AEG CERAMIC HOB 6010 K User manual

6010 K
Glaskeramik-Kochfeld
Ceramic glass hob
Table de cuisson vitrocéramique
Montage- und Gebrauchsanweisung
Installation and Operating Instructions
Instructions de montage et mode d’emploi

16
Dear Customer,
Please read these user instructions carefully and keep them to refer to
later.
Please pass the user instructions on to any future owner of the appli-
ance.
The following symbols are used in the text:
1Safety instructions
Warning! Information that affects your personal safety.
Important! Information that prevents damage to the appliance.
3Useful tips and hints
2Environmental information

17
Contents
Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Description of the Appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Cooking surface layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Assignment of control knobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Control Knobs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Residual heat indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Operating the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Setting the heat setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
To switch the outside ring on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Tips on Cooking and Frying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Energy saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Examples of cooking applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
What to do if … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

18
Operating Instructions
1Safety instructions
3Please comply with these instructions. If you do not, any damage re-
sulting is not covered by the warranty.
5This appliance conforms with the following EU Directives:
–73/23/EEC dated 19.02.1973 Low Voltage Directive
–89/336/EEC dated 03.05.1989 EMC Directive inclusive of Amending
Directive 92/31/EEC
–93/68/EEC dated 22.07.1993 CE Marking Directive
Correct use
•This appliance should be used only for normal domestic cooking and
frying of food.
•The appliance must not be used as a work surface or as a storage sur-
face.
•Additions or modifications to the appliance are not permitted.
•Do not place or store flammable liquids, highly inflammable materials
or fusible objects (e.g. plastic film, plastic, aluminium) on or near the
appliance.
Children’s safety
•Small children must be kept away from the appliance.
•Only let bigger children work on the appliance under supervision.
General safety
•The appliance may only be installed and connected by trained, regis-
tered service engineers.
•Built-in appliances may only be used after they have built in to suita-
ble built-in units and work surfaces that meet standards.
•In the event of faults with the appliance or damage to the glass ce-
ramic (cracks, scratches or splits), the appliance must be switched off
and disconnected from the electrical supply, to prevent the possibility
of an electric shock.
•Repairs to the appliance must only be carried out by trained regis-
tered service engineers.

19
Safety during use
•Remove stickers and film from the glass ceramic.
•There is the risk of burns from the appliance if used carelessly.
•Cables from electrical appliances must not touch the hot surface of
the appliance or hot cookware.
•Overheated fats and oils can ignite quickly. When cooking with fat or
oil (e.g. chips) do not leave the appliance unattended.
•Switch the cooking zones off after each use.
Safety when cleaning
•For cleaning, the appliance must be switched off and cooled down.
•For safety reasons, the cleaning of the appliance with steam jet or
high-pressure cleaning equipment is not permitted.
How to avoid damage to the appliance
•The glass ceramic can be damaged by objects falling onto it.
•The edge of the glass ceramic can be damaged by being knocked by
the cookware.
•Cookware made of cast iron, cast aluminium or with damaged bot-
toms can scratch the glass ceramic if pushed across the surface.
•Objects that melt and things that boil over can burn onto the glass
ceramic and should be removed straightaway.
•Do not use the cooking zones with empty cookware or without cook-
ware.

20
Description of the Appliance
Cooking surface layout
Assignment of control knobs
Double ring cooking zone
750/2200W
Hob Cooking
Zone Control
Knobs
Single cooking zone
1800W
Single cookingzone
1200W
Residual heat
indicator Single cooking zone 1200W

21
Control Knobs
The cooking power can be set anywhere between level 1 and 9.
Residual heat indicator
The residual heat indicator lights up, as soon as the corresponding
cooking zone is hot.
1Danger! Risk of burns from residual heat. After being switched off, the
cooking zones need some time to cool down. Look at the residual heat
indicator.
2Residual heat can be used for melting and keeping food warm.
Operating the appliance
3When a cooking zone is switched on, it may hum briefly. This is a char-
acteristic of all ceramic glass cooking zones and does not impair either
the function or the life of the appliance.
1 lowest power
9 highest power
0 Off position
ZConnection double ring cooking zone

22
Setting the heat setting
1.When boiling water/searing food, select a high heat setting.
2.As soon as steam forms or the fat or oil is hot, set a lower heat setting.
3.To end the cooking process, turn to the Off position.
To switch the outside ring on and off
By switching the outside ring on or off, the effective heating surface
can be matched to the size of the cookware.
3Before the outside ring can be switched on, the inside ring must be
switched on.
Heat setting Ring control knob Knob setting
To increase turn clockwise 1 - 9
To reduce turn anti-clock-
wise 9 - 1
switch off 0
Outside ring Ring switch Switch setting
To switch on Turn clockwise,
past a slight re-
sistance, as far as
it will go
Z
Turn anti-clockwise to the
desired heat setting 1 - 9
To switch off Turn to the Off position 0

23
Tips on Cooking and Frying
3Information on acrylamides
According to the latest scientific knowledge, intensive browning of
food, especially in products containing starch, can constitute a health
risk due to acrylamides. Therefore we recommend cooking at the lowest
possible temperatures and not browning foods too much.
Cookware
•You can recognise good cookware from the bottoms of the pans. The
bottom should be as thick and flat as possible.
•Cookware made of enamelled steel or with aluminium or copper bot-
toms can leave discolorations on the glass ceramic surface which are
difficult or impossible to remove.
Energy saving
2Always place cookware on the cook-
ing zone before it is switched on.
2If possible, always place lids on the
pans.
2Switch cooking zones off before the
end of the cooking time, to take ad-
vantage of residual heat.
2Bottom of pans and cooking zones
should be the same size.

24
Examples of cooking applications
The information given in the following table is for guidance only.
Heat
set-
ting
Cooking-
process suitable for Cooking time Tips/Hints
0Residual heat, Off posi-
tion
1Keeping
food
warm
Keeping cooked foods
warm as required Cover
1-2
Melting Hollandaise sauce,
melting butter, chocolate,
gelatine 5-25 mins. Stir occasionally
Solidi-
fying Fluffy omelettes, baked eggs 10-40 mins. Cook with lid on
2-3 Simmer-
ing on
low heat
Simmering rice and milk-
based dishes
Heating up ready-cooked
meals
25-50 mins.
Add at least twice as
much liquid as rice, stir
milk dishes part way
through cooking
3-4 Steaming
Braising Steaming vegetables, fish braising meat 20-45 mins. With vegetables add
only a little liquid (a
few tablespoons)
4-5 Boiling
Steaming potatoes 20-60 mins. Use only a little liquid,
e. g.: max. ¼l water
for 750 g potatoes
Cooking larger quantities
of food, stews and soups 60-150 mins. Up to 3 l liquid plus in- gredients
6-7 Gentle
Frying
Frying escalopes, veal
cordon bleu, cutlets, ris-
soles, sausages, liver, roux,
eggs, pancakes, dough-
nuts
Steady
frying Turn halfway through cooking
7-8 Heavy
Frying
Hash browns, loin steaks,
steaks, Flädle (pancakes
for garnishing soup)
5-15 mins.
per pan Turn halfway through cooking
9
Boiling
Searing
Deep
frying
Boiling large quantities of water, cooking pasta, searing meat
(goulash, pot roast), deep frying chips
