Advida P-25 User manual

Before attempting to connect or operate this product, please read these
instructions carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.
Installation Guide
Included Installation Instructions
Network Camera
Model No.
P-25

2
WARNING:
• To prevent injury, this apparatus must be
securely attached to the wall/ceiling in
accordance with the installation instructions.
•
All work related to the installation of this
product should be made by qualified service
personnel or system installers.
• The installation shall be carried out in accor-
dance with all applicable installation rules.
•
The connections should comply with local
electrical code.
• Batteries (battery pack or batteries installed)
shall not be exposed to excessive heat such
as sunlight, fire or the like.
CAUTION:
• Any changes or modifications not expressly
approved by the party responsible for compli-
ance could void the user’s authority to operate
the equipment.
• The network camera is only intended for a con-
nection to an ethernet or PoE network without
routing to the outside plant.
NOTE: This equipment has been tested and
found to comply with the limits for a Class A digi-
tal device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference when the
equipment is operated in a commercial environ-
ment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed
and used in accordance with the instruction man-
ual, may cause harmful interference to radio com-
munications.
Operation of this equipment in a residential area
is likely to cause harmful interference in which
case the user will be required to correct the inter-
ference at his own expense.
FCC Caution: To assure continued compliance,
(example - use only shielded interface cables
when connecting to computer or peripheral
devices). Any changes or modifications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate this equipment.
For U.S.A
The model number and serial number of this
product may be found on the surface of the unit.
You should note the model number and serial
number of this unit in the space provided and
retain this book as a permanent record of your
purchase to aid identification in the event of
theft.
Model No.
Serial No.
For U.S.A
CAN ICES-3(A)/NMB-3(A)
For Canada

3
Contents
Important safety instructions......................................................................................................... 4
Limitation of liability....................................................................................................................... 5
Disclaimer of warranty................................................................................................................... 5
Preface .......................................................................................................................................... 5
Main functions............................................................................................................................... 6
About the user manuals ................................................................................................................ 7
System requirements for a PC ...................................................................................................... 7
Trademarks and registered trademarks......................................................................................... 8
Copyright....................................................................................................................................... 8
Network security ........................................................................................................................... 9
Precautions ................................................................................................................................. 10
Precautions for installation.......................................................................................................... 14
Major operating controls ............................................................................................................. 16
Preparations ................................................................................................................................ 18
Installations/Connections............................................................................................................ 19
Insert/remove an SD memory card* ............................................................................................ 28
Adjustment .................................................................................................................................. 29
Mounting the front cover............................................................................................................. 32
Attaching the mounting surface on the top surface of the camera body.................................... 33
Configure the network settings ................................................................................................... 36
Troubleshooting........................................................................................................................... 38
Specifications.............................................................................................................................. 40
Standard accessories.................................................................................................................. 45
* SDXC/SDHC/SD memory card is described as SD memory card.

4
Important safety instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not block any ventilation openings. Install in accordance with the manufacturer's instruc-
tions.
6) Do not install near any heat sources such as radiators, heat registers, stoves, or other appara-
tus (including amplifiers) that produce heat.
7) Only use attachments/accessories specified by the manufacturer.
8) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use caution when moving the cart/apparatus combi-
nation to avoid injury from tip-over.
S3125A
9) Unplug this apparatus during lightning storms or when unused for long periods of time.
10) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.

5
Limitation of liability
THIS PUBLICATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE, OR NON-INFRINGEMENT OF
THE THIRD PARTY'S RIGHT.
THIS PUBLICATION COULD INCLUDE TECHNICAL INACCURACIES OR TYPOGRAPHICAL
ERRORS. CHANGES ARE ADDED TO THE INFORMATION HEREIN, AT ANY TIME, FOR THE
IMPROVEMENTS OF THIS PUBLICATION AND/OR THE CORRESPONDING PRODUCT (S).
Disclaimer of warranty
IN NO EVENT SHALL advidia BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR
REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES,
INCLUDING BUT NOT LIMITED TO BELOW:
(1) ANY LOSS OR DAMAGE, INCLUDING WITHOUT LIMITATION, DIRECT OR INDIRECT,
SPECIAL, CONSEQUENTIAL OR EXEMPLARY, ARISING OUT OF OR RELATING TO THE
PRODUCT;
(2) ANY INCONVENIENCE, LOSS, OR DAMAGE CAUSED BY INAPPROPRIATE USE OR
NEGLIGENT OPERATION OF THE USER;
(3) ALL MALFUNCTIONS OR TROUBLES FROM UNAUTHORIZED DISASSEMBLE, REPAIR OR
MODIFICATION OF THE PRODUCT BY THE USER, REGARDLESS OF THE CAUSE OF THE
MALFUNCTION OR TROUBLE;
(4) INCONVENIENCE OR ANY LOSS ARISING WHEN IMAGES ARE NOT DISPLAYED, DUE TO
ANY REASON OR CAUSE INCLUDING ANY FAILURE OR PROBLEM OF THE PRODUCT;
(5) ANY PROBLEM, CONSEQUENTIAL INCONVENIENCE, OR LOSS OR DAMAGE, ARISING
OUT OF THE SYSTEM COMBINED BY THE DEVICES OF THIRD PARTY;
(6) ANY CLAIM OR ACTION FOR DAMAGES, BROUGHT BY ANY PERSON OR ORGANIZATION
BEING A PHOTOGENIC SUBJECT, DUE TO VIOLATION OF PRIVACY WITH THE RESULT OF
THAT SURVEILLANCE-CAMERA'S PICTURE, INCLUDING SAVED DATA, FOR SOME
REASON, BECOMES PUBLIC OR IS USED FOR ANY PURPOSE;
(7) LOSS OF REGISTERED DATA CAUSED BY ANY FAILURE.
The network camera P-25 is designed to operate using a PC on a network (10BASE-T/
100BASE-TX), and can be installed outdoors.
By connecting to a network (LAN) or the Internet, images and audio from the camera can be moni-
tored on a PC via a network.
Note:
 • It is necessary to configure the network settings of the PC and its network environment to
monitor images from the camera on the PC. It is also necessary to install a web browser on the
PC.
Preface

6
Equipped with a new codec engine
The redesigned codec engine can output up to 60 frames per second in Full-HD quality.
The equipped enhanced Super Dynamic function makes it possible to achieve 133 dB
dynamic range.
By combining images taken at different shutter speeds and using pixel level brightness correction,
more natural looking pictures can be taken even when objects have large differences in illumination.
* When frame rate is set to 60 fps,Off is displayed for Super Dynamic function.
Equipped with a high-sensitivity MOS sensor and noise reduction function (MNR)
The high-sensitivity sensor and new method of noise reduction (MNR: Multi-process Noise
Reduction)*1 make it possible to take easy-to-view images even under low illumination conditions.
*1 With the multi-process noise reduction that prioritizes noise reduction for central areas and reso-
lution for edge areas where noise is prominent, MNR is able to produce clear images while limit-
ing noise across the entire image.
IR LED equipped
The equipped infrared LED makes it possible to take pictures at zero lx of objects as far as 30 m
{98.43 feet} away.
Equipped with 2 SD memory card slots and enhanced image recording
 • Byusing2SDmemorycardssequentially,imagescanberecordedoverlongperiodsoftime.
 • Thedualrecordingfunction(recordingimageson2SDmemorycardssimultaneously)makesit
possible to back up data.
The camera conforms to the IP66*3 and Type 4X (UL50)*4, is compliant with NEMA 4X*5
ratings, and provides high dust resistance and waterproof performance.
Waterproofing treatment is not required for the camera body (waterproofing treatment is required
for cable connections).
*3 IP66 rating: The applicable product has "Dust tight (6)" protection against foreign solids and has
"Powerful water jets (6)" against water (IEC60529).
*4 Type 4X (UL50): "4X" is a grade of the waterproofing standard of UL.
*5 NEMA: Dust resistance and waterproof performance standards set by National Electrical
Manufacturers Association (United States).
Main functions

7
About the user manuals
There are 2 sets of operating instructions for the P-25 as follows.
 • InstallationGuide:Explainshowtoinstallandconnectdevices.
 • Operating Instructions (included in the CD-ROM): Explains how to perform the settings and
how to operate this camera.
Adobe®Reader®is required to read these operating instructions on the provided CD-ROM.
When the Adobe Reader is not installed on the PC, download the latest Adobe Reader from the
Adobe web site and install it.
The external appearance and other parts shown in this manual may differ from the actual product
within the scope that will not interfere with normal use due to improvement of the product.
English screens are used in these operating instructions.
System requirements for a PC
CPU: Intel®CoreTM 2 Duo 2.4 GHz or faster recommended
Memory: A minimum of 1 GB or more (for 32-bit OSs), 2 GB or more (for 64-bit OSs)
memory is required when using Microsoft®Windows®8.1, Microsoft®
Windows®8, Microsoft®Windows®7.
A minimum of 1 GB or more memory is required when using Microsoft®
Windows Vista®.
Network interface: 10BASE-T/100BASE-TX 1 port
Audio interface: Sound card (when using the audio function)
Monitor: Image capture size: 1024 x 768 pixels or more
Color: 24-bit True color or better
OS: Microsoft®Windows®8.1
Microsoft®Windows®8
Microsoft®Windows®7
Microsoft®Windows Vista®
Web browser: Windows®Internet Explorer®11 (32-bit)
Windows®Internet Explorer®10 (32-bit)
Windows®Internet Explorer®9 (32-bit)
Windows®Internet Explorer®8 (32-bit)
Windows®Internet Explorer®7 (32-bit)
Others: CD-ROM drive
(It is necessary to read the operating instructions and use the software on
the provided CD-ROM.)
Adobe®Reader®
(It is necessary to view the PDF file on the provided CD-ROM.)

8
IMPORTANT:
 • Forinformationontheoperationverificationofthesupportedoperatingsystemsandwebbrows-
ers, refer to our website at http://advidia.com/cameras/.
 • When using a PC that does not meet the above requirements, displaying of images may
become slower or the web browser may become inoperable.
 • Audio may not be heard if a sound card is not installed on a PC. Audio may be interrupted
depending on the network environment.
 • MicrosoftWindowsRT,MicrosoftWindows7StarterandMicrosoftWindowsVistaStarterare
not supported.
 • WhenusingWindows8.1orWindows8,useitinthedesktop.Thesoftwarecannotbeusedin
the Modern UI design.
Note:
 • For further information about PC system requirements and precautions for when using Microsoft
Windows 8.1, Microsoft Windows 8, Microsoft Windows 7, Microsoft Windows Vista, or Windows
Internet Explorer, click "Manual" - "Open" from the supplied CD-ROM and refer to "Notes on
Windows®/ Internet Explorer®versions".
Trademarks and registered trademarks
 • Adobe,AcrobatReader,andAdobeReaderareeitherregisteredtrademarksortrademarksof
Adobe Systems Incorporated in the United States and/or other countries.
 • Microsoft,Windows,WindowsVista,WindowsMedia,InternetExplorer,andActiveXareeither
registered trademarks or trademarks of Microsoft Corporation in the United States and/or other
countries.
 • Microsoftproductscreenshot(s)reprintedwithpermissionfromMicrosoftCorporation.
 • IntelandIntelCorearetrademarksofIntelCorporationintheU.S.andothercountries.
 • SDXCLogoisatrademarkofSD-3C,LLC.
 • iPad, iPhone, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other
countries.
 • AndroidisatrademarkofGoogleInc.
 • Allothertrademarksidentifiedhereinarethepropertyoftheirrespectiveowners.
Copyright
Distributing, copying, disassembling, reverse compiling and reverse engineering of the software
provided with this product are all expressly prohibited. In addition, exporting any software provided
with this product violating export laws is prohibited.

9
Network security
As you will use this unit connected to a network, your attention is called to the following security
risks.
①Leakage or theft of information through this unit
②Use of this unit for illegal operations by persons with malicious intent
③Interference with or stoppage of this unit by persons with malicious intent
It is your responsibility to take precautions such as those described below to protect yourself
against the above network security risks.
 • Usethisunitinanetworksecuredbyafirewall,etc.
 • If this unit is connected to a network that includes PCs, make sure that the system is not
infected by computer viruses or other malicious entities (using a regularly updated anti-virus
program, anti-spyware program, etc.).
 • Protectyournetworkagainstunauthorizedaccessbyrestrictinguserstothosewhologinwith
an authorized user name and password.
 • Applymeasuressuchasuserauthenticationtoprotectyournetworkagainstleakageortheftof
information, including image data, authentication information (user names and passwords),
alarm mail information, FTP server information and DDNS server information.
 • Aftertheunitisaccessedbytheadministrator,makesuretoclosethebrowser.
 • Changetheadministratorpasswordperiodically.
 • Do not install the camera in locations where the camera or the cables can be destroyed or
damaged by persons with malicious intent.

10
Precautions
Refer installation work to the dealer.
Installation work requires technique and experi-
ences. Failure to observe this may cause fire,
electric shock, injury, or damage to this product.
Be sure to consult the dealer.
Stop the operation immediately when
something is wrong with this product.
When smoke goes up from the product, the
smell of smoke comes from the product, or the
exterior of the product has deteriorated, con-
tinued use will cause a fire or fall of the product
resulting in injury, or damage to the product.
In this case, turn the power off immediately and
contact qualified service personnel for service.
Do not attempt to disassemble or modify
this product.
Failure to observe this may cause fire or elec-
tric shock.
Consult the dealer for the repair or inspections.
Do not insert any foreign objects.
Fire or electrical shock may be caused if water
or any foreign objects, such as metal objects,
enter inside the unit.
Turn the power off immediately and contact
qualified service personnel for service.
Select an installation area that can sup-
port the total weight.
Selecting an inappropriate installation surface
may cause this product to fall down or topple
over, resulting in injury or accidents.
Installation work shall be started after sufficient
reinforcement.
Periodic inspections shall be conducted.
Rust on the metal parts or screws may cause a
fall of the product resulting in injury or acci-
dents.
Consult the dealer for the inspections.
Do not use this product in an inflammable
atmosphere.
Failure to observe this may cause an explosion
resulting in injury.
Avoid installing this bracket in the loca-
tions where salt damage occurs or corro-
sive gas is produced.
Otherwise, the mounting portions will deterio-
rate and accidents such as a fall of the product
may occur.
Do not install this product in locations
subject to vibration.
Loosening of mounting screws or bolts may
cause a fall of the product resulting in injury or
accidents.
Install this product in a location high
enough to avoid people and objects from
bumping the product.
Failure to observe this may cause injury.
Do not hang down from this product or
use this product as a pedestal.
Failure to observe this may cause a drop
resulting in accidents.
Do not strike or give a strong shock to this
product.
Failure to observe this may cause fire or injury.
Turn the power off when do wiring of this
product.
Failure to observe this may cause electric
shock. In addition, short circuit or wrong wiring
may cause fire.
The exclusively designed mount bracket
shall be used.
Failure to observe this may cause a drop
resulting in injury or accidents.
Use the exclusively designed mount bracket for
installation.

11
The screws and bolts must be tightened to
the specified torque.
Failure to observe this may cause a drop
resulting in injury or accidents.
Do not rub the edges of metal parts with
your hand.
Failure to observe this may cause injury.
Do not install or clean the camera, or
touch this product, the power cable or the
connected cables during thunder storms.
Failure to observe this may cause electric shock.
Keep SD memory card away from infants
and children.
Otherwise, they may swallow the card by mis-
take.
In this case, consult a doctor immediately.
The measures of protection against snow-
fall shall be taken.
In areas where lots of snow accumulates, the
weight of snow may cause the product to fall
resulting in injury or accidents. Protect the
product against snowfall by installing under
eaves.
Be sure to install the safety wire.
The measures of protection against a fall
of this product shall be taken.
Failure to observe this may cause a drop result-
ing in injury or accidents.
Do not damage the power cable.
Do not damage, fabricate, twist, stretch, bun-
dle,
or forcibly bend the power cable. Do not
place heavy objects on it, and keep it away
from heat sources.
Use of a damaged power cable may cause
electric shock, short circuit, or fire.
Consult the dealer for repair.
Correctly perform all wiring
Short circuits in the wiring or incorrect wiring
may cause fire or electrical shock.
Do not install this product on a place that
is greatly influenced by wind.
Installation on a place where the wind speed is
60 m {196.85 feet} or more per second may
cause a fall of the product resulting in injury or
accidents.
Turn the power off when cleaning this product.
Failure to observe this may cause injury.
[Precautions for use]
This product has no power switch.
When turning off the power, disconnect the
power supply from the 12 V DC power supply or
the PoE device.
To keep on using with stable performance
Do not use this product in hot and humid con-
ditions for a long time. Failure to observe this
causes component degradation resulting in life
shortening of this product.
Do not expose the product to direct heat
sources such as a heater.
Do not touch the front cover (transparent
cover) with your bare hands.
A dirty cover causes deterioration of picture quality.
Handle this product with care.
Do not drop this product, nor apply shock or
vibration to the product. Failure to observe this
may cause trouble. If a strong shock or vibra-
tion is applied to the front cover, it may cause
damage or allow water to enter this product.
About the battery
A battery is installed inside the camera. Do not
leave the battery exposed in environments of
excessive heat as a result of sunlight or fire.
About the PC monitor
Displaying the same image on a monitor for a
long time may damage the monitor. It is recom-
mended to use a screen-saver.

12
When an error is detected, this product
will restart automatically.
This product will be inoperable for around 2
minutes after the restart just as when the power
is turned on.
About the automatic status detection
function
When this product malfunctions due to exoge-
nous noise, etc. for 30 seconds or more, the
product will automatically reset and will return to
normal state. When the product is reset, initializa-
tion will be carried out as when the power of the
product is turned on. When the product repeat-
edly resets, exogenous noise level around the
product may be high and that may cause mal-
function. Contact your dealer for instructions.
Product disposal/transfer
Data saved on this product or a storage device
used with this product may lead to personal
information leakage.
When it is necessary to dispose or give this
product to someone, even when for repair, make
sure that there is no data on this product.
Cleaning this product body
Be sure to turn off the power before cleaning.
Failure to observe this may cause injury. Do not
use strong abrasive detergent when cleaning
this product. Otherwise, it may cause discolor-
ation. When using a chemical cloth for clean-
ing, read the caution provided with the chemi-
cal cloth product.
Cleaning the lens
Use a lens cleaning paper (used to clean cam-
era lenses or lenses of spectacles). When using
solvent, use an alcohols solvent and do not use
a thinner or a glass cleaner.
Transmission interval
Image transmission interval may become slow
depending on the network environment, PC
performance, shooting subject, access num-
ber, etc.
Periodically images on the screen appear
to be distorted
When the camera is installed in a location where
it is subject to small vibrations (for example, when
it is installed near devices that vibrate), images
may appear distorted and stretched lengthways.
This phenomenon is a characteristic of image
pickup devices that use CMOS sensors and is
caused by the relationship between the periodic
movements of the camera and the timing that the
image sensor reads images. This is not a prob-
lem with the camera. To reduce the possibility of
this phenomenon occurring, install the camera in
a secure location.
About SD memory card
 • To remove the SD memory card from the
unit, press the [Setup] button on the “Live”
page, select the [SD memory card] tab,
and set the SD memory card operation to
“Not use”. Then, remove the SD memory
card. Alternatively, hold down the SD ON/
OFF button for about 2 seconds. When
the flashing SD MOUNT lamp goes out,
you can remove the SD memory card.
 • WhenusinganSDmemorycard,formatit
using this product. Recorded data on the
SD memory card will be deleted when for-
matted. If an unformatted SD memory card
or an SD memory card formatted with
other devices is used, this product may
not work properly or performance deterio-
ration may be caused. Refer to the
Operating Instructions on the provided
CD-ROM for how to format an SD memory
card.
 • When some SD memory cards are used
with this product, the product may not work
properly or performance deterioration may
be caused. Use the SD memory cards rec-
ommended in page 44.
 • WhenusinganSDmemorycardsupporting
Class 10 of the speed class, use a UHS-I
(Ultra High Speed-I) compliant card.

13
About the MOS image sensor
 • Whencontinuouslyshootingabrightlight
source such as a spotlight, the color filter
of the MOS image sensor may become
deteriorated and this may cause
discoloration.
Even when changing the fixed shooting
direction after continuously shooting a
spotlight for a certain period, the
discoloration may remain.
 • Whenshootingfast-movingsubjectsor
objects crossing the shooting area may look
to be bending askew.
Code label
The code labels (accessory) are required at
inquiry for trouble. Use caution not to lose
these labels. It is recommended to paste one
of the labels onto the CD-ROM case.
AVC Patent Portfolio License
THIS PRODUCT IS LICENSED UNDER THE
AVC PATENT PORTFOLIO LICENSE FOR THE
PERSONAL USE OF A CONSUMER OR
OTHER USES IN WHICH IT DOES NOT
RECEIVE REMUNERATION TO (i) ENCODE
VIDEO IN COMPLIANCE WITH THE AVC
STANDARD ("AVC VIDEO") AND/OR (ii)
DECODE AVC VIDEO THAT WAS ENCODED
BY A CONSUMER ENGAGED IN A
PERSONAL ACTIVITY AND/OR WAS
OBTAINED FROM A VIDEO PROVIDER
LICENSED TO PROVIDE AVC VIDEO. NO
LICENSE IS GRANTED OR SHALL BE
IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM
MPEG LA, L.L.C.
SEE HTTP://WWW.MPEGLA.COM
Equipment classification and power
source indication label
Refer to the indication label on the bottom side
of this unit for the equipment classification,
power source, and other information.
: Direct current symbol
About the dehumidifying device
 • This product has dehumidifying device to
keep the inside at low moisture level, pre-
venting condensation and quickly dissipat-
ing dew if produced.
 • Dew may be produced depending on the
conditions of temperature, humidity, winds,
and rain, and it may take time to dehumidify.
 • Neversealthesurfacesofthedehumidify-
ing device.
Dehumidifying device

14
Precautions for installation
Installation area for this product
Contact your dealer for assistance if you are
unsure of an appropriate place in your particu-
lar environment.
 • Make sure that the installation area is
strong enough to hold this product, such
as a concrete ceiling.
 • Installthecamerainthefoundationareaof
the architecture or where sufficient strength
is assured.
 • If a wall or ceiling board such as plaster
board is too weak to support the total
weight, the area shall be sufficiently rein-
forced.
Do not place this product in the following
places:
 • Locationswhereachemicalagentisused
such as a swimming pool
 • Locations subject to oil smoke such as a
kitchen
 • Locationsthathaveaspecificenvironment
that is subject to an inflammable atmo-
sphere or solvents
 • Locations where a radiation, an X-ray, a
strong radio wave or a strong magnetic
field is generated
 • Locations where corrosive gas is pro-
duced, locations where it may be damaged
by briny air such as seashores
 • Locations where the temperature is not
within the specified range (☞ page 40).
 • Locationssubjecttovibrations,suchason
vehicles, marine vessels, or above product
lines (This product is not designed for on-
vehicle use.)
Check before installation
Compatibility of devices is restricted. Before
installation, check the ratings and dimensions
of the devices to be used.
Contact your dealer for details.
Before installation
 • Usethecameramountbracket(accessory)
to install the camera on the ceiling or wall.
 • Anchorboltsandscrewsusedtomount
the camera on the ceiling or wall are not
supplied. Prepare bolts and screws that
match the structure and materials of the
installation location and satisfy the
performance and reliability specifications
shown below.
 • Requiredscrews:
Directly installed on a wall or ceiling:
M5 screw x4
Secure the camera to a two-gang junction
box:
M4 screw with Spring washer and ø7.5
～10 Washer x4
Secure the adapter box: M5 screw x4
 • Minimumpull-outstrength:539N{121lbf}
(per 1 pc.)
Power supply
This product has no power switch.
When turning off the power, turn off a power
supply or remove a power cable. When the
power cable of the product is connected to the
power supply device, the power will be
supplied to the product.
Before cleaning the product, make sure that
the power cable is not connected to the main
power supply.
About the network connection
When connecting to a network using the network
cable of this product, observe the following.
 • When wiring for the network, design and
engineer not to be affected by thunder.
 • It is impossible to install this product in
combination with a pan/tilt head.
Advidia assumes no responsibility for injuries or property damage resulting from failures
arising out of improper installation or operation inconsistent with this documentation.

15
Screw tightening
 • Thescrewsandboltsmustbetightened
with an appropriate tightening torque
according to the material and strength of
the installation area.
 • Donotuseanimpactdriver.Useofan
impact driver may damage the screws or
cause tightening excessively.
 • Whenascrewistightened,makethe
screw at a right angle to the surface. After
tightening the screws or bolts, perform
checks to ensure that the tightening is
sufficient enough so that there is no
movement or looseness.
The measures of protection against a fall
of this product shall be taken.
Failure to observe this may cause a drop resulting
in injury or accidents. Be sure to install the safety
wire.
Procure fixing screws separately.
The screws that secure this product are not
supplied. Prepare them according to the mate-
rial and strength of the area where the product
is to be installed.
Radio disturbance
When this product is used near TV/radio
antenna, strong electric field or magnetic field
(near a motor, a transformer or a power line),
images may be distorted and noise sound may
be produced.
Take notice of humidity.
Install this product when the humidity is low. If
this product is installed during rainfall or at a
high humidity, the inside may be exposed to
moisture and the front cover may become
foggy.
Heater unit
This product is equipped with an internal heater
unit for use in cold climates. The heater unit turns
on automatically when the temperature inside the
product drops below 0 °C {32 °F}. However, in
an extremely low-temperature environment below
–30 °C {–22 °F}, snow and frost may not be
defrosted from the front cover.
When using the product in cold climates, take
notice of the ambient and internal temperatures
of the product.
When this product is installed and operated in
low temperatures below –10 °C {14 °F}, normal
images may not be obtained immediately after
startup. In such a case, wait around 2 hours or
more, and turn on the power again.
Protection from lightning
When cables are used outdoors, there is a
chance that they may be affected by lightning.
In such a case, install a lightning arrestor close
to the camera, and make the length of the
network cable between the camera and
lightning arrestor as short as possible to
prevent the camera from being damaged by
lightning.
PoE (Power over Ethernet)
Use a PoE hub/device that is compliant with
IEEE802.3af standard.
Router
When connecting this product to the Internet,
use a broadband router with the port forward-
ing function (NAT, IP masquerade).
Refer to the Operating Instructions (included in
the CD-ROM) for further information about the
port forwarding function.
LAN cable
Shielded (STP) LAN cables must be used with
this unit to ensure compliance with EMC
standards.
Time & date setting
It is necessary to set the time & date before put-
ting this product into operation. Refer to the
Operating Instructions on the provided CD-ROM
for descriptions of how to perform the settings.
Make sure to remove this product if it will
no longer be used.

16
Major operating controls
Front cover
Sunshield Rear part of sunshield
Rear cover
Safety wire
Tilting lock screw
Network cable
Alarm input/output cable
Power cable (12 V DC)
Microphone/line input cable (white)
Audio output cable (black)
Camera mount bracket
(accessory)
RJ45 (female)
EXT I/O terminal
Panning lock screw

17
Mount bracket cover x2
(accessories)
Link indicator (lit when linking)
Access indicator (lit when accessing)
Auto focus (AF) button
Initial set button
WIDE button
TELE button
SD memory card slot
SD slot 1 (SD1)
SD slot 2 (SD2)
SD memory card error indicator/Auto focus
indicator (blinks when adjusting auto focus)
IR LED
Lens
Lens cover
Packing
PAL/NTSC
switch
Monitor output
jack
SD ON/OFF button

18
IMPORTANT:
 • Preparethe mountingscrewsaccordingtothematerialoftheareawherethecameramount
bracket and the adapter box are to be installed. In this case, wood screws and nails should not
be used.
 • Ifawallorceilingboardsuchasplasterboardistooweaktosupportthetotalweight,thearea
shall be sufficiently reinforced.
 • Thecameramountbracket(accessory)canbedirectlymountedonthewallorceilingusinga
junction box (locally procured) embedded in the wall or ceiling, or a wall or ceiling with a cable
access hole.
 • Thescrewsthatsecurethecameramountbracketonawallarenotsupplied.Preparethe
screws according to the material, structure, strength and other factors of the mounting area
and the total weight of objects to be mounted.
Installation
place
Appropriate mount
bracket
Recommended
screw
Number of
screw
Minimum pull-out
strength (per 1 pc.)
Ceiling/wall Directly mount M5 4 pcs. 539 N {121 lbf}
Ceiling/wall Junction box M5 4 pcs. 539 N {121 lbf}
Ceiling/wall Adaptor box
(approx. 510 g
{1.13 lbs})
M5 4 pcs. 539 N {121 lbf}
Preparations

19
Secure the camera to the camera mount bracket
The tilt angle is locked downward at shipment.
1Loosen the tilting lock screw approx. 1 rotation and adjust the tilt angle of the camera to the
horizontal position.
2Tighten the tilting lock screw again after tilt angle adjustment.
Note:
 • Useahexagonalwrenchwithwidthacrossflatsof4mm(locallyprocured)toloosenortighten
the tilting lock screw.
3Pass each cable and the safety wire through the camera mount bracket, and secure the cam-
era to the camera mount bracket with the camera fixing screws x3 (accessories).
Pass the network cable first through the camera mount bracket before passing through the
other cables.
IMPORTANT:
 • Ensurethatthecamerafixingscrewsarefirmlysecured.
Recommended tightening torque: 0.78 N·m {0.58 lbf·ft}
Camera main body
Safety wire
Network cable
Mounting boss for safety wire
Cable clamp
Drain slit
Camera mount bracket
(accessory)
Camera fixing screw x3 (M4 x 10)
(accessories)
Installations/Connections
Tilting lock screw
Camera main body
Horizontal
Approx. 90 °
Camera mount bracket
(accessory)

20
4Remo ve the screws from the mounting boss of the safety wire and the mounting boss of the cable
cl
amp.
5Secure the safety wire with the screw from the mounting boss. Then, bundle the wire and the
cable using the cable clamp and secure them with each screw from the mounting boss as illus-
trated.
IMPORTANT:
 • Ensurethatthesafetywireisfirmlysecured.
Recommended tightening torque: 0.59 N·m {0.44 lbf·ft}
Connection
Turn off a circuit breaker before making a connection. Before starting the connection, prepare the
required devices and cables.
Network cable
RJ45 (female)
Alarm input/output cable
4P alarm cable (accessory)
Microphone/line input cable (white)
Audio output cable (black)
Power cable
(12 V DC)
2P power cable
(accessory)
12 V DC (red)
GND (black)
LAN cable
(category 5e or better, straight)
<Required cable>
LAN cable (category 5e or better, straight)
1Connect the microphone/line input cable and the microphone (for use of the audio reception
function).
Inputimpedance: Approx.2kΩ(unbalanced)
Recommended cable length: Less than 1 m {3.28'} (for microphone input)
Less than 10 m {32.8'} (for line input)
Recommended microphone: Plug-in power type microphone (option)
Connect a monaural mini plug (ø3.5 mm).
Supply voltage: 2.5 V ±0.5 V
Recommendedsensitivityofmicrophone:−48dB±3dB(0dB=1V/Pa,1kHz)
Inputlevelforthelineinput: Approx.−10dBV
