AEG T75175AV User manual

USER
MANUAL
EN User Manual 2
Tumble Dryer
FR Notice d'utilisation 23
Sèche-linge
RU Инструкция по эксплуатации 46
Сушильный барабан
T75175AV

CONTENTS
1. SAFETY INFORMATION.............................................................................................3
2. SAFETY INSTRUCTIONS.............................................................................................5
3. ACCESSORIES............................................................................................................. 7
4. PRODUCT DESCRIPTION...........................................................................................8
5. CONTROL PANEL....................................................................................................... 8
6. PROGRAMME TABLE................................................................................................. 9
7. OPTIONS....................................................................................................................10
8. SETTINGS...................................................................................................................12
9. BEFORE FIRST USE................................................................................................... 12
10. DAILY USE................................................................................................................13
11. HINTS AND TIPS..................................................................................................... 14
12. CARE AND CLEANING.......................................................................................... 14
13. TROUBLESHOOTING.............................................................................................15
14. TECHNICAL DATA..................................................................................................16
15. INSTALLATION........................................................................................................18
16. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U. REGULATION
1369/2017........................................................................................................................21
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler - features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.aeg.com2

1. SAFETY INFORMATION
Before beginning the installation and use of this
appliance, carefully read the supplied instructions. The
manufacturer is not responsible for any injuries or
damage that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent
disability.
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
•Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of
it appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance when
the door is open.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
ENGLISH 3

1.2 General Safety
•Do not change the specification of this appliance.
•If the tumble dryer is put on top of a washing
machine, use the stacking kit. The stacking kit,
available from your authorized vendor, can be used
only with the appliance specified in the instructions
supplied with the accessory. Read it carefully before
installation (refer to the Installation leaflet).
•Do not install the appliance behind a lockable door, a
sliding door or a door with a hinge on the opposite
side, that would prevent the appliance door from
being fully open.
•The ventilation opening in the base must not be
covered by a carpet, mat, or any floor covering.
•CAUTION: The appliance must not be supplied
through an external switching device, such as a timer,
or connected to a circuit that is regularly switched on
and off by a utility.
•Connect the mains plug to the mains socket only at
the end of the installation process. Make sure that the
mains plug is accessible after installation.
•Ensure good air ventilation in the room where the
appliance is installed to avoid the backflow of
unwanted gases into the room from appliances
burning gas or other fuels, including open fires.
•Exhaust air must not be discharged into a flue which is
used for exhausting fumes from any appliances
burning gas or other fuels.
•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
•Do not exceed the maximum load of 7 kg (refer to the
"Programme chart" chapter).
•Do not use the appliance if items have been soiled
with industrial chemicals.
www.aeg.com4

•Wipe away lint or packaging debris that has
accumulated around the appliance.
•Do not run the appliance without a filter. Clean the lint
filter before or after each use.
•Do not dry unwashed items in the tumble dryer.
•Items that have been soiled with substances such as
cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers should
be washed in hot water with an extra amount of
detergent before being dried in the tumble dryer.
•Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes
or pillows fitted with foam rubber pads should not be
dried in the tumble dryer.
•Fabric softeners, or similar products, should only be
used as specified by the product manufacturer’s
instructions.
•Remove all objects from items that could be a source
of fire ignition such as lighters or matches.
•WARNING: Never stop a tumble dryer before the end
of the drying cycle unless all items are quickly
removed and spread out so that the heat is
dissipated.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
2. SAFETY INSTRUCTIONS
2.1 Installation
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use the appliance
where the temperature can be lower
than 5°C or higher than 35°C.
• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Always keep the appliance vertical
when it is being moved.
• The rear surface of the appliance
must be put against a wall.
• When the appliance is in its
permanent position, check if it is
levelled correctly with the aid of a
spirit level. If it is not, adjust the feet
accordingly.
ENGLISH 5

2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Do not touch the mains cable or the
mains plug with wet hands.
2.3 Use
WARNING!
Risk of injury, electric shock,
fire, burns or damage to the
appliance.
• This appliance is for household use
only.
• Do not dry damaged (torn, frayed)
items that contain padding or fillings.
• If laundry has been washed with a
stain remover, carry out an additional
rinse cycle before starting a drying
cycle.
• Dry only fabrics that are suitable to
dry in the appliance. Follow the
cleaning instruction on the item label.
• Do not drink or prepare food with the
condensed water/distilled water. It
can cause health problems to people
and pets.
• Do not sit or stand on the open door
of the appliance.
• Do not dry dripping wet clothes in the
appliance.
2.4 Care and cleaning
WARNING!
Risk of injury or damage to
the appliance.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
2.5 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
www.aeg.com6

3. ACCESSORIES
3.1 Stacking kit
Product name: SKP11.
Available from your authorized dealer.
Stacking kit can be used only with the
washing machines specified in the
leaflet. See leaflet attached. Read
carefully the instructions supplied with
the kit.
3.2 Pedestal with the drawer
Product name: PDSTP10.
Available from your authorized dealer.
To put the appliance higher at the level
which helps to easy load and remove the
laundry.
The drawer can be use for laundry
storage e.g. : towels, cleaning products
and more. Read carefully the instructions
supplied with the accessory.
3.3 Vent kit
Universal kit for vented dryers where an
outdoor outlet is not possible. The tank
collects lint and condensation, thus
avoiding dirt and damage due to
moisture in the room where the tumble
dryer is placed.
Read carefully the instructions supplied
with the kit.
ENGLISH 7

4. PRODUCT DESCRIPTION
1
3
2
5
6
7
4
1Control panel
2Appliance door (reversible)
3Primary Filter
4Adjustable feet
5Plastic ring
6Side/rear ventilation opening
7Rating plate
5. CONTROL PANEL
1 2 3
456789
1Programme knob and OFF switch 2Display
www.aeg.com8

3Push button Delay
4Push button Start/Pause
5Push button Time
6Push button Buzzer
7Push button Anti-crease
8Push button Sensitive
9Push button Delicate
5.1 Display
Indicators Description
Drying phase
Cooling phase
Crease guard
Delay start
Child lock
Programme duration
- Time programme interval (10 min. - 3h.)
- Delay start interval (30 min. - 20h.)
6. PROGRAMME TABLE
Programmes Type of load Load (max.)1) /
Fabric mark
Cotton
Extra Dry Drying level: extra dry. 7kg/
Strong Dry Drying level: strong dry. 7kg/
Cupboard Dry 2) 3) Drying level: cupboard dry. 7kg/
ENGLISH 9

Programmes Type of load Load (max.)1) /
Fabric mark
Iron Dry2) Drying level: suitable for ironing. 7kg/
Synthetic
Extra Dry Drying level: extra dry. 3kg/
Cupboard Dry 2) Drying level: cupboard dry. 3kg/
Iron Dry Drying level: suitable for ironing. 3kg/
Special
Time With this programme you can use the Time
option and set the programme duration. 7kg/
Refresh Refreshing textiles that were in storage. 1kg
Bed linen Bed linen such as single and double sheets,
pillowcases, duvet cover. 2kg/
Jeans
Leisure clothing such as jeans, sweat-shirts
of different material thicknesses (e.g. at the
neck, cuffs and seams). 7kg/
Sports Sportswear, thin and light fabrics, microfib-
er, polyester. 2kg/
Easy Iron
Easy care fabrics for which a minimum of
ironing is necessary. The drying results can
be different from one type of fabric to an-
other. Shake the items before putting them
in the appliance. When the programme has
ended, immediately remove the items and
put them on a hanger.
1kg (or 5 shirts)/
Wool Refresh
Refreshing a wool fabrics. Wool items be-
come soft and cosy. Remove the items im-
mediately after the programme end.
1kg
1) The maximum weight refers to dry items.
2) For test institutes only: Standard programmes for tests are specified in the EN 61121 document.
3) The Cotton Cupboard Dry ECO programme is the “Standard cotton programme” according to
Commission Regulation EU No. 392/2012. It is suitable for drying normal wet cotton laundry and it is the
most efficient programme in terms of energy consumption for drying wet cotton laundry.
7. OPTIONS
7.1 Delicate
With this option you can set a delicate
drying programme that has a low
temperature. Use this option with a
fabrics that have the symbol on the
fabric label (e.g. acrylic, viscose).
www.aeg.com10

7.2 Sensitive
To dry lightly of fabrics that are
frequently worn. Programme starts on full
heat setting, which is then decrease as
the programme continue to be lightly to
the laundry.
7.3 Anti-crease
Extends the anti-crease phase by 60
minutes at the end of the drying cycle.
This function reduces creases. The
laundry can be removed during the anti-
crease phase.
7.4 Buzzer
The buzzer sounds at the:
•cycle end
• start and end of the anti-crease phase
• cycle interruption
The buzzer function is by default always
on. You can use this function to activate
or deactivate the sound.
You can activate the Buzzer
option with all programmes.
7.5 Time
This option is applicable only to the Time
Drying programme. You can set the
programme duration, from a minimum of
10 minutes to a maximum of 3 hours. The
setting of the duration is related to the
quantity of laundry in the appliance.
We recommend that you set
a short duration for small
quantities of laundry or for
only one item.
7.6 Options table
Programmes1) Delicate Sensitive Anti-crease Time
Cotton
Extra Dry ■■■
Strong Dry ■■■
Cupboard Dry ■■■
Iron Dry ■■■
Synthetic
Extra Dry ■■■
Cupboard Dry ■■■
Iron Dry ■■■
Special
Time Drying ■ ■ ■
Refresh ■ ■
Bed linen ■ ■
Jeans ■■■
Sports ■ ■
Easy Iron ■ ■
ENGLISH 11

Programmes1) Delicate Sensitive Anti-crease Time
Wool Refresh ■
1) The Delicate and Sensitive functions cannot be set together.
8. SETTINGS
A DB C FE
G
A. Push button Delicate
B. Push button Sensitive
C. Push button Anti-crease
D. Push button Buzzer
E. Push button Time
F. Push button Start/Pause
G. Push button Delay
8.1 Adjustment of the
remaining laundry moisture
degree
To change the default degree of the
remaining moisture of the laundry:
1. Use the programme knob to set any
programme.
2. Wait approximately 8 seconds.
3. Press and hold buttons (A) and (E) at
the same time.
One of the these indicators comes on:
• the maximum dry laundry
•the more dry laundry
• the standard dry laundry
4. Press the button (F) again and again
until the indicator of the correct level
comes on.
5. To confirm the adjustment, press and
hold buttons (A) and (E) at the same
time for approximately 2 seconds.
8.2 Child lock function
This option prevents children to play with
the appliance while a programme
operates. The programme knob and the
touchpads are locked.
Only OFF switch is unlocked.
Activating the child lock
option:
1. Use the programme knob to set any
programme.
2. Wait approximately 8 seconds.
3. Press and hold touchpads (C) and (D)
at the same time. The child lock
indicator comes on.
The child lock indicator comes on.
It is possible to deactivate
the child lock option while a
programme operates. Press
and hold the same
touchpads until the child
lock indicator goes off.
8.3 Buzzer permanent off
To deactivate or activate the acoustic
signals, press and hold for approximately
2 seconds touchpads (A) and (B) at the
same time.
9. BEFORE FIRST USE
Before you use the appliance for the first
time:
• Clean the tumble dryer drum with a
moist cloth.
• Start a 1 hour programme with moist
laundry.
www.aeg.com12

10. DAILY USE
10.1 Start a programme
without delay start
1. Prepare the laundry and load the
appliance.
CAUTION!
Make sure that when you
close the door, the
laundry does not get
caught between the
appliance door and the
rubber seal.
2. Set the correct programme and
options for the type of load.
The display shows the programme
duration.
The drying time you see on
the display, when the cotton
programme is selected, is
related to the load of 5 kg
and standard conditions .
Real drying time will depend
on type of the load (quantity
and composition), the room
temperature and the
humidity of your laundry
after spin drying phase.
3. Press the Start/Pause touch button.
The programme starts.
10.2 Starting the programme
with delay start
1. Set the correct programme and
options for the type of load.
2. Press the delay start button again
and again until the display shows the
delay time you want to set.
You can delay the start
of a programme from a
minimum of 30 minutes
to a maximum of 20
hours.
3. Press the Start/Pause touchpad.
The display shows the countdown of the
delay start.
When the countdown is completed, the
programme starts.
10.3 Change a programme
1. Turn the Programme knob to OFF
2. Set the programme.
10.4 At the end of the
programme
When the programme is completed:
•The indicator flashes.
•An intermittent acoustic signal
operates (If the Buzzer function is on).
• The indicator Filter comes on.
• The Start/Pause indicator is on.
The appliance continues to operate with
the crease guard phase for
approximately other 30 minutes.
The crease guard phase removes creases
from your laundry.
You can remove the laundry before the
crease guard phase is completed. We
recommend, for better results, that you
remove the laundry when the phase is
almost completed or completed.
When the crease guard phase is
completed:
• The indicator is on but does not
flash.
•Start/Pause indicator goes off.
1. Turn the Programme knob to OFF
2. Open the appliance door.
3. Remove the laundry.
4. Close the appliance door.
Always clean the filter
when a programme is
completed.
10.5 Stand-by function
To decrease the energy consumption,
this function automatically deactivates
the appliance:
•After 5 minutes if you do not start the
programme.
• After 5 minutes from the end of the
programme.
ENGLISH 13

11. HINTS AND TIPS
11.1 Preparing the laundry
• Close the zips.
•Close the fasteners of duvet covers.
• Do not dry ties or ribbons loose (e.g.
apron ribbons). Tie them before you
start a programme.
• Remove all items from pockets.
• Turn items with the internal layer
made of cotton inside out. Cotton
layer must be faced outwards.
• Always set the programme suitable
for the type of laundry.
• Do not put light and dark colours
together.
• Use suitable programme for cottons,
jersey and knitwear to reduce
shrinkage.
• Do not exceed the maximum load
stated in the programmes chapter or
shown on the display.
• Dry only the laundry that is suitable
for tumble drying. Refer to the fabric
label on the items.
• Do not dry large and small items
together. Small items can be trapped
inside the large items and remain wet.
Fabric label Description
Laundry is suitable for tumble drying.
Laundry is suitable for tumble drying at higher temperatures.
Laundry is suitable for tumble drying at low temperatures only.
Laundry is not suitable for tumble drying.
12. CARE AND CLEANING
12.1 Cleaning the filter
The filter collects the fluff.
The fluff occurs while the
cloths are dried in the
tumble dryer.
1. Open the door.
www.aeg.com14

2. Pull the filter.
3. Open the filter.
4. Use a moist hand to clean the filter.
5. Close the filter.
6. Remove fluff from the filter socket.
For this a vacuum cleaner can be
used.
7. Put the filter inside the filter socket .
12.2 Cleaning the drum
WARNING!
Disconnect the appliance
before you clean it.
Use a standard neutral soap detergent to
clean the inner surface of the drum and
drum lifters. Dry the cleaned surfaces
with a soft cloth.
CAUTION!
Do not use abrasive
materials or steel wool to
clean the drum.
12.3 Cleaning the control
panel and housing
Use a standard neutral soap detergent to
clean the control panel and housing.
Use a moist cloth to clean. Dry the
cleaned surfaces with a soft cloth.
CAUTION!
Do not use furniture
cleaning agents or cleaning
agents which can cause
corrosion.
13. TROUBLESHOOTING
Problem Possible solution
You cannot activate the appliance. Make sure that the mains plug is connected
to the mains socket.
Check fuse in fuse box (domestic installa-
tion).
The programme does not start. Press Start/Pause.
Make sure that the appliance door is closed.
ENGLISH 15

Problem Possible solution
The appliance door does not close. Make sure that the installation of the filter is
correct.
Make sure that the laundry does not catch
between the appliance door and the rubber
seal.
The display shows a long programme dura-
tion. 1)
Make sure that the weight of the laundry is
applicable to the duration of the pro-
gramme.
Make sure that the filter is clean.
The laundry is too wet. Spin the laundry in
the washing machine again.
Make sure that the room temperature is not
too warm.
The display shows a short programme dura-
tion.
Set the Time Drying or the Extra Dry pro-
gramme.
The display shows Err2).If you want to set a new programme, deacti-
vate and activate the appliance.
Make sure that the options are applicable to
the programme.
The display shows (e.g. E51)2).Deactivate and activate the appliance. Start
a new programme. If the problem occurs
again, contact the Service.
1) After maximum 5 hours, the programme ends automatically
2) only dryers with the display.
If the drying results are not
satisfactory
• The set programme was incorrect.
• The filter is clogged.
• There was too much laundry in the
appliance.
• The drum is dirty.
• Incorrect setting of the conductivity
sensor.
• The airflow slots are clogged.
14. TECHNICAL DATA
Height x Width x Depth 850 x 600 x 600 mm (maximal 630 mm)
Max. depth with the appliance door open 1090 mm
Max. width with the appliance door open 950 mm
Adjustable height 850 mm (+ 15 mm - feet regulation)
Drum volume 108 l
www.aeg.com16

Maximum load volume 7kg
Voltage 230 V
Frequency 50 Hz
Sound power level 66 dB
Total power 2600 W
Energy efficiency class C
Energy consumption on the standard cotton
programme with the full load. 1)
4,25 kWh
Energy consumption on the standard cotton
programme with the partial load. 2)
2,35 kWh
Annual energy consumption3) 510,00 kWh
Left-on mode power absorption 4) 0,90 W
Off mode power absorption 4) 0,10 W
Type of use Household
Allowed ambient temperature + 5°C to + 35°C
Level of protection against ingress of solid
particles and moisture ensured by the pro-
tective cover, except where the low voltage
equipment has no protection against mois-
ture
IPX4
1) With reference to EN 61121. 7 kg of cotton centrifuged at 1000 rpm.
2) With reference to EN 61121. 3,5 kg of cotton centrifuged at 1000 rpm.
3) Energy consumption per year in kWh, based on 160 drying cycles of the standard cotton programme
at full and partial load, and the consumption of the low-power modes. Actual energy consumption per
cycle will depend on how the appliance is used (REGULATION (EU) No. 392/2012).
4) With reference to EN 61121.
The information given in the chart above is compliant with the EU Commission regulation
392/2012 implementing directive 2009/125/EC.
14.1 Consumption data
Programme Spun at / residual humidity Drying time1)
Energy
consump-
tion2)
Cotton Eco 7 kg
Cupboard Dry 1400 rpm / 50% 100 min. 3,70 kWh
1000 rpm / 60% 115 min. 4,25 kWh
ENGLISH 17

Programme Spun at / residual humidity Drying time1)
Energy
consump-
tion2)
Iron Dry 1400 rpm / 50% 75 min. 2,55 kWh
1000 rpm / 60% 87 min. 3,20 kWh
Cotton Eco 3,5 kg
Cupboard Dry 1400 rpm / 50% 61 min. 2,05 kWh
1000 rpm / 60% 70 min. 2,35 kWh
Synthetic 3 kg
Cupboard Dry 1200 rpm / 40% 40 min. 1,20 kWh
800 rpm / 50% 46 min. 1,47 kWh
1) For partial loads, the cycle time is shorter and appliance uses less energy.
2) Improper ambient temperature and/or poorly centrifuged laundry can prolong cycle time and increase
the energy consumption.
15. INSTALLATION
15.1 Unpacking
CAUTION!
Before use all parts of the
transport packaging must be
removed.
1. Open loading door.
2. Pull off adhesive strips from inside
machine on top of drum.
3. Remove foil hose and polystyrene
padding from the machine.
www.aeg.com18

15.2 Vent hose
As to the outlet itself, if you
have decided on a install
wall/window grille, a good
local builder’s merchant can
supply you with the
necessary fittings and
installation advice.
Make sure that the vent hose
length is less than 2 m, and
that it contains no more than
2 bends.
WARNING!
It is important not to
connect the vent hose to, for
example, a cooker hood, or
a chimney or flue pipe
designed to transmit the
exhaust from a fuel burning
appliance.
Note that to prevent condensation
problems, it is essential that the dryer be
installed with the flexible hose to
transmit its “exhaust” at least beyond
the kitchen units; preferable outside the
kitchen. In order to prevent the
appliance from overheating, it is
important that the steam exhaust is
unobstructed. Thus, if a permanent hose
installed to an external wall or ceiling, it
must be ensured an exhaust capacity of
minimum 150 m3/h. If the dryer is
installed adjacent to kitchen units, make
sure that the vent hose is not squashed.
If the hose is not fully squashed, drying
efficiency will be decreased , resulting in
longer drying times and higher energy
consumption. If the hose is fully
squashed, the automatic cut-outs with
which the appliance is fitted can operate.
When operating the tumble dryer, the
room temperature must not be lower
than +5°C and higher than +35°C, as it
can affect the performance of the
appliance.
If the hose is long and the
room temperature low, the
moisture might condense to
water inside the hose. This is
an usual occurrence. To
prevent this water from the
hose, it is recommend to
drill a small hole (via. 3 mm)
in the lowest point of the
hose and to put a small
container below it. (See
picture, point B).
B
Installation
There are 3 vent outlets: on
the left, right side and at the
rear.
1. Pull the ring nut Afrom the vent
outlet at the rear.
ENGLISH 19

A
A
2. Screw on the ring nut to the hose
and push it into position.
A
3. The not used vents must be sealed
with supplied covers.
15.3 Load door reversal
WARNING!
Before changing the door
stop, disconnect the mains
plug.
Note regarding contact
protection: The appliance is
only secure for operations
again once all plastic parts
have been put.
1. Open load door.
2. Unscrew hinge Afrom the front of
the appliance and remove the load
door.
3. Remove cover plates B. To do this,
put a thin screwdriver into the slots
as shown in the illustration, push
down lightly and remove the cover
plates.
A
A
B
C
B
4. Use an applicable tool and apply
pressure to unlock part C, remove
and turn it through 180°, then put on
the other side. There is a small spring
below locking block C. To put all
parts together correctly, look at the
illustrations:
www.aeg.com20
