LFR7314O4V
EN User Manual | Washing Machine
aeg.com\register

FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler –
features you might not find on ordinary appliances. Please spend a few minutes reading
to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
CONTENTS
1. SAFETY INFORMATION................................................................................ 3
2. SAFETY INSTRUCTIONS.............................................................................. 5
3. PRODUCT DESCRIPTION............................................................................. 6
4. TECHNICAL DATA......................................................................................... 8
5. INSTALLATION...............................................................................................8
6. CONTROL PANEL........................................................................................ 13
7. DIAL AND BUTTONS....................................................................................15
8. SETTINGS.................................................................................................... 18
9. BEFORE FIRST USE....................................................................................19
10. PROGRAMMES.......................................................................................... 19
11. DAILY USE..................................................................................................25
12. HINTS AND TIPS........................................................................................ 30
13. CARE AND CLEANING.............................................................................. 32
14. TROUBLESHOOTING................................................................................ 38
15. CONSUMPTION VALUES.......................................................................... 42
16. QUICK GUIDE............................................................................................ 43
17. ENVIRONMENTAL CONCERNS................................................................45
2 ENGLISH

1. SAFETY INFORMATION
Before beginning the installation and use of this
appliance, carefully read the supplied instructions.
The manufacturer is not responsible for any injuries or
damage that are the result of incorrect installation or usage.
Always keep the instructions in a safe and accessible location
for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
• Children between 3 and 8 years of age and persons with
very extensive and complex disabilities shall be kept away
from the appliance unless continuously supervised.
• Children of less than 3 years of age should be kept away
from the appliance unless continuously supervised.
• Children should be supervised to ensure that they do not
play with the appliance.
• Keep all packaging away from children and dispose of it
appropriately.
• Keep detergents away from children.
• Keep children and pets away from the appliance when the
door is open.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
ENGLISH 3

1.2 General Safety
• This appliance is for washing domestic-type, machine-
washable laundry only.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
• Do not change the specification of this appliance.
• The appliance maximum load is 10.0 kg. Do not exceed the
maximum load of each programme (refer to the
“Programmes” chapter).
• The operating water pressure at the water entry point from
the outlet connection must be between 0.5 bar (0.05 MPa)
and 10 bar (1.0 MPa).
• The ventilation opening in the base must not be covered by
a carpet, mat, or any floor covering.
• The appliance must be connected to the water mains using
the new supplied hose sets, or other new hose sets
supplied by the Authorised Service Centre.
• Old hose sets must not be reused.
• If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service Centre
or similarly qualified persons to avoid an electrical hazard.
• Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the socket.
• Do not use high pressure water sprays and/or steam to
clean the appliance.
• Clean the appliance with a moist cloth. Use only neutral
detergents. Do not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
4 ENGLISH

2. SAFETY INSTRUCTIONS
2.1 Installation
The installation must comply with
relevant national regulations.
• Remove all the packaging and the transit
bolts including rubber bush with plastic
spacer.
• Keep the transit bolts in a safe place. If the
appliance is to be moved in the future they
must be reattached to lock the drum to
prevent an internal damage.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Follow the installation instructions supplied
with the appliance.
• Do not install or use a damaged
appliance.
• Do not install or use the appliance where
the temperature can be less than 0°C or
where it is exposed to the weather.
• The floor area on which the appliance is to
be installed must be flat, stable, heat
resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• When the appliance is in its permanent
position, check if it is levelled correctly
with the aid of a spirit level. If it is not,
adjust the feet accordingly.
• Do not install the appliance directly above
a floor drain.
• Do not spray water on the appliance and
do not expose it to excessive humidity.
• Do not install the appliance where the
appliance door cannot be fully opened.
• Do not put a closed container to collect
possible water leakage under the
appliance. Contact the Authorised Service
Centre to ensure which accessories can
be used.
2.2 Electrical connection
WARNING!
Risk of fire and electric shock.
• WARNING: This appliance is designed to
be installed / connected to a grounding
connection in the building.
• Always use a correctly installed
shockproof socket.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable. Should
the mains cable need to be replaced, this
must be carried out by our Authorised
Service Centre.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• Do not touch the mains cable or the mains
plug with wet hands.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
2.3 Water connection
• The inlet water shall not exceed 25 °C.
• Do not cause damage to the water hoses.
• Before connection to new pipes, pipes not
used for a long time, where repair work
has been carried out or new devices fitted
(water meters, etc.), let the water flow until
it is clean and clear.
• Ensure that there are no visible water
leaks during and after the first use of the
appliance.
• Do not use an extension hose if the inlet
hose is too short. Contact the Authorised
Service Centre for the replacement of the
inlet hose.
• When unpacking the appliance, It is
possible to see water flowing from the
drain hose. This is due to the testing of the
appliance with the use of water in the
factory.
• You can extend the drain hose to
maximum 400 cm. Contact the Authorised
Service Centre for the other drain hose
and the extension.
ENGLISH 5

• Make sure that there is access to the tap
after the installation.
2.4 Use
WARNING!
Risk of injury, electric shock, fire, burns
or damage to the appliance.
• Follow the safety instructions on the
detergent packaging.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
• Do not wash fabrics which are heavily
soiled with oil, grease or other greasy
substances. It can damage rubber parts of
the washing machine. Prewash such
fabrics by hand before loading them into
the washing machine.
• Do not touch the glass door while a
programme operates. The glass can get
hot.
• Make sure that all metal objects are
removed from the laundry.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts will be available
for 10 years after the model has been
discontinued: motor and motor brushes,
transmission between motor and drum,
pumps, shock absorbers and springs,
washing drum, drum spider and related
ball bearings, heaters and heating
elements, including heat pumps, piping
and related equipment including hoses,
valves, filters and aquastops, printed
circuit boards, electronic displays,
pressure switches, thermostats and
sensors, software and firmware including
reset software, door, door hinge and
seals, other seals, door locking assembly,
plastic peripherals such as detergent
dispensers. Please note that some of
these spare parts are only available to
professional repairers, and that not all
spare parts are relevant for all models.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains
electrical and water supplies.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
• Remove the door catch to prevent children
or pets from becoming trapped in the
drum.
• Dispose of the appliance in accordance
with local requirements for the disposal of
Waste Electrical and Electronic Equipment
(WEEE).
3. PRODUCT DESCRIPTION
3.1 Special features
Your new washing machine meets all modern
requirements for an effective treatment of
laundry with low water, energy and detergent
consumption and proper care of fabric.
• The UniversalDose drawer with a
compartment dedicated to each type of
detergent, including a compartment for
PODS®, equipped with a system able to
spread and mixing the detergent in an
optimal way, and to dissolve the detergent
residues after each cycle.
• The ProSense technology detects the
laundry load size defining the programme
duration in 30 seconds. The washing
6 ENGLISH

programme is tailored to the laundry load
and the type of fabric without consuming
more time, energy and water than
necessary.
• The steam has a quick and easy way to
refresh the clothes. The gentle steam
programmes remove odours and reduce
creases in dry fabrics so they need little
ironing.
The Plus Steam option, finishes every
cycle with gentle steam that relaxes the
fibres and reduces fabric creasing. Ironing
will be easier!
• The AEG Steam Fragrance, thanks to the
steam programmes offers the perfect
solution for refreshing even the most
delicate garments without washing. Use
the delicate fragrance exclusively
developed by AEG to add a pleasant
feeling of "just-washed" garment to the
removing odours and wrinkles action.
3.2 Appliance overview
1 2 3 9
5
6
7
4
10
8
11 12
1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Rating plate
6Drain pump filter
7Feet for levelling the appliance
8Drain hose
9Inlet hose connection
10 Mains cable
11 Transit bolts
12 Hose support
00000000
00A
Mod. xxxxxxxxx
000V ~ 00Hz 0000 W
910000000 00
A
B
C
Prod.No.
D
The rating plate reports:
A. model name
B. product number
C. electrical ratings
D. serial number
ENGLISH 7

4. TECHNICAL DATA
Dimension Width/ Height/ Total depth 59.7 cm /84.7 cm /66.0 cm
Electrical connection Voltage
Overall power
Fuse
Frequency
230 V
2100 W
10 A
50 Hz
Level of protection against ingress of solid particles and moisture ensured
by the protective cover, except where the low voltage equipment has no
protection against moisture
IPX4
Water supply pressure Minimum
Maximum
0.5 bar (0.05 MPa)
10 bar (1.0 MPa)
Water supply 1) Cold water
Maximum Load Cotton 10.0 kg
Spin Speed Maximum spin speed 1351 rpm
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
5. INSTALLATION
WARNING!
Refer to Safety chapters.
5.1 Unpacking
WARNING!
Remove all the packaging and the transit
bolts before installing the appliance.
WARNING!
Use the gloves.
1. Remove the external film. If necessary,
use a cutter.
2. Remove the cardboard top and the
polystyrene packaging materials.
3. Remove the internal film.
4. Open the door and remove the
polystyrene piece from the door seal and
all the items from the drum.
8 ENGLISH

5. Carefully put the appliance down on its
rear side.
6. Put the front polystyrene packaging
element on the floor under the appliance.
Make sure not to damage the hoses.
7. Remove the polystyrene protection from
the bottom.
1
2
8. Pull up the appliance in vertical position.
9. Remove the power supply cable and the
drain hose from the hose holders.
It is possible to see water flowing
from the drain hose. This is due to
the testing with water of the appliance
in factory.
10. Remove the three bolts by using the
spanner supplied with the appliance.
11. Pull out the plastic spacers.
12. Put the plastic caps, that you find in the
user manual bag, in the holes.
ENGLISH 9

We recommend that you keep the
packaging and the transit bolts for any
movement of the appliance.
5.2 Positioning and levelling
1. Install the appliance on a flat hard floor.
Make sure that carpets do not stop the
air circulation below the appliance.
Make sure that the appliance does not
touch the wall or other units.
2. Loosen or tighten the feet to adjust the
level.
WARNING!
Do not put cardboard, wood or equivalent
materials below the appliance feet to
adjust the level.
x4
The appliance must be level and stable.
A correct adjustment of the appliance
level prevents the vibration, noise and
the movement of the appliance when in
operation.
When the appliance is installed on a
plinth or a tumble dryer is stacked on the
washing machine, use the accessories
described in chapter 'Accessories'. Read
carefully the instructions supplied with
the appliance and with the accessory.
5.3 Fixing plate kit
If you install the appliance on a plinth that is
not an accessory supplied by AEG, secure
the appliance with the fixing plates. This
spare part is available in web shop or from
authorised dealer.
Read carefully the instructions supplied with
the accessory.
5.4 The inlet hose
1. Connect the water inlet hose to the back
of the appliance.
2. Position it toward left or right depending
on the position of the water tap.
10 ENGLISH

20º20º
45º45º
Make sure that the inlet hose is not in
vertical position.
3. If necessary, loose the ring nut to set it in
the correct position.
4. Connect the water inlet hose to the cold
water tap with 3/4" thread.
WARNING!
The inlet water shall not exceed 25 °C.
CAUTION!
Make sure that there are no leaks from
the couplings.
Do not use an extension hose if the inlet
hose is too short. Contact the service
centre for information on inlet hose
replacement.
5.5 Water-stop device
The inlet hose has a water stop device. This
device prevents water leaks in the hose
because of its natural ageing.
The red sector in the window «A» shows this
fault.
A
If this occurs, close the water tap and contact
the authorized service centre to replace the
hose.
5.6 Water drainage
The drain hose should be positioned at a
height of not less than 60 cm and not more
than 100 cm from the floor.
You can extend the drain hose to
maximum 400 cm. Contact the
authorized service centre to buy the other
drain hose and the extension.
ENGLISH 11

It is possible to connect the drain hose in different ways:
min.600 mm
max.1000 mm
• Connect the drain hose to the spigot and
tighten it with a clamp.
• Position the hose directly to a built-in drain
pipe in the room wall and tighten it with a
clamp.
• Without the plastic hose guide, to a sink
spigot - put the drain hose in the spigot
and tighten it with a clamp.
• To a stand pipe with vent hole - insert the
drain hose directly into a drain pipe or
stand pipe.
• The drain hose can be bent into U shape
and put around the plastic guide. On the
edge of a sink - fasten the guide to the
water tap or to the wall.
Make sure that the drain hose makes a
loop to prevent particles going into the
appliance from the sink.
Make sure that the plastic guide cannot
move when the appliance drains and the
drain hose end is not immersed in the
water. There may be a return of dirty
water into the appliance. Buy accessories
from authorised supplier.
The end of the drain hose must always
be ventilated , i.e. the inner diameter of
the drain pipe (min. 38 mm - min. 1.5")
must be larger than the external diameter
of the drain hose.
5.7 Electrical connection
At the end of installation you can connect the
mains plug to the mains socket.
The rating plate and the 'Technical Data'
chapter indicate the necessary electrical
ratings. Make sure that they are compatible
with the mains power supply.
Check that your domestic electrical
installation can take the maximum load
required, also taking into account any other
appliances in use.
12 ENGLISH

Connect the appliance to an earthed
socket.
The power supply cable must be easily
accessible after installing the appliance.
For any electrical work required to install this
appliance, contact our Authorised Service
Centre.
The manufacturer does not accept any
responsibility for damage or injury through
failure to comply with the above safety
precaution.
6. CONTROL PANEL
6.1 Control panel description
32 4 5
12 11 9 8 7
10
16
The options are not selectable with all washing programmes. Check the compatibility
between options and washing programmes in the "Options compatibility with programmes"
paragraph in the "Programmes" chapter. An option can exclude another one, in this case
the appliance doesn't allow you to set the incompatible options together.
Make sure the screen and touch buttons are always clean and dry.
1On/Off push button
2Programme dial
3Display
4Finish In touch button
5Start/Pause touch button
6PODS® touch button
7Plus Steam touch button
8Extra Rinse touch button
9Time Save touch button
10 Stains/Prewash touch button and
permanent Child Lock option
11 Spin touch button
12 Temperature touch button
ENGLISH 13

6.2 Display
Door locked indicator.
Washing phase indicator. It flashes during pre-wash and wash phase.
Rinsing phase indicator. It flashes during rinse phase.
Spinning and draining phase indicator. It flashes during spin and drain phase.
Steam phase indicator.
Anti-crease phase indicator.
Eco programme indicator: it lights on when the selected programme and options have an
eco profile.
Add garments indicator: it lights on when the programme starts and the user can still
pause the appliance and add more laundry.
Extra Rinse indicator.
ProSense indicator.
Finish In indicator.
14 ENGLISH

The digital indicator can show:
• Programme duration (e. g. ).
The time shown when the programme is set could not correspond
to effective duration and change after ProSense phase.
• Maximum load.
• Finish in time (e. g. or ).
• Cycle end ( ).
• Warning code (e.g. ).
• Indication of total operating hours of the appliance. Refer to the 'Operating hours
counter' section in the 'Settings' paragraph for more details.
Maximum load indicator. The value is shown for three seconds after programme selection,
alternated with cycle duration.
Maximum laundry indicator. It blinks if the laundry amount exceeds the declared load.
This indicator reminds to run a cleaning cycle.
Child safety lock indicator.
The Temperature area:
Temperature indicator
Cold water indicator
The spin area:
Spin speed indicator
No Spin indicator. Spin phase is off.
Extra Silent indicator.
Rinse hold indicator.
Pre-wash indicator.
Stain indicator.
7. DIAL AND BUTTONS
7.1 On/Off
Pressing this button for a few seconds allows
to activate or deactivate the appliance. Two
different tunes sound while switching the
appliance on or off.
As the Stand-by function automatically
deactivates the appliance to decrease the
energy consumption in a few cases, you may
need to activate the appliance again.
For more details, refer to Stand-by paragraph
in Daily Use chapter.
7.2 Programme dial
By rotating the programme dial it is possible
to select the desired programme.
ENGLISH 15

7.3 Introduction
The options/functions are not selectable
with all washing programmes. Check the
compatibility between options/functions
and washing programmes in the
"Programme Chart". An option/function
can exclude another one, in this case the
appliance doesn't allow you to set the
incompatible options/functions together.
Make sure the screen and touch buttons
are always clean and dry.
7.4 Finish In
Set this option as last after programme
and other options selection, otherwise it
can be cancelled if you change some
setting.
This option allows choosing the time within
which a programme should terminate. The
programme end can be postponed by one 1
hour every button touch until 24 hours
maximum.
The display shows the normal programme
duration alternatively with the set programme
end time (expressed in hours 0h). The
minimum selectable time corresponds to
rounded up hour of the maximum duration of
a programme (e.g. if the cycle duration lasts
3:15 hours, the minimum selectable time will
be 4h).
After programme start, the door is locked and
the appliance starts the ProSense phase.
When load estimation ends, on the display
the icon of running phase blinks and the time
digit counts down in steps of one hour and in
steps of 1 minute during the last hour.
7.5 Start/Pause
Touch the Start/Pause button to start,
pause the appliance or interrupt a running
programme.
7.6 PODS®
Touch this button to activate or deactivate the
PODS® option .
When activated the relevant indicator is on.
Follow the Pods manufacturer's dosage and
storage recommendations.
Put maximum two tablets or single-dose
detergents in the PODS® compartment in the
detergent dispenser drawer.
The option remains active also for next cycles
until it is deactivated and if it is selectable
with the set programme.
7.7 Plus Steam
This option adds a steam phase followed by a
short anti-crease phase at the end of the
washing programme.
The steam phase reduces fabric creasing and
facilitates the fabric ironing.
The Plus Steam option achieves good results
with a small load because steam better
penetrates the laundry if there is more space.
For this reason, the programme maximum
load combined with this option is 2 kg
(approximately 8 - 10 shirts).
When setting the Plus Steam option, the
maximum load drops to 2 kg in the display
and programme time is adjusted accordingly.
The indicator blinks in the display during
steam phase.
This option can affect the programme
duration.
When the programme stops the display
shows a zero , the indicator is steady
on.
The anti-crease phase starts, the indicator
is blinking, and the Start/Pause led
remains lit. The drum performs smooth
movements for about 30 minutes to keep the
steam benefit.
To interrupt the anti-crease phase, you can:
• Press the On/Off button for a few
seconds to activate or the deactivate the
appliance.
• Turning the programme dial in another
position.
16 ENGLISH

When the anti-crease movements stop and
the door unlocks, the appliance proposes
again the previous set programme.
A small laundry load helps to reach better
results.
7.8 Extra Rinse
With this option you can add a few rinses to
the selected washing programmes and
optimise the fabric softener distribution and
improve the fabric softness.
It is suggested when you use the fabric
softener.
Useful for people allergic to detergents and in
areas where the water is soft.
This option increases the programme
duration.
The button indicator comes on.
7.9 Time Save
With this option you can decrease the
programme duration.
• If your laundry is normally or lightly soiled,
it may be advisable to shorten the washing
programme. Touch this button once to
decrease the duration.
• In case of smaller load, touch this button
twice to set an extra quick programme.
In this case, the temperature 95°C is not
selectable.
The led of the button is on and the display
shows the set programme duration.
This option can also be used to shorten
the steam programme duration.
7.10 Stains/Prewash
Press this button repeatedly to activate one of
the two options.
The relevant indicator goes on in the display.
•Stains
Select this option to add an anti-stain
phase to a programme in order to treat
heavily soiled or stained laundry with stain
remover.
Pour the stain remover into compartment
. The stain remover will be added in
the appropriate phase of the washing
programme.
This option is not available with a
temperature lower than 40 °C.
•Prewash
Use this option to add a pre-wash phase
at 30 °C before the washing phase.
This option is recommended for heavily
soiled laundry, especially if containing
sand, dust , mud and other solid particles.
The options can increase the programme
duration.
These two options cannot be set
together.
7.11 Spin
When you set a programme, the appliance
automatically selects the default spin speed.
Touch this button repeatedly to:
•Change the spin speed.
The display shows only the spin
speeds available for the set
programme.
•Activate the Rinse Hold option .
The water of the last rinse is not drained
out to prevent the fabrics from creasing.
The washing programme ends with water
in the drum and the final spin phase is not
performed.
The display shows the indicator .
The drum turns regularly to reduce
creasing.
The door stays locked. The drum turns
regularly to reduce creasing. You must
drain the water to unlock the door.
Touch Start/Pause button : the
appliance performs the spinning phase
and drains the water.
•Activate the Extra silent option.
ENGLISH 17

All spinning phases (intermediate spin and
final spin) are suppressed and the
programme ends with water in the drum.
This helps to reduce creasing.
As the programme is very quiet, it is
suitable for use at night time when
cheaper electricity tariffs are available. In
some programmes the rinses are
performed with more water.
The display shows the indicator .
The door stays locked. The drum turns
regularly to reduce creasing. You must
drain the water to unlock the door.
Touch the Start/Pause button: the
appliance performs only the draining
phase.
•No Spin .
Set this option to deactivate all spin
phases. The display shows the indicator
. The appliance performs the only
draining phase of the selected washing
programme. Set this option for very
delicate fabrics. The rinses phase uses
more water for some washing
programmes
The appliance empties the water out
automatically after approximately 18
hours.
7.12 Temperature
When you select a washing programme, the
appliance automatically proposes a default
temperature.
Touch this button repeatedly until the desired
temperature value appears on the display.
When the display shows the indicators
and , the appliance does not heat the
water.
8. SETTINGS
8.1 Introduction
When pressing a key combination, do
not tilt your fingers downwards . The
sensors of the underneath buttons are
sensitive and may interfere with Your
choice.
8.2 Acoustic signals
This appliance is provided with different
acoustic signals, that operate when:
• You activate the appliance (special short
tune).
• You deactivate the appliance (special
short tune).
• You touch the buttons (click sound).
• You make a wrong selection (3 short
sounds).
• The programme is completed (sequence
of sounds for about 2 minutes).
• The appliance has a malfunction
(sequence of short sounds for about 5
minutes).
• When a laundry overload is detected
during ProSense phase (a double sound
played one).
To activate/deactivate this option, hold down
the Extra Rinse button until a beep or a
double beep sounds.
If you deactivate this function, the
acoustic signals stops playing at the end
of the programme only.
8.3 Child Lock
With this option you can prevent children from
playing with the control panel.
To activate/deactivate this option, hold down
the Stains/Prewash button until comes
on/goes off on the display.
The appliance will default to this option after
you switch it off.
The Child Lock function may not be available
for a few seconds after switching the
appliance on.
18 ENGLISH

8.4 Operating Hours Counter
It is possible to visualise the total operating
time of the appliance in hours, starting from
the first switching on. This value will count
operating time of the cycles (does not include
pauses, delayed start time). To visualise this
value, proceed as follows:
1. Switch the appliance on by pressing the
On/Off button.
2. Press and hold the Extra Rinse and Plus
Steam buttons for some seconds.
3. After 3 seconds the total hours operated
by the appliance are shown in the display:
e.g. 1276 hours, the display shows the
text Hr for 2 seconds, 12 (thousands and
hundreds) for 2 seconds and 76 (tens and
units).
4. To exit this mode, press any button or
switch the appliance off by means of
theOn/Off button.
If the procedure does not work (due to
timeout or wrong keys combination),
switch the appliance off and repeat
sequence from the beginning.
8.5 Factory Defaults
This function allows to restore the factory
default options. To activate this option follow
steps below:
1. Switch the appliance on by pressing
On/Off button.
2. Press and hold the Stains/Prewash and
Time Save buttons for some seconds.
3. The display will show for about 5
seconds.
9. BEFORE FIRST USE
During installation or before first use you
may observe some water in the
appliance. This is a residual water left in
the appliance after a full functional test in
the factory to ensure the appliance is
delivered to customers in perfect working
order and is no cause for concern.
1. Make sure that all transit bolts have been
removed from the appliance.
2. Make sure that the electrical power is
available and the water tap is open.
3. Pour 2 litres of water into the detergent
compartment marked by .
This action activates the drain system.
4. Pour a small quantity of detergent into the
compartment marked by .
5. Set and start a programme for cotton at
the highest temperature without any
laundry in the drum.
This removes all possible dirt from the drum
and the tub.
10. PROGRAMMES
10.1 Programme Chart
The programmes are described in this chart following the order of the selector dial from
the top to the bottom.
ENGLISH 19

Washing programmes
Programme Programme description
MixLoad 69min
Cotton and mixed synthetic fabrics. Ideal to wash your daily load in a short
time, for a better clothes care and good cleaning already at 30°C.
Eco 40-60
Low energy cycle for cottons. Decreases temperature and extends time to
reach good washing results.
Cottons
White and coloured cotton fabrics. Ideal for normal and heavy soil.
Synthetics
Synthetic items or mixed fabric items. Normal soil.
Delicates
Delicate fabrics such as acrylics, viscose and mixed fabrics requiring gentler
washing. Normal soil.
Wool
Machine washable wool, hand washable wool and other fabrics with «hand
washing» care symbol1).
20min 3kg
Cotton and synthetic items lightly soiled or worn only once.
Steam
Cotton, synthetic and mixed items. Special steam cycle without washing that
can be used to prepare your dried laundry for ironing or refreshing garments
worn once. This programme reduces creases, odours and relaxes the fibres.
Do not use any detergent.
When the programme is completed, quickly remove the laundry from the
drum2). If necessary, remove stains by washing or using localized stain remov‐
al. Steam programmes do not perform any hygienic cycle. Do not set a Steam
programme with these types of items:
• Items that are not suitable for tumble drying.
• Items with label "Dry clean only".
20 ENGLISH
