Aereco VBP+C4 Instruction Manual

EN - Document not contractual. Aereco can realise technical modifications on its products without prior notice.
TF6751_D
Installation and maintenance
VBP+C4
Hybrid assistance ventilation fan
TF6751_D
ENGLISH

2/28
TF6751_D
Aereco S.A.
1. Introduction ....................................................................................................................................3
1.1. Warnings.................................................................................................................................. 3
1.2. General.................................................................................................................................... 4
1.3. Main functions.......................................................................................................................... 4
1.4. Range of use ........................................................................................................................... 4
2. Product data...................................................................................................................................5
2.1. Components ............................................................................................................................ 5
2.2. Dimensions.............................................................................................................................. 6
2.3. Technical data............................................................................................................................... 7
3. Installation......................................................................................................................................8
3.1. Fitting on stack......................................................................................................................... 8
3.2. Fixing of the fan control unit .................................................................................................... 9
3.3. Case of an individual duct” .................................................................................................... 10
3.4. Case of ducts grouped under a single fan............................................................................. 10
3.5. Case of ducts grouped under 2 fans ..................................................................................... 11
3.6. Limits ..................................................................................................................................... 12
Anticipation of maintenance and chimney sweeping constraints ...................................................... 12
3.7. Installing the fan .................................................................................................................... 13
4. Connections .................................................................................................................................19
4.1. General connection diagram ................................................................................................. 19
4.2. Power connection.................................................................................................................. 21
5. Starting up/operation....................................................................................................................23
5.1. ST mode................................................................................................................................ 23
5.2. MS mode ............................................................................................................................... 24
5.3. Installation check up.............................................................................................................. 25
6. MAINTENANCE...........................................................................................................................26
6.1. Prior warnings........................................................................................................................ 26
6.2. Maintenance and cleaning..................................................................................................... 26
7. Technical Assistance ...................................................................................................................27
8. Warranty ......................................................................................................................................28
9. Protection of the environment ......................................................................................................28

3/28
TF6751_D
Aereco S.A.
1. INTRODUCTION
1.1. Warnings
BEFORE INSTALLING THE APPLIANCE, PLEASE READ THESE INSTRUCTIONS CAREFULLY.
▪The manufacturer cannot be held liable for damage caused by installation in violation of good practice
and/or contrary to the directions given in the installation manual.
▪This manual describes how the fan must be installed and used.
▪The whole system must be installed by an approved professional and in compliance with the standards
in force.
▪Do not use this appliance other than for its intended purpose.
▪After unpacking, make sure that it is not damaged. Any functional defect must be reported to your
dealer.
▪Wearing suitable gloves while handling the product is strongly recommended (some of the metal parts
have sharp edges).
Reminders of elementary safety rules:
The use of an electrical appliance requires observance of the following elementary rules:
▪Do not touch the appliance, even if it is earthed, if your body is moist or wet (hands, feet, etc.);
▪This system is not designed to be installed or used by persons whose intellectual and/or mental
faculties are impaired, or who lack experience and knowledge (including children), unless they have been
trained and are supervised by a person responsible for their safety during installation. To eliminate any risk
of an accident, keep them away from the appliance;
▪The electrical installation and connection work must be done by a qualified technician, in accordance
with the manufacturer's recommendations and in a manner consistent with the characteristics of the
product;
▪Before doing any work on the appliance, unplug it or otherwise disconnect it from its power supply and
make sure that the power cannot be restored accidentally while the work is being done;
▪Any change or replacement of a wire must be done by a qualified technician;
▪Young children must be kept far away from the appliance in order to ensure that they do not play with
it.
The following instructions must also be observed:
▪The number of fans and their arrangement must be studied so as to ensure the proper operation of the
system.
▪In general, barring special cases, all ducts of a given stack of housing units must be equipped with one
or more fans.

4/28
TF6751_D
Aereco S.A.
1.2. General
The VBP+C4 is a very-low-pressure assistance fan delivering pressure compatible with the design of passive stack
ventilation. It is intended to improve and optimize the draught of passive stack ventilation ducts and belongs to the category
of hybrid ventilation systems.
The VBP+C4 is available in 2 pre-configured versions:
ST version: Version pre-configured in ST mode, uncontrolled stand-alone, at constant speed adjustable on a built-in
potentiometer.
MS version: Version pre-configured in MS mode, controlled by a management system:
▪Management of the fans in groups (up to 5 groups of 5 VBP+),
▪Individual setting/adjustment of the speed of each fan according to the site configuration (number of
storeys, ductwork...)
▪Speed control of each fan according to the temperature, (item sold by Aereco), wind or by using a
clock (items not sold by Aereco)
▪Indication of operation of the system and alarm reporting.
This version requires the use of two specific types of modules.
The versions (ST and MS) are the same product with different pre-configurations. It is therefore easy to change from
one version to the other.
1.3. Main functions
▪Hybrid operation: in passive stack or mechanical mode (low pressure losses when stopped)
▪Compatibility with demand controlled ventilation
▪Low power consumption
▪Fire resistance: 400°C for 30 min (C4 classification in France)
▪Fire resistance: 400°C for 120 min (F400)
▪Direct power supply at 230 VAC, 50-60Hz
▪Adjustment of the speed according to the temperature, wind or by using a clock ("MS" mode)
▪Reporting of information for alarm (“MS” mode)
▪Possibility of grouping several ducts (aeraulic cross-section 984 cm²)
1.4. Range of use
▪Ventilation of residential buildings, offices, and other general-purpose premises
▪Renovation or new construction
1
▪Individual or collective ventilation ducts, which may be made of concrete or metal.
Remarks:
▪Use of the fan on ducts serving connected gas-fired appliances is subject to specific approval by the
competent authorities.
▪The height of the buildings equipped varies according to the regulation flow rate requirements, which
are specific to each country.
▪In France, this fan is marketed under a CSTB technical approval specifying its dimensioning and
installation conditions. The product is sold there under the HELYS H800 C4 name by the Acthys company
and is pre-configured in MS mode.
1
In some countries, a specific permit may be required for use in new buildings

5/28
TF6751_D
Aereco S.A.
2. PRODUCT DATA
2.1. Components
1: Fan
2: Control unit
2
3: Metal protection for the control unit
Note: the MS mode also requires two specific modules, a temperature probe and other electrical components. These
elements are described in the manual specific to this mode
2
Delivered connected to the fan
1
3
2

6/28
TF6751_D
Aereco S.A.
2.2. Dimensions
Dimensions in mm.
VBP+ C4 fan control unit and its metal protection:

7/28
TF6751_D
Aereco S.A.
2.3. Technical data
Hybrid fan
VBP+ C4
Mode
ST
MS
Code
VB21116
VB21124
Aeraulic
Maximum airflow
m3/h
800
Maximum pressure @ max. airflow (Ref)
Pa
23
Maximum pressure
Pa
35 (@ 200 m3/h)
Electric
Type of motor
EC (Electronic Commutation)
Power supply
230 V~, 50-60 Hz
Maximum power @Ref
W
41
Maximum power
W
46
Inrush protection (IP) of motor / control
unit
IP54 / IP65
Control/setting of speed
By built-in potentiometer
By MS management system
Degree of pollution
1
Characteristics
Weight
kg
20
Colour
Metallic grey/black
Material (jacket)
Galvanized steel/PE
Outside dimensions
mm
904 x ø610
Installation
Number of suction connections available
1
Output/discharge
mm
ø354
Installation
On roof, head of duct - 3 ø8mm screws
Operation
Turbine drive
By motor coupler
Maximum speed of rotation
RPM
650
Accessories
Modules
-
Module “FAN” (code VB21118) et
module “MAIN” (code VB21119)

8/28
TF6751_D
Aereco S.A.
3. INSTALLATION
3.1. Fitting on stack
The components necessary for adaptation to the emergences of the ducts vary from one site to another.
In the case of an individual duct, a horizontal platform, located at the level of the emergence of the duct, is necessary for
attachment and for airtightness with the fan. A plane plate of the right dimensions, attached to the top of the stack, is
sufficient.
For the grouping of ducts, an adaptation plenum compliant with the recommendations stated below is necessary to
ensure proper aeraulic operation of the whole (loss of head minimized) and for attachment and tightness with the fan(s).
General recommendations for the placement of adaptation components:
▪The adaptation components must be made of a material strong enough to bear the weight of
the fan(s).
▪The latter must be fastened to the stack securely and so as to assure a good seal with it; the
plenum as a whole must also be perfectly sealed.

9/28
TF6751_D
Aereco S.A.
3.2. Fixing of the fan control unit
It is strictly forbidden to drill the fan control unit.
The cable which links the fan to its control unit must be handled with care. It can not be modified of
lengthened
It is possible to fix the metal protection of the control unit either on a vertical face or on a horizontal face. In both cases the
control unit must be vertical with its cable glands facing downwards, to ensure an effective protection against the penetration
of water.
When installing the control unit on a horizontal face, it is necessary to maintain a distance between 50 mm and 550
mm between the fan housing and the metal protection of the control unit.
To make the VBP+ F400 compliant, every electrical cable linked to the control unit must be 400 °C resistant.

10/28
TF6751_D
Aereco S.A.
3.3. Case of an individual duct”
For a rectangular duct, the constraints are the following:
▪The top platform must be rectangular and measure at
least 600 x 600 mm.
▪The opening cross-section of the duct must not exceed
245 x 245 mm if it is desired to avoid reducing its cross-
section.
▪The fan must be centered on the duct.
For a circular duct, the constraints are the following:
▪The top platform must be rectangular and measure at
least 600 x 600 mm.
▪The opening cross-section of the duct must not exceed
Ø350 mm if it is desired to avoid reducing its cross-section.
▪The fan must be centered on the duct.
3.4. Case of ducts grouped under a single fan
For all grouped duct configurations, an adaptation plenum is necessary. The plenum must:
▪provide a top platform measuring at least 600 x 600 mm.
▪provide a circular outlet Ø350 mm centered on the stack
▪ensure a height of air of at least 180mm between the end of the stack and the outlet section Ø350 mm.
▪The fan must be centered on the outlet section Ø350 mm.
Example of a typical stack of the collective and individual type:

11/28
TF6751_D
Aereco S.A.
3.5. Case of ducts grouped under 2 fans
For all grouped duct configurations, an adaptation plenum is necessary.
▪The plenum, even if made in a single piece, must provide 2 distinct volumes, perfectly sealed from one
another.
▪For each of the 2 units, the plenum must provide a circular outlet Ø350 mm centered as closely as
possible on the grouped duct.
▪The plenum must ensure a height of air of at least 180 mm between the end of the stack and the
outlet sections Ø350 mm.
▪The fans must be centered on the outlets Ø350 mm.
▪Each 350 mm outlet must be at least 1,000 mm from the other and at least 500 mm from the bulkhead
separating the volumes.
The plenum must provide 2 virtual platforms measuring at least 800 x 600 mm each (see example below).
Example of grouping of 8 individual ducts:

12/28
TF6751_D
Aereco S.A.
3.6. Limits
All the following cases must be avoided, because they would lead to non-compliance with European
EMC requirements or non-compliant aeraulic performance or deterioration of the equipment or of
the ventilation system.
▪It is forbidden to install more than 2 fans per stack.
▪The stacks (1 or 2 fans) must be at least 3 m apart (distance from the outer edge of the fan to
the outer edge of the nearest fan of the other stack)
Anticipation of maintenance and chimney sweeping constraints
To allow access to the ducts located under the fan (inspection, chimney sweeping) it may sometimes be necessary to
incorporate one or more of the following features:
▪Soot door. This is generally located on the side of the stack or of the plenum.
▪Top plate tipping system (with hinges and catches).
▪Attachment that can be removed from and refitted on the top plate.

13/28
TF6751_D
Aereco S.A.
3.7. Installing the fan
1) Ensure the proper adaptation of the fan on its stack (see section above).
The plate holding the outlet Ø350 mm can be designed with 3 crimped M8 nuts positioned as shown below
to allow the attachment of the fan.
2) Remove the fan from the pallet.
▪Use only the 2 handles located under the uprights to handle the fan.
▪Wear suitable gloves (some of the metal parts may be sharp)
▪Do not set the fan down on an obstacle that might damage the turbine.
▪Do not lay the fan flat (horizontally)

14/28
TF6751_D
Aereco S.A.
3) Loosen the 4 screws and take off the cap
4) Check the couplig alignment between motor axis and turbine axis. The coupling piece must fall down freely between both
axes without any friction until the thread turbine axis.

15/28
TF6751_D
Aereco S.A.
5) In case it does not fall down freely, loosen the 3 nuts (see below) and realign the motor plate so that the couplig falls down
freely from the motor axis to the turbine axis.
6) Gradually, tighten the 3 nuts with a torque wrench to 7.5 Nm. Tightening must be done one by one per occurrence.

16/28
TF6751_D
Aereco S.A.
7) Once the 3 nuts are tightened, check that the couplig is still able to fall down freely from the motor axis to the turbine axis
without any friction.
8) Tighten the coupling screw on the turbine shaft using the torque wrench to 4.6 Nm

17/28
TF6751_D
Aereco S.A.
9) Tighten the couplig screw on the motor shaft using the torque wrench to 4.6 Nm
Warning : The flat part of the axis motor must be placed at the opposite side from the tightening coupling screw
10) Place a gasket* as a seal between the top plate and the base of the fan.
*provided on some versions

18/28
TF6751_D
Aereco S.A.
11) Attach the fan to its specific adaptation using 3 x Ø 8 mm stainless steel screws + washers.
Note: The 2 handles can be removed by pinching them; this eliminates a potential source of noise due to mechanical
vibration.
12) Position the control unit at least 50 mm from the fan. Choose the side facing North to reduce the influence of direct
sunlight. It must be positioned so that the cable connecting the fan to it is not loose. If necessary, fit cable clamps.
- Loosen the M6 screw that are maintaining the support
plate to the fan’s body. Remove the magnet located on
the protective metal cover back.
▪- Fix the base of the metal protection using the screws
supplied either vertically or horizontally.
▪- Remove the magnet located behind the box metal
protective cover
▪- Loosen the 4 screws that are maitaining the protective
driver box to the plate support.
- Set the plate on the plenum
- Put back the support box horizontally or vertically by
tightening the 4 screws

19/28
TF6751_D
Aereco S.A.
4. CONNECTIONS
All electrical connection operations must be made by a qualified professional and comply with the
standards in force.
No cable used for the connection may pass though the interior of the stack or of the plenum.
4.1. General connection diagram
The following diagrams show the wiring to be performed according to the selected operating version (ST or MS). Two sub-
cases can be dissociated:
▪Case A = 230 VAC power supply box away from the fans (example in the stairwell).
▪Case B = 230 VAC power supply box located near the fans on the terrace.
Mode ST:
▪Case A = 230 VAC power supply box away from the fans (example in the stairwell).
▪Case B = 230 VAC power supply box located near the fans on the terrace.

20/28
TF6751_D
Aereco S.A.
Mode MS:
▪Case A = 230 VAC power supply box away from the fans (example in the stairwell).
▪Case B = 230 VAC power supply box located near the fans on the terrace.
