Aervoe Sierra Wave 9653 User manual

Power Station
(9000mAh)
OPERATING INSTRUCTIONS
TECHNICAL INFORMATION
SPECIFICATIONS
SOLAR PANEL 1.5-watt monocrystalline
5V DC, 300mAh
POWER STATION BATTERY Lithium Poly, 3.7V/9000mAh (33Wh)
CHARGE PROTECTION Overcharge, over discharge, overload protection
and short circuit protection
POWER STATION INPUT 5V DC/1.5A
POWER STATION OUTPUT 5V 1A
5V 2A (high speed)
LIGHT 30 bright white LEDs, 300 Lumens
OPERATING TEMPERATURE 32° – 120°F (0° – 49°C)
WEIGHT 8 oz. (227g)
DIMENSIONS 6.56” x 3.25” x 0.625” (167 x 82.5 x 15.9 mm)
ACCESSORIES INCLUDED USB/Micro USB Cable
iPhone® Lightening tip adapter
CHARGING & OPERATING TIMES Estimate only. Actual times depend on available
sunshine, Power Bank battery level, and device
battery condition.
Charge 9000mAh Power Station Solar collector, up to 30 hours
USB, 8-10 hours
Recharge portable electronic
devices from a fully charged
9000mAh Power Station
iPhone 6, up to 5 times,
Galaxy 5, up to 4 times
Tablets will charge up to 50% of battery capacity
depending on model and size
Aervoe Industries, Inc.
Gardnerville, NV 89410 • [phone]
www.aervoe.com • [email protected]
9653inst CS:5/15
Sierra Wave is a registered trademark of Aervoe Industries, Inc.
RoHS
COMPLIANT

CHARGING DEVICES
The Multifunction USB Cable includes the iPhone® Lightning tip, 32-pin iPhone® tip, and
a micro USB tip to charge most portable electronics. You can use any device specific USB
charging adapter.
Charging through the Power Station
1. The Power Station can be used to charge devices using either the 1A USB port or 2A
USB port. The 2A port provides a higher rate of charge and should be used to charge
tablets.
2. Use the included USB/micro USB cable if your device uses a micro USB or iPhone
Lightening tip connection. Connect the standard USB plug on the included cable to the
1A or 2A USB output ports and the micro USB plug into your device. If using an iPhone
plug the included Lightening tip into the micro USB and then into your phone.
3. Both USB ports may be used at the same time.
4. Charging will automatically start when a device is plugged in.
5. Output and battery capacity may be monitored in the LCD display.
LCD DISPLAY & BATTERY METER
• The LCD display will activate when a device is plugged in and show the output level in
amps of power (A).
• Press and hold the ON/OFF button to cycle through amp output and battery capacity
information.
LIGHT/EMERGENCY FLASHER
Includes a 300 lumen light and emergency flasher
1. Press the ON/OFF button twice quickly to turn on the light.
2. Press 1 time for flashing mode.
3. Press the ON/OFF button again twice to turn off the light.
TROUBLESHOOTING
Warning: To avoid shock, injury or damage to the unit, do not disassemble the Power Station.
The warranty will be void if you do so. Contact Aervoe Industries, Inc. for assistance.
1. The Power Station is not charging from the solar collector or auxiliary USB power source
• If solar charging, make sure there is bright sun and it is angled toward the sun.
Reference the solar use guide above for positioning information.
• Make sure all connectors are attached securely
2. Your device is not charging properly when connected to the Power Station.
• Make sure all connectors are attached securely
• Verify that your device specifications are compatible with this unit
Sierra Wave®Power Station (9000mAh) #9653
This large capacity 9000mAh Power Station keeps portable electronics charged using USB power
ports. It can be charged with the built-in solar panel or through any USB power connection.
120V AC or 12V DC charging is also possible when using a wall or vehicle charging plugs (not
included). Includes a 300 lumen light and emergency flasher.
IMPORTANT SAFEGUARDS
Warning: to reduce the risk of electric shock or damage to this product, please read the
following.
• Read all instructions before operating and keep for later reference
• Administer close supervision when using around children
• Do not leave the power bank in direct sunlight, on hot surfaces, or in temperatures over
140°F, such as a hot vehicle.
• Do not submerge this unit or any accessories in liquid. This unit is weather resistant but
not waterproof.
• Do not drop, crush, or puncture
• Protect the solar panel from scratches and dust
• Do not use in flammable or explosive areas
• Discontinue use if electronic components or accessories are damaged. To avoid risk of
injury and damage to the unit, do not disassemble. Warranty is void if anyone other than
an authorized Aervoe Service Center associate performs any repair. Contact Aervoe for
assistance.
• Recharge at least every 3 months to keep the battery conditioned
• Includes built-in overcharge, over discharge, and short circuit protection
PARTS IDENTIFICATION
CHARGING THE POWER STATION
Built-in Solar Collector
1. Place the POWER STATION outdoors with the SOLAR COLLECTOR facing the sun. The
rate of charge will vary based on available solar energy, location, and time of day.
2. Charging input rate will automatically appear in the LCD Display. Adjust the angle of the
solar panel to increase charge rate.
3. Battery capacity may be monitored in the LCD display by pressing the POWER/DISPLAY
button to view the battery level.
USB Power Sources
Plug into any power source that offers 5V USB including computers, vehicles, or detachable
AC wall or 12V vehicle charger (not included).
1. Remove the USB/micro USB cable from the side of the Power Station.
2. Connect the micro USB end to the DC INPUT and the standard USB plug into any USB
power supply.
3. The input charge rate will appear in the LCD Display during charging.
4. Battery capacity may be monitored in the LCD display by pressing the POWER/DISPLAY
button to view the battery level.
Solar
Collector
iPhone
Lightning Tip
Micro USB Tip
Standard
USB Tip
USB/Micro
USB Cable
DC IN
(Micro USB)
Hanging
Loops
1A USB
Output
Power/Display
Button
Multifunction USB Cable
Standard USB iPhone
32-pin iPhone
Lightning
Micro
USB
LCD Display
2A USB
Output
Power/Display
Button
