Advent CADNAV2 User manual

CADNAV2
Cadillac

Components：
Cadillac T-Harnesses VHB Tape
HDMI Video Output Flash
Cable
GPS Antenna
Video Input Cable
Interface Module
Screw Driver Components Pry Tool
Installation Tools:
Towel

Pry the right
side cover of
shift lever.
2\ Pull the right side
cover of shift and
screws of trim.
3\
Pry the cover of
shift lever.
1\

Pry the right front
cover of shift lever.
6\
Remove the right
front cover and
unfasten the screws.
7\
Pry the trim of
shift lever.
4\
Remove the right
side cover of shift
lever.
5\

Take out the glove box.
9\
Unfasten 6 screws from
glove box.
8\

Remove the screws
holding the Radio
module in place.
10\
Remove the Radio Module.
11\

12\
Video output
flash cable
OEM video cabal
Video output
flash cable
Place as
shown.
13\ Connect all
cables.
14\
Attach to the
radio module as shown with
VHB tape supplied.
interface module

Wiring diagram: TF
USB
Rear View Camera
USB Connector
HDMI
Interface
Module
Power
Connector
Audio
Connector
Fuse
To HMI Blue
LVDS
Connector
NOT USED
GPS Antenna
To Vehicle
Central
or
Left Front
Speaker
To HMI
Black
16 Pins
Connector
To Radio
Gray
20 Pins
Connector

Wiring diagram
GPS antenna installation
1.
. Remove the right cover of storage box, thread the cable
from storage box to center console and tie up with OEM cable
together.
3. Plug GPS antenna in head unit.
Notice:
Make sure all equipments are installed in secure place. If installed other
automotive equipments, please be sure they are not interfering each
other. Read all instructions before installation, and be recommended to
install this unit by audio professional vendors.
Clean adhesion area with oil-soluble detergent, and fix
GPS antenna with adhesive tape tight.
2
Install antenna in car
GPS
Antenna

Video input flash cable
Main power cable 16
Pin female connector
OEM 16 Pin male
connector
OEM 20 Pin male
connector
Video output flash cable
Video output flash cable
Plug all cables as shown.
15\
T-harnesses
Audio input cable USB/AUX cable
GPS antenna Video output flash cable
Video input flash cable
Plug all cables as shown.
16\
Video input flash cable Main power cable 20
Pin female connector

Pry the cover of
central speaker.
17\
Unfasten 2 screws from
central speaker.
19\ Unplug the cable
of speaker.
20\
18\Remove the cover of
central speaker.

Central speaker flash cable
OEM central speaker cable
23\
Prepare a steer wire and
make it goes through from
the hole of central speaker
to glove box.
21\
Tape the speaker flash
cable on steer wire.
22\
Speaker flash cable
24\
Take back the steer
wire with speaker
flash cable from
speaker hole.
Connect speaker flash
cable with OEM central
speaker cable.

Speaker flash cable
Plug speaker flash cable
in central speaker.
25\
Fasten the both
side screws of
central speaker.
26\
Fix back the cover
of central speaker.
27\
28\ Fix the bracket on the
place as shown.

29\ Fix back the glove box.
30\ Turn on, enjoy it.
