AEG Electrolux BE3003021 User manual

BE3003021
EN
OVEN USER MANUAL

FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
ACCESSORIES AND CONSUMABLES
In the AEG webshop, you’ll find everything you need to keep all your AEG
appliances looking spotless and working perfectly. Along with a wide range of
accessories designed and built to the high quality standards you would expect,
from specialist cookware to cutlery baskets, from bottle holders to delicate
laundry bags…
Visit the webshop at:
www.aeg.com/shop
2

CONTENTS
4 Safety information
7 Product description
8 Before first use
9Dailyuse
10 Clock functions
11 Using the accessories
13 Additional functions
13 Helpful hints and tips
23 Care and cleaning
26 What to do if…
27 Installation
30 Environment concerns
31 GREAT BRITAIN & IRELAND -
Guarantee/Customer Service
The following symbols are used in this user
manual:
Important information concerning your
personal safety and information on how to
avoid damaging the appliance.
General information and tips
Environmental information
Subject to change without notice.
Contents 3

SAFETY INFORMATION
Before the installation and use of the appliance, carefully read the supplied instructions.
The manufacturer is not responsible if an incorrect installation and use causes injuries and
damages. Always keep the instructions with the appliance for future reference.
Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent disability.
• Do not let persons, children included, with reduced physical sensory, reduced mental
functions or lack of experience and knowledge use the appliance. They must have super-
vision or instruction for the operation of the appliance by a person who is responsible for
their safety.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Keep children and pets away from the appliance when it operates or when it cools down.
Accessible parts are hot.
• If the appliance has a child safety device, we recommend that you activate it.
Installation
WARNING!
Only a qualified person must install this appliance.
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Obey the installation instruction supplied with the appliance.
• Always be careful when you move the appliance because it is heavy. Always wear safety
gloves.
• Do not pull the appliance by the handle.
• Keep the minimum distance from the other appliances and units.
• Make sure that the appliance is installed below and adjacent safe structures.
• The sides of the appliance must stay adjacent to appliances or to units with the same
height.
Electrical connection
WARNING!
Risk of fire and electrical shock.
• All electrical connections should be made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the electrical information on the rating plate agrees with the power sup-
ply. If not, contact an electrician.
• Always use a correctly installed shockproof socket.
4Safety information

• Do not use multi-plug adapters and extension cables.
• Make sure not to cause damage to the mains plug and to the mains cable. Contact the
Service or an electrician to change a damaged mains cable.
• Do not let mains cables to come in touch with the appliance door, specially when the
door is hot.
• The shock protection of live and insulated parts must be fastened in such a way that it
cannot be removed without tools.
• Connect the mains plug to the mains socket only at the end of the installation. Make
sure that there is access to the mains plug after the installation.
• If the mains socket is loose, do not connect the mains plug.
• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.
• Use only correct isolation devices: line protecting cut-outs, fuses (screw type fuses re-
moved from the holder), earth leakage trips and contactors.
• The electrical installation must have an isolation device which lets you disconnect the
appliance from the mains at all poles. The isolation device must have a contact opening
width of minimum 3 mm.
Use
WARNING!
Risk of injury, burns or electric shock or explosion.
• Use this appliance in a household environment.
• Do not change the specification of this appliance.
• Make sure that the ventilation openings are not blocked.
• Do not let the appliance stay unattended during operation.
• Deactivate the appliance after each use.
• Internally the appliance becomes hot when in operation. Do not touch the heating ele-
ments that are in the appliance. Always use oven gloves to remove or put in accessories
or ovenware.
• Be careful, when you open the appliance door while the appliance is in operation. Hot air
can release.
• Do not operate the appliance with wet hands or when it has contact with water.
• Do not apply pressure on the open door.
• Do not use the appliance as a work surface or as a storage surface.
• Always keep the appliance door closed when the appliance is in operation.
• Open the appliance door carefully. The use of ingredients with alcohol can cause a mix-
ture of alcohol and air.
• Do not let sparks or open flames to come in contact with the appliance when you open
the door.
• Do not put flammable products or items that are wet with flammable products in, near
or on the appliance.
WARNING!
Risk of damage to the appliance.
Safety information 5

• To prevent damage or discoloration to the enamel:
– Do not put ovenware or other objects in the appliance directly on the bottom.
– Do not put aluminium foil directly on the bottom of the appliance.
– do not put water directly into the hot appliance.
– do not keep moist dishes and food in the appliance after you finish the cooking.
– be careful when you remove or install the accessories.
• Discoloration of the enamel has no effect on the performance of the appliance. It is not
a defect in the sense of the warranty law.
• Use a deep pan for moist cakes. Fruit juices cause stains that can be permanent.
Care and Cleaning
WARNING!
Risk of injury, fire or damage to the appliance.
• Before maintenance, deactivate the appliance and disconnect the mains plug from the
mains socket.
• Make sure the appliance is cold. There is the risk that the glass panels can break.
• Replace immediately the door glass panels when they are damaged. Contact the Service.
• Be careful when you remove the door from the appliance. The door is heavy!
• Clean regularly the appliance to prevent the deterioration of the surface material.
• Remaining fat or food in the appliance can cause fire.
• Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use
abrasive products, abrasive cleaning pads, solvents or metal objects.
• If you use an oven spray, obey the safety instructions on the packaging.
• Do not clean the catalytic enamel (if applicable) with any kind of detergent.
Internal light
• The type of light bulb or halogen lamp used for this appliance, is only for household ap-
pliances. Do not use it for house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect the appliance from the power supply.
• Only use lamps with the same specifications.
Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent children and pets to get closed in the appliance.
6Safety information

PRODUCT DESCRIPTION
General overview
4 632 5
1
13
7
8
9
10
11
12
5
4
3
2
1
1Control panel
2Control knob for oven functions
3Power lamp/symbol
4Electronic programmer
5Control knob for temperature
6Temperature lamp/symbol/indicator
7Heating element
8Oven lamp
9Fan
10 Rear wall heating element
11 Bottom heat
12 Shelf support, removable
13 Shelf positions
Product description 7

Accessories
•Nonstick wire shelf
For cookware, cake tins, roasts.
•Grill / roasting pan
To bake and roast or as pan to collect fat.
•Trivet
For roasting and grilling.
Use the trivet only with the grill/roasting pan.
BEFORE FIRST USE
WARNING!
Refer to "Safety information" chapter.
Initial Cleaning
• Remove all parts from the appliance.
• Clean the appliance before first use.
Refer to chapter "Care and Cleaning".
Setting the time
The oven only operates after time set.
8Before first use

When you connect the appliance to the electrical
supply or in case of a power cut, the Time func-
tion indicator flashes automatically.
To set the current time use " +" or " - " button.
After approximately 5 seconds, the flashing stops
and the display shows the time of day set.
For time change you must not set an automatic
function (Duration or End ) at the same
time.
DAILY USE
WARNING!
Refer to "Safety information" chapter.
To use the appliance, press the control knob. The control knob comes out.
Activating and deactivating the appliance
1. Turn the control knob for the oven functions to select an oven function.
2. Turn the control knob for the temperature to select a temperature.
3. To deactivate the appliance turn the control knobs for the oven functions and temper-
ature to off position.
Knob symbol, indicator or lamp (depends on the model - refer to the appliance
overview):
• The indicator comes on when the oven heats up.
• The lamp comes on when the appliance operates.
• The symbol shows whether the knob controls one of the cooking zones, the oven func-
tions or the temperature.
Oven Functions
Oven function Application
Light Use this function to light up the oven interior.
True Fan Cooking To bake maximum on three oven levels at the same time.
Decrease the oven temperatures (20-40 °C) compared with
Conventional. And to dry food.
Pizza Setting To bake on one oven level food with a more intensive
browning and a crispy base. Decrease the oven tempera-
tures (20-40 °C) compared with Conventional
Conventional Cooking To bake and roast on one oven level.
Bottom Heat To bake cakes with crispy or crusty bases and to preserve
food
Daily use 9

Oven function Application
Defrost To defrost frozen food.
Grilling To grill flat food in the middle of the grill and to toast.
Fast Grilling To grill flat food in large quantities and to toast.
Turbo Grilling To roast larger joints of meat or poultry on one level. Also
for browning food e.g. gratin.
Electronic programmer
1Function indicators
2Function indicators
3Time display
4Button "+"
5Selection button
6Button "-"
456
1 2 3 2
CLOCK FUNCTIONS
Clock function Application
Time of day Shows the time. To set, change or check the time.
Minute minder To set a countdown time.
A signal sounds, after the time period is completed.
This function has no effect on the operation of the oven.
Duration To set how long the oven has to be in operation.
End To set the switch-off time for an oven function.
Duration and End can be used at the same time, if the oven is to be switched on and
off automatically later. In this case first set Duration , then End .
Setting the clock functions
1. Set an oven function and temperature (necessary only for Duration and End).
10 Clock functions

2. Push the Selection button again and
again until necessary function indicator
flashes.
3. To set the time for Minute minder ,
Duration or End , use "+" or "-"
button.
The related function indicator comes on.
When the time period is completed, the
function indicator flashes and an acous-
tic signal sounds for 2 minutes.
With the functions Duration and End the oven stops automatically.
4. Push any button to stop the signal.
5. Turn the oven functions control knob and the temperature control knob to off posi-
tion.
Cancelling the clock functions
1. Push the Selection button again and again until necessary function indicator flashes.
2. Push and hold button "-".
After some seconds the clock function goes out.
USING THE ACCESSORIES
WARNING!
Refer to "Safety information" chapter.
Installing the Oven Accessories
The deep pan and the wire shelf have side edges.
These edges and the shape of the guide-bars cau-
ses the anti-tilt safety for the oven accessories.
Using the accessories 11

Installing the wire shelf and the deep pan to-
gether
Put the wire shelf on the deep pan. Push the deep
pan between the guide-bars of one of the oven
levels.
Trivet and grill/roasting pan
WARNING!
Risk of burns when removing the accessories from a hot oven.
You can use the trivet to roast larger pieces of meat or poultry on one level:
• Put the trivet inside the deep pan so that the
supports of the oven shelf point up.
• Put the deep pan in the oven at the necessa-
ry level.
You can use the trivet to grill flat dishes in large quantities and to toast:
• Put the trivet inside the deep pan so that the
supports of the oven shelf point downwards.
• Put the deep pan in the oven at the necessa-
ry level.
12 Using the accessories

ADDITIONAL FUNCTIONS
Cooling fan
When the appliance operates, the cooling fan activates automatically to keep the surfaces
of the appliance cool. If you deactivate the appliance, the cooling fan can continue to oper-
ate until the appliance cools down.
HELPFUL HINTS AND TIPS
Inner side of door
In some models on the inner side of the door you can find:
• the numbers of the shelf positions (selected models)
• information about the heating functions, recommended shelf positions and tempera-
tures for typical dishes (selected models).
The temperature and baking times in the tables are guidelines only. They depend on the
recipes, quality and quantity of the ingredients used.
Baking
General instructions
• Your new oven may bake or roast differently to the appliance you had before. Adapt your
usual settings (temperature, cooking times) and shelf positions to the values in the ta-
bles.
• With longer baking times, the oven can be switched off about 10 minutes before the end
of baking time, to use the residual heat.
When you use frozen food, the trays in the oven can twist during baking. When the
trays get cold again, the distortion will be gone.
How to use the Baking Tables
• We recommend to use the lower temperature the first time.
• If you cannot find the settings for a special recipe, look for the one that is almost the
same.
• Baking time can be extended by 10 - 15 minutes, if you bake cakes on more than one
level.
• Cakes and pastries at different heights do not always brown equally at first. If this oc-
curs, do not change the temperature setting. The differences equalize during the baking
procedure.
Baking on one level:
Baking in tins
Type of baking Oven function Shelf position Temperature °C Time in min.
Ring cake or brio-
che
True Fan Cooking 1150 - 160 50 - 70
Additional functions 13

Type of baking Oven function Shelf position Temperature °C Time in min.
Madeira cake /
fruit cakes
True Fan Cooking 1140 - 160 70 - 90
Fatless sponge
cake / Fatless
sponge cake
True Fan Cooking 2140 - 150 35 - 50
Fatless sponge
cake / Fatless
sponge cake
Conventional
Cooking
2160 35 - 50
Flan base - short
pastry
True Fan Cooking 2170 - 180
1)
10 - 25
Flan base -
sponge mixture
True Fan Cooking 2150 - 170 20 - 25
Apple pie / Apple
pie (2 tins Ø20
cm, diagonally off
set)
True Fan Cooking 2160 60 - 90
Apple pie / Apple
pie (2 tins Ø20
cm, diagonally off
set)
Conventional
Cooking
1180 70 - 90
Cheesecake Conventional
Cooking
1170 - 190 60 - 90
1) Preheat the oven
Cakes / pastries / breads on baking trays
Type of baking Oven function Shelf position Temperature °C Time in min.
Plaited bread /
bread crown
Conventional
Cooking 3170 - 190 30 - 40
Christmas stollen Conventional
Cooking 2160 - 180
1)
50 - 70
Bread (rye
bread):
1. First part of
baking proc-
ess.
2. Second part
of baking
process.
Conventional
Cooking 11. 230
1)
2. 160 - 180
1. 20
2. 30 - 60
Cream puffs /
eclairs
Conventional
Cooking 3190 - 210
1)
20 - 35
Swiss roll Conventional
Cooking 3180 - 200
1)
10 - 20
14 Helpful hints and tips

Type of baking Oven function Shelf position Temperature °C Time in min.
Cake with crum-
ble topping (dry) True Fan Cooking 3150 - 160 20 - 40
Buttered almond
cake / sugar cakes
Conventional
Cooking 3190 - 210
1)
20 - 30
Fruit flans (made
with yeast
dough / sponge
mixture)
2)
True Fan Cooking 3150 35 - 55
Fruit flans (made
with yeast
dough / sponge
mixture)
2)
Conventional
Cooking 3170 35 - 55
Fruit flans made
with short pastry True Fan Cooking 3160 - 170 40 - 80
Yeast cakes with
delicate toppings
(e.g, quark, cream,
custard)
Conventional
Cooking 3160 - 180
1)
40 - 80
1) Preheat the oven
2) Use deep pan
Biscuits
Type of baking Oven function Shelf position Temperature °C Time in min.
Short pastry bis-
cuits True Fan Cooking 3150 - 160 10 - 20
Short bread /
Short bread / Pas-
try Stripes
True Fan Cooking 3140 20 - 35
Short bread /
Short bread / Pas-
try Stripes
Conventional
Cooking 3160
1)
20 - 30
Biscuits made
with sponge mix-
ture
True Fan Cooking 3150 - 160 15 - 20
Pastries made
with egg white,
merungues
True Fan Cooking 380 - 100 120 - 150
Macaroons True Fan Cooking 3100 - 120 30 - 50
Biscuits made
with yeast dough True Fan Cooking 3150 - 160 20 - 40
Puff pastries True Fan Cooking 3170 - 180
1)
20 - 30
Rolls True Fan Cooking 3160
1)
10 - 25
Helpful hints and tips 15

Type of baking Oven function Shelf position Temperature °C Time in min.
Rolls Conventional
Cooking 3190 - 210
1)
10 - 25
Small cakes /
Small cakes (20
per tray)
True Fan Cooking 3150
1)
20 - 35
Small cakes /
Small cakes (20
per tray)
Conventional
Cooking 3170
1)
20 - 30
1) Preheat the oven
Multileveled Baking
Cakes / pastries / breads on baking trays
Type of baking
True Fan Cooking
Temperature in
°C Time in min.Shelf position
2 levels 3 levels
Cream puffs /
eclairs 1 / 4 -160 - 180
1)
25 - 45
Dry streusel cake 1 / 4 -150 - 160 30 - 45
1) Preheat the oven
Biscuits / small cakes / small cakes / pastries / rolls
Type of baking
True Fan Cooking
Temperature in
°C Time in min.Shelf position
2 levels 3 levels
Short pastry bis-
cuits 1 / 4 1 / 3 / 5 150 - 160 20 - 40
Short bread /
Short bread / Pas-
try Stripes
1 / 4 1 / 3 / 5 140 25 - 50
Biscuits made
with sponge mix-
ture
1 / 4 -160 - 170 25 - 40
Biscuits made
with egg white,
meringues
1 / 4 -80 - 100 130 - 170
Macaroons 1 / 4 -100 - 120 40 - 80
Biscuits made
with yeast dough 1 / 4 -160 - 170 30 - 60
Puff pastries 1 / 4 -170 - 180
1)
30 - 50
Rolls 1 / 4 -180 30 - 55
16 Helpful hints and tips

Type of baking
True Fan Cooking
Temperature in
°C Time in min.Shelf position
2 levels 3 levels
Small cakes /
Small cakes (20
per tray)
1 / 4 -150
1)
25 - 40
1) Preheat the oven
Tips on baking
Baking results Possible cause Remedy
The cake is not browned
enough underneath. Wrong shelf position. Place the cake lower.
The cake sinks (becomes soggy,
lumpy, streaky).
The oven temperature is too
high.
The next time you bake set a
slightly lower oven tempera-
ture.
The cake sinks (becomes soggy,
lumpy, streaky). The baking time is too short.
Set a longer baking time. Bak-
ing times cannot be reduced
by setting higher tempera-
tures.
The cake sinks (becomes soggy,
lumpy, streaky).
There is too much liquid in the
mixture.
Use less liquid. Pay attention to
mixing times, especially if you
use a mixing machine.
The cake is too dry. The oven temperature is too
low.
The next time you bake set a
higher oven temperature.
The cake is too dry. The baking time is too long. The next time you bake set a
shorter baking time.
The cake browns unevenly.
The oven temperature is too
high and the baking time is too
short.
Set a lower oven temperature
and a longer baking time.
The cake browns unevenly. The mixture is unevenly distrib-
uted.
Spread the mixture evenly on
the baking tray.
The cake is not ready in the
baking time given.
The oven temperature is too
low.
The next time you bake set a
slightly higher oven tempera-
ture.
Bakes and gratins
Dish Oven function Shelf position Temperature °C Time in min.
Pasta bake Conventional
Cooking 1180 - 200 45 - 60
Lasagne Conventional
Cooking 1180 - 200 25 - 40
Vegetables au
gratin
1)
Turbo Grilling or
True Fan Cooking 1160 - 170 15 - 30
Helpful hints and tips 17

Dish Oven function Shelf position Temperature °C Time in min.
Baguettes topped
with melted
cheese
Turbo Grilling or
True Fan Cooking 1160 - 170 15 - 30
Sweet bakes Conventional
Cooking 1180 - 200 40 - 60
Fish bakes Conventional
Cooking 1180 - 200 30 - 60
Stuffed vegeta-
bles
Turbo Grilling or
True Fan Cooking 1160 - 170 30 - 60
1) Pre-heat the oven
Roasting
Roasting dishes
• Use heat-resistant ovenware to roast (please read the instructions of the manufacturer).
• Large roasting joints can be roasted directly in the deep pan (if present) or on the wire
shelf above the deep pan.
• Roast lean meats in a roasting tin with a lid. This will keep the meat more succulent.
• All types of meat, that can be browned or have crackling, can be roasted in the roasting
tin without the lid.
Roasting with Turbo Grilling
Beef
Type of meat Quantity Oven func-
tion
Shelf posi-
tion
Temperature
°C Time min.
Pot roast 1 - 1.5 kg Conventional
Cooking 1230 120 - 150
Roast beef or fil-
let: rare
per cm. of
thickness Turbo Grilling 1190 - 200
1)
5 - 6
Roast beef or fil-
let: medium
per cm. of
thickness Turbo Grilling 1180 - 190
1)
6 - 8
Roast beef or fil-
let: well done
per cm. of
thickness Turbo Grilling 1170 - 180
1)
8 - 10
1) Preheat the oven
Pork
Type of meat Quantity Oven func-
tion
Shelf posi-
tion
Temperature
°C Time min.
Shoulder, neck,
ham joint 1 - 1.5 kg Turbo Grilling 1160 - 180 90 - 120
Chop, spare rib 1 - 1.5 kg Turbo Grilling 1170 - 180 60 - 90
Meat loaf 750 g - 1 kg Turbo Grilling 1160 - 170 50 - 60
18 Helpful hints and tips

Type of meat Quantity Oven func-
tion
Shelf posi-
tion
Temperature
°C Time min.
Porkknuckle (pre-
cooked) 750 g - 1 kg Turbo Grilling 1150 - 170 90 - 120
Veal
Type of meat Quantity Oven func-
tion
Shelf position Temperature
°C
Time min.
Roast veal 1 kg Turbo Grilling 1160 - 180 90 - 120
Knuckle of
veal
1.5 - 2 kg Turbo Grilling 1160 - 180 120 - 150
Lamb
Type of meat Quantity Oven func-
tion
Shelf position Temperature
°C
Time min.
Leg of lamb,
roast lamb
1 - 1.5 kg Turbo Grilling 1150 - 170 100 - 120
Saddle of
lamb
1 - 1.5 kg Turbo Grilling 1160 - 180 40 - 60
Game
Type of meat Quantity Oven func-
tion
Shelf position Temperature
°C
Time min.
Saddle of
hare, leg of
hare
up to 1 kg Conventional
Cooking
1230
1)
30 - 40
Saddle of ven-
ison
1.5 - 2 kg Conventional
Cooking
1210 - 220 35 - 40
Haunch of
venison
1.5 - 2 kg Conventional
Cooking
1180 - 200 60 - 90
1) Preheat the oven
Poultry
Type of meat Quantity Oven func-
tion
Shelf position Temperature
°C
Time min.
Poultry por-
tions
200 - 250 g
each
Turbo Grilling 1200 - 220 30 - 50
Half chicken 400 - 500 g
each
Turbo Grilling 1190 - 210 35 - 50
Chicken, pou-
lard
1 - 1.5 kg Turbo Grilling 1190 - 210 50 - 70
Duck 1.5 - 2 kg Turbo Grilling 1180 - 200 80 - 100
Goose 3.5 - 5 kg Turbo Grilling 1160 - 180 120 - 180
Turkey 2.5 - 3.5 kg Turbo Grilling 1160 - 180 120 - 150
Helpful hints and tips 19

Type of meat Quantity Oven func-
tion
Shelf position Temperature
°C
Time min.
Turkey 4 - 6 kg Turbo Grilling 1140 - 160 150 - 240
Fish (steamed)
Type of meat Quantity Oven func-
tion
Shelf position Temperature
°C
Time min.
Whole fish 1 - 1.5 kg Conventional
Cooking
1210 - 220 40 - 60
Grilling
Always grill with the maximum temperature setting.
Set the shelf into the shelf position as recommended in the grilling table.
Always set the pan to collect the fat into the first shelf position.
Grill only flat pieces of meat or fish.
Always preheat the empty oven with the grill functions for 5 minutes.
CAUTION!
Always grill with the oven door closed.
Grilling
Food to be gril-
led Shelf position Temperature Time in min.
1st side 2nd side
Roast beef 2210 - 230 30 - 40 30 - 40
Filet of beef 3230 20 - 30 20 - 30
Back of pork 2210 - 230 30 - 40 30 - 40
Back of veal 2210 - 230 30 - 40 30 - 40
Back of lamb 3210 - 230 25 - 35 20 - 25
Whole Fish, 500 -
1000 g 3 / 4 210 - 230 15 - 30 15 - 30
Fast Grilling
Food to be grilled Shelf position Time in min.
1st side 2nd side
Burgers / Burgers 48 - 10 6 - 8
Pork fillet 410 - 12 6 - 10
Sausages 410 - 12 6 - 8
Fillet steaks, veal steaks 47 - 10 6 - 8
Toast / Toast
1)
51 - 3 1 - 3
Toast with topping 46 - 8 -
1) Preheat the oven
20 Helpful hints and tips
