AEG BS9314001 User manual

BS9314001 EN User manual

CONTENTS
1. SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4. BEFORE FIRST USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5. CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6. DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7. CLOCK FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8. AUTOMATIC PROGRAMMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
9. USING THE ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
10. ADDITIONAL FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
11. HELPFUL HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
12. CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
13. WHAT TO DO IF… . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
14. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
15. GREAT BRITAIN & IRELAND - GUARANTEE/CUSTOMER SERVICE . . . . . . . . . . . . . . . . . 47
16. EUROPEAN GUARANTEE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler –
features you might not find on ordinary appliances. Please spend a few minutes reading to get
the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com
Register your product for better service:
www.aeg.com/productregistration
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available.
The information can be found on the rating plate. Model, PNC, Serial Number.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
2www.aeg.com

1. SAFETY INFORMATION
Before the installation and use of the appliance, careful-
ly read the supplied instructions. The manufacturer is
not responsible if an incorrect installation and use cau-
ses injuries and damages. Always keep the instructions
with the appliance for future reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent disability.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they are supervised by an adult or a
person who is responsible for their safety.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Keep children and pets away from the appliance
when it operates or when it cools down. Accessible
parts are hot.
• If the appliance has a child safety device, we recom-
mend that you activate it.
• Cleaning and user maintenance shall not be made by
children without supervision.
1.2 General Safety
• Internally the appliance becomes hot when in opera-
tion. Do not touch the heating elements that are in
the appliance. Always use oven gloves to remove or
put in accessories or ovenware.
• Do not use a steam cleaner to clean the appliance.
• Before maintenance cut the power supply.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can
ENGLISH 3

scratch the surface, which may result in shattering of
the glass.
• Only use the core temperature sensor recommended
for this appliance.
• To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must in-
stall this appliance.
• Remove all the packaging.
• Do not install or use a damaged appli-
ance.
• Obey the installation instruction sup-
plied with the appliance.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Do not pull the appliance by the han-
dle.
• Keep the minimum distance from the
other appliances and units.
• Make sure that the appliance is instal-
led below and adjacent safe struc-
tures.
• The sides of the appliance must stay
adjacent to appliances or to units with
the same height.
Electrical connection
WARNING!
Risk of fire and electrical shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the electrical informa-
tion on the rating plate agrees with
the power supply. If not, contact an
electrician.
• Always use a correctly installed shock-
proof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Contact the Service or an electrician to
change a damaged mains cable.
• Do not let mains cables to come in
touch with the appliance door, spe-
cially when the door is hot.
• The shock protection of live and insu-
lated parts must be fastened in such a
way that it cannot be removed without
tools.
• Connect the mains plug to the mains
socket only at the end of the installa-
tion. Make sure that there is access to
the mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to discon-
nect the appliance. Always pull the
mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you discon-
nect the appliance from the mains at
all poles. The isolation device must
have a contact opening width of mini-
mum 3 mm.
4www.aeg.com

2.2 Use
WARNING!
Risk of injury, burns or electric
shock or explosion.
• Use this appliance in a household en-
vironment.
• Do not change the specification of this
appliance.
• Make sure that the ventilation open-
ings are not blocked.
• Do not let the appliance stay unatten-
ded during operation.
• Deactivate the appliance after each
use.
• Be careful, when you open the appli-
ance door while the appliance is in op-
eration. Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with wa-
ter.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Always keep the appliance door
closed when the appliance is in opera-
tion.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
WARNING!
Risk of damage to the appliance.
• To prevent damage or discoloration to
the enamel:
– do not put ovenware or other ob-
jects in the appliance directly on the
bottom.
– do not put aluminium foil directly on
the bottom of the appliance.
– do not put water directly into the hot
appliance.
– do not keep moist dishes and food
in the appliance after you finish the
cooking.
– be careful when you remove or in-
stall the accessories.
• Discoloration of the enamel has no ef-
fect on the performance of the appli-
ance. It is not a defect in the sense of
the warranty law.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be perma-
nent.
Steam Cooking
WARNING!
Risk of burns and damage to the
appliance.
• Do not open the appliance door dur-
ing steam cooking. Steam can release.
2.3 Care and Cleaning
WARNING!
Risk of injury, fire or damage to
the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold. There
is the risk that the glass panels can
break.
• Replace immediately the door glass
panels when they are damaged. Con-
tact the Service.
• Be careful when you remove the door
from the appliance. The door is heavy!
• Clean regularly the appliance to pre-
vent the deterioration of the surface
material.
• Remaining fat or food in the appliance
can cause fire.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal ob-
jects.
• If you use an oven spray, obey the
safety instructions on the packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of detergent.
2.4 Internal light
• The type of light bulb or halogen lamp
used for this appliance, is only for
ENGLISH 5

household appliances. Do not use it
for house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same specifi-
cations.
2.5 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
3. PRODUCT DESCRIPTION
21
11
5
4
6
7
9
10
5
4
3
2
18
3
1Control panel
2Electronic programmer
3Water drawer
4Socket for the core temperature sen-
sor
5Heating element
6Lamp
7Fan
8Rear wall heating element
9Steam generator with cover
10 Shelf support, removable
11 Shelf positions
3.1 Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
6www.aeg.com

Grill- / Roasting pan
To bake and roast or as a pan to collect
fat.
Patisserie tray
For rolls, brezels and small pastries. Suit-
able for steam functions. The discoloura-
tion of the surface has no effect on the
functions.
Steam set
One unperforated and one perforated
food container.
The steam set drains the condensing wa-
ter away from the food during steam
cooking. Use it to prepare food that
should not be in the water during the
cooking (e.g. vegetables, pieces of fish,
chicken breast). The set is not suitable
for food that needs to soak in the water
(e.g. rice, polenta, pasta).
Core temperature sensor
To measure how far the food is cooked.
Sponge
For absorbing the remaining water from
the steam generator.
Telescopic runners
For shelves and trays.
ENGLISH 7

4. BEFORE FIRST USE
WARNING!
Refer to the Safety chapters.
4.1 Initial Cleaning
• Remove all parts from the appliance.
• Clean the appliance before first use.
Refer to chapter "Care and
Cleaning".
4.2 First Connection
When you connect the appliance to the
mains or after a power cut, you have to
set the language, display contrast, dis-
play brightness and time of day. Use the
shuttle to set the values. Press OK to
confirm.
5. CONTROL PANEL
5.1 Electronic programmer
1 2 3 4 5 6 7 8 9
Use the sensor fields to operate the appliance
Num-
ber
Sen-
sor
field
Function Comment
1
-Display Shows the current settings of
the appliance.
2
ON / OFF To activate and deactivate the
appliance.
3
OK and shuttle To confirm the selection or set-
ting. Rotate the shuttle to navi-
gate.
4
Home key To show the main menu.
5
Time and additional functions To set different functions.
When a heating function oper-
ates, touch the sensor field to
set the timer, Child Lock, Fa-
vourite Programme memory,
Heat + Hold , Set + Go , or to
change the settings of the Core
Temperature Sensor.
8www.aeg.com

Num-
ber
Sen-
sor
field
Function Comment
6
Heating Functions or Assisted
Cooking To choose a heating function, touch the sensor field once. To
choose the Assisted Cooking
function, touch it twice. To acti-
vate or deactivate the light,
touch the field for 3 seconds.
7
Temperature selection To set the temperature or show
the current temperature in the
appliance. To activate or deac-
tivate the Fast Heat Up func-
tion, touch the field for 3 sec-
onds.
8
Minute Minder To set the Minute Minder .
9
Favourite Programme To view your favourite pro-
grammes.
Display
A
DE
B C
A) Heating function
B) Time of day
C) Heat-up indicator
D) Temperature
E) Duration time or end time of a func-
tion
Other indicators in the display
Symbol Function
Minute Minder The function is active.
Time Shows the current time.
Duration Shows the time required for the cooking cycle.
End Time Shows when the cooking cycle ends.
Time Indication Shows how long the heating function operates.
Heat-up indicator Indicates the temperature level in the cavity.
The display shows it also when you deactivate
the appliance and the cavity is still warm.
Fast Heat Up Indi-
cator The function is active. It decreases the heat up time.
Weight Automatic The automatic weight system is active, or
weight can be changed.
Heat + Hold The function is active.
ENGLISH 9

6. DAILY USE
WARNING!
Refer to the Safety chapters.
6.1 Navigating the menus
Operation of the menus:
1. Activate the appliance.
2. Rotate the shuttle clockwise or coun-
terclockwise to select the menu op-
tion.
3. Press OK to move to the submenu
or accept the setting.
At any time you can get back to the
main menu with .
6.2 The menus in overview
Main menu
Symbol Menu item Description
Assisted Cooking Contains a list of automatic cooking
programmes.
Heating Functions Contains a list of heating functions.
Steam Cleaning Cleans with steam.
Basic Settings Contains a list of other settings.
Favourite Programme Contains a list of the favourite cook-
ing programmes saved by the user.
Submenu for: Basic Settings
Symbol Submenu Application
Set Time of Day Sets the current time on the clock.
Time Indication When ON, the display shows the cur-
rent time after you deactivate the ap-
pliance.
SET + GO When ON, you can activate the func-
tion after you activate a heating func-
tion.
Heat + Hold When ON, you can activate the func-
tion after you activate a heating func-
tion.
Extra time Activates and deactivates the func-
tion.
Display Contrast Adjusts the display contrast by de-
grees.
Display Brightness Adjusts the display brightness by de-
grees.
Set Language Sets the language for the display.
Buzzer Volume Adjusts the volume of press-tones
and signals by degrees.
10 www.aeg.com

Symbol Submenu Application
Key Tones
Activates and deactivates the tone of
the touch fields. It is not possible to
deactivate the tone of the ON / OFF
touch field.
Alarm/Error Tones Activates and deactivates the alarm
tones.
Cleaning Assistant Helps you with the cleaning proce-
dure.
Service Shows the software version and con-
figuration.
Factory Settings Resets all settings to factory settings.
6.3 Heating functions
Submenu for: Heating Functions
heating function Application
Full Steam For vegetables, fish, potatoes, rice, pasta
or special side-dishes.
Half Steam + Heat For dishes with a high moisture content
and for poaching fish, custard royale and
terrines.
Quarter Steam + Heat To bake bread, roast large pieces of meat
or to warm up chilled and frozen meals.
Eco Steam The ECO functions let you optimize the
energy consumption during cooking. It is
necessary to set the cooking time first. To
get more information about the recom-
mended settings, refer to the cooking ta-
bles with the equivalent usual heating
function.
Moist Fan Baking For energy-saving baking and cooking of
mainly dry bakery items as well as for bak-
ing in tins on 1 shelf position.
True Fan Cooking To bake maximum on 3 shelf positions at
the same time and to dry food. Set the
temperature 20 - 40 °C lower than for Con-
ventional Cooking .
Pizza Setting To bake food on 1 shelf position for a
more intensive browning and a crispy bot-
tom. Set the temperature 20 - 40 °C lower
than for Conventional Cooking .
Slow Cook For preparing especially tender, succulent
roasts.
ENGLISH 11

heating function Application
Conventional Cooking For baking and roasting on 1 level
Frozen Foods To make your convenience food like e.g.
French Fries, Wedges, spring rolls crispy.
Turbo Grilling To roast larger meat joints or poultry with
bones on 1 shelf position. Also to gratinate
and to brown.
Fast Grilling To grill flat food in large quantities. To
toast bread.
Grilling To grill flat food and to toast.
Keep Warm To keep food warm.
Defrost To defrost frozen food.
Bottom Heat For baking cakes with crispy or crusty
bases and to preserve food.
Dough Proving For controlled rising of yeast dough before
baking.
Bread Baking To bake bread.
Au Gratin For dishes like lasagna or potato gratin. Al-
so to gratinate and brown.
Preserving To preserve vegetables e.g. mixed pickles
in glasses and liquid.
Drying For drying of sliced fruits like apples,
plums, peaches and vegetables as toma-
toes, zucchini or mushrooms.
Plate Warming To preheat your plate for serving.
Steam Regenerating To reheat your already cooked food di-
rectly on a plate.
Eco Roasting The ECO functions let you optimize the
energy consumption during cooking. It is
necessary to set the cooking time first. To
get more information about the recom-
mended settings, refer to the cooking ta-
bles with the equivalent usual heating
function.
12 www.aeg.com

6.4 Activating a heating
function
1. Activate the appliance.
2. Select the Heating Functions menu.
Press OK to confirm.
3. Set a heating function. Press OK to
confirm.
4. Set the temperature. Press OK to
confirm.
Press to go directly to the
Heating Functions menu. You
can use it when the appliance is
activated.
6.5 Steam cooking
The water drawer cover is in the control
panel.
1. Press the cover to open the water
drawer.
2. Fill the water drawer with 800 ml of
water.
The water supply is sufficient for ap-
proximately 50 minutes.
Do not put water directly into the
steam generator.
Use only water as the liquid. Do
not use filtered (demineralised)
or distilled water.
3. Activate the appliance.
4. Set the steam heating function (refer
to the “Heating functions” table)
and the temperature.
5. If necessary, set the function Dura-
tion or End Time . The first
steam shows after approximately 2
minutes. An acoustic signal sounds
when the appliance is at approxi-
mately the set temperature. The sig-
nal sounds again at the end of the
cooking time.
6. Deactivate the appliance.
When the steam generator is
empty, an acoustic signal
sounds.
When the appliance is cool, soak up all
remaining water from the steam genera-
tor with the sponge. If necessary, clean
the steam generator with vinegar. Let
the appliance dry fully with the door
open.
6.6 Heat-up indicator
When you activate a heating function,
the bar on the display comes on. The bar
shows that the temperature increases.
Fast Heat Up Indicator
This function decreases the heat-up
time. To activate the function, hold
for 3 seconds. The heat-up indicator al-
ternates.
Residual heat
When you deactivate the appliance, the
display shows the residual heat. You can
use the heat to keep the food warm.
6.7 Energy saving
The appliance contains features
which help you save energy
during everyday cooking:
•Residual heat:
– When the heating function or pro-
gramme operates, the heating ele-
ments are deactivated 10% earlier
(the lamp and fan continue to oper-
ate). For this feature to operate, the
cooking time must be longer than
30 minutes or you must use the
clock functions ( Duration , End
Time ).
– When the appliance is off, you can
use the heat to keep food warm.
The display shows the remaining
temperature.
•Cooking with the lamp off - touch
and hold for 3 seconds to deacti-
vate the lamp during cooking.
•Eco functions - refer to section "Heat-
ing Functions" (for selected models
only).
ENGLISH 13

7. CLOCK FUNCTIONS
Symbol Function Description
Minute Minder
To set a countdown (max. 2 h 30 min). This func-
tion has no effect on the operation of the appli-
ance. You can also activate it when the appliance
is deactivated. Press to activate the function.
Use the shuttle to set the minutes and OK to start.
Duration To set the length of an operation (max. 23 h 59
min).
End Time To set the switch-off time for a heating function
(max. 23 h 59 min).
If you set the time for a clock function,
the time starts to count down after 5 sec-
onds.
If you use the clock functions Du-
ration and End Time , the appli-
ance deactivates the heating ele-
ments after 90 % of the set time.
The appliance uses the residual
heat to continue the cooking
procedure until the time ends.
The residual heat can stay in the
appliance from 3 to 20 minutes.
Setting the clock functions
1. Set a heating function.
2. Press again and again until the
display shows the necessary clock
function and the related symbol.
3. Use the shuttle to set the necessary
time. Press OK to confirm. When the
time ends, an acoustic signal
sounds. The appliance deactivates.
The display shows a message.
4. Press a sensor field to stop the sig-
nal.
Useful information:
• With Duration and End Time , you
must set the heating function and the
temperature first. Then you can set the
clock function. The appliance deacti-
vates automatically.
• You can use Duration and End Time at
the same time if you want to automati-
cally activate and deactivate the appli-
ance at a given time later.
• When you use the Core Temperature
Sensor (if applicable), the Duration
and End Time functions do not oper-
ate.
7.1 Heat + Hold
The Heat + Hold function keeps pre-
pared food warm at 80 °C for 30 mi-
nutes. It activates after the baking or
roasting procedure ends.
• You can activate or deactivate the
function in the Basic Settings menu.
• Conditions for the function:
– The set temperature is more than 80
°C.
– The function Duration is set.
Activating the function
1. Activate the appliance.
2. Select the heating function.
3. Set the temperature above 80 °C.
4. Press again and again until the
display shows Heat + Hold . Press
OK to confirm.
When the function ends, an acoustic sig-
nal sounds.
The Heat + Hold function stays on if you
change the heating functions.
7.2 Extra Time
The Extra Time makes the heating func-
tion continue after the Duration ends.
• Applicable for all heating functions
with Duration or Weight Automatic .
• Not applicable for heating functions
with the core temperature sensor.
14 www.aeg.com

Activating the function:
1. When the cooking time ends, an
acoustic signal sounds. Press a sen-
sor field.
2. The display shows the message for
Extra Time for five minutes.
3. Press to activate (or to cancel).
4. Set the Extra Time period. Press OK
to confirm.
8. AUTOMATIC PROGRAMMES
WARNING!
Refer to the Safety chapters.
8.1 Automatic programmes
These 3 automatic programmes give op-
timum settings for each type of meat or
other recipes:
• Meat programmes with Weight Auto-
matic ( Assisted Cooking menu) —
This function automatically calculates
the roasting time. To use it you need
to input food weight.
• Meat programmes with CT Sensor Au-
tomatic ( Assisted Cooking menu) —
This function automatically calculates
the roasting time. To use it you need
to input core temperature. When the
programme ends an acoustic signal
sounds.
• Recipe Automatic ( Assisted Cooking
menu) — This function uses prede-
fined values for a dish. Prepare the
dish according to recipe from this
book.
Weight Automatic dishes
Roast Pork
Roast Veal
Braised Meat
Roast Game
Roast Lamb
Chicken, whole
Turkey, whole
Duck, whole
Goose, whole
CT Sensor Automatic dishes
Loin of Pork
CT Sensor Automatic dishes
Roast Beef
Scandinavian Beef
Loin of Game
Lamb Joint, medium
Boned Poultry
Whole Fish
You can find the recipes for the
automatic programmes specified
for this appliance on our website.
To find the proper Recipe Book
check the PNC number on the
rating plate on the front frame of
the appliance cavity.
8.2 Assisted Cooking with
Recipe Automatic
This appliance has a set of recipes you
can use. The recipes are fixed and you
cannot change them.
Activating the function:
1. Activate the appliance.
2. Select the Assisted Cooking menu.
Press OK to confirm.
3. Select the category and dish. Press
OK to confirm.
4. Select Recipe Automatic . Press OK
to confirm.
When you use the Manual func-
tion, the appliance uses the auto-
matic settings. You can change
them as with other functions.
ENGLISH 15

8.3 Assisted Cooking with
Weight Automatic
This function automatically calculates the
roasting time. To use it, it is necessary to
input the food weight.
Activating the function:
1. Activate the appliance.
2. Select Assisted Cooking . Press OK
to confirm.
3. Select the category and dish. Press
OK to confirm.
4. Select the Weight Automatic . Press
OK to confirm.
5. Use the shuttle to set the food
weight. Press OK to confirm.
The automatic programme starts. You
can change the weight at any time. Use
the shuttle to change the weight. When
the time ends, an acoustic signal sounds.
Press a sensor field to deactivate the sig-
nal.
With some programmes turn
over the food after 30 minutes.
The display shows a reminder.
9. USING THE ACCESSORIES
WARNING!
Refer to the Safety chapters.
9.1 Core temperature sensor
The core temperature sensor measures
the core temperature of the meat. When
the meat is at the set temperature, the
appliance deactivates.
There are two temperatures to set:
• The oven temperature
• The core temperature
Only use the core temperature
sensor supplied or the correct re-
placement parts.
Using the core temperature sensor:
1. Put the tip of the core temperature
sensor into the centre of the meat.
2. Activate the appliance.
3. Put the plug of the core temperature
sensor into the socket at the front of
the appliance.
The display shows the core tempera-
ture sensor.
4. Use the shuttle in less than 5 sec-
onds to set the core temperature.
5. Set the oven function and, if neces-
sary, the oven temperature.
The appliance calculates an approxi-
mate end time. The end time is dif-
ferent for different quantities of
food, set oven temperatures (mini-
mum 120 °C) and operating modes.
The appliance calculates the end
time in approximately 30 minutes.
The core temperature sensor
must stay in the meat and in the
socket during the cooking.
6. When the meat is at the set core
temperature, an acoustic signal
sounds. The appliance deactivates
16 www.aeg.com

automatically. Touch a sensor field
to stop the signal.
7. Remove the core temperature sen-
sor plug from the socket and remove
the meat from the oven.
To change the core temperature,
press .
WARNING!
The core temperature sensor is
hot. There is a risk of burns. Be
careful when you remove the tip
and the plug of the core temper-
ature sensor.
9.2 Inserting the oven accessories
The deep pan and the wire shelf have
side edges. These edges and the shape
of the guide-bars are a special device to
prevent the cookware from slipping.
Inserting the wire shelf and the deep
pan together
Put the wire shelf on the deep pan. Push
the deep pan between the guide-bars of
one of the oven levels.
9.3 Telescopic runners - inserting the oven accessories
Put the baking tray or deep pan on the
telescopic runners.
ENGLISH 17

Put the wire shelf on the telescopic run-
ners so that the feet point downwards.
The high rim around the wire
shelf is a special device to pre-
vent the cookware from slipping.
9.4 Inserting the wire shelf and the deep pan together
Put the wire shelf on the deep pan. Put
the wire shelf and the deep pan on the
telescopic runners.
10. ADDITIONAL FUNCTIONS
10.1 Favourite Programme
menu
You can save your favourite settings, like
duration, temperature or heating func-
tion. They are available in the Favourite
Programme menu. You can save 20 pro-
grammes.
Saving a programme
1. Activate the appliance.
2. Set a heating function or an Assisted
Cooking function.
3. Touch again and again until the
display shows " SAVE ". Press OK to
confirm.
4. The display shows the first free
memory position. Press OK to con-
firm.
5. Enter the name of the programme.
The first letter flashes. Use the shut-
tle to change the letter. Press OK.
6. Use the shuttle to move the cursor
to the right or to the left. Press OK.
The next letter flashes. Do steps 5
and 6 again as necessary.
7. Press and hold OK to save.
Useful information:
• You can overwrite a memory position.
When the display shows the first free
memory position, use the shuttle and
press OK to overwrite an existing pro-
gramme.
• You can change the name of a pro-
gramme in the menu Edit Programme
Name .
Activating the programme
1. Activate the appliance.
2. Select the Favourite Programme
menu. Press OK to confirm.
3. Select your favourite programme
name. Press OK to confirm.
18 www.aeg.com

10.2 Function Lock
The Function Lock prevents an acciden-
tal change of the heating function. You
can activate the Function Lock only when
the appliance operates.
Activating the Function Lock :
1. Activate the appliance.
2. Set a heating function or setting.
3. Press again and again until the
display shows Function Lock .
4. Press OK to confirm.
Deactivating the Function Lock :
1. Press .
2. Press OK to confirm.
10.3 Child Lock
The Child Lock prevents an accidental
operation of the appliance.
Activating and deactivating the Child
Lock function:
1. Activate the appliance.
2. Touch and at the same time
until the display shows a message.
10.4 SET + GO
The SET + GO function lets you set a
heating function (or programme) and
use it later with one press of the sensor
field.
Activating the function:
1. Activate the appliance.
2. Set a heating function.
3. Press again and again until the
display shows Duration .
4. Set the time.
5. Press again and again until the
display shows SET + GO .
6. Press OK to confirm.
To start SET + GO , press a sensor field
(except for ). The set heating function
starts.
When the heating function ends, an
acoustic signal sounds.
Useful information:
• When the heating function operates,
the function Function Lock is on.
• You can activate and deactivate the
SET + GO function in the Basic Set-
tings menu.
10.5 Automatic switch-off
For safety reasons the appliance deacti-
vates after some time:
• If a heating function operates.
• If you do not change the oven temper-
ature.
Temperature Switch-off time
30 °C - 115 °C 12.5 h
120 °C - 195 °C 8.5 h
200 °C - 230 °C 5.5 h
The automatic switch-off works
with all functions, except Light ,
Duration , End Time and Core
Temperature Sensor.
10.6 Cooling fan
When the appliance operates, the cool-
ing fan activates automatically to keep
the surfaces of the appliance cool. If you
deactivate the appliance, the cooling fan
can continue to operate until the appli-
ance cools down.
ENGLISH 19

11. HELPFUL HINTS AND TIPS
11.1 Inner side of the door
In some models, on the inner side of
the door you can find:
• The numbers of the shelf positions.
• Information about the heating func-
tions, recommended shelf positions
and temperatures for typical dishes.
The temperature and baking
times in the tables are guidelines
only. They depend on the rec-
ipes and the quality and quantity
of the ingredients used.
11.2 Advice for special
heating functions of the oven
Keep Warm
Use this function if you want to keep
food warm.
The temperature regulates itself auto-
matically to 80 °C.
Plate Warming
For warming plates and dishes.
Distribute plates and dishes evenly on
the oven shelf. Move stacks around after
half of the warming time (swap top and
bottom).
The automatic temperature is 70 °C.
Recommended shelf position: 3.
Dough Proving
You can use this automatic function with
any recipe for yeast dough you like. It
gives you a good atmosphere for rising.
Put the dough into a dish that is big
enough for rising and cover it with a wet
towel or plastic foil. Insert a wire shelf on
level one and put the dish in. Close the
door and set the function dough prov-
ing. Set the necessary time.
11.3 Cooking with steam
Cookware for steam cooking
• Use only heat and corrosion resistant
cookware or chrome steel food con-
tainers (for some models only).
Shelf positions
• The correct shelf positions are in the
table below. Count the shelf positions
from the bottom to the top.
General notes
• When you cook longer than 30 mi-
nutes or when you cook large quanti-
ties of food, add water if it is necessa-
ry.
• Put the food into the correct cooking
containers and put the containers on
the shelves. Make sure that there is
some distance between the shelves to
let the steam circulate around each
container.
• After each use, remove the water from
the water drawer, connecting hoses
and steam generator. Refer to the
chapter "Care and cleaning".
Notes on the tables for steam cooking
• The tables give data for typical dishes.
• The temperature and time are for
guidance only and depend on the
type, dimensions and quantity of the
food and cookware.
• Use a recipe that is almost the same if
you cannot find the settings for your
recipe.
• Start the procedure with a cold appli-
ance unless the data in the tables is
different.
• When you cook rice, use a ratio of
1.5:1 – 2:1 water to rice because rice
absorbs water.
11.4 Steam water table
Water in the water drawer (ml) Time
1)
(min.)
400 15 - 25
600 25 - 40
800 40 - 50
20 www.aeg.com
