1.About This Manual
1.1 Scope of Validity
1.2 Target Group
This manual mainly describes the product information, guidelines for installation,
operation, maintenance and troubleshooting. And this manual applies to Afore
Single Phase AC Coupled Inverter.
2.Safety & Symbols
2.1 Safety Precautions
1. All work on the inverter must be carried out by qualified electricians.
2. Do not touch the inverter cover until 5 minutes after disconnecting both AC
power supply.
3. Do not touch the inverter enclosure when operating, keep away from materials
that may be affected by high temperatures.
4. Please ensure that the used device and any relevant accessories are disposed
of in accordance with applicable regulations.
5. Afore inverter should be placed upwards and handled with care in delivery. Pay
attention to waterproof. Do not expose the inverter directly to water, rain, snow or
spray.
6. Alternative uses, modifications to the inverter not recommended. The warranty
can become void if the inverter was tampered with or if the installation is not in
accordance with the relevant installation instructions.
This manual is for qualified personnel. The tasks described in this manual must
only be performed by qualified personnel.
AF1K-SL-0 AF1.5K-SL-0 AF2K-SL-0 AF2.5K-SL-0 AF3K-SL-0
AF3.6K-SL-0 AF4K-SL-0 AF4.6K-SL-0 AF5K-SL-0
AF5.5K-SL-0 AF6K-SL-0
Please keep this manual available all the time in case of any emergency.
About This Manual
01

Afore inverter strictly comply with relevant safety standards. Please read and
follow all the instructions and cautions during installation, operation and
maintenance.
2.2 Explanations of Symbols
Safety & Symbols 02
Danger of electric shock
The inverter contains fatal DC and AC power. All work on the inverter
must be carried out by qualified personnel only.
Beware of hot surface
The inverter’s housing may reach uncomfortably hot 60°C (140°F) under high
power operation. Do not touch the inverter enclosure when operation.
Residual power discharge
Do not open the inverter cover until 5 minutes after disconnection both
DC and AC power supply.
Do not dispose of this device with the normal domestic waste.
CE mark
The inverter complies with the requirements of the applicable
CE guidelines.
Refer to manual before service.
Important notes
Read all instructions carefully. Failure to follow these instructions,
warnings and precautions may lead to device malfunction or damage.

3. Introduction
3.1 Basic Instruction
The Afore AF-SL-0 AC Coupled inverters are designed to increase energy
independence for homeowners. Energy management is based on time-of-use
and demand charge rate structures, significantly reduce the amount of energy
purchased from the public grid and optimize self-consumption.
Introduction
03
AC Coupled
Inverter
Meter Meter
Single Phase AC Coupled (Retro Fit)
Three Phase AC Coupled (Retro Fit)
PV Array
PV Array
Single-phase
Inverter
Storage battery Emergency load
Generation meter Consumption meter
Load
Storage battery Emergency load Load
Grid
Grid
Three-phase
Inverter
AC Coupled
Inverter

3.2 Operation Modes
3.2.1 Self-use
A. Normal Mode
Introduction 04
Battery power to load
Battery power
to load
Load Curve
Local load
PV power
Sell energy
PV charging battery
Priority: Load > Battery > Grid
This mode applies to situation that with low feed in subsidy and high electricity
price.
1. Solar energy supply to the local load and charge to the battery first.
2. The excess power export to the public grid.
3. The wind turbines can be connected to the PV.
4. When off gird and the power is lacking, the generator will be turned on
automatically.

Introduction
05
3.2.2 Charging First
Priority: Battery > Load > Grid
This mode applies to situation with frequent power outages. When the public
grid is off, enough energy can be supplied to the local load by the batteries.
Battery will be charged first, and discharge energy for the local load when the
grid is off. It would be charged automatically.
Load Curve
Local load
PV power
PV charging battery
Load / Grid
Sell energy
Buy Electricity
Buy Electricity
3.2.3 Command charge and discharge
This mode the charging and discharging power operates according to the set
parameters.
Within the power range that the battery can accept, run according to the set
parameters, otherwise run the charge and discharge command according to the
upper and lower limits of the battery.
3.2.4 External EMS dispatch
This mode power of charging and discharging is controlled by external EMS
communication commands, which is suitable for occasions with centralized
EMS.
To meet the power of EMS charging and discharging, the residual energy is fed
back to the grid.
Priority: Battery charge command > Load > Grid

Introduction 06
3.2.5 EPS
3.2.6 Timed charge and discharge
When the grid is suddenly off or abnormal, inverter will change to off grid status
automatically. Energy from PV system and battery will supply the local load.
There are 4 types of timed charge and discharge control, each of which can be
set for 3 time periods respectively. It operates according to these four types
within the set time period, and resumes operation in the setting mode of
3.2.1~3.2.4 after the time expires.
3.2.6.1 AC Charge
During the set time period, the battery is charged with the set power. When the
PV power is not enough, the power is drawn from the grid until the set SOC is
reached, and the timing charging function is stopped.
3.2.6.2 Force Charge
During the set time period, the battery is charged with the set power, and the
power is only drawn from the PV, not from the grid, and the timing charging
function is stopped after the set SOC.
3.2.6.3 Force Discharge
During the set time period, discharge the battery with the set power until the set
SOC stops the timed discharge function.
3.2.6.4 Forbid discharge
During the set time period, the PV power will give priority to the charging, not
the load1.

Installation
07
4. Installation
4.1 Pre-installation
4.1.1 Unpacking & Package List
Unpacking
On receiving the inverter, please check to make sure the packing and all
components are not missing or damaged. Please contact your dealer directly for
supports if there is any damage or missing components.
Package List
Open the package, please check the packing list shown as below.
3
76 9 10
5
Monitoring
Quick
Installation
Instructions
54
1
Quick
Installation
Instructions
Warranty
Card
2
12 514
13
11
Certificate
Of Inspection
17
515 16 18
8

Installation 08
4.1.2 Product Overview
No. Qty Items No. Qty Items
1
1
1
1
1
1
4
1
4
2
Hybrid Inverter
Certificate Of Inspection
Quick Installation Instructions
Warranty Card
Monitoring Quick Installation Instructions
Wall Mounting Bracket
AC Wiring Cover Screw
Security Screw
1
1
1
1
1
3
3
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
AC Waterproof Cover
AC Wiring Terminal
Grounding Terminal
Battery Connector
Monitor Module
Communication Adapter
Mounting Bracket Screw
Plastic Expansion Tube
Smart Meter (Opitional)
Communication Connectors
370mm
513mm
192mm

Installation
09
Inverter Terminals
The inverters are designed for indoor and outdoor installation (IP65), to increase
the safety, performance and lifespan of the inverter, please select the mounting
location carefully based on the following rules:
• The inverter should be installed on a solid surface, far from flammable or
corrosion materials, where is suitable for inverter’s weight and dimensions.
• The ambient temperature should be within -25℃~ 60℃(between -13 °F and
140°F).
• The installation of inverter should be protected under shelter. Do not expose
the inverter to direct sunlight, water, rain, snow, spray lightning, etc.
4.1.3 Mounting Location
41 2
3
No. Items
Battery Port
Communication Port
1
2
No. Items
Conitor Module Port
AC Port & EPS Port
3
4

Installation 10
The inverter should be installed vertically on the wall, or lean back on plane
with a limited tilted angle. Please refer to below picture.
Leave the enough space around inverter, easy for accessing to the inverter,
connection points and maintenance.
<15°
>0°
Max
300mm
300mm 300mm
500mm
50mm

Installation
11
4.2 Mounting
Step 1
Step 3
Step 2
264mm
219mm
17mm
Security
screw

Installation 12
4.3 Electrical Connection
Communication Adapter pin assignment
Grid
Smart meter
Crical Load
Load
TV
12345678
No. COM2
1
2
3
4
5
6
7
8
COM1
NTC+
NTC-
Dry Contact
Dry Contact
DRM
DRM
CTU
CTN
Meter 485A
Meter 485B
BAT 485A
485A
485B
BAT CANH
BAT CANL
BAT 485B

Installation
13
AF-SL-0 AC Coupled inverters are compatible with lithium battery. For lead acid
battery or batteries with other brands, please confirm with local distributor or
Afore for technical support.
4.3.1 Baery Connecon
Note:
Set battery type and manufacturer, please refer to Chapter 5.3.
BMS( Battery Management System) communication is needed
between inverter and battery.
Note:
Battery cable suggestion Cross - section 8-10 AWG
Please make sure the battery polarities are correct.
Battery cable
19±1mm
Step 1

Installation 14
Pass the crimped battery harness through the waterproof connector and the cover.
Insert the wire harness into the terminals according to “+” and “-” polarity, make the
insulated terminals parallel with the terminals , the crimping screw torque is 2.0±0.1N.m
Step 2
Step 3
A “click” sound will be heard when the connector assembly is correct.
Step 4

Installation
15
Note:
Once the clamping nut is tightened, the nut will be locked.
Use an open-end wrench to tighten the waterproof lock.
Step 5
Insert the battery connector into the inverter, if hear a “click”, it means the battery
connection is finished.
Step 6

Installation 16
4 5
4.3.1.1 BAT-CAN/RS485
CAN/RS485
Lithium
4.3.1.2 BAT-NTC
NTC
3-8
1
2
PIN Assignment
NTC-
NTC+
RJ45 Plug
12345678
/
Lead Acid
PIN Assignment
1PIN 2 3 6 7 8
5
1-3
4CANH
/
6-8
CANL
/
2345678
PIN Assignment
1PIN
4-5
1-2
3RS485A
/
6
/
7-8 /
RS485B

Installation
17
Before connecting, a separate AC breaker between individual inverter and AC
input power is necessary. This will ensure the inverter be securely disconnected
during maintenance and fully protected from current of AC input.
An extra AC breaker is needed for On-Grid connection to be isolated from grid
when necessary. Below are requirements for the On-Grid AC-breaker.
•
Connect DC protector or breaker first before connecting.
• emove insulation sleeve 11mm(0.5 inch) length, unscrew the bolts, insert the
AC input wires according to polarities indicated on the terminal block and
tighten the terminal screws.
Note:
Qualified electrician will be required for the wiring.
The AC terminal contains “GRID” and “EPS”, GRID for load, and EPS for
emergency load.
4.3.2 AC Connection
Inverter Model AC breaker specification
32A/200V/230V AC breakerAF1-6K-SL-0
Cable（mm²）
4-6 1.2N·m
Torque value
Model
1-6kW 8-10AWG
Wire Size
Please follow steps for AC connection
Step 1
Note:
Cable suggestion
Cross-section 8-10AWG
10±0.5mm
