Advantech PCIE-1760 User manual

User Manual
PCIE-1760
8-Ch Relay and 8-Ch Isolated
Digital Input PCIE Card

PCIE-1760 User Manual ii
Copyright
The documentation and software included with this product are copyrighted 2023 to
Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to
make improvements on the products described herein at any time without notice. No
part of this manual may be reproduced, copied, translated, or transmitted in any form
or by any means without prior written permission from Advantech Co., Ltd. The infor-
mation provided in this manual is intended to be accurate and reliable. However,
Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringement of
the rights of third parties, which may result from its use.
Acknowledgments
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names and trademarks are the property of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that this product will be free from
defects in materials and workmanship for 2 years from the date of purchase.
This warranty does not apply to products that have been repaired or altered by per-
sons other than repair personnel authorized by Advantech, nor does it apply to prod-
ucts that have been subject to misuse, abuse, accident, or improper installation.
Under the terms of this warranty, Advantech assumes no liability for consequences
arising from such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time, and freight. Please consult your dealer for more details.
If you believe that you have a defective product, follow these steps:
1. Collect all the information about the problem encountered (e.g., CPU speed,
Advantech products used, other hardware and software used, etc.). Note any-
thing abnormal and list any on-screen messages that appear when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain a return merchandise authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully completed Repair and Replacement
Order Card, and proof of purchase date (e.g., a photocopy of your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number clearly on the outside of the package and ship it prepaid
to your dealer.
Part No. 2003E76012 Edition 3
Printed in Taiwan May 2023

iii PCIE-1760 User Manual
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend using shielded cables. This type
of cable is available from Advantech. Please contact your local supplier for ordering
information.
FCC Class A
This equipment has been tested and found to comply with the limits for a Class A dig-
ital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy, and if not installed and used in accordance with the user manual,
may cause harmful interference to radio communications. Operation of this equip-
ment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his or her own expense.
Technical Support and Assistance
1. Visit the Advantech website at www.advantech.com/support for the latest infor-
mation about this product.
2. Should you require additional assistance, contact your distributor, sales repre-
sentative, or Advantech's customer service center for technical support. Please
have the following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (OS, version, application software, etc.)
–A complete description of the problem
–The exact wording of any error messages
Packing List
Before setting up the system, check that the items listed below are included and in
good condition. If any item does not accord with the table, please contact your dealer
immediately.
PCIe bus main communication interface board
Startup Manual
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.

PCIE-1760 User Manual iv

v PCIE-1760 User Manual
Contents
Chapter 1 Introduction..........................................1
1.1 Product Overview...................................................................................... 2
Figure 1.1 PCIE-1760 .................................................................. 2
1.2 Product Features....................................................................................... 2
1.2.1 Board ID........................................................................................ 2
1.3 Driver Installation ...................................................................................... 3
Figure 1.2 XNavi Installer ............................................................ 3
1.4 Software Utility .......................................................................................... 3
1.5 Software Development Using DAQNavi SDK ........................................... 4
1.6 FPGA Code Update .................................................................................. 4
1.7 Hardware Installation ................................................................................ 4
Figure 1.3 Device Manager ......................................................... 5
1.8 Accessories............................................................................................... 5
Chapter 2 Installation and Field Applications ....7
2.1 Signal Connection and Pin Assignments .................................................. 8
2.1.1 Isolated Digital Input Signal Connection ....................................... 8
Figure 2.1 Digital input signal connection with wet contact config-
uration......................................................................... 8
Figure 2.2 Digital input signal connection with dry contact configu-
ration........................................................................... 9
2.1.2 Relay Output Signal Connection................................................... 9
Figure 2.3 Relay output signal connection................................. 10
Figure 2.4 Digital input signal connection with dry contact configu-
ration......................................................................... 10
2.1.3 Counter Signal Connection ......................................................... 11
Figure 2.5 TTL type counter output signal connection............... 11
Figure 2.6 Sink type counter output signal connection .............. 12
2.1.4 Pin Assignment ........................................................................... 12
Figure 2.7 Pin assignment of PCIE-1760 .................................. 12
2.1.5 Switch and Jumper Settings ....................................................... 13
Chapter 3 Function Details.................................17
3.1 Digital Input ............................................................................................. 18
3.1.1 Digital Input Interrupt................................................................... 18
Figure 3.1 Digital input rising edge interrupts ............................ 18
Figure 3.2 Digital input falling edge interrupts ........................... 18
Figure 3.3 Digital input both edges interrupts ............................ 18
3.1.2 Digital Input Pattern Match Interrupt ........................................... 18
Figure 3.4 Digital input pattern match interrupt for pattern
“10xx0100”................................................................ 19
3.1.3 Digital Input Debounce Filter....................................................... 19
Figure 3.5 Digital input debounce filter ...................................... 19
3.1.4 Instant Digital Input Acquisition................................................... 19
Figure 3.6 Instant digital input acquisition.................................. 19
3.2 Digital Output .......................................................................................... 20
3.2.1 Static Digital Output Update........................................................ 20
Figure 3.7 Static digital output update ....................................... 20
3.3 Counter Output........................................................................................ 20
3.3.1 Event Counting ........................................................................... 20
Figure 3.8 Rising edge event counting ...................................... 20

PCIE-1760 User Manual vi
Figure 3.9 Falling edge event counting ..................................... 20
Figure 3.10Event counting with pause gate ............................... 21
3.3.2 Pulse Width Measurement.......................................................... 21
Figure 3.11Pulse width measurement ........................................ 21
3.4 Device Description and Configuration..................................................... 21
Figure 3.12Device description shown in Navigator .................... 22
Appendix A Specifications.................................... 23
A.1 Isolation Digital Input............................................................................... 24
A.2 Relay Output ........................................................................................... 24
A.3 Counter ................................................................................................... 25
A.4 General ................................................................................................... 26
A.5 Function Block Diagram.......................................................................... 27

Chapter 1
1Introduction

PCIE-1760 User Manual 2
1.1 Product Overview
This chapter provides an overview of Advantech industrial data acquisition module
for PCIE-1760 — surveying the product lineups, features, drivers, utilities, and acces-
sories. PCIE-1760 are differential digital I/O modules. The function for these models
are isolated digital I/O, TTL I/O, solid-state relay (SSR), and counters.
All of the PCIe modules are capable of use in all kinds of PCIe chassis. Detailed
instructions and functions will be described in the following sections.
Figure 1.1 PCIE-1760
1.2 Product Features
1.2.1 Board ID
A board ID can be assigned to the PCIe chassis by the rotary switch and slot number.
The board ID will be shown in the software and can be used to distinguish modules.
The number shown around the rotary switch shows if the device is in operation or
not. For example, When configured as 0, the board ID is automatically assigned by
the device driver software. When configured as a value other than 0, the configured
value is used. Do not configure the same value (except for 0) for hardware devices
with the same model name. Refer to the device specifications for the configuration of
the board ID.
If changed, a new board ID value takes effect only after a cold reset. The number
assigned to each PCIe module follows a rule combining the ChassisID and slot num-
ber. Refer to section 3.4 for more detailed information.

3 PCIE-1760 User Manual
Chapter 1 Introduction
1.3 Driver Installation
The driver package can be found via the Advantech Support Portal (https://
www.advantech.com/support). Search for PCIe on the support portal to find the cor-
responding driver/SDK package. You’ll receive the XNavi installer after the download
session finishes.
Execute the installer and it will guide you through the session. You can choose the
device and software components you’d like to install in the system (Figure 1.2). After
the selection, click on “start” to begin the installation.
Figure 1.2 XNavi Installer
1.4 Software Utility
Advantech offers device drivers, SDKs, third-party driver support, and application
software to help you fully exploit the functions of your PCIe system. All these soft-
ware packages are available on the Advantech website: http://www.advantech.com/.
The Advantech Navigator is a utility that allows you to set up, configure, and test your
device; and later stores your settings in a proprietary database.
1. To set up the I/O device for your card, you should first run the Advantech Navi-
gator program (by accessing Start/Programs/Advantech Automation/XNavi
Advantech Navigator). The settings can also be saved.
2. You can then view the device(s) already installed on your system (if any) on the
Installed Device tree view. If the software and hardware installation have com-
pleted, you will see the PCIe modules in the Installed Devices list.

PCIE-1760 User Manual 4
1.5 Software Development Using DAQNavi SDK
DAQNavi SDK is the software development kit for programming applications with
Advantech DAQ products. The necessary runtime DLL, header files, software man-
ual and tutorial videos can be installed via XNavi installer, which can be found under
C:\Advantech\DAQNavi (default directory) after finishing installation.
1.6 FPGA Code Update
The FPGA can also be updated via the interface in Navigator. However, it isn’t normal
to make an FPGA update. Advantech strongly suggests consultation with technical
support before starting an FPGA update.
1.7 Hardware Installation
After the device driver installation has completed, you can now continue to install the
PCIE-1760 card in any PCI Express slot on your computer. Follow the steps below to
install the card on your system.
1. Turn off your computer and unplug the power cord and cables. TURN OFF your
computer before installing or removing any components on the computer.
2. Remove the cover of your computer.
3. Remove the slot cover on the back panel of your computer.
4. Touch the metal part on the surface of your computer to neutralize the static
electricity that might be on your body.
5. Insert the PCIE-1760 card into a PCI Express slot. Hold the card only by its
edges and carefully align it with the slot. Insert the card firmly into place. Use of
excessive force must be avoided, otherwise the card might get damaged.
6. Fasten the bracket of the PCI Express card on the back panel of the computer.
7. Connect appropriate accessories to the PCI Express card.
8. Replace the cover of your computer chassis. Re-connect the cables you
removed in step 1.
9. Plug in the power cord and turn on the computer.
After the PCIE-1760 card is installed, you can verify whether it is properly installed on
your system through the Device Manager:
1. Access the Device Manager through Control Panel/System/Device Manager.
2. The device name of the PCIE-1760 should be listed on the Device Manager tab
as follows.

5 PCIE-1760 User Manual
Chapter 1 Introduction
Figure 1.3 Device Manager
After your card is properly installed on your system, you can now configure your
device using the Advantech Navigator after you install XNavi on your computer.
1.8 Accessories
All of the following lists the accessories for PCIE-1760
PCL-10137-1E: 37-pin D-SUB cable, 1 m
PCL-10137-2E: 37-pin D-SUB cable, 2 m
PCL-10137-3E: 37-pin D-SUB cable, 3 m
ADAM-3937-BE: DB37 DIN-rail Wiring Board
Note! If your card is properly installed, you should see the device name of your
card listed on the Device Manager tab. If you do see your device name
listed on it but marked with an exclamation sign “!”, it means your card
has not been correctly installed. In this case, remove the card device
from the Device Manager by selecting its device name and press the
Remove button. Then go through the driver installation process again.

PCIE-1760 User Manual 6

Chapter 2
2Installation and Field
Applications

PCIE-1760 User Manual 8
2.1 Signal Connection and Pin Assignments
2.1.1 Isolated Digital Input Signal Connection
A digital input channel senses the state of the external sensor or switch, and passes
it through a galvanic isolator (opto-coupler) to the internal circuit. This prevents the
internal components and the host devices (e.g. PC) from damaging when such fault
conditions arise. The device supports both wet contact and dry contact configurations
for digital input signal connection, which can be configured by onboard jumpers for
each channel independently.
For wet contact configuration, an external voltage source is applied between the pos-
itive digital input (DI+) terminal and the negative digital input (DI−) terminal through a
switch as shown in Figure 2.1. If the switch is closed, circuit loop is formed among the
external source, the switch, and the opto-coupler. The current flowing on this loop is
sensed by the opto-coupler, and the digital input state is ON. On the other hand, if the
switch is open, no current flows through the opto-coupler, and the digital input state is
OFF. The voltage of the external source must meet the minimum value of ON state as
specified in the device specifications for proper operation.
An external signal source can also be used for a digital input channel. This is shown
in Figure 2.1 and Figure 2.2 for wet and dry contact configuration, respectively. The
signal source toggles between a high level voltage and a low level voltage, which
results in digital input ON and OFF states.
Figure 2.1 Digital input signal connection with wet contact configuration
The input voltage, which is the voltage between the DI+ terminal and the DI− terminal
for wet contact configuration and between the DI− terminal and the DIGND terminal
for dry contact configuration, must be either higher than the minimum value of ON
state or lower than the maximum value of OFF state for a deterministic result. If the
input voltage is between these two values, the result is undetermined, which may be
ON or OFF. In addition, do not input a voltage higher than the maximum allowable
value of ON state or lower than the minimum allowable value of the OFF state, other-

9 PCIE-1760 User Manual
Chapter 2 Installation and Field Applications
wise the device may be damaged under such circumstance. Refer to the device
specifications for ON and OFF state voltage ranges.
Figure 2.2 Digital input signal connection with dry contact configuration
2.1.2 Relay Output Signal Connection
A relay output channel sends a signal to control the ON/OFF state of a relay. Some of
the relays are of Form A (normally open) or Form B (normally closed) type, which is
configured by the onboard jumper for each channel independently, and others are of
Form C (normally open and normally closed) type. All types are described in detail as
follows:
For Form A type, if the relay is in ON state, the common (COM) terminal is con-
nected to the normally open (NO) terminal; on the other hand, if the relay is in
OFF state, the terminals are disconnected from each other.
For Form C type, if the relay is in OFF state, the COM terminal is connected to
the normally NO terminal; on the other hand, if the relay is in ON state, the ter-
minals are disconnected from each other.
For Form C type, if the relay is in ON state, the COM terminal is connected to
the NO terminal, and the normally closed (NC) terminal is disconnected. On the
other hand, if the relay is in OFF state, the COM terminal is connected to the NC
terminal, and the NO terminal is disconnected.
This is shown in Figure 2.3. The default state is OFF state.

PCIE-1760 User Manual 10
Figure 2.3 Relay output signal connection
The relay is a non-directional component, which means that the external source can
be applied in either direction. However, both the load voltage and current must be
within the range as specified in the device specifications for proper operation and to
prevent the device from damage.
Figure 2.4 Digital input signal connection with dry contact configuration

11 PCIE-1760 User Manual
Chapter 2 Installation and Field Applications
2.1.3 Counter Signal Connection
Counter Input Connection:
Please refer to “2.1.1 Isolated Digital Input Signal Connection”.
Counter Output Connection:
The type of counter output signal can be TTL or sink, which is selected by an
onboard jumper.
When configured as TTL type output, the signal is sent through a galvanic isolator
and a logic gate. A voltage logic level is generated between the counter output and
the digital ground (DGND) terminal. This is shown in Figure 2.5.
Figure 2.5 TTL type counter output signal connection
When configured as sink type output, the signal is sent through a galvanic isolator to
control the ON/OFF state of a switch. The state of the switch then decides if the load
is conducting or not. The device supports sink (NPN) type configuration for counter
output signal connection. This is shown in Figure 2.6.

PCIE-1760 User Manual 12
Figure 2.6 Sink type counter output signal connection
2.1.4 Pin Assignment
Figure 2.7 Pin assignment of PCIE-1760

13 PCIE-1760 User Manual
Chapter 2 Installation and Field Applications
2.1.5 Switch and Jumper Settings
Pin Name Direction Description Pin Number
IDI<0..7>+ I Isolated digital input positive terminals 20 ~ 27
IDI<0..7>- I Isolated digital input negative terminals 2 ~ 9
CNT<0..1>_CLK+ I Counter clock input positive terminals.
Shared with IDI+ terminals.
23, 27
CNT<0..1>_CLK- I Counter clock input negative terminals.
Shared with IDI- terminals.
5, 9
CNT<0..1>_GATE+ I Counter gate input positive terminals.
Shared with IDI+ terminals.
21, 25
CNT<0..1>_GATE- I Counter gate input negative terminals.
Shared with IDI- terminals.
3, 7
CNT<0..1>_OUT O Counter output terminals. 10, 28
GND - Ground terminal. 1
RLY<0..1>_NO O Relay output normally open terminals. 32, 35
RLY<0..1>_NC O Relay output normally close terminals. 33, 36
RLY<2..7>_OUT O Relay output terminals. Can be configured
as normally close or normally open by on-
board jumpers.
11 ~ 13,
29 ~ 31
RLY<0..7>_COM O Relay output common terminals. 14 ~ 19,
34, 37

PCIE-1760 User Manual 14
Switch Setting
*Default setting
Jumper Setting
Digital Input Configuration (JP0 - JP7)
*Default setting
Relay Output Configuration (JP8 – JP13)
*Default setting
Power-on Configuration (JP14)
*Default setting
Board ID Switch Position
1234
0* UP UP UP UP
1 UP UP UP DOWN
2 UP UP DOWN UP
3 UP UP DOWN DOWN
4 UP DOWN UP UP
5 UP DOWN UP DOWN
6 UP DOWN DOWN UP
7 UP DOWN DOWN DOWN
8 DOWN UP UP UP
9 DOWN UP UP DOWN
10 DOWN UP DOWN UP
11 DOWN UP DOWN DOWN
12 DOWN DOWN UP UP
13 DOWN DOWN UP DOWN
14 DOWN DOWN DOWN UP
15 DOWN DOWN DOWN DOWN
Jumper Setting Description
Dry contact*
Wet contact
Jumper Setting Description
Form A (normally open)*
Form B (normally close)
Jumper Setting Description
Keep last status after hot reset
Reset to default status after hot reset*
Other manuals for PCIE-1760
1
Table of contents
