Aereco VBP+ R Instruction Manual

EN - Document not contractual. Aereco can realise technical modifications on its products without prior notice.
Installation and maintenance
VBP+ R
Hybrid assistance ventilation fan
TF5774_C
ENGLISH

2/22
TF5774_C
Aereco S.A.
CONTENTS
CONTENTS................................................................................................................................................................................ 2
INTRODUCTION ............................................................................................................................................................... 3
WARNINGS ................................................................................................................................................................. 3
GENERAL.................................................................................................................................................................... 4
MAIN FUNCTIONS......................................................................................................................................................... 4
RANGE OF USE............................................................................................................................................................ 4
PRODUCT DATA.............................................................................................................................................................. 5
COMPONENTS............................................................................................................................................................. 5
DIMENSIONS ............................................................................................................................................................... 5
TECHNICAL DATA......................................................................................................................................................... 6
INSTALLATION ................................................................................................................................................................ 7
FITTING ON STACK....................................................................................................................................................... 7
CASE OF AN INDIVIDUAL DUCT ...................................................................................................................................... 8
CASE OF DUCTS GROUPED UNDER A SINGLE FAN ........................................................................................................... 8
CASE OF DUCTS GROUPED UNDER 2FANS .................................................................................................................... 9
ANTICIPATION OF MAINTENANCE AND CHIMNEY SWEEPING CONSTRAINTS ...................................................................... 10
INSTALLING THE FAN.................................................................................................................................................. 10
CONNECTIONS .............................................................................................................................................................. 11
GENERAL CONNECTION DIAGRAM ............................................................................................................................... 11
POWER CONNECTION ................................................................................................................................................ 15
CONFIGURING IN ST OR MS MODE ............................................................................................................................. 16
CONNECTION IN ST MODE.......................................................................................................................................... 17
CONNECTION IN MS MODE......................................................................................................................................... 17
STARTING UP / OPERATION........................................................................................................................................ 18
ST MODE.................................................................................................................................................................. 18
MS MODE ................................................................................................................................................................. 19
5.3 INSTALLATION CHECK UP............................................................................................................................................ 19
MAINTENANCE .............................................................................................................................................................. 20
PRIOR WARNINGS...................................................................................................................................................... 20
MAINTENANCE AND CLEANING .................................................................................................................................... 20
TECHNICAL ASSISTANCE............................................................................................................................................ 21
WARRANTY.................................................................................................................................................................... 22
PROTECTION OF THE ENVIRONMENT ....................................................................................................................... 22

3/22
TF5774_C
Aereco S.A.
INTRODUCTION
WARNINGS
BEFORE INSTALLING THE APPLIANCE, PLEASE READ THESE INSTRUCTIONS CAREFULLY.
▪The manufacturer cannot be held liable for damage caused by installation in violation of good practice and/or contrary
to the directions given in the installation manual.
▪This manual describes how the fan must be installed and used.
▪The whole system must be installed by an approved professional and in compliance with the standards in force.
▪Do not use this appliance other than for its intended purpose.
▪After unpacking, make sure that it is not damaged. Any functional defect must be reported to your dealer.
▪Wearing suitable gloves while handling the product is strongly recommended (some of the metal parts have sharp
edges).
Reminders of elementary safety rules:
The use of an electrical appliance requires observance of the following elementary rules:
▪Do not touch the appliance, even if it is earthed, if your body is moist or wet (hands, feet, etc.);
▪This system is not designed to be installed or used by persons whose intellectual and/or mental faculties are
impaired, or who lack experience and knowledge (including children), unless they have been trained and are
supervised by a person responsible for their safety during installation. To eliminate any risk of an accident, keep
them away from the appliance;
▪The electrical installation and connection work must be done by a qualified technician, in accordance with the
manufacturer's recommendations and in a manner consistent with the characteristics of the product;
▪Before doing any work on the appliance, unplug it or otherwise disconnect it from its power supply and make
sure that the power cannot be restored accidentally while the work is being done;
▪Any change or replacement of a wire must be done by a qualified technician;
▪Young children must be kept far away from the appliance in order to ensure that they do not play with it.
The following instructions must also be observed:
▪The number of fans and their arrangement must be studied so as to ensure the proper operation of the system.
▪In general, barring special cases, all ducts of a given stack of housing units must be equipped with one or more
fans.

4/22
TF5774_C
Aereco S.A.
GENERAL
The VBP+ R is a very-low-pressure assistance fan delivering pressure compatible with the design of passive stack ventilation.
It is intended to improve and optimize the draught of passive stack ventilation ducts, and belongs to the category of hybrid
ventilation systems.
It is available in 2 pre-configured versions:
ST version (VB21184): Version pre-configured in ST mode, uncontrolled stand-alone, at constant speed adjustable on a built-
in potentiometer.
MS version (VB21183): Version pre-configured in MS mode, controlled by a management system:
▪Management of the fans in groups (up to 5 groups of 5 VBP+),
▪Individual setting/adjustment of the speed of each fan according to the site configuration (number of storeys,
ductwork...)
▪Speed control of each fan according to the temperature, (item sold by Aereco), wind or by using a clock (items
not sold by Aereco)
▪Indication of operation of the system and alarm reporting.
This version requires the use of two specific types of modules.
The versions (ST and MS) are the same product with different pre-configurations. It is therefore possible to change
from one version to the other. The possible change of configuration will imply a specific identification of the product
(the label states the baseline configuration).
MAIN FUNCTIONS
▪Hybrid operation: in passive stack or mechanical mode (low pressure losses when stopped)
▪Compatibility with demand-controlled ventilation
▪Low power consumption
▪Direct power supply at 230 V~, 50-60Hz
▪Adjustment of the speed according to the temperature, wind or by using a clock ("MS" mode)
▪Reporting of information for working or default (“MS” mode)
▪Possibility of grouping several ducts (in case of large aeraulic section)
RANGE OF USE
▪Ventilation of residential buildings, offices, and other general-purpose premises
▪Renovation or new construction
1
▪Individual or collective ventilation ducts, which may be made of concrete or metal.
Remarks:
▪Use of the fan on ducts serving connected gas-fired appliances is subject to specific approval by the competent
authorities.
▪The height of the buildings equipped varies according to the regulation flow rate requirements, which are specific
to each country.
▪In France, the MS version of this product is sold under the name “HELYS H800 R”by the Acthys Company.
1
In some countries, a specific permit may be required for use in new buildings

5/22
TF5774_C
Aereco S.A.
PRODUCT DATA
COMPONENTS
Note: the MS mode also requires two specific modules, a temperature probe and other
electrical components. These elements are described in the manual specific to this
mode.
DIMENSIONS
Dimensions in mm.
Fan

6/22
TF5774_C
Aereco S.A.
TECHNICAL DATA
Hybrid fan
VBP+ R
Version
ST
MS
Code
VB21184
VB21183
Aeraulics
Maximum flowrate (Ref)
m3/h
800
800
Maximum pressure @
Maximum flowrate (Ref)
Pa
27
27
Maximum pressure
Pa
39 Pa (@ 200 m³/h)
35 Pa (@ 200 m3/h)
Electric
Type of motor
EC (Electronic Commutation)
Power supply
230 V~, 50-60 Hz
Maximum power @ (Ref)
W
41
39
Maximum power (electrical
design)
W
42
Inrush protection (IP) of motor
IP54
Control/setting of speed
By built-in potentiometer
By MS management system
Degree of pollution
1
Characteristics
Weight
kg
17
Colour
Metallic grey/black
Material (envelop)
Galvanized steel / PE
Outside dimensions
mm
904 x ø610
Installation
Number of suction connections
available
1
Inlet connection
mm
ø354
Installation
On roof, head of duct –3 x ø8mm screws
Operation
Turbine drive
By motor coupler
Maximum speed of rotation
RPM
650
Accessories
Modules
-
"VBP+" module (ref. VB21118) and
"main" module (ref. VB21119)

7/22
TF5774_C
Aereco S.A.
INSTALLATION
FITTING ON STACK
The components necessary for adaptation to the roof ducts vary from one site to another.
In the case of an individual duct, a horizontal platform, located at the level of the emergence
of the duct, is necessary for attachment and for airtightness with the fan. A plane plate of the
right dimensions, attached to the top of the stack, is sufficient.
For the grouping of ducts, an adaptation plenum compliant with the recommendations
stated below is necessary to ensure proper aeraulic operation of the whole (minimized pressure
losses) and for attachment and tightness with the fan(s).
General recommendations for the placement of adaptation components:
▪The adaptation components must be made of a material strong enough to bear the weight of the fan(s).
▪The latter must be fastened to the stack securely and so as to assure a good seal with it; the plenum as a
whole must also be perfectly sealed.

8/22
TF5774_C
Aereco S.A.
CASE OF AN INDIVIDUAL DUCT
For a rectangular duct, the constraints are the following:
▪The top platform must be rectangular and measure at least 600 x 600 mm.
▪The opening cross-section of the duct must not exceed 245 x 245 mm if it is
desired to avoid reducing its cross-section.
▪The fan must be centred on the duct.
For a circular duct, the constraints are the following:
▪The top platform must be rectangular and measure at least 600 x 600 mm.
▪The opening cross-section of the duct must not exceed Ø350 mm if it is
desired to avoid reducing its cross-section.
▪The fan must be centred on the duct.
CASE OF DUCTS GROUPED UNDER A SINGLE FAN
For all grouped ducts configurations, an adaptation plenum is necessary. The plenum must:
▪provide a top platform measuring at least 600 x 600 mm.
▪provide a circular outlet Ø350 mm centred on the stack.
▪ensure a minimum height of air between the end of the stack and the outlet section Ø350 mm, that is to say 120
mm or 180 mm.
▪The fan must be centred on the outlet section Ø350 mm.
Example of a typical stack of the collective and individual type:

9/22
TF5774_C
Aereco S.A.
CASE OF DUCTS GROUPED UNDER 2 FANS
For all grouped duct configurations, an adaptation plenum is necessary.
▪The plenum, even if made in a single piece, must provide 2 distinct volumes, perfectly sealed from one another.
▪For each of the 2 units, the plenum must provide a circular outlet Ø350 mm centred as closely as possible on the
grouped duct.
▪Ensure a minimum height of air between the end of the stack and the outlet section Ø350 mm, that is to say 120 mm
or 180 mm.
▪The fans must be centred on the outlets Ø350 mm.
▪Each Ø350 mm outlet must be at least 1,000 mm from the other and at least 500 mm from the bulkhead separating
the volumes.
The plenum must provide 2 virtual platforms measuring at least 800 x 600 mm each (see example below).
Example of grouping of 8 individual ducts:
LIMITS
All the following cases must be avoided, because they would lead to non-compliance with European
EMC requirements or non-compliant aeraulic performance or deterioration of the equipment or of
the ventilation system.
•It is forbidden to install more than 2 fans per stack.
•The stacks (1 or 2 fans) must be at least 3 m apart (distance from the outer edge of the fan
to the outer edge of the nearest fan of the other stack)

10/22
TF5774_C
Aereco S.A.
ANTICIPATION OF MAINTENANCE AND CHIMNEY SWEEPING CONSTRAINTS
In order to allow access to the ducts located under the fan (inspection, chimney sweeping) it may sometimes be necessary to
incorporate one or more of the following features:
▪Soot door. This is generally located on the side of the stack or of the plenum.
▪Top plate tipping system (with hinges and catches).
▪Attachment that can be removed from and refitted on the top plate.
INSTALLING THE FAN
1) Ensure the proper adaptation of the fan on its stack (see section above).
The plate holding the outlet Ø350 mm can be designed with 3 crimped M8 nuts positioned as shown below to allow
the attachment of the fan.
2) Remove the fan from the pallet.
▪Use only the 2 handles located under the uprights to handle the fan.
▪Wear suitable gloves (some of the metal parts may be sharp)
▪Do not set the fan down on an obstacle that might damage the turbine.
▪Do not set the fan flat (horizontally)

11/22
TF5774_C
Aereco S.A.
3) Place a gasket as a seal between the top plate and the base of the fan.
4) Attach the fan to its specific adaptation using 3 x Ø 8 mm stainless steel screws + washers.
Note: The 2 handles can be removed by pinching them; this eliminates a
potential source of noise due to mechanical vibration.
CONNECTIONS
All electrical connection operations must be made by a qualified professional and comply with the standards in
force.
No cable used for the connection may pass though the interior of the stack or of the plenum.
GENERAL CONNECTION DIAGRAM
The following drawings show the electrical connections according to the chosen working mode (ST or MS mode). Two cases
can be identified:
▪Case A = 230 V~ electrical box is far from the fans (for example in the stairs)
▪Case B = 230 V~ electrical box is close to the fans in terrace

12/22
TF5774_C
Aereco S.A.
General isolating switch: The use of a switch - general isolating switch is recommended upward the entire individual proximity
switch. Check that the switch are well opened (no supply) during the installation.
There must be an individual protection for each fan, using a fuse or a circuit breaker (thermal protection, overload protection
or similar) according to standard EN 60335-1.
Advised fuse: 16A maximum
The supply cable must have 3 conductors, be between Ø6 mm and Ø12 mm, comply with the installation standards in force
(colour code in particular), have conductors with a cross section of at least 1.5 mm², and be able to withstand the environment
in which it is installed (in particular, be resistant to UV).
Switch - general isolating switch: A manual circuit breaker must be located on the 230V~ supply, upward the fan(s). It has
to be visible and accessible from each connected fan. It can be shared by several fans or individual depending on the
installation, to allow a quick and easy manual power cut in case of problem or accident.
ST mode:
▪Case A: 230 V~ electrical box is far from the fans (for example in the stairs)
▪Case B: 230 V~ electrical box is close to the fans in terrace

13/22
TF5774_C
Aereco S.A.
MS mode:
▪Case A: 230 V~ electrical box is far from the fans (for example in the stairs)
▪Case B: 230 V~ electrical box is close to the fans in terrace.

14/22
TF5774_C
Aereco S.A.
MS mode (recommendations)

15/22
TF5774_C
Aereco S.A.
POWER CONNECTION
The fans are supplied with 230V~ using a junction box to be installed at the base of the fan. The connection must be done
directly on an electrical box and in no case on a traditional socket.
It is recommanded to use a differential circuit breaker of 300 mA for a group of 10 fans.
The power connection cable of the fan can be identified by the annotation “230 V – 50 Hz” at its edge. Each wire is marked:
▪“N” = neutral
▪“PE” = earth protection
▪“L” = phase
Edge of the power connection cable
Make the connection in accordance with standard practice via an IP65 junction box installed at the base of the fan.
Recommendation:
Add a grounding strap and connect it with the M6 screw , on the crimped nut provided for this purpose located on the fan
casing
2
2
Reliée à la terre, cette tresse participe à la réduction des émissions CEM du produit et à limiter le danger dans le cas où le câble menant
au moteur serait coupé (dispositif d'évacuation secondaire).

16/22
TF5774_C
Aereco S.A.
CONFIGURING IN ST OR MS MODE
The versions (ST and MS) are the same basic fan with different pre-configurations. It is therefore possible to change
from one version to the other if necessary. The pre-configured mode is marked on the label on the outside of the product.
If you wish to change the management mode, proceed as follows:
Check that the power supply has in fact been cut off for at least 5 minutes before starting (to eliminate
the risk of electrical shocks from the discharging of certain components).
1) Remove the cover from the top of the fan.
2) Remove the cover from the protection box of the user interface

17/22
TF5774_C
Aereco S.A.
3) Place the jumper at bottom left according to the chosen management mode:
▪on pins 1 & 2 for the "MS" mode
▪on pins 2 & 3 for the “ST” mode
CONNECTION IN ST MODE
The ST mode doesn’t require any additional specific connection other than power connection.
CONNECTION IN MS MODE
Check that the power supply has in fact been cut off for at least 5 minutes before starting (to eliminate
the risk of electrical shocks from the discharging of certain components).
In this mode, each fan has its own control line. The operation consists in connecting the cable from the MS device to the control
cable of the management module (FAN module). For the complete installation of the MS mode, refer to the installation manual
of the MS management components.
The cable must be between Ø6 mm and Ø12 mm, comply with the installation standards in force,
have 4 conductors each having a cross section of at least 1.5 mm², be no longer than 25 m between
the fan and its management module, and be able to withstand the installation environment (in
particular, be resistant to UV). Depending on the EMC specific to the installation site, the cable must
be put in a metallic shield. These recommendations ensure the EMC and limit the tension lost. Above this
length, the good working of the appliance won’t be guaranteed.
The cable must not include a yellow & green conductor, the colour pair used only for earth wires.
The current in these cables does not exceed 20 mA.
The “MS” cable of the fan can be identified by the annotation “MS” at its edge. Each wire is marked with a number: 1,
2, 3, 4. Connect the cable and mark each wire (using colours for example) in order to identify which wire is connected:
1, 2, 3, 4.
MS cable edge
Make the connection in accordance with standard practice via an IP65 junction box installed at the base of the fan.

18/22
TF5774_C
Aereco S.A.
STARTING UP / OPERATION
▪Before commissioning, check that the fan is securely attached to its stack and that no
object has been left inside the duct or might interfere with the turbine.
▪Do not insert anything through the fan.
▪Check that a bonding jumper is in fact connected to the body.
ST MODE
1) Power up the appliance. It then starts.
The motor technology used may lead to starting errors. If this happens, the appliance fails to start and
begins vibrating slightly. Do not touch anything; the appliance will itself initiate a starting cycle, until it actually
starts.
2) To adjust the speed, unscrew the plug on the left.
Take all the usual precautions, because the
appliance is still working. Do not insert
anything through the unit.
Set the speed level, operating the
potentiometer.
Any curve between the minimum (a) and maximum (b) curves presented in the graph below can be obtained. The number of
possible adjustments between these curves is infinite. Intermediary curves are given as examples (not exhaustive).
3) Screw the plug back. Then put the top cover back on the fan.

19/22
TF5774_C
Aereco S.A.
MS MODE
1) Power up the appliance, which then waits for a setpoint command from the management system.
For the rest of the starting up process, please refer to the installation manual of the management modules.
Once the MS mode has been activated, the appliance should start.
The motor technology used may lead to starting errors. If this happens, the appliance fails to start and
begins vibrating slightly. Do not touch anything; the appliance will itself initiate a starting cycle, until it
actually starts.
5.3 INSTALLATION CHECK UP
In order to ensure the proper fonctionning of the installation, do not forget to check the following key points :
Actions
Comments
Check that a 300mA is used for the main differential circuit breaker
□
Measure the power supply (230V) in the derivation box for each
fan
□
Check that all RJ12 cables between modules are pluged according
to the installation and maintenance manual.
□
Check the fixation from devices to plenum (3 Ø8mm screws +
washers)
□
Check the grounding strap connection on the fan body insert
□
Check that there are no foreign bodies inside the product body that
can make noise or prevent the turbine from rotating
□
Check one by one that all devices work properly (turbine rotation)
one it is plugged to 230V (see instructions)
□
Wait 15 minutes (checking time) to ensure there are no error
messages on the modules
□
Check that the numbered modules are connected to the equivalent
fans (Module 1 to fan 1, etc.)
□
Check the group configuration (see module manual)
□

20/22
TF5774_C
Aereco S.A.
MAINTENANCE
PRIOR WARNINGS
Before doing any work on the appliance:
Cut off the power.
Wait at least 5 min after cutting off the power supply before intervention on the appliance.
The appliance may still be charged even though the 230 V~ power supply circuit has been cut off, leading
to a risk of electrical shocks.
It is recommended to use some gloves to move the product (some metallic parts of the product can
be sharp).
The appliance may be stopped but restarts automatically (for example if there is a momentary interruption
in the control circuit of the MS version), with a risk of injury.
➔Never insert anything through the fan, and in particular the suction stream in which the turbine
is located.
➔Never handle an appliance or remove it from its stack when it is connected.
➔Cut off the power supply and make sure that it cannot be reconnected.
➔Wait for the turbine to come to a full stop.
MAINTENANCE AND CLEANING
We recommend carrying out a visual observation of the proper operation of each fan once a year and if necessary
cleaning its blades.
1) Cut the plastic clips that secure the access hatch to the
fixed part of the fence.
DO NOT CUT the metallic staple linking the access hatch to
the support.
2) Open to clean the inside of the fan.
3) Close the access hatch and put some new plastic clips.
