AEG Electrolux S92358-KA2 User manual

S92358-KA2
User Manual Refrigerator
Notice d'utilisation Réfrigérateur

2AEG/Electrolux 8184261-00/9
Safety instructions
Your new fridge may have other functions compared to your previous one.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
For the User
· The refrigerator is intended for
the storage of foodstuffs and the
production of cold water, with or
without carbon dioxide, for normal
household use in accordance with
these instructions.
· If the gas cylinder is used for
other purposes than that intended
or if it is filled by an unauthorised
person, all guarantees
automatically become null and
void . In order to ensure reliable
functioning, only an Electrolux
Cylinder may be used.
·Do not keep explosive gases or
liquids in the refrigerator or freezer
compartment. They may explode
and cause injury and material
damage.
·Do not let sharp objects come
into contact with the refrigerating
system on the back of and inside the
cabinet. If the refrigerating system is
punctured, the cabinet will be
damaged and foodstuff inside may
spoil.
·Do not keep carbonised drinks or
bottles in the freezer compartment.
The glass bottles may break.
·The cabinet is heavy. The edges
and projecting parts of the cabinet
may be sharp.
Be careful when moving the cabinet
and always use gloves.
Child Safety
·Pay attention so that small
children do not gain access to the
operating controls or the inside of
the cabinet.
WARNING
Keep ventilation openings, in the
appliance enclosure or in the built-in
structure, clear of obstruction.
WARNING
Do not use mechanical devices or
other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
WARNING
Do not damage the refrigerant
circuit.
WARNING
Do not use electrical appliance
inside the food storage
compartments of the appliance,
unless they are of the type
recommended by the manufacturer.
WARNING
Connect to potable water supply
only.

3AEG/Electrolux 8184261-00/9
Scrapping old appliances
The symbol on the product or on its packaging indicates that this
product may not be treated as household waste. Instead it should be taken to
the appropriate collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this product,
please contact your local council, your household waste disposal service or
the shop where you purchased the product.
Contents
Safety instructions 2............
Scrapping old appliances 3.......
Contents 3....................
Description of the Appliance 4....
Control Panel 5................
BEFORE USE 5............
Using the fridge 5..........
To start the fridge and set the correct
temperature 6..............
Temperature inside the fridge 6...
Measuring the temperature 6......
Switching off 7................
Alarms and other features 7......
Control Panel (water dispenser) 9..
HINT and TIPS 12..........
Saving energy 12...............
Protect the environment 12.......
Food Storage 13...............
MAINTENANCE and
CLEANING 13..........
Removing the ventilation grille 13.
Cleaning 14...................
Servicing and cleaning the
water dispenser. 14..........
Service during operation 14......
To change the lamp 15..........
Change of carbon filter 15.......
Defrosting the fridge 15.........
When the appliance is not in use 16
SOMETHING NOT
WORKING 16...........
Holiday Mode 16..............
TECHNICAL
SPECIFICATION 19.....
Permissible water pressure (to ensure
reliable function). 19........
INSTALLATION 20.........
Mounting the handles 20.........
Unpacking 20.................
Remove the transport supports 20.
Cleaning 20...................
Electrical connection 21.........
Installation of carbon filter 22.....
Electrical cord 22..............
Installing the cabinet 22.........
Door Reversal 23..............
When the water system is started
for the first time. 24.........

4AEG/Electrolux 8184261-00/9
Description of the Appliance
4
1. glass shelf
2. grid
3. vegetable drawer
4. ventilasjonsgrill
5. butter compartment
6 door shelf
7. bottle shelf
1
2
1
1
1
1
1
3
5
6
6
6
7
Control Panel
ALARM OFF
ON/OFF
ABC DF
GH
E
COOLMATIC
5
A. Refrigerator power switch
Switches the refrigerator on and off.
B. Green indicator lamp
Lights when the fridge is operating.
C. Temperature display.
D. Temperature adjustment
buttons
E. COOLMATIC button
Used to switch the Coolmatic feature
on and off.
F. Yellow indicator lamp
G. Alarm shut-off button
Used to turn the audible alarm off.
H. Red warning lamp
Flashes when one of the alarms in
the cabinet has been triggered.

5AEG/Electrolux 8184261-00/9
BEFORE USE
Position and clean the cabinet as
explained in the section
"Installation".
Check that the drain hose at the rear
of the cabinet discharges into the
drip tray.
Before inserting the power plug into the outlet and switching on
the cabinet for the first time, leave it standing upright for about 4
hours. Otherwise the compressor may sustain damage. This time
will allow the oil sufficient time to return to the compressor.
Using the fridge
To start the fridge and set the correct temperature
Press the ON/OFF-button. The green
indicator lamp lights.
Setting the temperature
Press the buttons until the desired
temperature flashes in the
temperature display (The
temperature can be set between +2°C
and +8°C.)
"+" raises the temperature.
"-" lowers the temperature.
ALARM OFF
ON/OFF COOLMATIC5
Once set, the temperature display shows "-" until the temperature inside the
fridge reaches +9°C or below.
Allow the cabinet to run for a period of 24 hours whenever the temperature
setting is changed. This will allow the temperature to stabilise inside the
cabinet.
It is not necessary to reset the temperature when the cabinet is switched on
after it has been out of use. The electronics recalls the previously set
temperature.
Temperature inside the fridge
A suitable temperature inside the fridge is approx. +5°C. Storage
temperature in the cabinet is even on all of the shelf levels. The vegetable
box which is placed in the bottom has a temperature of 3-4°C warmer than
the intended temperature setting.

6AEG/Electrolux 8184261-00/9
Measuring the temperature
If the temperature is measured using
a standard, single thermometer, this
should be put in a glass of water
centrally placed inside the cabinet.
This will reflect the temperature
inside the food products. Do not
place the thermometer hanging or
lying directly on the shelf.
Hints:
· Distribute foodstuffs to allow
cold air to circulate freely between
the products.
· Also never put warm products
into the cabinet. Wait until they have
cooled down.
· Cover all foods properly.
Switching off
To switch off press and hold the
ON/OFF button for approx. 1
second. A so-called "count down" is
started in the temperature display,
which counts backwards from "3" to
"1". After "1" is reached the
appliance switches off. Illumination
at the temperature display goes off.
ALARM OFF
ON/OFF 5COOLMATIC
Note:
The appliance cannot be switched on or off if unplugged, or if there is no
power being supplied to it. Following connection to the mains power supply,
the appliance returns to the same operating state as before the interruption of
main power.
If the appliance is not going to be used for an extended period:
1. Switch appliance off by pressing and holding the ON/OFF button for
approximately 1 second (see above).
2. Unplug or switch off at the mains supply.
3. Clean thoroughly (see section: "Maintenance and Cleaning").
4. Leave door open to avoid accumulation of odours.

7AEG/Electrolux 8184261-00/9
Alarms and other features
Temperature alarm
The warning lamp lights and an
alarm sounds if it gets warmer than
-12°C.
Switching off the audible alarm:
Press the switch-off button. The red
warning lamp goes out when it
becomes colder than -13°C.
Action cool (COOLMATIC)
Use Coolmatic to refrigerate a large
quantity of products. When
Coolmatic is switched on, the
temperature is automatically set to
+2°C.
After about 6 hours, Coolmatic is
switched off and the temperature
gradually returns to the previously
set temperature. It is possible to
switch off Coolmatic manually by
pressing the Coolmatic button once
more.
Door open alarm
If the fridge door remains open for
more than 5 minutes, the red
warning lamp starts flashing and an
audible alarm sounds.
To switch off the alarm:
Press the "alarm shut-off button".
The red warning lamp goes out when
the door is closed.
ALARM OFF
ON/OFF COOLMATIC5
ALARM OFF
ON/OFF COOLMATIC5
ALARM OFF
ON/OFF COOLMATIC5
Quick chill
This function has two usage areas. One area in connection with cans / bottles
being quickly chilled on the quick chill shelf, and the other in connection
with large amounts of food at room temperature being placed on the shelf.

8AEG/Electrolux 8184261-00/9
Chilling of bottles:
When groceries are placed on the
shelf (see under section; Quick chill
shelf) the air regulator should be
turned to it's maximum position,
then press the Coolmatic button.
The temperature display shows the
current temperature and the yellow
lamp being lit.
MAX
MIN
ALARM OFF
ON/OFF COOLMATIC5
Chilling of warm groceries:
This function is used in connection with large amounts of groceries at room
temperature being placed in the fridge. Pressing the Coolmatic button starts
this function.
The temperature display shows the current temperature and the yellow lamp
being lit.
When this function has been activated forced air will chill the groceries, and
the temperature in the cabinet reset to +2°C. After 6 hours the Coolmatic
automatically shuts off and the temperature gradually goes back to its
normal setting.
Carbon filter's function:
The built-in carbon filter means that
strong smelling groceries can be
placed near other groceries without
affecting their taste or aroma.
Control Panel (water dispenser)
IJ N
MOKL
I. Yellow indicator lamp
Lights up when the locking function has been activated.
J. Button for carbonated water.
- Used for the choice of carbonated water.
- For the engagement and disengagement of the locking function.

9AEG/Electrolux 8184261-00/9
K. Button for ordinary water.
- Used for the choice of ordinary water.
- Switches the background lighting on and off.
- Switches off the indicator lamp for water filter replacement.
L. Yellow indicator lamp
Lights up when the water filter must be changed.
M. Water out-feed
Activated when a glass or something similar is pressed upwards against the
flap.
N. Flap
O. Lighting
The functions of the waterdispenser
The locking function:
The locking function is activated by
the production plant.
For temporary unlocking:
Keepthebutton(J)pressedinfor
about three seconds until the yellow
indicator lamp (I) goes out. The
locking function is re-activated
automatically after about three
seconds.
For permanent unlocking:
Keep the buttons (J) and (K) pressed
in at the same time for about three
seconds. The button (J) or (K) lights
up to indicate unlocking.
To activate the locking function:
Keep the buttons (J) and (K) pressed
in at the same time for about three
seconds. Activation is indicated by
the yellow indicator lamp (I) lighting
up.
Selecting and obtaining water:
Before obtaining water, selection is
carried out either by pressing the
button for carbonated water (J) or
the button for ordinary water (K).
The actual choice is indicated by the
button which lights up. The selection
of water can be changed while the
water is running.
IJ N
MOKL

10 AEG/Electrolux 8184261-00/9
Water is obtained by pressing a glass
or other container against the
opening (N). Stop the water flow by
moving the glass or container
downwards away from the opening
(O). Any water that drips or is
spilled is collected in the drip bowl
below the water dispenser. When the
carbonated water is being
obtained, there is a slight afterflow
when the glass is removed. The drip
bowl can be detached and emptied
when necessary.
Lighting:
The water dispenser lighting (O)
illuminates automatically when
water is obtained.
For continuous lighting:
1. Make sure that the water
dispenser is unlocked.
2. Then hold the button for ordinary
water (K) pressed in for about three
seconds until the illuminates.
The lighting then illuminates with
about 50 % of its full intensity.
To switch off the lighting:
1. Ensure that the water dispenser is
unlocked.
2. Then hold the button for ordinary
water (K) pressed in for about three
seconds until the lighting goes out.
IJ N
MOKL
