OPERATION MANUAL
Single Freestanding Oven
(with Steam Clean)
76cm (30”)
SIC 76

Congratulations on the purchase of your AEG appliance.
We are sure it will provide many years of great cooking experience.
You may find that it has different features and characteristics to your last
appliance.
It is essential you read this operation manual thoroughly to fully
understand all of the various functions and operations. Experiment with
your cooking and take advantage of the features your new appliance offers.
This manual should be retained for future reference. Should ownership of
the appliance be transferred, please ensure that the manual is also passed
onto the new owner.
Contents
A -Installation check and warnings Page 3
B -Accessories Page 4
C -Using the appliance for the first time Page 4
D-Electronic Programmer Operation Page 5 -7
E-Ceramic Cooktop Control Panel Page 8
F-Ceramic Cooktop Functions Page 9
G-Oven Functions& Control Panel Page 10 –17
H-Cleaning and maintenance Page 18-19
I-Trouble shooting guide Page 20
J-Installation instructions and measurements Page 20-21
K-Electrical wiring diagrams and instructions Page 22 -24
L-Warranty Page 25

A -Installation check and warnings
IMPORTANT:
Please ensure that the oven cavity, venting and wiring is as specified in the relevant
section G of this manual.
A licensed electrician with relevant qualifications must perform electrical work when installing or
servicing the appliance. The supply cable and fuse rating must be suitable for the appliance. You
must never repair or replace any part of the appliance unless specifically recommended in the
operation manual.
Ventilation opening must not be covered or obstructed in any way.
DO NOT use aluminum foil on the base of ovens
The use of foil on the base of the oven to avoid spillage and improve cleaning is not
recommended. The bottom element is concealed under the base of the oven liner (not exposed).
Foil or dishes with reflective qualities must never be placed on the base of the oven during
cooking as the concentration of direct and reflected heat will damage the enamel surface.
Damage resulting from such use is not covered under the provisions of the warranty.
Initial heat up
Some smoke and smell may be noticed during the initial heat up cycle. This should quickly
dissipate.
If abnormal levels of smoke are observed (i.e.: it is not food that is burning), have the appliance
thoroughly checked.
Don’t use the appliance as a space heater
The appliance must never be used for warming or heating the surrounding room. Combustible
materials must never be placed on or near the appliance.
Do not leave children alone
Children must not be left unsupervised in the area where the appliance is in use. Children must
never be allowed to sit or stand on any part of the appliance.
Wear proper apparel when using the appliance
Loose fitting, hanging or highly flammable garments (such as synthetics) should never be worn
while using the appliance.
Use only dry pot holders
Moist or damp pot holders on hot surfaces may result in burns from steam. Do not allow pot
holder to touch hot heating elements. Do not use a towel or bulky cloth when handling hot
cooking utensils in the appliance.
Oven compartments must never be used for storage
Items, particularly flammable materials, must never be stored in an oven or near surface units.
Do not use water on grease fires
Fires or flame should be smothered using flameproof material or extinguished using a dry
chemical or other suitable fire retardant.

B -Accessories
Your appliance should come equipped with the following items.
•1 x pair of Retractable Slide Runners fitted to upper position and capable of being moved
to any selected position as required
•1 x Deep Enameled Roasting Pan with dual height reversible Grill Rack insert –ready for
sliding into side rack positions or fitting onto Retractable Slide Runners
•2 x Wire Oven Shelves that can be fitted into Retractable Slide Runners or for sliding into
side rack positions
•1x Pyrex Dish on retention rack with handles, with dual height reversible Grill Rack insert
–fitted onto wire oven shelf
•Note: Additional Retractable Slide Runners are available as an optional extra and can be
fitted at any time
•Note: Additional oven shelves and pans are available as optional extras. Also, the Pyrex
dish provided is an excellent water vessel for the Steam Clean function.
C -Using the appliance for the first time
After installation remove all notification labels (not identification or warning labels) and packaging
materials. After cleaning make sure cleaned surfaces are thoroughly rinsed and wiped dry using a
clean, soft cloth.
Power on
NOTE: oven will not operate unless the clock is set.
When power is first applied the display will flash and shows 00:00.
The time of day is displayed in digital 24 hours format (e.g.: 18:00 is 6:00 pm). Press the reset
button to select manual mode and set clock as describe in section C.
Burning in
Before cooking in the appliance an initial pre-heating is required to burn off the fine oil film used to
protect the elements for shipping. The first time you heat up the oven (or grill) the oil will be given
off as smoke, which is perfectly normal.
Select a cooking mode and set the oven temperature to 180°C. With the oven door closed, leave
for approximately 5 minutes.
Repeat the above step for each cooking mode.
After completing the above make sure all controls are turned off. The oven is now ready for
cooking and grilling.

D -Electronic Programmer Operation
The 24 hour clock allows the setting of automatic cooking options up to 24 hours in
advance.
1-Minus Time Button
2Mode (Countdown Timer with Alarm, Cooking duration, Finish Cooking)
3+Plus Time Button
Setting the time on the 24 hour clock
IMPORTANT –NOTE FOR NEW INSTALLATION AND FIRST OPERATION
1-The clock will require setting when you first turn on the power (or following a power
failure).
2-At power on, the relay contact is opened. The display and AUTO symbol flashes and
time of day starts from 0:00.
3-Press PLUS and MINUS button simultaneously for minimum 3 seconds. The AUTO
symbol goes out, POT symbol goes on the DOT is flashing. With the PLUS button the
time will advance slowly, and then speed up. If you over-shoot the desired time , use the
MINUS button)
4-Press the MODE button to select the time of day setting mode. The DOT will be
Conventional Oven
5-The oven is now ready for use and to accept the selected cooking functions
6-The timer can be set for countdown up to 24 hours and for automatic cooking modes up
to 10 hours and will countdown to zero. When zero is reached the alarm will sound.
7-To set the countdown timer
8-Press the MODE button for minimum 3 seconds. The BELL symbol is flashing and the
display shows 0:00. Using the PLUS button advance the timer to the desired time.
9-Once the countdown timer is set, the normal time of day will return to the display within 7
seconds. If you wish to check how much time remains on the countdown, press the
10-MODE button for 3 seconds. The remaining time will be displayed. After 7 seconds the
normal time will return to the display.
11-To silence the alarm press the MODE button for minimum 4 seconds

Adjusting the tone of the electronic timer alarm.
The tone is adjusted simply by pressing the minus button. Each time it is pressed the tone will
change.
There are 3 different tones from which you can select.
The electronic timer will store in its memory the last tone activated
Manual cooking
Once the time of day is set the POT symbol will be displayed. The oven is now in manual
operation mode ready for you to select the desired cooking function and temperature
Automatic cooking modes (Based on setting the duration “DUR”)
Set function and temperature to the desired position
For example: if you wish to cook for 45 minutes. Press the MODE button minimum for 4 seconds.
Press the MODE button again. The AUTO symbol is flashing and the display shows “dur”. The
display automatically switches over between "dur" display and 0:00. During this time you can set
the duration time of 45 minutes by pressing the PLUS button (use MINUS button should you over-
shoot the required time). Release and the display will return to the normal time of day after 7
seconds. The AUTO symbol will also appear indicating that you have set the automatic cooking
function.
The oven will operate for 45 minutes only, turn off automatically and the alarm will sound. The
AUTO symbol is flashing and the POT symbol will disappear. The alarm will turn off after pressing
the MODE button.
If you hold the MODE button down longer than 4 seconds the oven will return to the normal
cooking mode.
If further cooking is required, either leave on manual or repeat the above setting sequence.
Note: If you have not turned the function and thermostat setting off, your oven will now continue
to operate manually. The AUTO symbol will disappear and the POT symbol will reappear.
Based on setting a cook stop time
1Set the function and thermostat control to the desired position
2For example: if you commence cooking and decide you would like the oven to turn off at
6.00pm. Press the MODE button minimum for 4 seconds. Press the MODE button two
times again. The AUTO symbol is flashing and the display shows “End”. The display
automatically switches over between "End" and time of day. During this time you can set
the cooking stop time to 6.00pm, i.e.18:00 on the 24 hour clock, by pressing the PLUS
button (use MINUS button should you over-shoot the required time). Release and the
display will return to the normal time of day after 7 seconds. The AUTO symbol will also
appear indicating that you have set the automatic cooking function.
3The oven will continue to cook until 18:00 (6.00pm) and then switch off and the alarm will
sound. The AUTO symbol is flashing and the POT symbol will disappear. The alarm will
turn off after pressing the MODE button.
4If you hold the MODE button pressed longer then 4 seconds the oven will return to the
normal cooking mode.
If further cooking is required, either leave on manual or repeat the above setting sequence.

Note: If you have not turned the function and thermostat setting off, your oven will now continue
to operate manually. The AUTO symbol will disappear and the POT symbol will reappear.
Fully automatic –(Start Later –Stop Later)
Your oven may be programmed to start, cook for the desired time and turn off automatically.
This function is particularly useful in the preparation of the evening meal, should you be out
during the day, it will be ready on your return home. For example if your cooking time is 45
minutes and you want the cooking to finish at 6.00 p.m.
Press the MODE button minimum for 4 seconds. Press the MODE button again. Set the cooking
duration time for say 45 minutes using the PLUS or MINUS button.
Press the MODE button again. Set the stop cooking time to 6.00pm (18:00). Release and the
display will return to the normal time of day after 7 seconds. The AUTO symbol will be displayed.
Using the above settings, the oven is now programmed automatically to commence cooking 45
minutes prior to 6.00 pm. Then automatically turn off.
When cooking is complete the AUTO symbol is flashing and the POT symbol will disappear and
the alarm will sound. The alarm will turn off after pressing the MODE button.
If you hold the MODE button pressed longer then 4 seconds the oven will return to the normal
cooking mode.
Canceling automatic settings
To cancel a program:
Press plus and minus button simultaneously for minimum 3 seconds.
NOTE:
On oven start up or possibly at other times, due to electricity supply deviations –the
programmer may freeze on a function –if this occurs we recommend that, after checking
other solutions without success, it is recommended that power supply be disconnected to
the appliance and allow it to be in this position for some minutes before reconnecting.
This may have a result of clearing the frozen position allowing you to reset the
programmer for normal operation.
Cooling Fan
The Single and Double Ovens are provided with a cooling fan motor to reduce the heat around
the oven. The fan motor is controlled by a sensor, which will start when the temperature achieves
the level pre-fixed and stop working when the temperature is reduced accordingly.
This safeguards both the oven and the adjoining cupboards from the possibility of temperature
damage.
Safety Thermostat
Your oven is fitted with an over temperature sensor that will automatically shut down your oven
for a period if it is deemed to be overheating-this sensor is fitted to the rear wall of the oven,
inside the outer case –it will only activate in extreme circumstances and is provided as protection
to the appliance and the adjoining furnishings. If activated it will shut down the appliance for a
short time and will automatically reset allowing normal operations –you should consult your
service technician if the problem re-occurs.

E -Ceramic Cooktop Control Panel
Ceramic Cooktop Controls:
Switch controlling
the left, front hot
plate.
Turning the knob
anticlockwise
activates only the
center area of the
hot plate.
Turning the knob
clockwise activates
the full hot plate.
Switch controlling
the left, back hot
plate.
Turning the knob
clockwise activates
the full hot plate.
Switch controlling
the right, back hot
plate.
Turning the knob
anticlockwise
activates only the
small round area of
the hot plate.
Turning the knob
clockwise activates
the full oval hot
plate.
Switch controlling
the right, front hot
plate.
Turning the knob
clockwise activates
the full hot plate.

F -Ceramic Cooktop Functions
•WARNING
All operations relative to installation and electric connection should be carried out by qualified
personnel in conformity with the regulations in force in your country.
The specific instructions are described in the booklet section for the installer
NOTICE
•Use only flat pans with a sufficiently thick base, equal to or not much larger than the hot plate
selected (fig.1)
•The containers should not have rough bottoms in order to avoid scratching the heat surface
of the top.
•Do not switch the electric plate on without the pan over the plate.
•Do not cook any food directly on the hot area. Avoid overflows of liquid and should they occur
clean away promptly.
•Turn off the plate few minutes before the cooking end.
Switching on
Set the power by rotating the knob, taking into consideration that the highest number corresponds
with the maximum power.
The pilot light is switched ON when at least one element is on. The residual heat indicator will
light up when the temperature in any area is higher than 50OC.
Cleaning
Remove leftover and grease or spillage from the cooking surface with the special scraper (fig.3)
(optional).
Then clean the heating area thoroughly with a paper towel and ceramic cleaning products for the
correct care of your appliance. Never use abrasive sponge or irritating chemical detergents such
as over spray or spot removers.

G -Oven Functions & Control Panel
Control Panel:
150
200
230
100
50
MODE
19 : 05
Warming Drawer & continuous warm function of main oven:
This switch controls the warming This switch controls the warming
element in the oven (200 Watt) drawer (200 Watt)
The warming drawer and warming element of the main oven heats continuously until it reaches
75 Degrees C and this temperature will be maintained throughout the warming process as
required.
