AEG BPB23112ZM User manual

aeg.com/register
BPB23112ZM
EN User Manual | Oven
aeg.com\register

Welcome to AEG! Thank you for choosing our appliance.
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Subject to change without notice.
CONTENTS
1. SAFETY INFORMATION................................................................................ 2
2. SAFETY INSTRUCTIONS.............................................................................. 4
3. INSTALLATION...............................................................................................7
4. PRODUCT DESCRIPTION............................................................................. 9
5. CONTROL PANEL.......................................................................................... 9
6. BEFORE FIRST USE....................................................................................10
7. DAILY USE....................................................................................................10
8. CLOCK FUNCTIONS.................................................................................... 12
9. USING THE ACCESSORIES........................................................................14
10. ADDITIONAL FUNCTIONS.........................................................................15
11. HINTS AND TIPS........................................................................................ 15
12. CARE AND CLEANING.............................................................................. 18
13. TROUBLESHOOTING................................................................................ 23
14. ENERGY EFFICIENCY...............................................................................24
15. ENVIRONMENTAL CONCERNS................................................................25
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved. Children of less than 8 years of age and
persons with very extensive and complex disabilities shall
2 ENGLISH

be kept away from the appliance unless continuously
supervised.
• Children should be supervised to ensure that they do not
play with the appliance.
• Keep all packaging away from children and dispose of it
appropriately.
• WARNING: The appliance and its accessible parts become
hot during use. Keep children and pets away from the
appliance when in use and when cooling down.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
1.2 General Safety
• This appliance is for cooking purposes only.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
• Only a qualified person must install this appliance and
replace the cable.
• Do not use the appliance before installing it in the built-in
structure.
• Disconnect the appliance from the power supply before
carrying out any maintenance.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons to avoid an electrical hazard.
• WARNING: Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric shock.
• WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements or the surface of the appliance cavity.
ENGLISH 3

• Always use oven gloves to remove or insert accessories or
ovenware.
• To remove the shelf supports first pull the front of the shelf
support and then the rear end away from the side walls.
Install the shelf supports in the opposite sequence.
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the glass door since they can scratch the surface,
which may result in shattering of the glass.
• Before pyrolytic cleaning, remove all accessories and
excessive deposits/spills from the appliance cavity.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must install this
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions supplied
with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Do not pull the appliance by the handle.
• Install the appliance in a safe and suitable
place that meets installation requirements.
• Keep the minimum distance from other
appliances and units.
• Before mounting the appliance, check if
the appliance door opens without restraint.
• The appliance is equipped with an electric
cooling system. It must be operated with
the electric power supply.
Cabinet minimum height
(Cabinet under the worktop
minimum height)
590 (600) mm
Cabinet width 560 mm
Cabinet depth 550 (550) mm
Height of the front of the
appliance
594 mm
Height of the back of the
appliance
576 mm
Width of the front of the ap‐
pliance
595 mm
Width of the back of the ap‐
pliance
559 mm
Depth of the appliance 569 mm
Built in depth of the appli‐
ance
548 mm
Depth with open door 1022 mm
Ventilation opening mini‐
mum size. Opening placed
on the bottom rear side
560x20 mm
Mains supply cable length.
Cable is placed in the right
corner of the back side
1500 mm
Mounting screws 4x25 mm
2.2 Electrical connection
WARNING!
Risk of fire and electric shock.
• All electrical connections should be made
by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
4 ENGLISH

electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable. Should
the mains cable need to be replaced, this
must be carried out by our Authorised
Service Centre.
• Do not let mains cables touch or come
near the appliance door or the niche below
the appliance, especially when it operates
or the door is hot.
• The shock protection of live and insulated
parts must be fastened in such a way that
it cannot be removed without tools.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you disconnect
the appliance from the mains at all poles.
The isolation device must have a contact
opening width of minimum 3 mm.
• Fully close the appliance door before you
connect the mains plug to the mains
socket.
• This appliance is supplied with a main
plug and a main cable.
Cable types applicable for installation or re‐
placement for Europe:
H07 RN-F, H05 RN-F, H05 RRF, H05 VV-F, H05
V2V2-F (T90), H05 BB-F
For the section of the cable refer to the total
power on the rating plate. You can also refer
to the table:
Total power (W) Section of the cable
(mm²)
maximum 1380 3x0.75
maximum 2300 3x1
maximum 3680 3x1.5
The earth cord (green / yellow cable) must be
2 cm longer than the brown phase and blue
neutral cables.
2.3 Use
WARNING!
Risk of injury, burns and electric shock or
explosion.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay unattended
during operation.
• Deactivate the appliance after each use.
• Be careful when you open the appliance
door while the appliance is in operation.
Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with water.
• Do not apply pressure on the open door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully. The
use of ingredients with alcohol can cause
a mixture of alcohol and air.
• Do not let sparks or open flames to come
in contact with the appliance when you
open the door.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
WARNING!
Risk of damage to the appliance.
• To prevent damage or discoloration to the
enamel:
– do not put ovenware or other objects
in the appliance directly on the bottom.
– do not put aluminium foil directly on
the bottom of cavity of the appliance.
ENGLISH 5

– do not put water directly into the hot
appliance.
– do not keep moist dishes and food in
the appliance after you finish the
cooking.
– be careful when you remove or install
the accessories.
• Discoloration of the enamel or stainless
steel has no effect on the performance of
the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• Always cook with the appliance door
closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make sure the
door is never closed when the appliance
operates. Heat and moisture can build up
behind a closed furniture panel and cause
subsequent damage to the appliance, the
housing unit or the floor. Do not close the
furniture panel until the appliance has
cooled down completely after use.
2.4 Care and cleaning
WARNING!
Risk of injury, fire, or damage to the
appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains plug
from the mains socket.
• Make sure the appliance is cold. There is
the risk that the glass panels can break.
• Replace immediately the door glass
panels when they are damaged. Contact
the Authorised Service Centre.
• Clean regularly the appliance to prevent
the deterioration of the surface material.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do not
use abrasive products, abrasive cleaning
pads, solvents or metal objects.
• If you use an oven spray, follow the safety
instructions on its packaging.
2.5 Pyrolytic cleaning
WARNING!
Risk of Injury / Fires / Chemical
Emissions (Fumes) in Pyrolytic Mode.
• Before carrying out the pyrolytic cleaning
and initial preheating remove from the
oven cavity:
– any excess food residues, oil or
grease spills / deposits.
– any removable objects (including
shelves, side rails, etc., provided with
the appliance) especially any non-stick
pots, pans, trays, utensils, etc.
• Read carefully all the instructions for
pyrolytic cleaning.
• Keep children away from the appliance
while the pyrolytic cleaning operates. The
appliance becomes very hot and hot air is
released from the front cooling vents.
• Pyrolytic cleaning is a high temperature
operation that can release fumes from
cooking residues and construction
materials, as such consumers are advised
to:
– provide good ventilation during and
after the pyrolytic cleaning.
– provide good ventilation during and
after the initial preheating.
• Do not spill or apply water on the oven
door during and after the pyrolytic cleaning
to avoid damaging the glass panels.
• Fumes released from all pyrolytic ovens /
cooking residues as described are not
harmful to humans, including children, or
persons with medical conditions.
• Keep pets away from the appliance during
and after the pyrolytic cleaning and initial
preheating. Small pets (especially birds
and reptiles) can be highly sensitive to
temperature changes and emitted fumes.
• Non-stick surfaces on pots, pans, trays,
utensils etc., can be damaged by the high
temperature pyrolytic cleaning operation of
all pyrolytic ovens and can be also a
source for low level harmful fumes.
2.6 Internal lighting
WARNING!
Risk of electric shock.
6 ENGLISH

• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
• This product contains a light source of
energy efficiency class G.
• Use only lamps with the same
specifications.
2.7 Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
2.8 Disposal
WARNING!
Risk of injury or suffocation.
• Contact your municipal authority for
information on how to dispose of the
appliance.
• Disconnect the appliance from the mains
supply.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
• Remove the door catch to prevent children
or pets from becoming trapped in the
appliance.
3. INSTALLATION
WARNING!
Refer to Safety chapters.
3.1 Building in
www.youtube.com/electrolux
www.youtube.com/aeg
How to install your AEG/Electrolux
Oven - Column installation
18
594
589
114
21548
595+-1
min. 550
20
600
min. 560
3
5
60
20
80
520
60
198
523
(*mm)
ENGLISH 7

min. 550
20
595+-1
18
590
min. 560
594
589
114
21548
3
5
70
60 520
60
20
198
523
(*mm)
3.2 Securing the oven to the cabinet
8 ENGLISH

4. PRODUCT DESCRIPTION
4.1 General overview
6
5
97
8
5
4
1
2
3
31 42
1Control panel
2Knob for the heating functions
3Display
4Control knob (for the temperature)
5Heating element
6Lamp
7Fan
8Shelf support, removable
9Shelf positions
4.2 Accessories
•Wire shelf
For cookware, cake tins, roasts.
•Baking tray
For cakes and biscuits.
•Telescopic runners
With the telescopic runners you can put in
and remove the shelves more easily.
5. CONTROL PANEL
5.1 Retractable knobs
To use the appliance press the knob. The
knob comes out.
5.2 Sensor fields / Buttons
To set the time.
To set a clock function.
To set the time.
ENGLISH 9

5.3 Display
A B
DG EF C
A. Timer / Temperature
B. Heat-up and residual heat indicator
C. Food Sensor (selected models only)
D. Door lock (selected models only)
E. Hours / minutes
F. Demo Mode (selected models only)
G. Clock functions
6. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
Set the time before you use the oven.
6.1 Initial Cleaning
Step 1 Step 2 Step 3
Remove all accessories and remov‐
able shelf supports from the appli‐
ance.
Clean the appliance and the acces‐
sories only with a microfibre cloth,
warm water and a mild detergent.
Place the accessories and the re‐
movable shelf supports in the appli‐
ance.
6.2 Initial preheating
Preheat the empty oven before the first use.
Step 1 Remove all accessories and removable shelf supports from the oven.
Step 2 Set the maximum temperature for the function: .
Let the oven operate for 1 h.
Step 3 Set the maximum temperature for the function: .
Let the oven operate for 15 min.
The oven can emit an odour and smoke during preheating. Make sure that the room is ventilated.
7. DAILY USE
WARNING!
Refer to Safety chapters.
7.1 How to set: Heating function
Step 1 Turn the knob for the heating functions
to select a heating function.
Step 2 Turn the control knob to select the tem‐
perature .
Step 3 When the cooking ends, turn the knobs
to the off position to turn off the oven.
10 ENGLISH

7.2 Heat-up indicator
When the oven function operates, the bars in
the display appear one by one when the
temperature in the oven increases, and
disappear when it decreases.
7.3 Heating functions
Heating func‐
tion
Application
Off position
The oven is off.
True Fan Cooking
To bake on up to three shelf po‐
sitions at the same time and to
dry food.
Set the temperature 20 - 40 °C
lower than for Conventional
Cooking.
Conventional
Cooking
To bake and roast food on one
shelf position.
Moist Fan Baking
This function is designed to save
energy during cooking. When
you use this function, the tem‐
perature inside the appliance
may differ from the set tempera‐
ture. The residual heat is used.
The heating power may be re‐
duced. For more information re‐
fer to "Daily Use" chapter, Notes
on: Moist Fan Baking.
Fast Grilling
To grill thin pieces of food in
large quantities and to toast
bread.
Turbo Grilling
To roast large meat joints or
poultry with bones on one shelf
position. To make gratins and to
brown.
Heating func‐
tion
Application
Pizza Function
To bake pizza. To make inten‐
sive browning and a crispy bot‐
tom.
Meat
To prepare very tender and juicy
roasts.
Keep Warm
To keep food warm. Please note
that some dishes may continue
to cook and dry out while being
kept warm. Cover the dishes if
necessary
Defrost
To defrost food (vegetables and
fruit). The defrosting time de‐
pends on the amount and size of
the frozen food.
Pyrolysis
To turn on the pyrolytic cleaning
of the oven.
7.4 Notes on: Moist Fan Baking
This function was used to comply with the
energy efficiency class and ecodesign
requirements (according to EU 65/2014 and
EU 66/2014). Tests according to: IEC/EN
60350-1.
The oven door should be closed during
cooking so that the function is not interrupted
and the oven operates with the highest
energy efficiency possible.
When you use this function the lamp
automatically turns off after 30 sec.
For the cooking instructions refer to "Hints
and tips" chapter, Moist Fan Baking. For
general energy saving recommendations
refer to "Energy Efficiency" chapter, Energy
Saving.
ENGLISH 11

8. CLOCK FUNCTIONS
8.1 Clock functions table
Clock function Application
Time of Day
To show or change the time of day. You can change the time of day
only when the oven is off.
Duration
To set the length of cooking. Use only when a heating function is set.
End Time
To set the oven turn-off time. Use only when a heating function is set.
Time Delay
Combination of functions: Duration, End Time.
Minute Minder
To set a countdown time. This function has no effect on the operation
of the oven.
Minute Minder - can be set at any time, also if the oven is off.
00:00
Count Up Timer
If you do not set any other clock function the function automatically
monitors how long the oven works.
Counting starts immediately when the oven starts to heat.
Count Up Timer cannot be used with the functions: Duration, End
Time.
8.2 How to set: Time of day
After the first connection to the mains, wait
until the display shows: hr, 12:00. 12 -
flashes.
Step 1 , - press to set the hour.
Step 2 - press to confirm.
The display shows the set hour and: min. 00 - flashes.
Step 3 , - press to set the minutes.
Step 4 - press to confirm.
The display shows the set time.
- press repeatedly to change the time of day. - flashes in the display.
8.3 How to set function: Duration
Step 1 Set a heating function.
12 ENGLISH

Step 2 - press repeatedly. - starts to flash.
Step 3 , - press to set the minutes. - press to confirm.
Step 4 , - press to set the hours. - press to confirm.
When the set time ends the signal sounds for 2 min. Time setting flashes in the display. The oven
turns off automatically.
Step 5 Press any button to stop the signal.
Step 6 Turn the knobs to the off position.
8.4 How to set function: End Time
Step 1 Set a heating function.
Step 2 - press repeatedly. - starts to flash.
Step 3 , - press to set the hour. - press to confirm.
Step 4 , - press to set the minutes. - press to confirm.
At the set end time the signal sounds for 2 min. The time setting flashes in the display. The oven
turns off automatically.
Step 5 Press any button to stop the signal.
Step 6 Turn the knobs to the off position.
8.5 How to set function: Time Delay
Step 1 Set a heating function.
Step 2 - press repeatedly. - starts to flash.
Step 3 , - press to set the minutes for the function: Duration. - press to confirm.
Step 4 , - press to set the hour for the function: Duration. - press to confirm.
- starts to flash.
Step 5 , - press to set the hour for the function: End Time. - press to confirm.
Step 6 , - press to set the minutes for the function: End Time. - press to confirm.
The display shows: the set temperature, , .
Oven turns on automatically later on, works for the set Duration time and stops at the set End Time.
At the set End Time the signal sounds for 2 min. The time setting flashes in the display. The oven turns off.
Step 7 Press any button to stop the signal.
Step 8 Turn the knobs to the off position.
ENGLISH 13

8.6 How to set function: Minute
Minder
Minute minder can be both set when the oven
is turned on and off.
Step 1 - press repeatedly. , 00 - flash.
Step 2 , - press to set the seconds and than the minutes.
When the time you set is longer than 60 min, hr flashes.
Step 3 Set the hours.
Minute Minder - starts automatically after 5 sec.
After 90% of the set time the signal sounds.
Step 4 When the set time ends the signal sounds for 2 min. 00:00, - flash. Press any button to stop the
signal.
8.7 How to set function: Count Up
Timer
, - press and hold to reset the Count Up Timer. The timer starts to count up again.
9. USING THE ACCESSORIES
WARNING!
Refer to Safety chapters.
9.1 Inserting accessories
A small indentation at the top increases
safety. The indentations are also anti-tip
devices. The high rim around the shelf
prevents cookware from slipping of the shelf.
Wire shelf:
Push the shelf between the guide bars of the shelf
support and make sure that the feet point down.
14 ENGLISH

Baking tray:
Push the tray between the guide bars of the shelf
support.
10. ADDITIONAL FUNCTIONS
10.1 How to use: Child lock
When the function is on the oven cannot be
turned on accidentally.
Step 1 Ensure the knob for the heating func‐
tions is in the off position.
Step 2 , - press and hold at the same
time for 2 sec.
The signal sounds. SAFE , - appear on the dis‐
play. The door is locked.
To turn off the Child Lock, repeat the step 2.
10.2 Residual heat indicator
When you turn off the oven, the display
shows the residual heat indicator if the
temperature in the oven is more than 40 °C.
10.3 Automatic switch-off
For safety reasons the appliance turns off
after some time, if a heating function works
and you do not change any settings.
(°C) (h)
30 - 115 12.5
(°C) (h)
120 - 195 8.5
200 - 245 5.5
250 - maximum 3
After an automatic switch-off, turn the knobs
to the off position.
The Automatic switch-off does not work with
the functions: Light, Duration, End Time.
10.4 Cooling fan
When the appliance operates, the cooling fan
turns on automatically to keep the surfaces of
the appliance cool. If you turn off the
appliance, the cooling fan can continue to
operate until the appliance cools down.
10.5 Safety thermostat
Incorrect operation of the oven or defective
components can cause dangerous
overheating. To prevent this, the oven has a
safety thermostat which interrupts the power
supply. The oven turns on again
automatically when the temperature drops.
11. HINTS AND TIPS
Refer to Safety chapters.
11.1 Cooking recommendations
The oven has five shelf positions.
ENGLISH 15

Count the shelf positions from the bottom of
the oven floor.
Your oven may bake or roast differently to the
oven you had before.
Baking cakes
Do not open the oven door before 3/4 of the
set cooking time is up.
If you use two baking trays at the same time,
keep one empty level between them.
Cooking meat and fish
Leave the meat for approximately 15 minutes
before carving so that the juice does not seep
out.
To prevent too much smoke in the oven
during roasting, add some water into the
deep pan. To prevent the smoke
condensation, add water each time after it
dries up.
Cooking times
Cooking times depend on the type of food, its
consistency, and volume.
Initially, monitor the performance when you
cook. Find the best settings (heat setting,
cooking time, etc.) for your cookware, recipes
and quantities when you use this appliance.
11.2 Moist Fan Baking - recommended accessories
Use the dark and non-reflective tins and containers. They have better heat absorption than the
light colour and reflective dishes.
Pizza pan Baking dish
Ramekins
Flan base tin
Dark, non-reflective
28 cm diameter
Dark, non-reflective
26 cm diameter
Ceramic
8 cm diameter, 5
cm height
Dark, non-reflective
28 cm diameter
11.3 Moist Fan Baking
For the best results follow suggestions listed
in the table below.
(°C) (min)
Sweet rolls, 16 pieces baking tray or dripping pan 180 2 20 - 30
Rolls, 9 pieces baking tray or dripping pan 180 2 30 - 40
Pizza, frozen, 0.35 kg wire shelf 220 2 10 - 15
Swiss roll baking tray or dripping pan 170 2 25 - 35
Brownie baking tray or dripping pan 175 3 25 - 30
Soufflè, 6 pieces ceramic ramekins on wire
shelf
200 3 25 - 30
Sponge flan base flan base tin on wire shelf 180 2 15 - 25
16 ENGLISH

(°C) (min)
Victoria sandwich baking dish on wire shelf 170 2 40 - 50
Poached fish, 0.3 kg baking tray or dripping pan 180 3 20 - 25
Whole fish, 0.2 kg baking tray or dripping pan 180 3 25 - 35
Fish fillet, 0.3 kg pizza pan on wire shelf 180 3 25 - 30
Poached meat, 0.25
kg
baking tray or dripping pan 200 3 35 - 45
Shashlik, 0.5 kg baking tray or dripping pan 200 3 25 - 30
Cookies, 16 pieces baking tray or dripping pan 180 2 20 - 30
Macaroons, 24 pieces baking tray or dripping pan 180 2 25 - 35
Muffins, 12 pieces baking tray or dripping pan 170 2 30 - 40
Savory pastry, 20
pieces
baking tray or dripping pan 180 2 25 - 30
Short crust biscuits,
20 pieces
baking tray or dripping pan 150 2 25 - 35
Tartlets, 8 pieces baking tray or dripping pan 170 2 20 - 30
Vegetables, poached,
0.4 kg
baking tray or dripping pan 180 3 35 - 45
Vegetarian omelette pizza pan on wire shelf 200 3 25 - 30
Mediterranean vege‐
tables, 0.7 kg
baking tray or dripping pan 180 4 25 - 30
11.4 Information for test institutes
Tests according to IEC 60350-1.
( °C) (min)
Small
cakes, 20
per tray
Conventional
Cooking
Baking tray 3 170 20 - 35 -
Small
cakes, 20
per tray
True Fan
Cooking
Baking tray 3 150 - 160 20 - 35 -
Small
cakes, 20
per tray
True Fan
Cooking
Baking tray 2 and 4 150 - 160 20 - 35 -
Apple pie, 2
tins Ø20
cm
Conventional
Cooking
Wire shelf 2 180 70 - 90 -
ENGLISH 17

( °C) (min)
Apple pie, 2
tins Ø20
cm
True Fan
Cooking
Wire shelf 2 160 70 - 90 -
Fatless
sponge
cake, cake
mould Ø26
cm
Conventional
Cooking
Wire shelf 2 170 40 - 50 Preheat the oven for
10 min.
Fatless
sponge
cake, cake
mould Ø26
cm
True Fan
Cooking
Wire shelf 2 160 40 - 50 Preheat the oven for
10 min.
Fatless
sponge
cake, cake
mould Ø26
cm
True Fan
Cooking
Wire shelf 2 and 4 160 40 - 60 Preheat the oven for
10 min.
Short bread True Fan
Cooking
Baking tray 3 140 - 150 20 - 40 -
Short bread True Fan
Cooking
Baking tray 2 and 4 140 - 150 25 - 45 -
Short bread Conventional
Cooking
Baking tray 3 140 - 150 25 - 45 -
Toast, 4 - 6
pieces
Grill Wire shelf 4 max. 1 - 5 Preheat the oven for
10 min.
Beef bur‐
ger, 6
pieces, 0.6
kg
Grill Wire shelf,
dripping pan
4 max. 20 - 30 Put the wire shelf on
the fourth level and
the dripping pan on
the third level of the
oven. Turn the food
halfway through the
cooking time.
Preheat the oven for
10 min.
12. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
18 ENGLISH

12.1 Notes on cleaning
Cleaning Agents
Clean the front of the appliance only with a microfibre cloth with warm water and a mild de‐
tergent.
Use a cleaning solution to clean metal surfaces.
Clean stains with a mild detergent.
Everyday Use
Clean the cavity after each use. Fat accumulation or other residue may cause fire.
Moisture can condense in the appliance or on the door glass panels. To decrease the con‐
densation, let the appliance work for 10 minutes before cooking. Do not store the food in the
appliance for longer than 20 minutes. Dry the cavity only with a microfibre cloth after each
use.
Accessories
Clean all accessories after each use and let them dry. Use only a microfibre cloth with warm
water and a mild detergent. Do not clean the accessories in a dishwasher.
Do not clean the non-stick accessories using abrasive cleaner or sharp-edged objects.
12.2 How to remove: Shelf supports
Remove the shelf supports to clean the oven.
Step 1 Turn off the oven and wait until it is
cold.
Step 2 Pull the front of the shelf support
away from the side wall.
Step 3 Pull the rear end of the shelf support
away from the side wall and remove
it.
2
1
Step 4 Install the shelf supports in the oppo‐
site sequence.
The retaining pins on the telescopic
runners must point to the front.
12.3 How to use: Pyrolysis
Clean the oven with Pyrolysis.
WARNING!
There is a risk of burns.
CAUTION!
If there are other appliances installed in
the same cabinet, do not use them at the
same time as this function. It can cause
damage to the oven.
ENGLISH 19

Before the Pyrolysis:
Turn off the oven and wait until
it is cold.
Remove all accessories. Clean the oven floor and the inner door
glass with warm water, a soft cloth and
a mild detergent.
Step 1 Set the function: . - flashes.
Step 2 , - press to set the cleaning mode.
Option Cleaning mode Duration
P1 Light cleaning 1:00
P2 Normal cleaning 1:30
Step 3 - press to start the cleaning.
Step 4 After cleaning, turn the knob for the heating functions to the off position.
During the cleaning the oven lamp is off. The oven door stays locked. When the oven is cold, the door un‐
locks.
When the oven is at the set temperature, the door locks. Until the door unlocks the display shows: the bars of the
heat indicator, . To stop cleaning before it is completed, turn the knob for the oven functions to the off posi‐
tion.
When the cleaning ends:
Turn off the oven and wait until it
is cold.
Clean the cavity with a soft cloth. Remove the residue from the bottom of
the cavity.
12.4 Cleaning reminder
The oven reminds you when to clean the
oven with: Pyrolysis.
Pyrolysis - flashes in the display for 10 sec
after each activation and deactivation of the
oven.
, - press at the same time to turn off the
reminder.
12.5 How to remove and install: Door
The oven door has three glass panels. You can remove the oven door and the internal glass
panels to clean them. Read the whole "Removing and installing door" instruction before you
remove the glass panels.
CAUTION!
Do not use the oven without the glass panels.
20 ENGLISH
