VEGA-320_Heat_Spreader Startup Manual 1
Before you start installing your heat spreader, please make
sure that the following items have been shipped:
1 x VEGA-320 heat spreader with thermal pad
1 x Thermal pad attachment
1 x Startup manual
1 x China RoHS
2 x Screws
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Product Pictures
Top View Bottom View
VEGA-320 Heat Spreader
Startup Manual
Below is the dimensions of VEGA-320 heat spreader:
Unit: mm
1. Remove the thermal pad protecting lm on VEGA-320
heat spreader
2. Install 2 pcs screws to VEGA-320 heat spreader
25.00
Screw: F/S D=4.5,
H=0.8+M2.5*5L
17.00 2.60
13.00 21.00
Heat Spreader Installation
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the VEGA-320 Heat spreader.
Part No. 2046032010
Printed in Taiwan
1st Edition
January 2020
Dimensions

2 VEGA-320_Heat_Spreader Startup Manual
3. Secure VEGA-320 heat spreader to your chassis
4. After securing the heat spreader to your chassis, remove all the protective lm on thermal pad attachment
5. Align one of thermal pad attachment edge to the mark on VEGA-320 heat spreader and install thermal pad
Heat Spreader Installation (Cont.)
