AEG 95600 G Specification sheet

AUS ERFAHRUNG GUT
95600 G - 95601 G - 95602 G
95604 G
Gas hob
Table de cuisson
Kochmulde
Gaskookplaat
Piano di cottura
Operating and Installation Instructions GB
Notice dutilisation et dencastrement BE
Gebrauchs- und Einbauanweisung BE
Gebruiksaanwijzing en
Installatievoorschri t NL/BE
Istruzioni per luso e linstallazione IT

2
Important Safety Information
You MUST read these warnings carefully before installing or using the
hob. If you need assistance, contact our Customer Care Department on
87 5 35 35
Installation
lThis hob must be installed by qualified personnel, according to the
manufacturers instructions and to the relevant British Standards.
lAny gas installation must be carried out by a registered C RGI installer.
lRemove all packaging before using the hob.
lEnsure that the gas and electrical supply complies with the type stated on the
rating plate, located near the gas supply pipe.
lDo not attempt to modify the hob in any way.
Child Safety
lThis hob is designed to be operated by adults. Do not allow children to play
near or with the hob.
lThe hob gets hot when it is in use. Children should be kept away until it has
cooled.
lChildren can also injure themselves by pulling pans or pots off the hob.
During Use
lThis hob is intended for domestic cooking only. It is not designed for
commercial or industrial purposes.
lWhen in use a gas cooking hob will produce heat and moisture in the room in
which it has been installed. Ensure there is a continuous air supply, keeping air
vents in good condition or installing a cooker hood with a venting hose.
ENGLISH GB

3
lWhen using the hob for a long period time, the ventilation should be improved,
by opening a window or increasing the extractor speed.
lDo not use this hob if it is in contact with water. Do not operate the hob with wet
hands.
lEnsure the control knobs are in the  FF position when not in use.
lWhen using other electrical appliances, ensure the cable does not come into
contact with the hot surfaces of the cooking appliance.
lUnstable or misshapen pans should not be used on the hob as unstable pans
can cause an accident by tipping or spillage.
lNever leave the hob unattended when cooking with oil and fats.
lNever use plastic or aluminium foil dishes on the hob.
lPerishable food, plastic items and areosols may be affected by heat and should
not be stored above or below the hob unit.
Service
lThis hob should only be repaired or serviced by an authorised Service Engineer
and only genuine approved spare parts should be used.
Environmental Information
lAfter installation, please dispose of the packaging with due regard to safety and
the environment.
lWhen disposing of an old appliance, make it unusable, by cutting off the cable.
Keep this instruction book for future reference and ensure
it is passed on to any new owner.
These instructions are only valid for countries whose identification
symbols are shown on the inside cover of this instruction booklet and on
the appliance itself.
{

4
This appliance is manufactured according to
the following EEC directives:
73/23 EEC - 90/683 EEC - 93/68 EEC -
89/336 EEC - 90/396 EEC,
current edition.
Guide to Use the instructions
The following symbols will be found in the text to guide you throughout the Instructions:
Safety Instructions
Step by step instructions for an
operation
F
Contents
Important Safety Information........................................................................ 2
Instructions for the User ............................................................................... 5
Description of the Hob .................................................................................... 5
Operation ........................................................................................................ 6
Maintenance and Cleaning ............................................................................. 6
Something Not Working? ................................................................................
Service and Spare Parts ................................................................................
Guarantee Conditions ..................................................................................... 9
Instructions for the Installer ....................................................................... 10
Engineers technical data .............................................................................. 10
Important safety requirements ...................................................................... 10
Location ........................................................................................................ 11
Installation ..................................................................................................... 11
Building over a kitchen unit with door ........................................... 15
Fitting the hob to the worktop ........................................................ 15
Electrical connections ................................................................................... 16
Fault Finding ................................................................................................. 18
Commissioning ............................................................................................. 21
Conversion from Natural Gas to LPG ........................................................... 22
iHints and Tips
Environmental Information
{

5
1. Hob Top
2. Rapid Burner
3. Semi-rapid Burners
4. Auxiliary Burner
5. Control knob for back right burner (semi-rapid)
6. Control knob for back left burner (semi-rapid)
7. Control knob for front left burner (rapid)
8. Control knob for front right burner (auxiliary)
Description of the Hob (Model 956 2 G)
335678
2
4
INSTALLATION
Any gas installation must be carried out by a registered CORGI installer, and
in accordance with existing rules and regulations.
The relevant instructions are to be found in the second section of this manual.
Please, ensure that, once the hob is installed, it is easily accessible for the
engineer in the event of a breakdown.
WHEN THE HOB IS FIRST INSTALLED
nce the hob has been installed, it is important to remove any protective
materials, which were put on in the factory.

6
Before any maintenance or cleaning can be carried out, you must
DISCONNECT the hob from the electricity supply.
The hob is best cleaned whilst it is still warm, as spillage can be removed more
easily than if it is left to cool.
The Hob Top
Regularly wipe over the hob top using a soft cloth well wrung out in warm water to
which a little washing up liquid has been added. Avoid the use of the following:
- household detergent and bleaches;
Maintenance and Cleaning
HOB BURNERS
To light a burner, turn the relevant control knob anticlockwise to the maximum position,
then push it down to ignite the burner. Upon, ignition, keep the knob pushed down
about 5 seconds, then adjust the flame as required.
If the burner does not ignite, turn the control knob to zero, and try again.
When switching on the mains, after installation or a power cut, it is quite normal
for the spark generator to be activated automatically.
To ensure maximum burner efficiency, you should only use pots and pans with a flat
bottom fitting the size of the burner used (see table).
Burner minimum maximum
diameter diameter
Large (rapid) 160 mm. 260 mm.
Medium (semi-rapid) 120 mm. 220 mm.
Small (Auxiliary) 80 mm. 160 mm.
Operation
i
As soon as a liquid starts boiling, turn down the flame so that it will barely keep
the liquid simmering.
If you use a saucepan which is smaller than the recommended si e, the flame
will spread beyond the bottom of the vessel, causing the handle to overheat.
Take care when frying food in hot oil or fat, as the overheated splashes could
easily ignite
If the control knobs become difficult to turn, please contact your local AEG
Service Force Centre.
i

7
- impregnated pads unsuitable for non-stick saucepans;
- steel wool pads;
- bath/sink stain removers.
Should the hob top become heavily soiled, it is recommended that a cleaning product
such as Hob Brite or Bar Keepers Friend is used.
Pan Supports
The pan supports are dishwasher proof. If washing them by hand, take care when
drying them as the enamelling process occasionally leaves rough edges. If necessary,
remove stubborn stains using a paste cleaner.
The Burners
The burner caps and crowns can be removed for cleaning.
Wash the burner caps and crowns using hot soapy water, and remove marks with a
mild paste cleaner. A well moistened soap impregnated steel wool pad can be used
with caution, if the marks are particularly difficult to remove.
After cleaning, be sure to wipe dry with a soft cloth.
Something Not Working?
If the hob is not working correctly, please carry out the following checks before
contacting your local AEG Service Force Centre.
SYMPT M
nThere is no spark when lighting the
gas
nThe gas ring burns unevenly
S LUTI N
uCheck that the unit is plugged in and
the electrical supply is switched on
uCheck that the RCCB has not tripped
(if fitted)
uCheck the mains fuse has not blown
uCheck the burner cap and crown
have been replaced correctly, e.g.
after cleaning.
uCheck the main jet is not blocked
and the burner crown is clear of food
particles.
uCheck the burner cap and crown
have been replaced correctly, e.g.
after cleaning.

8
Service and Spare Parts
When you contact the Service Force Centre, they will need the following
information:
1. Your name, address and post code.
2. Your telephone number
3. Clear and concise details of the fault
4. The model and the serial number (see rating label on the back of this
instruction booklet)
5. Date of purchase
If you require spare parts or an engineer contact your local Service Force Centre by
telephoning:
87 5 929 929
Your call will be routed to the your local Service Force Centre.
CUSTOMER CARE
For general enquiries concerning your AEG appliance and for further information
on AEG products, contact our Customer Care Department by letter or telephone as
follows:
Customer Care Department
AEG Domestic Appliances
55-77 High Street
Slough
Berkshire
SL1 1DZ
Tel : [phone]
If after all these checks, your hob still does not operate correctly, contact your local
AEG Service Force Centre.
Please note that it will be necessary to provide proof of purchase for any in-guarantee
service calls.
In-guarantee customers should ensure that the above checks have been made as
the engineer will make a charge if the fault is not a mechanical or electrical breakdown.

9
Guarantee Conditions
AEG offer the following guarantee to the first purchaser of this appliance.
1. The guarantee is valid for 12 months commencing when the appliance is handed over to
the first retail purchaser, which must be verified by purchase invoice or similar
documentation.
The guarantee does not cover commercial use.
2. The guarantee covers all parts or components which fail due to faulty workmanship or
faulty materials. The guarantee does not cover appliances where defects or poor
performance are due to misuse, accidental damage, neglect, faulty installation,
unauthorised modification or attempted repair, commercial use or failure to observe
re uirements and recommendations set out in the instruction book.
This guarantee does not cover such parts as light bulbs, removable glassware or plastic.
3. Should guarantee repairs be necessary the purchaser must inform the nearest AEG Service
Force Centre (manufacturers service or authorised agent). AEG reserves the right to
stipulate the place of the repair (i.e. the customers home, place of installation or AEG
workshop).
4. The guarantee or free replacement includes both labour and material.
5. Repairs carried out under guarantee do not extend the guarantee period for the appliance.
Parts removed during guarantee repairs become property of AEG.
6. The purchasers statutory rights are not affected by this guarantee.
European Guarantee
If you should move to another country within Europe then your guarantee moves with you to
your new home subject to the following ualifications:
* The guarantee starts from the date you first purchased your product.
* The guarantee is for the same period and to the same extent for labour and parts as exist
in the new country of use for this brand or range of products.
* This guarantee relates to you and cannot be transferred to another user.
* Your new home is within the European Community (EC) or European Free Trade Area.
* The product is installed and used in accordance with our instructions and is only used
domestically, i.e. a normal household
* The electrical supply complies with the specification given in the rating label.
* The product is installed taking into account regulations in your new country.
Before you move, please contact your nearest Customer Care centre, listed below, to give them
details of your new home. They will then ensure that the local Service Organisation is aware of
your move and able to look after you and your appliances.
France Senlis [phone]
Germany Nürnberg [phone]
Italy Pordenone [phone]
Sweden Stockholm [phone]
UK Slough [phone]

10
OVERALL DIMENSIONS Width: 580 mm.
Depth:510 mm.
Height: 88 mm.
Weight: 11 Kg.
CUT OUT DIMENSIONS Width: 550 mm.
Depth:470 mm.
Thickness: 30 mm.
SUPPLY CONNECTIONS Gas:
RC 1/2 inch (1/2 inch male) Rear right hand corner
Electric:
230-240V 50Hz supply, 3 core flexible cable with
non rewireable plug fitted with a 3 amp cartridge fuse.
IGNITION HT SPARK Spark Generator
Ispra Control's BF 50046 - 230-240V 0.6 YA T120
Spark Gap : Fixed
HEAT INPUT
Instructions for the Installer
Engineers technical data
Rear Left Burner 1.9 kW (6483 BTU/HR)
(semi rapid)
Front Left Burner 2.9 kW Natural Gas (9895 BTU/HR)
(rapid) 2.7 kW L.P.G. (9212 BTU/HR)
Rear Right Burner 1.9 kW (6483 BTU/HR)
(semi rapid)
Front Right Burner 1.0 kW (3412 BTU/HR)
(auxiliary)
APPLIANCE CLASS 3
APPLIANCE
CATEGORY II2H3+
GAS SUPPLY Natural gas G20 /
20mbar
Burner Dia. Tap By-pass
1/100 mm
Auxiliary 28
Semi-rapid 32
Rapid 40
Aeration adjustment none
