AEG FAVORIT 88089 User manual

FAVORIT 88089
EN
DISHWASHER USER MANUAL

FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have
created it to give you impeccable performance for many
years, with innovative technologies that help make life
simpler – features you might not find on ordinary
appliances. Please spend a few minutes reading to get the
very best from it.
ACCESSORIES AND CONSUMABLES
In the AEG webshop, you’ll find everything you need to
keep all your AEG appliances looking spotless and
working perfectly. Along with a wide range of accessories
designed and built to the high quality standards you
would expect, from specialist cookware to cutlery baskets,
from bottle holders to delicate laundry bags…
Visit the webshop at:
www.aeg.com/shop
2

CONTENTS
4 Safety information
6 Product description
8 Control panel
11 Use of the appliance
11 Setting the water softener
13 Use of dishwasher salt
13 Use of detergent and rinse aid
15 Multitab function
15 Loading cutlery and dishes
17 Washing programs
19 Setting and starting a washing
program
21 Care and cleaning
23 What to do if…
26 Technical data
26 Installation
30 Water connection
33 Electrical connection
33 Environment concerns
34 Warranty
The following symbols are used in this user
manual:
Important information concerning your
personal safety and information on how to
avoid damaging the appliance.
General information and tips
Environmental information
Subject to change without notice
Contents 3

SAFETY INFORMATION
For your safety and correct operation of the appliance, read this manual carefully before
installation and use. Always keep these instructions with the appliance even if you move or
sell it. Users must fully know the operation and safety features of the appliance.
Correct use
• Only use the appliance to clean household utensils that are suitable for dishwashers.
• Do not put solvents in the appliance. Risk of explosion.
• Put knives and all items with sharp points in the cutlery basket with their points down. If
not, put them in a horizontal position in the upper basket.
• Use only products specified for dishwashers (e.g. detergent, salt, rinse aid).
• If you open the door while the appliance is in operation, hot steam can escape. Risk of
skin burns.
• Do not remove dishes from the appliance before the end of the washing program.
• When the washing program is completed, disconnect the mains plug from the mains
socket and close the water tap.
• Only an authorised service engineer can repair this appliance. Use only original spare
parts.
• Do not do repairs yourself to prevent injury and damage to the appliance. Always con-
tact the Customer Care Centre.
General safety
• This appliance is intended to be used in household and similar applications such as:
– Staff kitchen areas in shops, offices and other working environments
– Farm houses
– By clients in hotels, motels and other residential type environments
– Bed and breakfast type environments.
• Some dishwasher detergents are strongly alkaline. They can be extremely dangerous if
swallowed. Avoid contact with skin and eyes. Keep the children away from the appliance
when the door is open. Check that the detergent dispenser is empty after completion of
the washing program.
• Obey the safety instructions from the manufacturer of the dishwasher detergent to pre-
vent burns to eyes, mouth and throat.
• Only put detergent in the dispenser before you start a washing program.
• Do not drink the water from the appliance. Detergent residue can stay in your appliance.
• Always close the door when you do not use the appliance to prevent injury and not to
stumble over the open door.
• Do not sit or stand on the open door.
4Safety information

Child safety
• This appliance is not intended for use by young children or infirm persons unless they
have been adequately supervised by a responsible person to ensure that they can use the
appliance safely.
• Children should be supervised to ensure that they do not play with the appliance.
• Keep all the packaging away from children. There is a risk of suffocation.
• Keep all detergents in a safe area. Do not let children touch the detergents.
• Keep children and pets away from the appliance when the door is open.
Installation
• Make sure that the appliance is not damaged because of transport. Do not connect a
damaged appliance. If necessary, contact the supplier.
• Remove all packaging before first use.
• A qualified and competent person must do the electrical installation.
• A qualified and competent person must do the plumbing installation.
• Do not change the specifications or modify this product. Risk of injury and damage to
the appliance.
• Do not use the appliance:
– If the mains cable or the water hoses are damaged.
– If the control panel, worktop or plinth area are damaged so that you can get access to
the inner side of the appliance.
Contact your local Customer Care Centre.
• Do not drill into the sides of the appliance otherwise damage to hydraulic and electrical
components may occur.
WARNING!
Follow carefully the instructions for electrical and water connections.
Safety information 5

PRODUCT DESCRIPTION
2
3
4
5
6
7
1
8
9
10
1Upper basket
2Air vent and water hardness dial
3Salt container
4Detergent dispenser
5Rinse aid dispenser
6Rating plate
7Filters
8Lower spray arm
9Upper spray arm
10 Top spray arm
Internal light
This appliance has an internal light that comes on when you open the door and goes off
when the door is closed.
WARNING!
Visible led radiation, do not stare into the beam.
Internal light equipped with LED lamp CLASS 2 in accordance with IEC 60825-1: 1993 +
A1:1997+ A2:2001.
Emission wave length: 450 nm
Maximum emitted power: 548 μW
If it is necessary to replace the light, contact your local Customer Care Centre.
6Product description

TimeBeam
The TimeBeam shows, on the kitchen floor, the
time of the washing program or the countdown of
the delay start.
With the TimeBeam you always know the remain-
ing time of the washing program and/or of the
delay start.
Nine different colours are available for TimeBeam
(refer to ‘Control panel’).
The TimeBeam shows:
• The time of the washing program. It decreases
with steps of one minute.
• The end of the washing programme. A zero
shows on the kitchen floor.
• The countdown of the delay start with steps of one hour (24h, 23h...).
The TimeBeam goes off when the appliance is switched off.
Product description 7

CONTROL PANEL
The controls are on the top of the control panel. To operate with the controls keep the ap-
pliance door ajar.
1234567 8 9
1On/off button
2Display
3Delay start touchpad
4Program touchpad
5Extra-Hygiene touchpad
6ÖKO PLUS touchpad
7Multitab touchpad
8RESET touchpad
9Indicators
Indicators
Salt indicator. It comes on when it is necessary to fill the salt container.
1)
After you fill the container, the salt indicator can stay on for some hours. This
does not have an unwanted effect on the operation of the appliance
Rinse aid indicator. It comes on when it is necessary to fill the rinse aid dispenser.
1)
End indicator. It comes on when the washing program is completed.
1) When the salt container and/or the rinse aid dispenser are empty, the related indicators do not come on while a
washing program operates.
On/off button
Press this button to switch on or off the appliance.
After 10 minutes from the end of the washing program, the AUTO OFF function automati-
cally switches off the appliance. This helps to decrease energy consumption.
The display
The display shows:
• The electronic adjustment of the level of the water softener
• The activation and deactivation of the rinse aid dispenser (only with the multitab func-
tion on)
• The number of the washing program
• The remaining time to the end of the washing program
• The end of a washing program (the display shows a zero)
8Control panel

• The time of the delay start
• The alarm codes
• The activation and deactivation of the acoustic signals.
• The setting of the colour of the TimeBeam.
Delay start touchpad
Press this touchpad to delay the start of the washing program from 1 to 24 hours. Refer to
'Setting and starting a washing program'.
Program touchpad
Press this touchpad repeatedly to set a washing program. Each time you press the touch-
pad, the display shows a number that is related to a washing program. Refer to 'Washing
programs' chart.
Extra-Hygiene touchpad
This function provides more hygienically clean dishes and glasses. During the last rinse, the
temperature increases to 70 °C and is kept above 65 °C minimum for 10 to 14 minutes.
Press this touchpad to activate the function. The related indicator comes on.
The function can be activated with all washing programs but has effect only on some pro-
grams. To see where the Extra-Hygiene function has effect, refer to the 'Washing programs'
chart.
ÖKO PLUS touchpad
This function decreases the temperature in the drying phase. The power consumption de-
creases by 25%. The dishes can be wet at the end of the program when you open the appli-
ance door. We recommend that you keep the door ajar and let the dishes dry.
Press this touchpad to activate the function. The related indicator comes on.
The function can be activated with all washing programs but has effect only on some pro-
grams. To see where the energy saver function has effect, refer to the 'Washing programs'
chart.
Multitab touchpad
Press this touchpad to activate or deactivate the multitab function. Refer to 'Multitab func-
tion'.
RESET touchpad
Press this touchpad to cancel a washing program in operation. Refer to 'Setting and start-
ing a washing program'.
Setting mode
The appliance must be in setting mode for these operations:
• To set and start a washing program.
• To set and start a delay start.
• To adjust electronically the level of the water softener.
• To activate or deactivate the rinse aid dispenser (only with the multitab function on).
• To deactivate or activate the acoustic signals.
Control panel 9

• To set the colour of the TimeBeam.
Switch on the appliance. The appliance is in setting mode when:
• The display shows two horizontal status bars.
Switch on the appliance. The appliance is not in setting mode when:
• The display shows the time of the washing program or of the delay start.
– To go back to the setting mode, it is necessary to cancel the program or the delay
start. Refer to 'Setting and starting a washing program'.
Acoustic signals
You can hear the acoustic signals when:
• The washing program is completed.
• You adjust electronically the level of the water softener.
• The appliance has a malfunction.
Factory setting: acoustic signals active.
Deactivating the acoustic signals
1. Switch on the appliance. Make sure that the appliance is in setting mode.
2. Press and hold touchpad (4) and touchpad (5) at the same time until the indicators of
touchpads (3), (4), (5) and (6) flash.
3. Release touchpad (4) and touchpad (5).
4. Press touchpad (5),
• The indicators of touchpad (3), (4) and touchpad (6) go off.
• The indicator of touchpad (5) continues to flash.
• The display shows the setting of the acoustic signals.
Acoustic signals activated.
Acoustic signals deactivated.
5. Press touchpad (5) to change the setting. The display shows the new adjustment.
6. Switch off the appliance to confirm.
To activate the acoustic signals again, do steps (1) through (6).
Setting the colour of the TimeBeam
1. Switch on the appliance. Make sure that the appliance is in setting mode.
2. Press and hold touchpad (4) and touchpad (5) at the same time until the indicators of
touchpads (3), (4), (5) and (6) flash.
3. Release touchpad (4) and touchpad (5).
4. Press touchpad (6),
• The indicators of touchpads (3), (4) and (5) go off.
• The indicator of touchpad (6) continues to flash.
• The display shows a number followed by the letter C. On the floor you can see the
colour that is related to the number.
10 Control panel

5. Press touchpad (6) again and again to change the colour. Each time you press touchpad
(6), the number in the display and the colour on the floor change (0C= TimeBeam dec-
ativated).)
6. Switch off the appliance to confirm.
USE OF THE APPLIANCE
Refer to the specific instructions for each step of the procedure.
1. Check if the water softener level is correct for the water hardness in your area. If neces-
sary set the water softener.
2. Fill the salt container with dishwasher salt.
3. Fill the rinse aid dispenser with rinse aid.
4. Load cutlery and dishes into the appliance.
5. Set the correct washing program for the type of load and soil.
6. Fill the detergent dispenser with the correct quantity of detergent.
7. Start the washing program.
If you use the combi detergent tablets ('3 in 1', '4 in 1', '5 in 1'), set the multitab function.
Refer to 'Multitab function'.
SETTING THE WATER SOFTENER
The water softener removes minerals and salts from the water supply. Minerals and salts
can have bad effect on the operation of the appliance.
Water hardness is measured in equivalent scales:
• mg/I (millimol per litre)
• ppm (parts per million),
• mmol/l (millimol per litre -international unit for the hardness of water).
Adjust the water softener in to the water hardness in your area. If necessary, contact your
local water authority.
Water hardness Water hardness setting
mg/l ppm mmol/l manually electronically
910 -1250 910 -1250 9.1 -12.5 210
760 -909 760 -909 7.6 -9.0 2 9
650 -759 650 -759 6.5 -7.5 2 8
510 -649 510 -649 5.1 -6.4 2 7
400 -509 400 -509 4.0 -5.0 2 6
330 -399 330 -399 3.3 -3.9 2 5
260 -329 260 -329 2.6 -3.2 1 4
190 -259 190 -259 1.9 -2.5 1 3
Use of the appliance 11

Water hardness Water hardness setting
mg/l ppm mmol/l manually electronically
70 -189 70 -189 0.7 -1.8 1 2
< 70 < 70 < 0.7 11
1)
1) No use of salt required.
You must set the water softener manually and electronically.
Manual adjustment
The appliance is set at the factory at position 2.
1. Remove the lower basket.
2. Turn the water hardness dial to position 1
or 2 (refer to the chart).
3. Put back the lower basket.
Electronic adjustment
The appliance is factory set at level 5.
1. Switch on the appliance. Make sure that the appliance is in setting mode.
2. Press and hold touchpad (4) and touchpad (5) at the same time until the indicators of
touchpads (3), (4), (5) and (6) flash.
3. Release touchpad (4) and touchpad (5).
4. Press touchpad (3),
• The indicators of touchpad (4), (5) and touchpad (6) go off.
• The indicator of touchpad (3) continues to flash.
• The acoustic signals sound.
• The display shows the setting of the water softener (example: and you hear five
acoustic signals = level 5).
5. Press touchpad (3) one time to increase the water softener level by one step. Continue
to press touchpad (3) until the required water softener level is achieved.
6. Switch off the appliance to confirm.
12 Setting the water softener

USE OF DISHWASHER SALT
CAUTION!
Only use dishwasher salt. Types of salt that are not suitable for dishwashers cause damage
to the water softener.
CAUTION!
Grains of salt and salty water on the bottom of the appliance can cause corrosion. Fill the
appliance with salt before you start a washing program.
Filling the salt container
1. Turn the cap counterclockwise to open the salt container.
2. Fill the salt container with 1 litre of water (only the first operation).
3. Use the funnel to fill the salt container
with salt.
4. Remove the salt around the opening of
the salt container.
5. Turn the cap clockwise to close the salt
container.
It is normal that water overflows from the
salt container when you fill it with salt.
USE OF DETERGENT AND RINSE AID
20
30
M
A
X
1
2
3
4
+
-
1234
5
6
7
Use of dishwasher salt 13

Use of detergent
CAUTION!
Only use detergents (powder, liquid or tablet) that are suitable for dishwashers.
Follow the recommendations on the detergent packaging for the use and storage of the
detergent.
To help the environment, do not use more than the correct quantity of detergent.
Filling with detergent
1. Press the release button
2
to open the lid
7
of the detergent dispenser.
2. Put the detergent in the dispenser
1
.
3. If the washing program has a prewash phase, put a small quantity of detergent on the
inner part of the appliance door.
4. If you use the detergent tablets, put the tablet in the detergent dispenser
1
.
5. Close the detergent dispenser. Press the lid until it locks into position.
Different brands of detergent dissolve in different times. Some detergent tablets do not
have the best cleaning results during short washing programs. Use long washing programs
when you use detergent tablets to fully remove the detergent.
Use of rinse aid
CAUTION!
Only use rinse aid specified for dishwashers.
Do not fill the rinse aid dispenser with other products (e.g. dishwasher cleaning agent, liq-
uid detergent). This can cause damage to the appliance.
Rinse aid makes it possible to dry the dishes without streaks and stains.
Rinse aid is automatically added during the last rinsing phase.
Follow these steps to fill the rinse aid dispenser:
Filling with rinse aid
1. Press the release button
6
to open the lid
5
of the rinse aid dispenser.
2. Fill the rinse aid dispenser
3
with rinse aid. The mark 'max' shows the maximum level.
3. Remove the spilled rinse aid with an absorbent cloth to prevent too much foam during
the washing program.
4. Close the rinse aid dispenser. Press the lid until it locks into position.
Adjusting the rinse aid dosage
Factory set: position 3.
You can set the rinse aid dosage between position 1 (lowest dosage) and position 4 (highest
dosage).
Turn the rinse aid selector
4
to increase or reduce the dosage.
Wash hands to remove any residue of rinse aid from skin.
14 Use of detergent and rinse aid

MULTITAB FUNCTION
The multitab function is for combi detergent tablets.
These tablets contain agents as detergent, rinse aid and dishwasher salt. Some types of tab-
lets can contain other agents.
Be sure that these tablets are suitable for the water hardness in your area (refer to the in-
structions on the packaging of the products).
The multitab function deactivates the flow of rinse aid and salt.
The multitab function deactivates the indicators of salt and rinse aid.
The program duration can increase if you use the multitab function.
Activate or deactivate the multitab function before the start of a washing program. You
cannot activate or deactivate the function while a washing program operates.
To activate the multitab function
• Press the multitab touchpad, the multitab indicator comes on. The function is activated.
– When you activate the multitab function, it stays on until you deactivate it.
To deactivate the multitab function and use separately detergent, salt and rinse aid
1. Press the multitab touchpad, the multitab indicator goes off. The function is deactiva-
ted.
2. Fill the salt container and the rinse aid dispenser.
3. Adjust the water hardness to the highest level.
4. Start a washing program without dishes.
5. When the washing program is completed, adjust the water softener to the water hard-
ness in your area.
6. Adjust the rinse aid dosage.
LOADING CUTLERY AND DISHES
Refer to the leaflet 'Examples of ProClean loads'.
Helpful hints and tips
CAUTION!
Only use the appliance for household utensils that are suitable for dishwashers.
Do not use the appliance to clean objects that can absorb water (sponges, household cloths,
etc.).
• Before you load cutlery and dishes:
– Remove all remains of food and debris.
– Soften burnt remains of food.
• While you load cutlery and dishes:
– Load hollow items (e.g. cups, glasses and pans) with the opening down.
– Make sure that water does not collect in the container or in a deep base.
Multitab function 15

– Make sure that cutlery and dishes do not lie inside one another.
– Make sure that cutlery and dishes do not cover other cutlery and dishes.
– Make sure that glasses do not touch other glasses.
– Put small objects in the cutlery basket.
• Plastic items and pans with non-stick coatings can retain water droplets. Plastic items do
not dry as well as porcelain and steel items.
• Put light items in the upper basket. Make sure that the items do not move.
CAUTION!
Make sure that the spray arms can move freely before you start a washing program.
WARNING!
Always close the door after you load or unload the appliance. An open door can be danger-
ous.
16 Loading cutlery and dishes

WASHING PROGRAMS
Program Type of soil Type of load Program description Functions
1
1)
All Crockery, cut-
lery, pots and
pans
Prewash
Wash 45 °C or 70 °C
Rinses
Dry
Extra-Hygiene
ÖKO PLUS
2Heavy soil Crockery, cut-
lery, pots and
pans
Prewash
Wash 70 °C
Rinses
Dry
ÖKO PLUS
3
2)
Normal soil Crockery and
cutlery
Prewash
Wash 50 °C
Rinses
Dry
4
3)
Fresh soil Crockery and
cutlery
Wash 60 °C
Rinse
Extra-Hygiene
5
4)
Normal soil Crockery and
cutlery
Prewash
Wash 50 °C
Rinses
Dry
Extra-Hygiene
ÖKO PLUS
6Light soil Crockery and
cutlery
Wash 55 °C
Rinses
Extra-Hygiene
7
5)
Mixed soil Crockery, cut-
lery, pots and
pans
Prewash
Wash 70 °C
Rinses
Dry
ÖKO PLUS
8Normal or
light soil
Delicate crock-
ery and glass-
ware
Wash 45 °C
Rinses
Dry
ÖKO PLUS
9Use this program to quickly
rinse the dishes. This prevents
the remaining food to bond
on the dishes and bad odours
to come out from the appli-
ance.
Do not use detergent with
this program.
Rinse
1) The appliance senses the type of soil and the quantity of items in the baskets. It automatically adjusts the
temperature and quantity of the water, the energy consumption and the program time.
2) This is the most silent washing program. The pump works at a very low speed to decrease the level of noise.
Because of the low speed, the program time is long.
3) With this program you can wash a load with fresh soil. It gives good washing results in a short time.
Washing programs 17

4) This is the standard program for test institutes. With this program you have the most efficient use of water and
energy consumption for crockery and cutlery with normal soil. Refer to the supplied leaflet for test information.
5) With this program you can wash a load with mixed soil. Very heavy soil in the lower basket and normal soil in
the upper basket. The water pressure in the lower basket is three times higher than in the upper basket. The
temperature of the water in the lower basket is 25% higher than in the upper basket.
Consumption values
Program Program time (mi-
nute)
Energy (kWh) Water (litre)
190 -160 0.9 -1.7 8 -15
2140 -160 1.4 -1.6 13 -14
3200 -220 1.1 -1.2 9 -11
430 0.8 9
5105 -115 0.81 -0.67 9.6 -11.6
650 -60 1.0 -1.1 10 -11
7130 -140 1.3 -1.5 14 -15
870 -80 0.8 -0.9 11 -12
914 0.05 4
The water pressure and temperature, the variations of the mains supply and the quantity of
dishes can change the consumption values.
18 Washing programs

SETTING AND STARTING A WASHING PROGRAM
Starting the washing program without delay start
1. Switch on the appliance. Make sure that the appliance is in setting mode.
2. Set the washing program. The number related to the washing program flashes in the
display.
3. If you want, set the Extra-Hygiene and/or the ÖKO PLUS function. Set these functions
after the setting of the washing program
4. Close the appliance door, the washing program starts.
Starting the washing program with delay start
1. Switch on the appliance. Make sure that the appliance is in setting mode.
2. Set the washing program and functions.
3. Press the delay start touchpad repeatedly until the display shows the time of the delay
start.
• The time of the delay start flashes in the display.
• The delay start indicator is on.
4. Close the appliance door, the countdown starts.
When the countdown is completed, the washing program starts automatically.
The opening of the appliance door interrupts the countdown. When you close the door, the
countdown continues from the point of interruption.
Cancelling the delay start
If the appliance door is open, and the countdown has not started
1. Press the delay touchpad repeatedly until the display shows the number of the washing
program.
• The program number flashes in the display.
2. Close the appliance door, the washing program starts.
If the appliance door is closed, and the countdown operates
1. Open the appliance door.
2. Press the delay touchpad repeatedly until the display shows the number of the washing
program.
• The number flashes for some seconds and then the time of the washing program
shows in the display.
3. Close the appliance door, the washing program starts.
WARNING!
Only interrupt or cancel a washing program if necessary.
Attention! Open the door carefully. Hot steam and water can escape.
Setting and starting a washing program 19

Interrupting a washing program
• Open the appliance door. The washing program stops.
• Close the appliance door. The washing program continues from the point of interruption.
Cancelling the washing program
If the washing program has not started, you can change the selection.
To change the selection while the washing program operates, it is necessary to cancel the
program.
• Press the RESET touchpad until the display shows two horizontal status bars.
Make sure that there is detergent in the detergent dispenser before you start a new wash-
ing program.
End of the washing program
When the washing program is completed, an intermittent acoustic signal sounds.
1. Open the appliance door.
• The end indicator is on
• The display shows a zero.
2. Switch off the appliance.
For better drying results, keep the appliance door ajar for some minutes.
Removing the load
• Let the dishes cool down before you remove them from the appliance. Hot dishes are
easily damaged.
• First remove items from the lower basket, then from the upper basket.
• There can be water on the sides and door of the appliance. Stainless steel becomes cool
more quickly than the dishes.
20 Setting and starting a washing program
