AES global e-Trans 200 User manual

To code e-TX/remote device: Rotate dial clockwise to CODE
DEVICE then press PB dial. CODE LEARN will display and green LED
will flash indicating coding sequence.
Press e-TX/remote button once > display will show ACCEPT REM 1,
then screen will display CONFIRM REM 1, press e-TX/remote
button one final time and screen will display REM 1 CODED.
To code e-Loop– Method 1: Rotate dial to CODE DEVICE then hold
e-Loop next to the Transceiver antenna. Now press PB dial and
release. Display will show E-LOOP CODED. CODE DEVICE will exit
and return to main screen.
To code e-Loop–Method 2: Rotate dial to CODE DEVICE then press
PB dial, CODE LEARN will be displayed. Now press and release e-
Loop CODE button. Screen will display E-LOOP CODED and will exit
back to main screen,(for commercial e-Loop, use the magnet
provided to activate the CODE button)
NEED MORE ASSISTANCE?
[phone]
SCAN THIS QR CODE TO BE BROUGHT TO OUR RESOURCES PAGE.
VIDEOS | HOW-TO GUIDES | MANUALS | QUICK START GUIDES
Ensure e-Trans is not in a steel/metal enclosure which can reduce
signal range.
The transceiver should be mounted as high as
possible with clear line of sight to loop to maximise range.
Check out our YouTube
channel for how to
guides
e-Trans 200 Connection Diagram
1
Coding devices:
STILL HAVING TROUBLE?
Find all of our support options such as Web Chat,
Full Manuals, Customer Helpline and more on
our website:
WWW.AESGLOBALONLINE.COM
* ALWAYS TEST THE UNIT ON SITE BEFORE INSTALLATION TO AVOID RE-STOCKING FEE * See full T&C’s on our website
10-36V ACDC
Output
Open/Start
Input
YouTube Full Manual
1.5M Detection zone
from centre of e-Loop
Open/Start
Input
Gate
control
board
Gate
control
board
Technical Specs:
Quick Start Guide
e – Trans 200

FAQ’S
Question Answer
Q: My loop will not code
to transceiver?
A: Ensure loop is held directly beside transceiver for pairing process, initiate code
process on transceiver, this should automatically detect loop and successfully pair if
close enough.
For commercial or inground loops: these can be paired in close proximity or further
away in location by using pairing method 2. See full manual for instructions.
Q: What is the max
distance between loop &
transceiver?
A: The loop can be placed up to 50M away from the transceiver using supplied
antenna, ensure a clear line of sight between loop & transceiver.
Please note: housing the transceiver in a metal enclosure or close to high voltage
power lines could reduce the transmission range. If you are having issues, please try
house the transceiver in its own separate enclosure or try an external antenna.
Q: Can I change the
sensitivity of the loop?
A: The loop has a detection area of 1.5M (radial) distance from the centre of loop.
By default, our loops are setup in a way that they will detect almost any vehicle as it
passes directly over the loop.
If you feel the loop is too sensitive and picking up smaller objects other than vehicles
it may be worth trying to recalibrate the loop firstly. Please refer to full manual on
how to do so with the e-Trans 200.
If still having issues, please call technical support to discuss. [phone]
Q: I have paired the loop,
but it is not triggering
gate/barrier?
A: Test by placing metal object or driving vehicle over loop, on the transceiver check if
Red/RX LED comes on while doing so, this will indicate the loop is triggering and signal
sent to transceiver firstly.
If gate is not triggering, double check wiring from gate motor, you can also test &
prove relay is changing state by using a multi-meter.
If still having issues, please call technical support to discuss further. [phone]
Q: Can I pair multiple
loops to 1x transceiver? A: Yes, you can pair up to 4x loops to either e-Trans 50 or e-Trans 200. This can be any
variety of loops; exit mode, presence mode, commercial or residential.
This product is not a complete product until fully installed. It is therefore
considered a component part of an overall system. The installer is responsible to
check that the end installation complies with local regulatory requirements. This
equipment forms part of a “fixed installation”.
2
STILL HAVING TROUBLE?
Find all of our support options such as Web Chat, Full Manuals, Customer
Helpline and more on our website:
WWW.AESGLOBALONLINE.COM
[phone]
STILL HAVING TROUBLE?
Find all of our support options such as Web Chat,
Full Manuals, Customer Helpline and more on
our website:
WWW.AESGLOBALONLINE.COM
* ALWAYS TEST THE UNIT ON SITE BEFORE INSTALLATION * See full T&C’s on our website
Quick Start Guide
e – Trans 200
AES Global Ltd - 4 Kilcronagh Business Park, Cookstown,
BT80 9HJ, UK.
Product Type: Wireless Vehicle Detection & Automation.
Hereby, AES GLOBAL LTD declares that the radio equipment
type E-TRANS-50 is in compliance with Directive 2014/53/EU.
The full text of the EU Declaration of Conformity is available
at the following internet address:
www.aesglobalonline.com/e-loop#ce
