Operator’s Manual
Aero-Pac® APT4000
24V AIRCRAFT TOWUNIT
APT4000
Model APT40000 Manual , Rev 20130103

eneral Description and Application
The APT4000 is a 24VDC aircraft towunit desi ned to provide pilots, flyin clubs,
private owners and aviation maintenance professionals with an affordable
reliable aircraft towunit.
The APT4000 is powered by two 12 VDC batteries, throu h an intelli ent
controller the speed is controlled.
The APT5000 includes.
1. 2 x 12VDC batteries.
2. Intelli ent char er 24VDC output, iput 110V/220VAC, which leaves no
memory effect on the batteries, and batteries can be char ed at all times.
3. Control handle, with forward and backwards selector. Speed can be
re ulated from 1 km/hr to 7 km/hr. Speed is re ulated by turnin handle.
4. Powder coated steel frame (optional in your color / lo o ).
5. Powder coated swin ate, for nose wheel attachment.
6. Different en ine confi uration possible.
7. Two durable tires, wide tires for rass operation and more rip.
8. Intelli ent electronic controller for speed and en ine control.
9. Red security pin, safely stow your unit in han ars with multiple users.
(The purpose of this red security pin, is to de-power the unit completely, with the
redpin inserted there is always a relay ener ized, without the redpin, no-one can
move your aircraft, never insert the red pin durin char in .)
It is ideal for:
• private aircraft han ars
• Flyin schools and clubs.
• FBOs, avionics & maintenance shops
• air shows and aircraft exhibitions
Char in instructions :
There is no memory effect on the battery.
Never leave the battery unchar ed for lon periods; it may result in dama e to
the battery. (connect black char er pin to black socket, red char er pin to red
socket, middle socket red is used for the safety red pin.)
Green li ht : battery fully char ed
Oran e li ht : battery 95% char ed.
Red li ht : battery fully char ed.

Handle Switch & Variable Speed Control: The directional rocker switch mounted
on the tu handle has three (3) positions: forward, neutral and reverse. Twistin
the left rip forward will move the tu at the desired speed. Note: The switch is
always hot. For prolon ed battery life, disconnect the redpin when not in use for
extended periods of time.
Aircraft Loadin & Unloadin : By means of an U-fork attach in varies hei ht
postions the aircraft nose ear (or tailwheel) is attached to the APT4000. The
lockin is done by a metal rod , which oes in over center position. Bi
advanta e no cables nor chains.
Subsequent adjustments will be necessary when usin the tu with multiple
aircraft. Different adapters available.
Use Chocks: When returnin the aircraft to the han ar, use chocks to prevent
hittin the rear of the han ar or other obstructions.

ADAPTER MOUNTIN
1. Place the adapter bars into the open ends of the Aero-Pac APT4000
towbar frame, and li htly ti htly the screws.
2. Approach aircraft from the front allowin adapter to fit nose ear
as needed accordin to plane type.
3. Secure the adapter to ear dependin on adapter type
and ti hten accordin ly.
4. Check plane area free.
By puttin the pin in the left or ri ht hole. You can adjust the hei ht, left hole is
recommended for strut attachments the ri ht hole is recommended for axle
attachments. Make sure there is a certain an le, like this you create some
downward pressure on the tires.
Practice Is Hi hly Recommended: Operatin your new APT4000 prior to hookin
it up to the aircraft is essential. Get familiar with the APT4000 by operatin it in
forward and reverse and at different speeds.
Then try movin the aircraft in an open area.
Do not attempt to park the aircraft in a ti ht space until you are thorou hly
familiar with the APT4000.
Always check for clearance around the entire aircraft prior to movin the aircraft.
Wheel Bearin s: Should receive li ht oil a few times annually.
Operatin Speed: The electric APT5000 is desi ned to operate at a slow walkin
pace for safety (max 7 Km/hr) .
OPERATION
The towbar units works and the principle that you need to press the wheels to
the round by pressin the handle. Otherwise it is impossible that the APT4000
of about 30 k (64 Lbs) can pull an aircraft of more than 1000 k . It is
important not to proceed fast initially, the aircraft has a certain inertia, so let the
airplane move first and then increase the speed by turnin the control handle.
The selector is to select forward or backwards, Left is forward, ri ht is
backwards.
By turnin the black handle, you select the speed of the unit. From 1 km/h up to
7 km/h.

Speed control , by turnin the handle speed is increasin Selector forward
and backwards.
THIS HANDEL IS FIXED TO CONTROL HANDLE BY 3mm key.
HINTS
1. KEEP CORRECT PRESSURE IN ALL TIRES FOR MAXIMUM OPERATION.
2. MOVE MAIN GEAR TIRES OVER RAILS AND DOOR TRACKS AT A SLIGHT ANGLE ONE,
MAKES TOWING EASIER
Specifications:
Char er input : 110-240 Volts AC, 50-60 Hz.
Shippin Wei ht: 42 k
Shippin Dimensions: 80 cm x 60 cm x 40 cm
Aero-Pac ®
I NDUSTRIAL PARK STROHOF
K RUISBOOMMOLENSTRAAT 7/9
8800 R OESELARE
BELGIUM
I NFO @ AERO - PAC . COM
