARS-1030 User Manual 8
Figure 1.2: Product Labeling (Back side view)

9 Chapter1
1.5 System Specifications
The MARS-1030 PDT detailed specifications follow. Unless otherwise
noted, all the specifications are subject to change without prior notifica-
tion.
Table 1.1: System Specification
MARS-1030
Processor - 400 MHz Intel PXA255 32 bits RISC CPU
Memory - 64 or 128 MB Flash ROM
- 64,128 or 256 MB SDRAM
Display - 240 x 320 3.5" TFT 256K Color LCD with LED
backlight
Audio
- One mono speaker
- 2.5 mm DIA Stereo Earphone Jack with
Microphone input
Radio Support - Wireless LAN: 802.11b (optional)
- Bluetooth: Class II (optional)
Communication Ports
- USB: Support USB v1.1 both host and client.
(PDT and Cradle)
- Serial: RS-232 via optional cable or Cradle.
Scan Engine
(Optional)
- Opticon Laser (1D) Engine
- HHP 2D Imager.
Expansion Slot
- One Compact Flash Type-II slot
- One PCMCIA slot
- One SD Card slot (supports SD memory only)
LED
- One Triple-Color LED for Charger Indicator
and Alarm Notification
- One Dual-Color LED for Scanner Indicator
Power System
- Standard Li-Ion Battery Pack, 3.7 V, 3000
mAh
- Advanced Smart Battery with Gas-Gauge
- Built-in Battery Charger
- 2.4 V / 15 mAh rechargeable backup battery
- One Battery Cover Sensor Switch
- Power Adapter: 100 ~ 240 V AC, 50/60 Hz
Input; 5 V DC / 2.6 A, 3 A Output

MARS-1030 User Manual 10
Button/Key
- Power button
- 4-way navigation button
- 4 Application Keys
- 3 Scanner Enable Keys
- SW Reset input button
- 16 Alpha-numeric key keyboard
Dimensions and Weight
- Dimensions: 192.5 mm (L) x 91.3 mm / 78
mm (W) x 42.2 mm / 60.6 mm (H)
- Weight: 560 g with Standard Battery Pack
500 g without Battery Pack
Color - Black
Standard packing list
and Optional
accessories
- Standard Packing list:
1. MARS-1030 Terminal
2. Stylus
3. USB Client Cable for Terminal
4. Earphone/ Microphone Set
5. Standard AC Adapter 5 V DC / 2.6 A
6. AC Power Cord
7. Standard Battery Pack (3.7 V, 3000 mAh)
8. CF Support Guide
9. Quick Guide
- Optional Accessory:
1. RS-232 Serial Cable for Terminal
2. USB Host Cable for Terminal
3. High-Capacity Li-Ion Battery Pack
(3.7 V, 4000 mAh)
4. RFID Card Cover
5. Single Dock
6. Pistol Grip
7. 4-Slot Battery Charger
8. Car Adapter
9. Holster
10. Protect Film
Software - Microsoft Windows CE.NET 4.2 Professional

11 Chapter1
1.6 Environment Standard
Table 1.2: Environment Standard
Operating Temperature 14 ~ 122° F (-10 ~ 50° C)
Storage Temperature -4 ~ 158° F (-20 ~ 70° C)
Humidity 5 ~ 80% (non-condensing)
Drop 5 ft (1.5 m) Drop to Concrete
Water & Dust proof IP54 Certificated
Vibration MIL STD 810F

MARS-1030 User Manual 12
1.7 Warranty and after service
Should this PDT malfunction, please contact your original retailer provid-
ing information about the product name, the serial number, and the details
about the problem.
1.8 Technical Support and Assistance
1. Visit the Advantech web site at www.advantech.com/support
where you can find the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's cus-
tomer service center for technical support if you need additional
assistance. Please have the following information ready before you
call:
– Product name and serial number
– Description of your peripheral attachments
– Description of your software (operating system, version, appli-
cation software, etc.)
– A complete description of the problem
– The exact wording of any error messages
1.9 Document Feedback
To assist us in making improvements to this manual, we would welcome
comments and constructive criticism. Please send all such - in writing to:
[email protected]

2
CHAPTER
Getting Started
This chapter describes the basic use of
the PDT.

MARS-1030 User Manual 14
Chapter 2 Getting Started
2.1 Check the package
Open the package and check that nothing is missing or damaged.
Figure 2.1: Inside the package
1. MARS-1030 Terminal
2. Standard Battery Pack (3.7 V, 3000 mAh)
3. Earphone/Microphone Set
4. Stylus
5. USB Client Cable for Terminal
6. CF Support Guide
7. Standard AC Adapter 5 VDC / 2.6 A
8. AC Power Cord
9. Quick Guide (Not Shown)
