AEG S93000KZM0 User manual

S93000KZM0
EN
FRIDGE USER MANUAL
2
DE
KÜHLSCHRANK BENUTZERINFORMATION
23
IT
FRIGO ISTRUZIONI PER L’USO
45
RU   

66

FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
ACCESSORIES AND CONSUMABLES
In the AEG webshop, you’ll find everything you need to keep all your AEG
appliances looking spotless and working perfectly. Along with a wide range of
accessories designed and built to the high quality standards you would expect,
from specialist cookware to cutlery baskets, from bottle holders to delicate
laundry bags…
Visit the webshop at:
www.aeg.com/shop
2

CONTENTS
4 Safety information
6 Control panel
9 First use
9Dailyuse
14 Helpful hints and tips
15 Care and cleaning
16 What to do if…
18 Technical data
18 Installation
20 Noises
22 Environmental concerns
The following symbols are used in this user
manual:
Important information concerning your
personal safety and information on how to
avoid damaging the appliance.
General information and tips
Environmental information
Subject to change without notice
Contents 3

SAFETY INFORMATION
In the interest of your safety and to ensure the correct use, before installing and first using
the appliance, read this user manual carefully, including its hints and warnings. To avoid
unnecessary mistakes and accidents, it is important to ensure that all people using the ap-
pliance are thoroughly familiar with its operation and safety features. Save these instruc-
tions and make sure that they remain with the appliance if it is moved or sold, so that ev-
eryone using it through its life will be properly informed on appliance use and safety.
For the safety of life and property keep the precautions of these user's instructions as the
manufacturer is not responsible for damages caused by omission.
Children and vulnerable people safety
• This appliance is not intended for use by persons (including children) with reduced physi-
cal, sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance by a person re-
sponsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
• Keep all packaging well away from children. There is risk of suffocation.
• If you are discarding the appliance pull the plug out of the socket, cut the connection
cable (as close to the appliance as you can) and remove the door to prevent playing chil-
dren to suffer electric shock or to close themselves into it.
• If this appliance featuring magnetic door seals is to replace an older appliance having a
spring lock (latch) on the door or lid, be sure to make that spring lock unusable before
you discard the old appliance. This will prevent it from becoming a death trap for a child.
General safety
WARNING!
Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of
obstruction.
• The appliance is intended for keeping foodstuff and/or beverages in a normal household
as explained in this instruction booklet.
• Do not use a mechanical device or any artificial means to speed up the thawing process.
• Do not use other electrical appliances (such as ice cream makers) inside of refrigerating
appliances, unless they are approved for this purpose by the manufacturer.
• Do not damage the refrigerant circuit.
• The refrigerant isobutane (R600a) is contained within the refrigerant circuit of the appli-
ance, a natural gas with a high level of environmental compatibility, which is neverthe-
less flammable.
During transportation and installation of the appliance, be certain that none of the com-
ponents of the refrigerant circuit become damaged.
If the refrigerant circuit should become damaged:
– avoid open flames and sources of ignition
4Safety information

– thoroughly ventilate the room in which the appliance is situated
• It is dangerous to alter the specifications or modify this product in any way. Any damage
to the cord may cause a short-circuit, fire and/or electric shock.
WARNING!
Any electrical component (power cord, plug, compressor) must be replaced by a certified
service agent or qualified service personnel to avoid hazard.
1. Power cord must not be lengthened.
2. Make sure that the power plug is not squashed or damaged by the back of the ap-
pliance. A squashed or damaged power plug may overheat and cause a fire.
3. Make sure that you can come to the mains plug of the appliance.
4. Do not pull the mains cable.
5. If the power plug socket is loose, do not insert the power plug. There is a risk of
electric shock or fire.
6. You must not operate the appliance without the lamp cover1) of interior lighting.
• This appliance is heavy. Care should be taken when moving it.
• Do not remove nor touch items from the freezer compartment if your hands are damp/
wet, as this could cause skin abrasions or frost/freezer burns.
• Avoid prolonged exposure of the appliance to direct sunlight.
•Bulb lamps2) used in this appliance are special purpose lamps selected for household ap-
pliances use only. They are not suitable for household room illumination.
Daily Use
• Do not put hot pot on the plastic parts in the appliance.
• Do not store flammable gas and liquid in the appliance, because they may explode.
•Do not place food products directly against the air outlet on the rear wall.3)
• Frozen food must not be re-frozen once it has been thawed out.
• Store pre-packed frozen food in accordance with the frozen food manufacturer's in-
structions.
• Appliance's manufacturers storage recommendations should be strictly adhered to. Refer
to relevant instructions.
• Do not place carbonated or fizzy drinks in the freezer compartment as it creates pressure
on the container, which may cause it to explode, resulting in damage to the appliance.
• Ice lollies can cause frost burns if consumed straight from the appliance.
Care and cleaning
• Before maintenance, switch off the appliance and disconnect the mains plug from the
mains socket.
• Do not clean the appliance with metal objects.
• Do not use sharp objects to remove frost from the appliance. Use a plastic scraper.
1) If the lamp cover is foreseen.
2) If the lamp is foreseen.
3) If the appliance is Frost Free.
Safety information 5

• Regularly examine the drain in the refrigerator for defrosted water. If necessary, clean
the drain. If the drain is blocked, water will collect in the bottom of the appliance.
Installation
For electrical connection carefully follow the instructions given in specific paragraphs.
• Unpack the appliance and check if there are damages on it. Do not connect the appli-
ance if it is damaged. Report possible damages immediately to the place you bought it.
In that case retain packing.
• It is advisable to wait at least four hours before connecting the appliance to allow the oil
to flow back in the compressor.
• Adequate air circulation should be around the appliance, lacking this leads to overheat-
ing. To achieve sufficient ventilation follow the instructions relevant to installation.
• Wherever possible the back of the product should be against a wall to avoid touching or
catching warm parts (compressor, condenser) to prevent possible burn.
• The appliance must not be located close to radiators or cookers.
• Make sure that the mains plug is accessible after the installation of the appliance.
•Connect to potable water supply only. 4)
Service
• Any electrical work required to do the servicing of the appliance should be carried out by
a qualified electrician or competent person.
• This product must be serviced by an authorized Service Centre, and only genuine spare
parts must be used.
Environment Protection
This appliance does not contain gasses which could damage the ozone layer, in either its
refrigerant circuit or insulation materials. The appliance shall not be discarded together
with the urban refuse and rubbish. The insulation foam contains flammable gases: the ap-
pliance shall be disposed according to the applicable regulations to obtain from your local
authorities. Avoid damaging the cooling unit, especially at the rear near the heat exchang-
er. The materials used on this appliance marked by the symbol are recyclable.
CONTROL PANEL
12345 6
1ON/OFF button
2Mode button
4) If a water connection is foreseen.
6Control panel

3OK button
4Temperature colder button
5Temperature warmer button
6Display
It is possible to change predefined sound of buttons to a loudly one by pressing together
Mode button and Temperature colder button for some seconds. Change is reversible.
Display
5 62 431
1Timer function
2COOLMATIC function
3Minute Minder function
4Child Lock function
5Alarm indicator
6Temperature indicator
Switching on
To switch on the appliance do these steps:
1. Connect the mains plug to the power socket.
2. Press the ON/OFF button if the display is off.
3. The alarm buzzer could operate after few seconds.
To reset the alarm refer to "High temperature alarm".
4. If "dEMo" appears on the display, the appliance is in demonstration mode. Refer to
"What to do if..." paragraph.
5. The temperature indicators show the set default temperature.
To select a different set temperature refer to "Temperature regulation".
Switching off
To switch off the appliance do these steps:
1. Press the ON/OFF button for 5 seconds.
2. The display switches off.
3. To disconnect the appliance from the power disconnect the mains plug from the pow-
er socket.
Temperature regulation
The set temperature of the fridge may be adjusted by pressing the temperature button.
Set default temperature:
• +5°C for the fridge
The temperature indicator shows the set temperature.
The set temperature will be reached within 24 hours.
Control panel 7

After a power failure the set temperature remains stored.
Minute Minder function
The Minute Minder function is to be used to set an acoustic alarm at the preferred time,
useful for example when a recipe requires to cool down a mixture for a certain lenght of
time.
To switch on the function:
1. Press the Mode button until the corresponding icon appears.
The Minute Minder indicator flashes.
The Timer shows the set value (30 minutes) for a few seconds.
2. Press the Timer regulator button to change the Timer set value from 1 to 90 minutes.
3. Press the OK button to confirm.
The Minute Minder indicator is shown.
The Timer start to flash (min).
At the end of the countdown the Minute Minder indicator flashes and an audible alarm
sounds:
1. press OK button to switch off the sound and terminate the function.
It is possible to deactivate the function at any time during the countdown:
1. Press the Mode button until the Minute Minder indicator flashes.
2. Press the OK button to confirm.
3. The Minute Minder indicator goes off.
It is possible to change the time at any time during the countdown and at the end by press-
ing the Temperature colder button and the Temperature warmer button.
Child Lock function
To lock the buttons from unintentional operation select the Child Lock function.
To switch on the function:
1. Press the Mode button until the corresponding icon appears.
2. The Child Lock indicator flashes.
3. Press the OK button to confirm.
The Child Lock indicator is shown.
To switch off the function:
1. Press the Mode button until the Child Lock indicator flashes.
2. Press the OK button to confirm.
3. The Child Lock indicator goes off.
COOLMATIC function
If you need to insert a large amount of warm food, for example after doing the grocery
shopping, we suggest activating the COOLMATIC function to chill the products more rapidly
and to avoid warming the other food which is already in the refrigerator.
To switch on the function:
1. Press the Mode button until the corresponding icon appears.
8Control panel

The COOLMATIC indicator flashes.
2. Press the OK button to confirm.
The COOLMATIC indicator is shown.
The COOLMATIC function shuts off automatically after approximately 6 hours.
To switch off the function before its automatic end:
1. Press the Mode button until the COOLMATIC indicator flashes.
2. Press the OK button to confirm.
3. The COOLMATIC indicator goes off.
The function switches off by selecting a different fridge set temperature.
Door open alarm
An acoustic alarm will sound if the door is left open for a few minutes. The door open alarm
conditions are indicated by:
• flashing Alarm indicator
• acoustic buzzer
When normal conditions are restored (door closed), the alarm will stop.
During the alarm, the buzzer can be switched off by pressing any button.
FIRST USE
Cleaning the interior
Before using the appliance for the first time, wash the interior and all internal accessories
with lukewarm water and some neutral soap so as to remove the typical smell of a brand-
new product, then dry thoroughly.
Do not use detergents or abrasive powders, as these will damage the finish.
If “dEMo” appears on the Display, the appliance is in demonstration mode: refer to “WHAT
TO DO IF...” paragraph.
DAILY USE
this appliance is sold in France.
In accordance with regulations valid in this country it must be provided with a special de-
vice (see figure) placed in the lower compartment of the fridge to indicate the coldest zone
of it.
First use 9

Movable shelves
The walls of the refrigerator are equipped with a
series of runners so that the shelves can be posi-
tioned as desired.
For better use of space, the front half-shelves can
lie over the rear ones.
Positioning the door shelves
To permit storage of food packages of various sizes, the door shelves can be placed at dif-
ferent heights.
Positioning the sliding box
The sliding box can be placed at different heights.
To make these adjustments proceed as follow:
1. lift the shelf with the sliding box up-
wards and out of the holders in the
door
2. remove the retaining bracket out of the
guide under the shelf
3. Reverse the above operation to insert
the sliding box at a different height.
10 Daily use

Carbon Air Filter
Your appliance is equipped with a carbon filter
CLEANAIR CONTROL behind a flap in the rear wall
of the fridge compartment.
The filter purifies the air from unwanted odours in
the fridge and LONGFRESH compartment meaning
that the storage quality will be further improved.
During the operation, always keep the air ventila-
tion flap closed.
LONGFRESH Compartment
In the LONGFRESH 0°C compartment the temperature is controlled automatically. It stays
constantly at about 0°C, no adjustment is necessary.
The constant storage temperature of about 0°C and the relative humidity of between 45
and 90 % provide optimal conditions for the various kinds of food.
You can therefore store a variety of fresh food in the LONGFRESH 0°C compartment, where
it will last up to 3 times longer with better quality compared to normal refrigerator com-
partments. This allows you to stock more fresh food. Taste, degree of freshness, quality and
nutritional values (vitamins and minerals) are well preserved. Loss of weight in vegetables
and fruit diminishes. Food yields a higher degree of nutritional value.
The LONGFRESH 0°C compartment is also suitable for defrosting food.
In this case the thawed food can be stored up to two days .
Humidity control
Both drawers can be used according to the de-
sired storage conditions independently of each
other with lower or higher humidity.
Regulation for each drawer is separate and is con-
trolled using the slide valve at the front of the
drawer.
• „Dry“: low air humidity -up to 50 % relative
humidity
This humidity level is reached when both sliders are set into this position and the ven-
tilation openings are wide open.
• Humid“: high relative humidity -up to 90%
This humidity level is reached when both sliders are set in this position and the
ventilation openings are closed. Humidity is kept and can not escape.
CLEANAIR CONTROL
Daily use 11

Longfresh drawers
The humidity is not adjustable.
The wire shelves inside the drawers permit that air
can circulate freely and consequently a better
conservation of foods.
The compartment has stops to prevent the draw-
ers from falling out when fully extended.
To remove the drawers (e.g. for cleaning purpo-
ses), pull them out as far as the stops, lift and re-
move.
You can remove all drawers to store large quanti-
ties of foods.
Storage time in the longfresh 0°C compartment for fresh food
Type of food Air humidity adjustment Storage time
Onion "dry” up to 5 months
Butter “dry” up to 1 month
Large pork cuts “dry” up to 10 days
Beef, venison, small pork cuts,
poultry “dry” up to 7 days
Tomato sauce “dry” up to 4 days
Fish, shellfish, cooked meat
products “dry” up to 3 days
Cooked seafood “dry” up to 2 days
Salad, vegetables Carrots,
herbs, Brussels sprouts, celery “humid” up to 1 month
12 Daily use

Type of food Air humidity adjustment Storage time
Artichokes, cauliflower, chico-
ry, iceberg lettuce, endive,
lamb’s lettuce, lettuce, leeks,
radicchio
“humid” up to 21 days
Broccoli, Chinese leaves, kale,
cabbage, radishes, Savoy cab-
bage
“humid” up to 14 days
Peas, kohlrabi “humid” up to 10 days
Spring onions, radishes, aspar-
agus, spinach “humid” up to 7 days
Fruit
1)
Pears, dates (fresh), strawber-
ries, peaches
1)
“humid” up to 1 month
Plums
1)
rhubarb, gooseberries
“humid” up to 21 days
Apples (not sensitive to cold),
quinces “humid” up to 20 days
Apricots, cherries “humid” up to 14 days
Damsons, grapes “humid” up to 10 days
Blackberries, currants “humid” up to 8 days
Figs (fresh) “humid” up to 7 days
Blueberries, raspberries “humid” up to 5 days
1) The riper the fruit, the shorter the storage time
Cakes containing cream and other kinds of pastry products can be stored in the longfresh
0°C compartment for 2 or 3 days.
Not to be placed in the longfresh 0°C compartment:
• cold sensitive fruit which have to be stored at cellar or room temperature like pineapple,
bananas, grapefruit, melons, mango, papaya, oranges, lemons, kiwi fruit.
• The types of food not mentioned above should be stored in the refrigerator compart-
ment (e.g. all sorts of cheese, cold cuts, etc.)
The level of air humidity in the drawers depends on the content of humidity in the stored
food, vegetable and fruit and on the frequency of door opening
The longfresh 0°C compartment is also suitable for slow thawing of food. In this case the
thawed food can be stored in the longfresh 0°C compartment for up to two days.
Tips:
• Pay attention to the freshness of the food, especially on the expiry date. Quality and
freshness influence the storage time.
Daily use 13

• The whole storage cycle time will depend on the preservation conditions made prior to
the final storage in the fridge.
• Food, fruit or vegetables should always be packed or wrapped up before storage.
• Animal food always store packed and dry.
• Food rich in proteins will go bad quicker. This means seafood will spoil before fish which
in turn will spoil before meat. While storing food in a 0°C compartment storage time for
that kind of food can be increased by up to three times as well without loss on quality.
• All food stored in a 0°C compartment should be taken out of the drawers roughly 15-30
min before consumption, particularly fruit and vegetables to be consumed without any
additional cooking process. Allowing fruit and vegetables to return to room temperature
will improve the texture and flavour.
HELPFUL HINTS AND TIPS
Hints for energy saving
• Do not open the door frequently or leave it open longer than absolutely necessary.
• If the ambient temperature is high and the Temperature Regulator is set to low tempera-
ture and the appliance is fully loaded, the compressor may run continuously, causing
frost or ice on the evaporator. If this happens, set the Temperature Regulator toward
warmer settings to allow automatic defrosting and so a saving in electricity consump-
tion.
Hints for fresh food refrigeration
To obtain the best performance:
• do not store warm food or evaporating liquids in the refrigerator
• do cover or wrap the food, particularly if it has a strong flavour
• position food so that air can circulate freely around it
Hints for refrigeration
Useful hints:
Meat (all types) : wrap in polythene bags and place on the glass shelf above the vegetable
drawer.
For safety, store in this way only one or two days at the most.
Cooked foods, cold dishes, etc..: these should be covered and may be placed on any shelf.
Fruit and vegetables: these should be thoroughly cleaned and placed in the special draw-
er(s) provided.
Butter and cheese: these should be placed in special airtight containers or wrapped in alu-
minium foil or polythene bags to exclude as much air as possible.
Milk bottles: these should have a cap and should be stored in the bottle rack on the door.
Bananas, potatoes, onions and garlic, if not packed, must not be kept in the refrigerator.
14 Helpful hints and tips

CARE AND CLEANING
CAUTION!
Unplug the appliance before carrying out any maintenance operation.
This appliance contains hydrocarbons in its cooling unit; maintenance and recharging must
therefore only be carried out by authorized technicians.
Periodic cleaning
The equipment has to be cleaned regularly:
• clean the inside and accessories with lukewarm water and some neutral soap.
• regularly check the door seals and wipe clean to ensure they are clean and free from
debris.
• rinse and dry thoroughly.
Do not pull, move or damage any pipes and/or cables inside the cabinet.
Never use detergents, abrasive powders, highly perfumed cleaning products or wax polishes
to clean the interior as this will damage the surface and leave a strong odour.
Clean the condenser (black grill) and the compressor at the back of the appliance with a
brush. This operation will improve the performance of the appliance and save electricity
consumption.
The lowest shelf, dividing the cooler compartment from the LONGFRESH 0°C compartment
can be removed only for cleaning. To remove pull out the shelf straight.
The cover plates above the drawers in the compartment can be taken out for cleaning.
To make sure fully functionality of the LONGFRESH 0°C compartment the lowest shelf and
cover plates must be put back in their original position after cleaning.
Take care of not to damage the cooling system.
Many proprietary kitchen surface cleaners contain chemicals that can attack/damage the
plastics used in this appliance. For this reason it is recommended that the outer casing of
this appliance is only cleaned with warm water with a little washing-up liquid added.
After cleaning, reconnect the equipment to the mains supply.
Replacing the carbon filter
The carbon filter helps to reduce the odours inside the fridge limiting the risk of unwanted
aroma in sensitive food
To get the best performance the carbon filter should be changed once every year.
New active air filters can be purchased from your local dealer.
Care and cleaning 15

• The air filter is placed behind the flap and
can be reached by pulling the flap outward
(1)
• pull out of the slot the exhausted air filter.
• insert the new air filter in the slot (2)
• close the flap.
The air filter is a consumable accessory and as such is not covered by the guarantee.
During the operation, always keep the air ventilation flap closed.
The air filter should be handled carefully to prevent its surface from being scratched.
Defrosting of the refrigerator
Defrosting of the fridge compartment is automatic.
The water that forms flows into a recipient on the compressor and evaporates. This recipi-
ent cannot be removed.
Periods of non-operation
When the appliance is not in use for long periods, take the following precautions:
•disconnect the appliance from electricity supply
• remove all food
•defrost5) and clean the appliance and all accessories
• leave the door/doors ajar to prevent unpleasant smells.
If the cabinet will be kept on, ask somebody to check it once in a while to prevent the food
inside from spoiling in case of a power failure.
WHAT TO DO IF…
WARNING!
Before troubleshooting, disconnect the mains plug from the mains socket.
Only a qualified electrician or competent person must do the troubleshooting that is not in
this manual.
1
2
5) If foreseen.
16 What to do if…

Problem Possible cause Solution
The appliance is noisy The appliance is not supported
properly Check if the appliance stands sta- ble (all the four feet should be on
the floor)
The appliance does not
operate. The lamp does
not operate.
The appliance is switched off. Switch on the appliance.
The mains plug is not connected
to the mains socket correctly. Connect the mains plug to the mains socket correctly.
The appliance has no power.
There is no voltage in the mains
socket.
Connect a different electrical ap-
pliance to the mains socket.
Contact a qualified electrician.
The lamp does not work. The lamp is in stand-by. Close and open the door.
The lamp is defective. Refer to "Replacing the lamp".
The compressor operates
continually.
The temperature is not set cor-
rectly. Set a higher temperature.
The door is not closed correctly. Refer to "Closing the door".
The door has been opened too
frequently. Do not keep the door open longer than necessary.
The product temperature is too
high. Let the product temperature de- crease to room temperature be-
fore storage.
The room temperature is too
high. Decrease the room temperature.
The compressor does not
start immediately after
pressing the COOLMATIC
switch, or after changing
the temperature.
This is normal, no error has oc-
curred. The compressor starts after a pe- riod of time.
Water flows on the rear
plate of the refrigerator.
During the automatic defrosting
process, frost defrosts on the
rear plate.
This is correct.
The temperature in the
appliance is too low/high.
The temperature regulator is not
set correctly. Set a higher/lower temperature.
The door is not closed correctly. Refer to "Closing the door".
The product temperature is too
high. Let the product temperature de- crease to room temperature be-
fore storage.
Many products are stored at the
same time. Store less products at the same time.
The temperature in the re-
frigerator is too high.
There is no cold air circulation in
the appliance. Make sure that there is cold air circulation in the appliance.
What to do if… 17

Problem Possible cause Solution
Upper or lower square is
shown in the temperature
Display.
An error has occurred in meas-
uring the temperature Call your service representative (the cooling system will continue
to keep food products cold, but
temperature adjustment will not
be possible).
dEMo appears on the Dis-
play. The appliance is in demonstra- tion mode (dEMo). Keep pressed approximately 10 sec. the OK button since a long
sound of buzzer is heard and the
Display shut off for a short while:
appliance start works regularly
Replacing the lamp
The appliance is equipped with a longlife LED interior light.
Only service is allowed to replace the lighting device. Contact your Service Center
Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to "Installation".
3. If necessary, replace the defective door gaskets. Contact the Service Center.
TECHNICAL DATA
Dimension of the recess
Height 1855 mm
Width 545 mm
Depth 575 mm
Voltage 230-240 V
Frequency 50 Hz
The technical information are situated in the rating plate on the internal left side of the
appliance and in the energy label.
INSTALLATION
WARNING!
Read the "Safety Information" carefully for your safety and correct operation of the appli-
ance before installing the appliance.
18 Technical data

Positioning
WARNING!
If you are discarding an old appliance that has a lock or catch on the door, you must ensure
that it is made unusable to prevent young children being trapped inside.
The appliance shall have the plug accessible after installation.
Install this appliance at a location where the ambient temperature corresponds to the cli-
mate class indicated on the rating plate of the appliance:
Climate class Ambient temperature
SN +10°C to + 32°C
N+16°C to + 32°C
ST +16°C to + 38°C
T+16°C to + 43°C
Electrical connection
Before plugging in, ensure that the voltage and frequency shown on the rating plate corre-
spond to your domestic power supply.
The appliance must be earthed. The power supply cable plug is provided with a contact for
this purpose. If the domestic power supply socket is not earthed, connect the appliance to a
separate earth in compliance with current regulations, consulting a qualified electrician.
The manufacturer declines all responsibility if the above safety precautions are not ob-
served.
This appliance complies with the E.E.C. Directives.
Ventilation requirements
The airflow behind the appliance must be suffi-
cient.
Installation of the carbon air filter
The carbon air filter is an active carbon filter which absorbs bad odours and permits to
maintain the best flavour and aroma for all foodstuffs without risk of odour cross contami-
nation.
50 mm min.
200 cm2
min.
200 cm2
Installation 19

On delivery the carbon filter is in a plastic bag to
maintain it’s duration and characteristics. The fil-
ter should be placed behind the flap before the
appliance is turned on.
1. Open the flap cover (1)
2. Remove the filter from the plastic bag
3. Insert the filter in the slot found in the back
of the flap cover (2)
4. Close the flap cover
During operation, always keep the air ventilation
flap closed.
The filter should be handled carefully so frag-
ments do not loosen from the surface.
NOISES
There are some sounds during normal running (compressor, refrigerant circulation).
BRRR!
HISSS!
CLICK!
BLUBB!
CRACK!
SSSRRR!
OK
CLICK!
CLICK!
1
2
20 Noises
