AEI COMMUNICATIONS Analog BYOD Master User manual

Analog BYOD Master
BY-3000-X(A)
Quick Guide
V 1.5

1 Over view
The analog BYOD master is an analog telephone to Wi-Fi connection adaptor that provides voice
communication. Read this QIG carefully to learn how to operate this product and take advantage of its features.
Package Contents
When unpacking the phone, ensure all the following items are present and undamaged. If anything
appears to be missing or broken, contact your dealer for a replacement.
1. Base Unit
2. AC Adaptor
3. Line Cable
4. Quick Installation Guide (This document)
2 Product Description
The following contains important information to help you familiarize with the functions of the phone.
Back View
Name
Description
1
Setting Button
To rest device to factory default or change device connecting mode.
2
Line in
Connects to line cord.
3
Line out
Connects to existing analog phone.
4
DC Power jack
Connects to AC power adapter.
5.
Status LED
Off
Device is connected to a AP
Red
Device is NOT connected to a AP
Green
Device is in AP mode or under Wi-Fi Sync
Blinking Green
Device is under factory resetting
Setting
Button
Line in
Line out
Status LED

3. Installation
The following illustration shows how to install the phone on the wall.
1. Setup 1st BYOD Master:
A. Web setup: Please use Firefox as the browser.
(i) Boot the BYOD Master to AP mode. Press the setting button and power on the 1st BYOD Master,
till the status LED light up in green, the BYOD Master is in AP mode.
(ii) Use a PC to scan and connect to the BYOD Master by the SSID: ”ADB8000” and Password
“ADB8000123”
(iii) The PC will get its IP address as “192.168.4.x”. Open a browser (Firefox suggested) and enter
the web address “192.168.4.1” to access web interface of BYOD Master
(iv) Basic setup:
(a) Input the SSID/password of destination access point and the TFTP provision server IP
address.
(b) Remove and plug in the power jack to reboot the BYOD Master.
(c) After linking to destination access point and connecting to provision server, the BYOD
Master will retrieve the corresponding provision file.
B. 1st BYOD Master provisioning
(i) BYOD Master will download the provision file through specified TFTP server. Please prepare
and setup the TFTP server and provision file prior to provisioning.
(ii) The provision filename is defined as the “MAC address.cfg”. For example - “000e43d30001.cfg”.

2. Setup 2nd and other BYOD Masters
A. Boot the 1st BYOD Master to AP mode: Press the setting button and power on the 1st BYOD Master.
When status LED lights up in green, the 1st BYOD Master is in AP mode.
B. Power on the 2nd BYOD Master, and the status LED of the 2nd BYOD Master would lights up in red.
Press and hole the setting button (5 seconds) till the status LED lights up in green. The 2nd BYOD
Master will perform will perform the Wi-Fi sync. (If the destination access point SSID field was
specified, the 2nd BYOD Master will be factory reset.)
C. Wi-Fi Sync
(i) The 2nd BYOD Master will connect to 1st BYOD Master and synchronize the Wi-Fi
SSID/Password of destination access point and the provision server IP address with the 1st
BYOD Master. The 2nd BYOD Master will reboot after the synchronization is completed.
(ii) After rebooting, the 2nd BYOD Master will link to specified access point and download the
provision file from TFTP server.
3. Factory default reset
User can remove all data by resetting a BYOD Master to factory default.
Boot the BYOD Master. Press and hold the setting button (5 seconds) till the LED is in green to perform
factory reset.
4 Support
For technological support, please email to [e-mail].
