Advitronics Telecom IP Video Converter Original operating instructions
IP Video Quick Installation
Before Getting Started
Before getting started, please check your IP Video package contents and your system meets the
following requirements.
Note: With problems, please refer to User Manual from the provided CD for details.
Package Contents
Your IP Video package ships with the
following items:
1 x IP Video BOX
1 x RJ45 (CAT 5) cable
2 x Composite Cable (RCA jacks)
1 x CD- Manual , Quick Installation and IP Program
1 x Quick installation (QI)
1 x 5V DC Power Adaptor
Minimum System Requirements
¡Ý 300MHz Intel Pentium II and above
Windows with IE6.0 + SP1 / LINUX ,MAC system
¡Ý 64MB memory
VGACard•support Hi-Colors and above and direct
draw
Internet card- RJ-45(CAT 5)
Internet Hub
Internet : one set of IP provided by your ISP
EX: xxx.xxx.xxx.xxx
1. Hardware Installation
IP Video Box Installation
A. Power off your computer and plug IP Video
with Hub ( Connect with Internet )
B. Power on computer and insert attached CD
C. Plug in Composite Video Source – like
Camcorder, Webcam, VHS/VCR , Video Box ,
DVD/VCD Player, TV Video Game and so on.
D. Please refer the Manual and follow each details
step, or follow the quick installation in Software
installation.
Connectors Illustration
The diagram below illustrates the typical connection of
the IP Video box :
Video out
2. Software introduction
IP Video Software information
Step 1 : Insert attached CD and the following wizard will AUTO jump.
There are four topic: Manual, Software, Download, FAQ, Utillity :
1. Manual: User Manual, Quick Installation
2. Driver : Include IP Edit , & IP KamVid_1070
3. Download : Firmware, Acrobat Reader (CN / ENG) , MSN /Yahoo Messenger
4. FAQ: IPvideo frequent ask question
5. Utillity: IPedit3, IP KamVid 1070
Step:2 Please go to Utillity to install program” IP KamVid 1070 “ to easily get the dynamic IP at first setting.
After install , there is a shortcut “IP KamVid 1070 “ on the desktop. Click shortcut.:
Step1: Step 2:
Step 3 : Click the IP address and you will get in the main
webpage, Please refer manual for details & special function. Step 4 : Goto software to install the IP Video viewer
