Lightspeed flexcat User manual

DAILY OPERATION INSTRUCTIONS
2. Remove the microphone from the charger and put on.
• The microphone will default to the Mute position, the
teacher status will turn to red.
• Place the microphone around your neck and insert the
earbud.
• Press the power/mute button, the teacher status will
turn blue, indicating the microphone is active.
1. Remove the pods from the charger and place them on the group tables.
• The speakers will stay powered on while charging when the switch is left in the on position.
• Note the location of the pod numbers.
VolVol
Mute
6
5
1
3
2
4
UP DN
Power /
Mute
3. Remove the remote and begin instruction. Use the
remote to:
• Address the whole class
• Instruct small groups
• Redirect small groups
• Monitor (listen only) small groups
• Activate student group sharing
• Adjust earbud volume

DAILY OPERATION
LIGHTSPEED TECHNOLOGIES
WWW.LIGHTSPEED-TEK.COM / TOLL FREE: 800.732.8999 / PHONE: [phone]
QS0477US01-2
Function Command Description
Whole Class
Instruction
Press center
button
Activates Redcat Access speaker to distribute teachers voice
to the entire class.
Pod Selection Press #1-6 Connect to each individual student group pod. The pod #
button will light and a tone will sound in the earbud when
connected (1-2 seconds).
Small Group
Monitoring
Press MUTE Move from pod to pod to monitor (listen only) student
groups. The MUTE button will light green and the pod
button will light red to indicate the teacher’s microphone is
muted. To unmute, simply press the MUTE button again.
Student Group
Sharing
Press #1-6, then
center button
(rapid press)
Allows one student group to address the whole class. Both
the center and pod # buttons will light and a tone will sound
in the earbud when connected (1-2 seconds).
Disconnect Press activated
pod # or center
button again
Disconnects the transmission and turns any audio off. The
pod # button or center button will go dark.
Teacher earbud
volume
Press Vol UP/
DOWN arrows.
Turns the volume to the teacher's earbud up or down. There
is an audible tone in the ear when pressing.
Using the remote:
1. Pod call button:
• Each of the pods are equipped with a call button students can press when they need
assistance.
• When the button is pressed, a tone sounds in the teacher earbud.
• The corresponding pod # will blink on the remote, alerting the teacher which group needs
assistance.
• The light will continue to blink until the teacher selects that pod.
• To clear multiple blinking lights: press center button twice (connect and disconnect from
whole class mode).
2. Return the components to the base station for nightly recharging:
• For convenience, we recommend leaving the pods powered on. They are designed to
charge normally in the ON position.
• Place all components in their respective charging slots:
– Pods: insert with charging contacts facing down.
– Flexmike(s): use corresponding mic 1 or 2 center charging slot.
– Remote(s): use corresponding mic 1 or 2 outside charging slot.
• Charging lights will turn on - red = charging; green = fully charged.
• The units will fully charge overnight.
NOTE: the blue link lights on the Flexmike(s) and pods will stay on to indicate the microphone
number (1 or 2) and that they are ready for operation.
VolVol
Mute
6
5
1
3
2
4
