INSTRUCTION BOOK
Wok burner
GB

2
Your New Appliance
Thank you for purchasing an AEG appliance.
To enable you to use your new hob efficiently and safely, please read this
instruction book carefully before installing or using the appliance, and retain
for future reference. Should the hob be transferred to a new owner please
ensure this instruction book is left with the appliance in order that the new
owner can get to know the functions of the appliance and the relevant
warnings.
If you require further assistance or advice, please contact our Customer Care
Department either by letter or telephone:
Customer Care Department
AEG Domestic Appliances
55-77 High Street
Slough
SL1 1DZ
Tel: [phone]

3
Contents Page no
For the user
Your new appliance ...................................................................................... 2
Safety information ........................................................................................ 4
Description of the product ......................................................................... 5
Placement of grid ................................................................................. 5
Operating instructions ................................................................................ 6
Burner cover/inner- and outer burner ring............................................ 7
Ignition electrode (A) ........................................................................... 7
hermo couple (B) ............................................................................... 7
Ignition .................................................................................................. 10
Cleaning and maintenance ....................................................................... 11
Splashguard ........................................................................................ 11
Stainless steel surfaces ....................................................................... 12
he wok .............................................................................................. 12
Something not working ............................................................................. 21
Service and spareparts ............................................................................. 22
Guarantee conditions ................................................................................ 23
For the installer
Technical data ............................................................................................. 13
Important safety requirments .................................................................. 14
Gas connection ........................................................................................... 15
ounting .................................................................................................. 16
Table of contents
1... 2...Step by step
Safety information
Hint and tips
Environmental information
How to read the operating instructions:

4
Safety information
These warnings are provided in the
interests of your safety. Ensure you
fully understand them before installing
or using the appliance.Your safety is of
paramount importance. If you are
unsure about the meaning of these
warnings contact the Customer Care
Department for assistance.
Installing
This wok must be installed according
to the instructions supplied. Any
installation work must be undertaken
by a qualified competent person.
Do not alter the specifications or
attempt to modify the appliance in any
way.
During Use
The wok is intended for domestic
cooking only. It is not designed for
commercial/industrial purposes.
Ensure that the control knob is in the
OFF position when not in use.
Do not use the wok if it is damaged in
any way, contact your local AEG
Service Centre.
Never use plastic or aluminium dishes
on the wok.
Never leave the wok unattended while
deep fat frying, or heating fats and oils.
Child Safety
Young children must not be allowed to
tamper with the wok or play with the
control.
The wok gets hot when it is in use.
Children should be kept away until the
wok has cooled.
Maintenance and Cleaning
Only clean this wok in accordance
with the instructions given in this
book.
Service
Repairs carried out by inexperienced
persons may cause injury or serious
malfunction of the appliance. Repairs
must only be carried out by a
qualified/competent person. Contact
your local AEG Service Centre.
Disposal
Make the wok unusable by cutting off
the cable.
Dispose of any packaging material and
old appliances at an authorised
disposal site.

5
Description of the product
Burner
Knob
Placement of grid
Guide pins for grid

6
Burner markings
The operating knob has a ring showing
the scale of markings.
Off.
Max. flame
and ignition position
Min. flame
Operating instructions

7
Burner cover/inner burner
ring/outer burner ring
Together with the inner burner ring the
outer burner ring forms a space where the
final mixture of gas and air takes place in
order for the gas burn correctly.
Please note: It is very important that the
inner burner ring/outer burner ring is
placed correctly, together with the cover.
See installation of the wok burner.
If the burner cover/rings are incorrectly
fitted the burner will not operate
correctly, and the burner may be damaged
within a short space of time. It is also
important, that the inner air ring is placed
correctly.
Ignition electrode (A)
The burner has been provided with an
ignition electrode. As long as the
operating knob is depressed, the
automatic ignition will ensure that a spark
is emitted between the ignition electrode
and the burner cover.
Thermo couple (B)
The gas unit features fully-secured gas
taps (thermo-couple)
In case the flame goes out, the thermo
couple automatically prevents gas
admission after a few seconds (Max. 90
seconds).
Note: Gas will flow while the operation
button is pressed - See start-up procedure.
Cover Burner ring
Inner
burner
Outer
burner
Ignition electrode (A)
Thermo couple (B)

8
Outer burner ring
Cover
Inner burner ring
Air valve
Burner body

9
Please note: If the wok is mounted in a
table top with a cupboard underneath,
the flame might be blown out if the
door is slammed.
The wok-unit has a special pan support
which enables use of a wok pot with
curved bottom.
When using cooking utensils with a
flat bottom the diameter of the utensils
must not be less than 26 cm.

10
1. Depress and turn the control knob
for the burner, the left to Max. flame
2. The ignition electrode will emit
sparks, and when the mixture of gas
and air is correct, the burner will be
ignited. Is not possible to connect
the unit to mains, a match may be
used to ignite the burner
3. After starting the burner, press the
control knob for approx. 10
seconds to activate the automatic
thermo couple.
4. Important Ignition position is at
Max flame
Ignition

11
Cleaning and maintenance
For reasons of hygiene and
safety, the cooking burner
must be kept clean.
Grease stains and spilled
food generate smoke when
heated, and can even cause
fire.
Splashguard
The splashguard can be removed to
make it easier to clean the surface.
What to do:
1. Hold the splashguard as shown
in the diagram.
2. Lift the splashguard straight up
3. Clean the top surface as
described in “cleaning the steel
surface”.
Be aware of the two retaining
pegs, which are sharp.
4. Replace the splashguard in
position ENSURE that it is
fitted the correct way round.
Never use hard or sharp
implements to lift off the
splashguard.

Do not wash the splashguard
in a dishwasher.
The hob must not be used
with the splashguard off.

12
Stainless steel surfaces
Perform daily cleaning with a slightly
damp cloth. For more severe soiling,
use a liquid cream. Always clean the
steel in the direction of the steel finish.
To ensure that the steel retains its
shine, it is recommended that you use
a polishing agent for stainless steel on
a regular basis. Always polish in the
direction of the steel finish (cross-
wise).
Never use steel wool, metal sponges or
other abrasive cleaning agents.
The wok
The operating panel with knob, pan
support, top plate and burner
covers/rings are to be cleaned with
ordinary cleaning agents.
However, do not use any kind of
scouring powder.
Avoid saucepans boiling over. If you
have been so unfortunate as to get
water in the burner this water should
be removed before reigniting the
burner, e.g. with a no-fluff cloth.

13
Type of gas
Natural, G-20 - 20mbar
Category and pressures
II2H3+ 20 - 28/37 mbar
Max. nominal load Q, HS:
Wok burner = 5,0 kW x 1
otal= 5,0 kW
FSD
he unit features fully-secured gas taps
(thermo-fuse).
HS = Gross calorific value
Q = Nominal load
Voltage= 220-240 V AC
Ignition transformer= 50 HZ - 0,6 VA
CE 048 A - 0030
Radio-noise reduction
his unit observes the current EEC-directive
on radio noise reduction.
his gas appliance is -approved and mar-
ked in accordance with the gas appliance
Directive (90/396/CEE), the low voltage
directive (73/23/CEE) and the EMC directive
(89/336/CEE incl. the agreed directive
changes.
Technical data
he hob must be connected via an
external switch with a contact
gap of min. 3 mm (the main switch
may be used)
Cable type: 0,75 mm² HO5VV-F
N L1
240 V
1N + PE

14
This hob must be installed in
accordance with the Gas Safety
(Installation and Use) Regulations
(Current Edition) and the IEE
Wiring Regulations (Current
Edition).
Detailed recommendations are
contained in the following British
Standards Codes Of Practice: B.S.
6172/ B.S. 5440, Par. 2 and B.S.
6891 Current Editions.
The hob should not be installed in a
bed sitting room with a volume of
less than 20 m³. If it is installed in a
room of volume less than 5 m³an
air vent of effective area of 110 cm²
is required. If it is installed in a
room of volume between 5 m³and
10 m³an air vent of effective area of
50 cm²is required, while if the
volume exceeds 11 m³no air vent is
required.
However, if the room has a door
which opens directly to the outside
no air vent is required even if the
volume is between 5 m³and 11 m³.
If there are other fuel burning
appliances in the same room, B.S.
5440 Part 2 Current Edition, should
be consulted to determine the
requisite air vent requirements.
This hob must be installed by
qualified personnel to the
relevant British Standards.
Any gas installation must be
carried out by a CORGI
registered installer.
The maufacturer will not
accept liability, should the
above instructions or any of
the other safety instructions
incorporated in this book be
ignored
Important safety requirments

15
Gas installation
In accordance with local
requirements for domestic gas
cooking appliances.
Gas installation must only be
carried out by an authorised person.
For gas types see technical data.
Gas connection
The gas intake is situated at the
lower rear of the appliance. The
intake has a ½" conical pipe thread
(see fig 1) If the appliance is to be
connected to a gas cylinder,
conversion with the optional
modification kit will be necessary.
Pressure test
The unit should be pressure-tested
at Max. 150 mbar.
Fig 1
Gas connection

16
Caution: In order to avoid a hazard this
appliance must be installed according to
these instructions for installation
The hob unit can be mounted in any
type of kitchen with a table surface
whose thickness is between 28 mm and
40 mm.
Headroom
The distance to any shelves or tops of a
cabinet under the hob is to be at least 47
mm.
Fixing
Screw the fixing brackets out to such an
extent that they can be turned in under
the table top. Tighten the brackets on to
the table top with an ordinary
screwdriver.
Cut-out measurements
One rectangular hole is sawn out for the
hob combination chosen.
The depth of the cut-out for any unit is:
490 mm
Length of hole = sum of all units`
externally measured length, less 20 mm.
Mounting of Reinforcement
Beams
A reinforcement Beam, with supporting
flanges at each end, is included with
each two-burner unit. For unit
combinations, a reinforcement beam
must be used between each unit.
Mounting
Minimum distance
to side wall:
150 mm
Minimum distance to
rear wall (non
flammable material):
50 mm
Reinforcement
beams

17
It is not necessary to attach the
reinforcement beam to the work top
surface, as it is held in place by a
specially designed moulding, which is
incorporated in the hob units flanges.
The units externally measured
length
145 mm:
Cooker hood
290 mm:
Two-zone ceramic-top electric hob
Two-burner gas hob
Grill
Fryer
Wok
580 mm:
Four-zone ceramic-top electric hob
Four-burner gas hob
725 mm:
Four-zone ceramic-top electric hob
Installation of a single unit
When mounting a single unit, be it a
half-or full size unit, in a
worktopsurface which is thicker than
30 mm, it is necessary to make a
special notch in both sides of the cut-
out hole, as shown in the adjacent
drawing.
The purpose of these notches is to
create space for the electrical cables.

18
Installation of wok burner
It is extremely important that
both the inner and outer
burner rings are fitted
correctly into their “guide
notch”, otherwise the burner
will burn with an incorrect
flame pattern and could be
ruined within a very short
period. You must be able to
hear a click telling you that
the rings have been correctly
fitted.
How to proceed:
1. Fit the air valve in the burner
body. See fig. 1
2. Then fit the inner burner ring,
taking care that the guide pin
engages in the notch. See fig. 2.
Fig. 1
Fig. 2
Air valve
Inner burner ring

19
3. Place the cover plate over. See
fig. 3.
4. Finally, fit the outer burner ring,
taking care that the guide pin
engages in the notch. See fig. 4.
Fig. 3
Fig. 4
Cover plate
Outer burner ring

20
An opening with a minimum area of 60
cm2 must be present at the back of the
cupboard (see fig.).
