Aerix DUET User manual

User Manual

Getting Started
Quick Start
Remote Control
CD Music
Bluetooth Music
Wi-Fi Music
FM radio
Menu Setting
Technical Specifications
Important Safety Instruction
p.02
p.04
p.07
p.09
p.10
p.11
p.12
p.13
p.14
p.16
Content
p.01

Getting Started
The box should contain the following System components:
1
2
3
4
5
1. Duet
2. User Manual
3. AC Power cord
4. FM Antenna
5. Remote control
6. AC Adaptor
source
sleep
menu
1 2 3
6
p.02

Getting Started Step 1.
Unpack all components from the shipping box. Please save
the original packaging material in case you ever need to
return the System since the Limited Warranty does not cover
shipping damages.
Step 2:
Remove the insulating plastic from the bottom of remote
control
Step 3:
Insert the DC Power cable of the external power supply into
the DC Power Plug on the Back Panel (see picture below).
Then connect the AC Power cable of the external power supply
to an AC outlet.
p.03

Quick Start Front
1. Dot LED Display：Showing system info
2. Slot CD Loader：Auto play CD Music
3. IR receiver
4. Transducer
5. Subwoofer
1
2
3
4
5
4
p.04

Quick Start
p.05

Quick Start Back
1&2. Wi-Fi Antenna
3. Bluetooth Antenna
4. FM ANT：FM Antenna （Plug in if necessary）
5. DC in：DC Power Plug （For 24V/3A DC Adopter）
6. USB：Factory firmware update
WARNING:
1.Insert the DC Power cable of the
external power supply into the DC
Power Plug on the Back Panel .
2.Then connect the AC Power cable
of the external power supply to an AC
outlet.
3.Do not connect AC outlet first！
4.Do not block the openings at all
times to prevent overheating！
123
4
5
6
FM ANT
DC IN
24V 3A
Designed & engineered in France
p.06

Remote Control ：Power on or Standby
Sleep：press once to switch 5/10/15/20/30 minute；
Countdown into Standby mode
：Mute
：Bluetooth Pairing or Disconnection（Long press）
：Volume increase / Page up at menu setting
：Dimmer on or off
：Skip back / Fast reverse（Long press）
：Play/Pause CD or BT Music / Enter command
：Skip forward or Fast forward（Long press）
：Repeat single song / repeat Albums / repeat off
：Volume decrease / Page down at menu setting
：Stop CD or BT Music / Twice to Eject CD
：Return command
Menu：Setting Time/Alarm time/Alarm on or off/Sound mode
Source：Select FM、CD、BT、Wi-Fi Music input
Number 1~3：Select or Store FM Station
source
sleep
menu
1 2 3
p.07

How to change battery in the remote control?
1. Open the battery lid that is on the backside of the remote
control.
2. Remove the existing battery and replace it with a new
lithium cell, 3 V battery (CR2025 type).
3. Inside the new battery compartment there are symbols
showing in which direction the batteries should be placed.
Remote Control
CR2025
+
p.08

CD Music 1.Insert the CD into the slot – make sure the printed side of
the CD is UP
2.The LED Display under the grille should display “CD” and
the CD should start playing automatically.
3.You can navigate the CD player by using the Stop,
Play/Pause, Skip/Fast Forward and Skip/Fast Reverse keys on
your remote control or product control keys.
4.Repeat:
Press repeat key once to repeat single song or repeat Albums
or to off repeat function.
5.Remove CD:
To remove the CD, press the Eject key, Screen will show
“EJECTED”
6.Do not play 8cm CD！
p.09

1.Press Duet source key to Bluetooth mode（display show
“PAIRING”）
2.Turn on your smart device(source) for Bluetooth function.
Select “Aerix Duet” from the pairing list.
3.As soon as they pair, they will automatically connect and
your Duet will display ” PAIRED”.
4.To enter pairing mode again, long press Bluetooth key form
Remote control.
5.For some devices you may need to input “0000” as the
pairing password.
6.Display may show song’s info when you stream Web
stations.
7.When system re-boot, it will auto connecting your mobile
device.
Bluetooth Music
To get the best sound quality when
streaming audio to your Duet over
Bluetooth, we highly recommend using
a device that supports aptX or AAC.
p.10

Wi-Fi Music 1.Download Play-Fi APP first（Android: Play store / iOS : App
Store/Windows: https://play-fi.com/）
2.Go to Duet Menu Wi-Fi setting page，select WPS or AP
mode.
3.Setting your mobile Wi-Fi input.
4.Searching to connect Play-Fi Device as “PlayFiDevicexxxxxx”
5.Go to Play-Fi APP.
6.Select Wi-Fi AP ID.
7.Setup AP to Duet （Display Searching CONNECTING TO
Wi-Fi CONNECTED；means connection success）
8.System may ask you device update (Do not disconnect while
system updating, or system will damage !)
9.Now, you can play Wi-Fi music by Play-Fi APP！（while play
Wi-Fi music display will show “STREAMING”）
10.If system reboot, change source to Wi-Fi.It will display
“CONNECTING TO Wi-Fi”.After a few seconds it will change to
” CONNECTED”.
Short cut:
1. Wi-Fi Music:press Source button key
for 3 seconds.
2. WPS Mode:press Source button key
for 3~8 seconds.
3. AP Mode:press Source button key
over 8 seconds.
p.11

1.Connect the External antenna to the External FM antenna
connector on the Back Panel.
2.Press the source key on the remote control or on the product,
select source to FM
3.The LED Display under the grille should display an FM
frequency, e.g. “XXX.X”.
4.To scan through frequencies, hold right or left key for a few
seconds and the FM radio searches for the next station
automatically. When a station has been found, the automatic
search stops. To keep scanning, repeat the action.
5.You can long press 1~3 key to memory FM stations on your
remote.
6.Select one of the 3 preset keys on the remote control, and
hold it down until ‘store’ appears on the LED display in the
Grille of product. The station has now been stored and can be
retrieved using the selected preset key.
7.Select an FM station with number 1~3 keys from remote.
FM Radio
p.12

TIME:
-Setting Time
-Enter to adjust Hour/Minute
-Use / key to increase or reduce
-Use / key to switch Hour/Minute
ALARM:
-Setting Alarm time as setting time step
-On/Off（Setting Alarm function on or off by up or down key）
-Source（FM or CD）
WI-FI:
-Setting WPS or AP Mode（by up or down key.Default is AP）
-Clear Data
SOUND:
Setting sound mode to 1.Natural 2.Hyper 3.Relax mode
Menu setting
p.13

Acoustic:
2 unit of 1.5" Transducer
5.25" Heavy magnetic rounded Subwoofer
Frequance : 45 Hz~20,000 Hz
Power:
Transducer: 50W x2
Subwoofer : 100W x1, THD <0.5%
Control Keys:
Vol.-/Vol.+/Play/Back/Next/Eject/Source/Power
Input:
DC：24V/3A, Wi-Fi Antenna x2, Bluetooth Antenna x1
FM Antenna x1, Slot-CD
Output:
USB Type A for Device firmware update / USB to LAN
Dimensions:
W605 x D390.5 x H424.5 mm (with color box)
Specifications
p.14

D.A.D (Dynamic Air Drive)
Powerful vertical-firing drivers compress airwaves downward towards
our acoustically designed passage at the bottom of each unit,
delivering sound evenly and consistently, every time, everywhere.
V.I.S (Virtual Intelli Sound)
Our advanced DSP chips are optimized with exclusive VIS technology,
the latest in human auditory psychoacoustics, and include three
built-in modes: Relax, Standard (Aerix mode) or Party. Each setting is
precisely engineered to deliver nothing less than the most premium
listening experience.
E.S.C (Encompassing Sound Circle )
Acoustics are at the heart of what we do, and we mean it quite literally
too, when we installed a 360° horn at the heart of each unit. The
architectural ideal Bell’s curve creates a halo effect surrounding the
unit, extending sound to you so no matter where you stand, you are
standing in optimum sound quality space.
Aerix
Technology
p.15

1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6 .Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9. Only use attachments/accessories specified by the manufacturer.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Unplug this apparatus during lightning storms or when
unused for long periods of time.
Important Safety
Instruction
p.16

Important Safety
Instruction
12. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or plug
is dama- ged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally,
or has been dropped.
13. This appliance shall not be exposed to dripping or splashing water and that
no object filled with liquids such as vases shall be placed on apparatus.
14. Correct Disposal of this product. This marking indicates that this product
should not be disposed with other household wastes throughout the EU. To
prevent possible harm to the environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was purchased.
They can take this product for environmental safe recycling.
15. Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type.
16. Do not ingest the battery, Chemical Burn Hazard.
Caution: Use of controls or
adjustments or performance of
procedures other than herein may
result in hazardous radiation exposure
or other unsafe operation.
p.17

17. (The remote control supplied with) This product contains a coin/button cell
battery. If the coin/button cell battery is swallowed, it can cause severe internal
burns in just 2 hours and can lead to death.
18. Keep new and used batteries away from children.
19. If the battery compartment does not close securely, stop using the product
and keep it away from children.
20. If you think batteries might have been swallowed or placed inside any part of
the body, seek immediate medical attention.
21. The battery (battery or batteries or battery pack) shall not be exposed to
excessive heat such as sunshine, fire or the like.
22. Do not handle leaking or damaged Lithium batteries.
23. Risk of leakage. Only use the specified type of Batteries. Never mix new and
used batteries. Observe correct polarity. Remove batteries from products that
are not in use for extended periods of time. Store batteries in a dry place.
24. Do not recharge non-rechargeable batteries.
25. Avoid exposure to extreme heat or cold.
This product contains a lithium coin
cell battery. Abused this can result in:
- Smoke or gas hazard
- Heat hazard
- Fire hazard
- Explosion hazard
Important Safety
Instruction
p.18

Compact Disk Drive:
The compact disk (CD) drive contains a laser. The laser radiates visible and
invisible laser radiation. Do not open optical housing. Avoid direct exposure to
the beam. The compact disc player should not be adjusted or repaired by anyone
except properly qualified service personnel.
Class 1 laser product: This CD player is classified as a CLASS 1 LASER
PRODUCT according to EN 60825- 1:1994+A1+A2, IEC 60825-1:1993+A1+A2. The
CLASS 1 LASER PRODUCT label is located on the Back Panel of the product.
This product complieswith 21 CFR Part 1040.10.
Technical details about the incorporated laser diode: Wavelength: 790 nm ±
15nm. Max accessible radiant power (during service): 0.492 mW.
Important Safety
Instruction
p.19
