Furrion NV2200 User manual

N
NV V2 22 20 00 0
N
NA AV VI IG GA AT TI IO ON N S SY YS ST TE EM M
O
OW WN NE ER R’ ’S S M MA AN NU UA AL L

P
P
PR
R
RE
E
EC
C
CA
A
AU
U
UT
T
TI
I
IO
O
ON
N
NS
S
S
1. Read these instructions entirely.
2. Keep these instructions. Whoever uses the unit should have access to this manual.
3. Heed all warnings. Follow all instructions.
4. This unit is designed to be used in a vehicle with 12V DC battery and negative
ground.
5. Do not operate the unit in any other way than described in this manual. Failure to
follow the instructions within this manual may void your warranty.
6. Do not disassemble or alter the unit in any way, because it will void your warranty.
Do not attempt to repair or to service the unit yourself.
7. Use only original accessories which are designed and manufactured for the unit
otherwise you will risk damage. Install the unit according to the mounting manual by
using the supplied mounting accessories. The forces of acceleration for accidents are
sometimes huge. Incorrect mounted units are a big risk for the driver and the car
passengers, during an accident.
8. Protect the unit from water and other liquids, which can enter the casing. A short
circuit or even fire could be the result.
9. To prevent a short circuit, never insert or stick any metallic objects (such as coins
or metal tools) into the unit.
10. Before you replace a defective fuse, try to find the cause for the short circuit.
Please pay attention to the cables of the power supply! If the short circuit doesn't
result from a failure of the power supply or wiring, you can replace the defective fuse
with a new one (same values).
11. When connecting to any other device, read its user's guide for detailed safety
instructions. Do not connect incompatible products.
12. Be careful not to drain the vehicle battery while using the unit when the vehicle
engine is turned off. Because the unit uses a considerable amount of energy and the
battery will be charged only while the engine is running, it might happen that the
battery will discharge to a point where it's no longer possible to start the engine.
13. According to the law in different countries, driving with monitors which are
showing movies in the viewing range of the driver is not allowed, because the driver
might be distracted from the traffic. Please respect the traffic regulations of your
country, or you might face penalties in case of an accident or even lose your
insurance coverage. Please pay attention to the volume inside your vehicle, because
you are obliged to notice exterior sounds like ground.
14. Don't expose the unit to hard impacts. A mechanical or electrical malfunction of
the unit could be the result.
15. This unit utilizes a laser class 1. During usage the control or adjust other than
those specified herein may result in hazardous exposure to coherent light. Do not
open covers and do not repair yourself. Refer servicing to qualified personnel.

F
F
FE
E
EA
A
AT
T
TU
U
UR
R
RE
E
ES
S
S
Disc (DVD/CD/VCD)
12 cm disc type supported: DVD-Video, DVD±R/RW, CD-DA, CD-R, and CD-RW.
Support audio format: MP3, Kodak Photo CD, AAC, WMA, M4A.
ID3 tag compatible.
16Mbit electronic shockproof: 3 seconds DVD video / 10 seconds CD audio.
Break-point memory function.
All area code supported.
Functions on DVD: play, pause, stop, previous chapter, next chapter, fast forward,
fast backward, subtitle selection, audio selection, A-B repeat, scene selection.
Functions on CD: play, pause, previous track, next track, random play, repeat play,
track selection.
Functions on VCD: play, pause, previous chapter, next chapter, fast forward, fast
backward, subtitle selection, audio selection, aspect ratio selection, A-B repeat.
Support picture format: JPEG.
Functions on picture: picture selection, automatic play, pause, previous picture,
next picture.
Support video format: MPEG 1 / 2 / 4, AVI, FLV, DAT, VOB, OGM, ASF (support
maximum resolution 720p).
Functions on video: video selection, play, pause, previous video, next video and
aspect ratio selection.
Radio (AM/FM)
USA/Europe/Latin America/Asia Frequency Spacing.
30 station presets (18FM / 12AM).
5 bands (FM1 / FM2 / FM3 / AM1 / AM2).
Automatic search (start at the current frequency to search all FM and AM
stations automatically, 30 of them with the strongest signal would be stored in
the station presets).
Search and play (start at the current frequency to search all FM and AM stations
automatically, every searched station will be played for 10 seconds before
searching for the next station).
Station preset storage (store the current station to a preset memory in a band).
Preset station recall (recall a preset station in a band).
Local / Distance.

Bluetooth
Support HFP, A2DP and AVRCP.
Support external microphone.
Main functions:
•Direct dial (on screen keypad)
•Missed call list
•Received call list
•Dialed call list
•Phone book
•Bluetooth audio (play, pause, previous track, next track)
Functions during phone conversation
•End call
•Transfer to phone (transfer a call back to mobile phone)
•Mute
•Keypad
•Redial
When a call is received, the unit will mute audio output and pause disc play, and
switch to Bluetooth conversation screen.
USB
Support maximum capacity: 32GB.
USB 1.0 and USB 2.0 compatible.
Support audio format: MP3, WAV, AAC, FLAC, WMA, APE.
Functions on audio: play, pause, previous track, next track, random play, repeat
play, track selection.
Support picture format: JPEG, JPG, GIF, PNG, BMP.
Functions on picture: play, pause, previous picture, next picture, picture
selection.
Support video format: MPEG 1 / 2 / 4, XivD, MP4, MOV, AVI, WMV, ASF, FLV, MKV,
VO B, DAT, MPG OGM , RM, RMVB (support maximum resolution 720p).
Functions on video: play, pause, previous video, next video, aspect ratio selection,
video selection.

CHASSIS
Double DIN (mountable).
Fixed front panel.
6.2” high definition TFT LCD.
800 x 3 (RGB) x 480 resolution.
GENERAL
Front / Rear USB input.
Front A/V aux input for portable media.
Front micro SD reader.
Rear composite video and audio output.
Rear subwoofer output.
Rear composite video and audio input.
Rear camera video and audio input.
Touch screen calibration mode.
Steering wheel key controls.
Built-in Bluetooth with microphone, providing Hands-Free operation (dial /
answer / phone book / call list synchronization), and A2DP for streaming audio
from your smartphone or other Bluetooth compatible devices.
Built-in 4 x 25Watt RMS output amplifier.
Automatic antenna control.
Pre Amplifier Control.
NAVIGATION
Only insert the Furrion map SD to use navigation function. For more information
or to purchase maps, please visit: www.furrion.com/maps.
Latest map guarantee (limited time only – within 30 days of initial activation).
CAMERA
When camera and signal wire is connected and operated properly, CAMERA
mode will be activated automatically when there is signal.
Image Display of Automatic Car Reversing Function in Shutdown Mode

I
IN NS ST TA AL LL LA AT TI IO ON N A AN ND D U US SA AG GE E R RE EQ QU UI IR RE EM ME EN NT TS S
Operation temperature: -20 to +70 degree Celsius.
Operation humidity: 45 to 80% relative humidity.
Storage temperature: -30 to +80 degree Celsius.
Storage humidity: 30 to 90% relative humidity.
Atmospheric pressure: 860 to 1,060 mbar.
Operation voltage: 10.5 – 16.0V DC, negative ground.
Fuse: 15-amps.
Standby current: ACC OFF ≤5mA.
DIN chassis dimensions: 178mm x 153mm x 100mm.

O
OP PE ER RA AT TI IO ON NA AL L P PA AN NE EL L
FUNCTIONS OF BUTTONS
[MICROPHONE]
This is used for Bluetooth phone.
[IR] SENSOR
Receiver for the remote control unit
[MICRO SD SLOT]
Note – The micro SD card is only for navigation purpose, please do not insert
micro SD card for other purposes. When the navigation function is activated,
do not remote micro SD card.
[POWER / VOL] KNOB
Press this knob to turn on the power.
Press this knob for more than 2 seconds to turn off the power.
Turn this knob clockwise or counter-clockwise to increase or decrease the
volume of the system.
[NAVI] BUTTON
Press this button to activate navigation function, press again to return to
current source.
[NAVI]
[USB]
[ ]
[RESET]
[MICRO SD SLOT]
[COVER]
[POWER/VOL]

[] EJECT
Press to eject the disc from the unit.
[AUX IN]
AUX connector on front panel.
[USB] PORT
USB connector
[RESET] BUTTON
Press this button to reset the unit in hardware.

R
RE EM MO OT TE E C CO ON NT TR RO OL L
REMOTE CONTROL FUNCTIONS
1 -[POWER] Button
•Press this button to power on when the unit is power off.
•Press this button more than 1 second to power off when the unit is
power on.
2 -[EJECT]Button
•Press to eject disc from the unit.
3 -[MUTE] Button
•Mute or unmute the speaker.
2
1
3
4
6
7
8
11
10
9
14
15
12
16
13
18
17
19
22
23
21
20
25
24
26
27
5

4 -[MODE]Button
•Press this button to switch between sources.
5 -[0 – 9] Buttons
•Use in the key pad screen to select the radio.
•Use to select the track in the track list screen.
•Press to enter DVD video chapters/titles in the key pad screen.
6 -[VOL+] Button
•Increase volume.
7 -[VOL-] Button
•Decrease volume.
8 -[OSD] Button
•Press to enter on screen display on DVD mode.
9 -[SEL] Button
•Press to enter audio setting.
10 -[STOP/BAND] Button
•Short Press to stop video and audio media.
•Long press to switch to next band alternately.
11 -[SEARCH] Button
•Press this button to open chapter or title search window while playing
DVD and USB.
12 -[BACK] Button
•Press this button to quit main menu if current screen is main menu.
13 -[UP/DOWN/LEFT/RIGHT/OK]Buttons
•Press UP/DOWN/LEFT/RIGHT for cursor movement in main menu or
setting mode.
•From the main menu, you can select your desired source or change your
settings.
•Press OK to fix the entered data in the key pad screen or enter the item
the cursor is on.
14 -[SETUP] Button
•Press this button to enter the main setting menu or return current
resource.
15 -[PIC]Button
•Press this button to enter monitor brightness setting.
16 -[A-B] Button
•Press to start demo playback from A to B.
17 -[RPT] Button
•Press to perform chapter repeat / title repeat / repeat off while playing
DVD mode.
•Press to perform repeat track / repeat all while playing CD.
•Press to perform repeat track / repeat folder / repeat all while playing
audio or video files on disc.
•Press to perform repeat track / repeat folder / repeat all while playing
audio or video files in USB memory.

18 -[ROOT]Button
•Press to go to the root menu on the DVD.
19 -[TITLE]
•Press to go to the title menu on the DVD.
20 -[PREVIOUS] Button
•Press to seek the next available lower station in Tuner mode.
•Press to select the next lower chapter number in DVD video mode.
•Press to select the next lower track in CD, USB Video, USB Audio mode.
21 -[NEXT] Button
•Press to seek the next available higher station in Tuner mode.
•Press to select the next higher chapter number in DVD video mode.
•Press to select the next higher track in CD, USB Video, USB Audio mode.
22 -[FAST BACKWARD] Button
•Press to manually select the next lower station in Tuner mode.
•Press to perform fast-backward searching. Press again to change the
speed to 2X, 4X, 8X or 16X.
23 -[FAST FORWARD] Button
•Press to manually select the next higher station in Tuner mode.
•Press to perform fast-forward searching. Press again to change the
speed to 2X, 4X, 8X or 16X.
24 -[SUB-T] Button
•Press to switch next available subtitle while playing DVD.
25 -[ANGLE]Button
•Press to switch the different angle while playing DVD. (Not all DVD disc
support this function).
26 -[AUDIO]Button
•Press to switch the audio channel of the disc while playing DVD.
27 -[ZOOM]Button
•Press to turn on and zoom in while playing DVD. You can zoom in up to
3X (Not all DVD disc support this function).

W
WH HE EE EL L K KE EY Y S ST TU UD DY Y
1. Touch the [setup] button on the Main Menu.
2. Touch the [Others] button. The below menu is displayed.
3. Touch the [Wheel Key Study] button. The below menu will be displayed.
1 -Restudy
2 -Mode 1
3 -Mode 2
4 -Source
5 -Previous
6 -Volume +
7 -End a call
8 -Mute
9 -Next
10 -Volume -
11 -Call
2
3
1
5
9
8
10
11
4
6
7

M
MA AI IN N M ME EN NU U
1 -Radio --- Touch the button to display the Radio mode.
2 -AUX1 --- Touch the button to display the AUX1 mode.
14
15
1
2
7
3
4
5
6
8
9
11
13
12
10

3 -USB Audio --- Touch the button to display the USB Audio mode.
4 -Disc Audio --- Touch the button to display the Disc Audio mode.
5 -Bluetooth Audio --- Touch the button to display the Bluetooth Audio mode.
6 -Camera --- Touch the button to display the Camera mode.
7 -Back --- Touch the button to display current play mode.
8 -Setup --- Touch the button to display the Setup menu.
9 -Telephone --- Touch the button to display the Telephone mode.
10 -AUX2 --- Touch the button to display the AUX2 mode.
11 -USB Video --- Touch the button to display the USB Video mode.
12 -Disc Video --- Touch the button to display the Disc Video mode.
13 -Navi --- Touch the button to display the Navigation mode.
14 -Background --- Touch the background to display the Main Menu.
15 -Clock
SCROLLING THE MENU
Flicking to right or left it will switch to next or previous page of Main Menu.
MOVING THE ICON POSITION
1. Touch any icon on Main Menu more than 3 seconds, the icon will float on Main
Menu.
2. Scrolling the floating icon to any position you want.

D
DI IS SC C V VI ID DE EO O P PL LA AY YE ER R O OP PE ER RA AT TI IO ON NS S
DVD SYSTEM SETUP
Note: If the setup operation is made in the middle of DVD video play, the disc will
re-start from the beginning.
WATCH A DISC
1. To read a disc:
Insert the disc into the center of the disc insertion slot with label side facing up.
CAUTION – For your safety, the driver should not insert or eject a disc, opening
operation panel while driving.
Note:
Do not insert foreign objects into the disc insertion slot.
If there is difficulty inserting the disc, there may be another disc in the system, or
the system may require service.
8cm discs are not allowed.
2. Disc starts playing automatically.
EJECT A DISC
1. To eject a disc press eject [] button to eject the disc. The play mode then
switches to the Radio mode.
If the disc is left in the ejected position for 15 seconds, the disc is automatically
reloaded. In this case, the play mode will remain in the Radio mode.
Note: If you force a disc into the system before automatic reload, it may damage a
disc.
DVD PLAYER MODE SCREEN
Touch any place of the screen to display DVD Video menu, touch the screen again to
return the playback. The display will return to the playback screen, if you do not
touch the screen for 7 seconds.

1 -Previous Chapter / Fast Backward button
2 -Play / Pause
3 -Next Chapter / Fast Forward button
4 -Subtitle switching button
5 -Repeat switching button
6 -Direct chapter or title searching button
7 -Audio Channel switching button
8 -Menu List button
9 -Total time
10 -DVD playback information
11 -Seek bar
12 -Elapsed playing time
13 -Return button (to Main Menu)
14 -System time
15 -Title information
16 -Chapter information
DVD PLAYER MENU OPERATION
Select the buttons displayed in the DVD Player Menu by direct touching it.
Play/Pause Playback
1. Touch [ ] button to pause during playback.
10
16
14
15
6
5
3
4
2
7
11
1
8
12
9
13

2. Touch [ ] button again to resume playback.
Skip a Chapter
1. Touch [ ] or [ ] button during playback.
Chapters are skipped down or up from current location, as many times as the button
is touched, and playback starts.
Skip by Seek Bar
Touch [ ] on seek bar and drag it to any position where you want to start playback.
Fast Forward / Fast Backward
1. Touch [ ] or [ ] button and hold 2 seconds to start fast backward or fast
forward during playback. The playback speed starts at 2x, then will increase to 4x,
8x and 16x. Release the button will continue playing with normal speed.
Note:
During fast forward and fast backward operation, there is no audio
reproduced.
The fast forward and fast backward speed may differ depending on the disc.
Search
1. In the DVD Video menu, touch [ ] button. The keypad screen appears with
the chapter/title number input mode.
Touch [Chapter] button turns the keypad to the chapter number input mode.
Touch [Title] button turns the keypad to the title number input mode.
Title: A large segment to divide the data area of the disc.
Chapter: A small segment to divide the data area of the disc.
2. Input the number of the chapter/title that you want to play with the [0] to [9]
key.

3. Touch [] button.
Playback starts from the scene of the input chapter number or title number.
Note:
If the input chapter/title number does not exist or searching with a
chapter/title is not allowed, the screen image will not change.
4. Touch [] button to close the keypad.
Repeat Playback
1. In the DVD Video menu, touch [] button.
2. Touch [ ] button once for Repeat Chapter, again for Repeat Title.
3. Touch [ ] button again to turn off the repeat playback.
Title Menu

1. In the DVD Video menu, touch [] button during playback.
Depending on the disc, the title menu may not be called.
2. Touch [ ] on the title menu screen.
3. Select the items in the title menu screen by directional buttons.
Depending on the disc, items may not be selected with the directional
buttons.
4. Touch [] button to fix on the selected item.
5. Touch [ ] button..
6. Touch [ ] button to close the title menu screen.

Audio Switch
For discs with two or more audio languages recorded, you can switch among the
audio languages during playback.
1. In the DVD Video menu, touch [ ] button during playback.
Each time you touch the button, you can switch among audio languages.
It may take time to switch among audio languages.
Depending on the disc, up to 8 kinds of audio languages may be recorded. For
detail, see the mark of the disc: ( indicates that8 audio languages
have been recorded).
When the power is turned on and when the disc is changed to a new one, the
audio language set as factory default is selected. If that audio language has
not been recorded on disc, the audio language is specified on the disc.
Depending on the disc, audio switch may be completely impossible or
impossible on some scenes.
Subtitle Switch
For discs with two or more subtitle languages recorded, you can switch among the
subtitle languages during playback.
1. In the DVD Video menu, touch [ ] button to select a subtitle during playback.
Each time you touch the button, you can switch among subtitles.
It may take time to switch among subtitles.
Depending on the disc, up to 32 kinds of subtitles may be recorded. For detail,
see the mark of the disc: ( indicates that 8 kinds of subtitles have been
recorded).
When the power is turned on and when the disc is changed to a new one, the
subtitle set as factory default is selected. If that subtitle has not been
recorded on disc, the subtitle is specified on the disc.
Depending on the disc, subtitle switch may be completely impossible or
impossible on some scenes.
2. To turn off subtitles, repeat touching [ ] until subtitles are turned off.
