ABB PVI-8.0-TL-OUTD User manual

ABB solar inverters
Product manual
PVI-6.0/8.0/10.0/12.5-TL-OUTD
(6.0 to 12.5 kW)

- 2 -
000427BG
IMPORTANT SAFETY INSTRUCTIONS
This manual contains important safety instructions that must be followed during installation
and maintenance of the equipment.
Operators are required to read this manual and scrupulously follow the indications reported
in it, since ABB cannot be held responsible for damages caused to people and/or things, or
the equipment, if the warranty conditions are not observed.

- 3 -
000427BG
Product Manual
PVI-6.0/8.0/10.0/12.5-TL-OUTD string inverters
1 - Introduction and general information
2 - Characteristics
3 - Safety and accident prevention
4 - Lifting and transport
5 - Installation
6 - Instruments
7 - Operation
8 - Maintenance
PVI-6.0/8.0/10.0/12.5-TL-OUTD-Product manual EN-Rev B(M000023BG)
EFFECTIVE 12/01/2015
© Copyright 2015 ABB. All Rights Reserved.

- 4 -
000002EG
Warranty and Supply Conditions
The warranty conditions are considered to be valid if the customer adhe-
res to the indications in this manual; any conditions deviating from those
described herein must be expressly agreed in the purchase order.
The equipment complies with the pertinent legislation currently in force in the country of in-
stallation and it has issued the corresponding declaration of conformity.
Not included in the supply
ABB accepts no liability for failure to comply with the instructions for correct installation and will
not be held responsible for systems upstream or downstream the equipment it has supplied.
It is absolutely forbidden to modify the equipment. Any modication, manipulation, or alteration
not expressly agreed with the manufacturer, concerning either hardware or software, shall re-
sult in the immediate cancellation of the warranty.
The Customer is fully liable for any modications made to the system.
Given the countless array of system congurations and installation envi-
ronments possible, it is essential to check the following: sufcient space
suitable for housing the equipment; airborne noise produced depending
on the environment; potential ammability hazards.
ABB will NOT be held liable for defects or malfunctions arising from: im-
proper use of the equipment; deterioration resulting from transportation
or particular environmental conditions; performing maintenance incor-
rectly or not at all; tampering or unsafe repairs; use or installation by
unqualied persons.
ABB will NOT be held responsible for the disposal of: displays, cables,
batteries, accumulators etc. The Customer shall therefore arrange for the
disposal of substances potentially harmful to the environment in accor-
dance with the legislation in force in the country of installation.
1
Introduction and general information

- 5 -
000428BG
1- Introduction and general information
Contents
Introduction and general information............................................................................................... 4
Warranty and Supply Conditions..........................................................................................................4
Not included in the supply.......................................................................................................4
Contents ..................................................................................................................................................5
Reference number index .......................................................................................................................8
Graphical representation of references...............................................................................................8
The document and who it is for ...........................................................................................................9
Purpose and structure of the document .................................................................................9
List of annexes .......................................................................................................................9
Staff characteristics.................................................................................................................9
Symbols ad signs .................................................................................................................................10
Field of use, general conditions ........................................................................................................11
Intended or allowed use........................................................................................................ 11
Limits in field of use............................................................................................................... 11
Improper or prohibited use ................................................................................................... 11
Characteristics................................................................................................................................. 12
General conditions ...............................................................................................................................12
Models and range of equipment .........................................................................................................13
Identification of the equipment and the manufacturer ..........................................................14
Characteristics and technical data.....................................................................................................16
Tightening torques ................................................................................................................19
Overall dimensions ...............................................................................................................19
Bracket dimensions...............................................................................................................20
Efficiency curves ..................................................................................................................................21
Power derating......................................................................................................................................23
Power derating due to environmental conditions .................................................................23
Power reduction due to the input voltage .............................................................................24
Characteristics of a photovoltaic generator......................................................................................25
Strings and Arrays.................................................................................................................25
Description of the equipment..............................................................................................................26
Operating diagram ................................................................................................................26
Connection of several inverters together..............................................................................27
Notes on the sizing of the system.........................................................................................27
Functionality and components of the equipment .................................................................28
Topographic diagram of the equipment ................................................................................29
Safety devices.......................................................................................................................................31
Anti-Islanding ........................................................................................................................31
Input Fuses ...........................................................................................................................31
Ground fault of the photovoltaic panels ................................................................................31
Other safety devices .............................................................................................................31
Safety and accident prevention ..................................................................................................... 32
Safety instructions and general information ....................................................................................32
Hazardous areas and operations .......................................................................................................33
Environmental conditions and risks ......................................................................................33
Signs and Labels ..................................................................................................................33
Thermal hazard ....................................................................................................................34
Clothing and protective devices for staff...............................................................................34

- 6 -
000428BG
1- Introduction and general information
Residual risks .......................................................................................................................................35
Table of residual risks ...........................................................................................................35
Lifting and transport........................................................................................................................ 36
General conditions ...............................................................................................................................36
Transport and handling .......................................................................................................36
Lifting.....................................................................................................................................36
Unpacking and checking ......................................................................................................36
List of components supplied .................................................................................................37
Weight of the groups of device .............................................................................................38
Installation ......................................................................................................................................... 39
General conditions ..............................................................................................................................39
Environmental checks...........................................................................................................40
Installations above 2000 metres...........................................................................................40
Installation position................................................................................................................41
Wall mounting .......................................................................................................................................42
Operations preparatory to PV generator connection.......................................................................43
Checking the correct polarity of the strings ..........................................................................43
Checking of leakage to ground of the photovoltaic generator..............................................43
Choice of differential protection downstream of the inverter ................................................43
Independent or parallel input channels configuration.....................................................................45
Channel configuration examples ..........................................................................................46
Independent channel configuration (default configuration) ..................................................47
Parallel channel configuration ..............................................................................................47
Input connection to PV generator (DC side) .....................................................................................48
String protection fuses (-FS model only)...........................................................................................50
Sizing of fuses.......................................................................................................................50
Installation procedure for quick fit connectors ......................................................................52
Grid output connection (AC side).......................................................................................................54
Characteristics and sizing of the line cable ..........................................................................54
Load protection switch (AC disconnect switch) ....................................................................55
Connection to the AC side terminal board............................................................................55
Communication and control board ....................................................................................................56
Connections to the communication and control board...................................................................57
Serial Connection Communication (RS485).........................................................................58
Procedure for connection to a monitoring system................................................................59
Remote control connection ...................................................................................................60
Configurable Relay connection (ALARM).............................................................................60
Instruments........................................................................................................................................ 61
General conditions ..............................................................................................................................61
Description of keyboard and LED Panel...............................................................................62
Operation.......................................................................................................................................... 63
General conditions ..............................................................................................................................63
Monitoring and data transmission .....................................................................................................64
User interface mode..............................................................................................................64
Types of data available .........................................................................................................64
Measurement tolerance ........................................................................................................64
Commissioning.....................................................................................................................................65
Display access and settings .................................................................................................67

- 7 -
000428BG
1- Introduction and general information
LED behaviour ......................................................................................................................................68
Specifications on the operation of the LEDs.........................................................................69
LED insulation fault ...............................................................................................................69
Description of the menus ....................................................................................................................70
General information ..............................................................................................................70
Statistics Menu......................................................................................................................72
Settings Menu .......................................................................................................................74
Info Menu ..............................................................................................................................82
AUTOTEST procedure in accordance with standard CEI 0-21........................................................83
Running the tests from the display menu .............................................................................83
Maintenance..................................................................................................................................... 85
General conditions ..............................................................................................................................85
Routine maintenance............................................................................................................86
Troubleshooting ....................................................................................................................86
Alarm Messages ...................................................................................................................86
Power limitation messages ...................................................................................................93
Registration on “Registration” website and calculation of second-level password (Service
Menu) .....................................................................................................................................................95
Resetting the time remaining to change the grid standard.............................................................98
Replacing the input fuses (version -FS) ............................................................................................99
Models equipped with fuse holder extractors .....................................................................100
Models equipped with safety caps......................................................................................100
Replacement of the buffer battery....................................................................................................101
Verification of ground leakage .........................................................................................................102
Behaviour of a system without leakage ..............................................................................102
Behaviour of a system with leakage ...................................................................................103
Measuring the insulation resistance of photovoltaic generator...................................................104
Storage and dismantling ..................................................................................................................105
Storage of the equipment or prolonged stop ......................................................................105
Dismantling, decommissioning and disposal......................................................................105
Further information ............................................................................................................................106
Contact us ...........................................................................................................................................107

- 8 -
000428BG
1- Introduction and general information
03 04 05 06
02
01
07
100908 11 12
100908 11 12
10 11 1209
STANDARD VERSION
-S VERSION
-FS VERSION
14 15 1716 18 19 2013
01 , Bracket
02 , Heat sink
03 , Front cover
04 , LED Panel
05 , Display
06 , Keyboard
07 , Handles
08 , DC Disconnect switch
09 , Input connectors (MPPT1)
10 , Input connectors (MPPT2)
11 , AC cable gland
12 , Service cable glands
13 , Fuse board (*only version -FS)
14 , DC Input terminal block
15 , AC Output terminal block
16 , Channel conguration switch
17 , Internal battery
18 , Signal terminal block
19 , RJ45 Connectors
20 , RS485 line termination switch
Reference number index
Graphical representation of references

- 9 -
000004EG
1- Introduction and general information
The document and who it is for
Purpose and structure of the document
This operating and maintenance manual is a useful guide that will enable
you to work safely and carry out the operations necessary for keeping the
equipment in good working order.
If the equipment is used in a manner not specied in the installer manual, the protection pro-
vided by the equipment may be impaired.
The language in which the document was originally written is ITALIAN; therefore, in the event of
inconsistencies or doubts please ask the manufacturer for the original document.
List of annexes
In addition to this operating and maintenance manual, (if applicable or on
request) the following enclosed documentation is supplied:
- EC declaration of conformity
- quick installation guide
WARNING: Part of the information given in this document is taken from the original docu-
ments of the suppliers. This document contains only the information considered necessary
for the use and routine maintenance of the equipment.
Staff characteristics
The customer must make sure that the operator has the necessary skill and training to do his/
her job. Personnel in charge of using and maintaining the equipment must be expert, aware
and skilled for the described tasks and must reliably demonstrate their capacity to correctly
interpret what is described in the manual.
For safety reasons, only a qualied electrician who has received training and/or demonstra-
ted skills and knowledge on the structure and operation of the unit may install the inverter.
The installation must be performed by qualied installers and/or licensed electricians in ac-
cordance with the existing regulations in the country of installation.
The employment of a person who is NOT qualied, is drunk, or on narcotics, is strictly forbid-
den.
The customer has civil liability for the qualication and mental or physical state of the profes-
sional gures who interact with the equipment. They must always use the personal protective
equipment required by the laws of the country of destination and whatever is provided by their
employer.

- 10 -
000006FG
1- Introduction and general information
Symbols ad signs
In the manual and/or in some cases on the equipment, the danger or
hazard zones are indicated with signs, labels, symbols or icons.
Table: Symbols
This points out that it is mandatory to consult the manual or original do-
cument, which must be available for future use and must not be dama-
ged in any way.
Generic hazard - Important safety information. This points out operations
or situations in which staff must be very careful.
Hazardous voltage - This points out operations or situations in which
staff must be very careful due to hazardous voltage.
Hot parts - This points out a hazard due to the presence of heated areas
or in any case areas that have hot parts (danger of burns).
This points out that the examined area must not be entered or that the
described operation must not be carried out.
This points out that it is mandatory to carry out the described operations
using the clothing and/or personal protective equipment provided by the
employer.
IP20
IP65 This indicates the degree of protection of the equipment according to
IEC standard 70-1 (EN 60529 June 1997).
Point of connection for grounding protection.
This indicates the allowed temperature range
5
10
This indicates the risk of electric shock. Time need to discharge stored
energy: 5/10 minutes
Respectively direct current and alternating current
Isolating transformer present or not present
Positive pole and negative pole of the input voltage (DC)
This indicates the centre of gravity of the equipment.

- 11 -
000007CG
1- Introduction and general information
Field of use, general conditions
ABB shall not be liable for any damages whatsoever that may result from
incorrect or careless operations.
You may not use the equipment for a use that does not conform to that provided for in the
eld of use. The equipment MUST NOT be used by inexperienced staff, or even experienced
staff if carrying out operations on the equipment that fail to comply with the indications in this
manual and enclosed documentation.
Intended or allowed use
This equipment is a inverter designed for:
transforming a continuous electrical current (DC)
supplied by a photovoltaic generator (FV)
in an alternating electrical current (AC)
suitable for feeding into the public distribution grid.
Limits in field of use
The inverter can be used only with photovoltaic modules which have ground isolated input
poles, unless they are accessories installed that enable earthing of the inputs. In this case
you must install an insulating transformer on the AC side of the system.
Only a photovoltaic generator can be connected in the input of the inverter (do not connect
batteries or other sources of power supply).
The inverter can be connected to the electricity grid only in countries for which it has been
certied/approved.
The inverter cannot be connected to the DC side in parallel to other inverters to convert ener-
gy from a photovoltaic generator with a power greater than the nominal power of the single
inverter.
The inverter may only be used in compliance with all its technical characteristics.
Improper or prohibited use
IT IS STRICTLY FORBIDDEN TO:
• Install the equipment in environments subject to particular conditions of ammability or in
adverse or disallowed environmental conditions, (temperature and humidity).
• Use the equipment with safety devices which are faulty or disabled.
• Use the equipment or parts of the equipment by linking it to other machines or equipment,
unless expressly provided for.
• Modify operating parameters that are not accessible to the operator and/or parts of the
equipment to vary its performance or change its isolation.
• Clean with corrosive products that could eat into parts of the equipment or generate elec-
trostatic charges.
• Use or install the appliance or parts of it without having read and understood the contents of
the user and maintenance manual.
• Heat or dry rags and clothing on the parts in temperature. In addition to being hazardous,
doing so would compromise component ventilation and cooling.

- 12 -
000008EG
General conditions
A description of the characteristics of the equipment is given so as to
identify its main components and specify the technical terminology used
in the manual.
Technical terminology and the fast retrieval system for information, are
supported by:
• Contents
• Reference number index
The Characteristics chapter contains information about the models, de-
tails of the equipment, characteristics and technical data, overall dimen-
sions and identication of the equipment itself.
The customer/Installer takes full responsibility if, when reading this manual, the chronological
order of its presentation established by the manufacturer is not observed. All information is
provided considering occasional inclusion of that provided in previous chapters.
In certain cases, there may be a need to separately document software
functionality or attach supplementary documentation to this manual in-
tended for more qualied professionals.
2
Characteristics

- 13 -
000429BG
2 - Characteristics
Models and range of equipment
The specic models of three-phase inverters covered by this manual are
divided into four groups according to their maximum output power:
6.0 kW, 8.0kW, 10.0 kW or 12.5 kW.
For inverters of equal output power the variant between the various mo-
dels is the presence or lack thereof of the DC disconnect switch 08 , or
the input fuses board 13 .
The choice of the inverter model must be made by a qualied technician who knows about
the installation conditions, the devices that will be installed outside the inverter and possible
integration with an existing system.
• PVI-6.0/8.0/10.0/12.5-TL-OUTD MODELS
PVI-6.0/8.0/10.0/12.5-TL-OUTD:
• Number of input channels: 2
• DC disconnect switch 08 : No
• Input fuses board 13 : No
• Input connectors: quick t connectors
(3 pair for each channel)
PVI-6.0/8.0/10.0/12.5-TL-OUTD-S:
• Number of input channels: 2
• DC disconnect switch 08 : Yes
• Input fuses board 13 : No
• Input connectors: quick t connectors
(2 pair for each channel)
PVI-6.0/8.0/10.0/12.5-TL-OUTD-FS:
• Number of input channels: 2
• DC disconnect switch 08 : Yes
• Input fuses board 13 : Yes
• Input connectors: quick t connectors
(3 pair for each channel)

- 14 -
000429BG
2 - Characteristics
N.B. The labels must NOT be
hidden with objects and ex-
traneous parts (rags, boxes,
equipment, etc.); they must be
cleaned regularly and kept vi-
sible at all times.
Identification of the equipment and the manufacturer
The technical data shown in this manual do not in any case replace
those shown on the labels attached to the equipment.
The labels attached to the equipment must NOT be removed, damaged, dirtied, hidden, etc.
The approval label contains the following information:
1. Manufacturer
2. Model
3. Rating data
4. Certication marks
TRIO
1
4
2
3
1
4
2
3
1
4
2
3
1
4
2
3

- 15 -
000429BG
2 - Characteristics
In addition to the label showing the specications of the inverter, there
are two part identication labels for the inverter and wiring box.
These labels list the following information:
The ofcially required information is located on the approval label. The identication label
is an accessory label which shows the information necessary for the identication and cha-
racterisation of the inverter by ABB.
N.B. The labels must NOT be hidden with objects and extraneous parts (rags, boxes, equip-
ment, etc.); they must be cleaned regularly and kept visible at all times.
P/N:PPPPPPPPPPP
WO:XXXXXXX
SO:SXXXXXXXX Q1
SN:YYWWSSSSSS WK:WWYY
PVI-XX.X-TL-OUTD-Y
ABB
• Inverter model
- XX.X = Inverter power rating:
- Y= Integrated disconnect switch / Input fu-
ses board with Integrated disconnect switch
• Inverter Part Number
• Inverter Serial Number composed of:
- YY = Year of manufacture
- WW = Week of manufacture
- SSSSSS = sequential number
• Week/Year of manufacture

- 16 -
000430BG
2 - Characteristics
Characteristics and technical data
Table: Technical Data PVI-6.0-TL-OUTD PVI-8.0-TL-OUTD PVI-10.0-TL-OUTD PVI-12.5-TL-OUTD
Input
Absolute Maximum
Input Voltage (Vmax,abs)900 V
Rated Input Voltage (Vdcr)580 V
Input start-up voltage (Vstart)360 V (adj. 250...500 V)
Input operating interval
(Vdcmin...Vdcmax)0.7 x Vstart...
850 V
Input Nominal Power(Pdcr)6200 W 8250 W 10300 W 12800 W
Number of Independent MPPT 2
Maximum input power for Each
MPPT (PMPPTmax)4200 W 5500 W 6500 W 8000 W
Input voltage interval
(VMPPTmin ... VMPPTmax) to Pacr
(parallel MPPT conguration)
200…750 V 270…750 V 300…750 V 360...750 V
DC Power limiting for each
MPPT with Independent MPPT
Conguration to Pacr, maximum
unbalance example
4200 W
[250V≤VMPPT≤750V]
other channel:
Pdcr-4200W
[175V≤VMPPT≤750V]
5500 W
[320V≤VMPPT≤750V]
other channel:
Pdcr-5500W
[175V≤VMPPT≤750V]
6500 W
[380V≤VMPPT≤750V]
other channel:
Pdcr-6500W
[225V≤VMPPT≤750V]
8000 W
[445V≤VMPPT≤750V]
other channel:
Pdcr-8000W
[270V≤VMPPT≤750V]
Maximum DC Input Current
(Idcmax) / for each MPPT
(IMPPTmax)
34.0 A / 17.0 A 34.0 A / 17.0 A 34.0 A / 17.0 A 36.0 A / 18.0 A
Maximum Return current
(AC side vs DC side) Negligible
Number of DC Connection Pairs
in Input for each MPPT
2 pair for -S version; 3 pair for standard and -FS version
2 pair for -S version; 3 pair for standard and -FS version
DC Input Connector type
(components indicated or equi-
valents)
Connector PV Tool Free WM / MC4
Type of photovoltaic panels that
can be connected at input accor-
ding to IEC 61730
Class A
Input protection
Reverse Polarity Protection Inverter protection only, from limited current source, for standard and -S versions,
and for -FS version when max 2 strings are connected
Input Overvoltage protection for
each MPPT - Varistors 2
Maximum short-circuit current for
each MPPT 22.0 A
Insulation Check Complying with the local standard
DC Disconnect Switch rating
(-S Version) Max. 25.0 A / 1000 V
Fuse rating (-FS Version) Max. 12.0 A / 1000 V

- 17 -
000430BG
2 - Characteristics
Table: Technical Data PVI-6.0-TL-OUTD PVI-8.0-TL-OUTD PVI-10.0-TL-OUTD PVI-12.5-TL-OUTD
Output
AC Connection to the grid Three phase 3W or 4W+PE
Nominal AC output voltage (Vacr)400 V
Output voltage range
(Vacmin...Vacmin)320...480 V (1)
Nominal AC Output Power
(Pacr @cosφ=1)6000 W 8000 W 10000 W 12500 W
Maximum apparent
Output power (Smax)6700 VA 8900 VA 11500 VA 13800 VA
Maximum output current (Iacmax)10.0 A 13.0 A 16.6 A 20.0 A
Contribution to
short-circuit current 12.0 A 15.0 A 19.0 A 22.0 A
Inrush current Negligible
Maximum fault current <25 A rms (100ms)
Rated Output Frequency (fr)50 Hz / 60 Hz
Output Frequency Range
(fmin...fmax)47...53 Hz / 57…63 Hz (2)
Nominal Power Factor
> 0.995 (adj. ± 0.9
with Pacr =10.0 kW
± 0.8 with max
6.67kVA)
> 0.995 (adj. ± 0.9
with Pacr =10.0 kW
± 0.8 with max
8.9kVA)
> 0.995 (adj. ± 0.9
with Pacr =10.0 kW
± 0.8 with max
11.5kVA)
> 0.995 (adj. ± 0.9
with Pacr =12.5 kW
± 0.8 with max
13.8kVA)
Total Current Harmonic
Distortion < 2%
AC Connections Type Screw Terminal block (max cross-section 16 mm2); cable gland M40
Output protection
Anti-islanding Protection Complying with the local standard
Maximum AC Overcurrent pro-
tection 12.0 A 15.0 A 19.0 A 22.0 A
Output overvoltage
protection - Varistors 3, plus gas arrester
Operating performance
Maximum Efciency (ηmax)97.8%
Weighted Efciency(EURO/CEC) 96.5% / - 96.8% / - 97.1% / - 97.2% / -
Power Supply Threshold 30.0 W
Stand-by Consumption < 10.0 W
Communication
Wired Local Monitoring (opt.) PVI-USB-RS232_485 (opt.)
Remote Monitoring (opt.) VSN300 Wi Logger Card(3) (opt.), PVI-AEC-EVO (opt.),
VSN700 Data Logger (opt.)
Wireless Local Monitoring (opt.) VSN300 Wi Logger Card(3) (opt.)
User Interface LCD Display with 16 characters x 2 line
Environmental
Ambient temperature
-25...+60°C
-13...140°F
with derating above
55°C / 131°F
-25...+60°C
-13...140°F
with derating above
55°C / 131°F
-25...+60°C
-13...140°F
with derating above
55°C / 131°F
-25...+60°C
-13...140°F
with derating above
50°C / 122°F
Storage temperature -40...80°C (-40...+176°F)
Relative Humidity 0...100% condensing
Noise Emission < 50 db(A) @ 1 m
Maximum operating altitude 2000 m / 6560 ft
External environment
pollution rating 3
Environmental Category External

- 18 -
000430BG
2 - Characteristics
Table: Technical Data PVI-6.0-TL-OUTD PVI-8.0-TL-OUTD PVI-10.0-TL-OUTD PVI-12.5-TL-OUTD
Physical
Environmental Protection Rating IP 65
Cooling System Natural
Overvoltage rating as per
IEC 62109-1 II (DC input) III (AC output)
Dimensions (H x W x D) 716mm x 645mm x 224mm / 28.2” x 25.4” x 8.8”
Weight < 41 kg / 90.4 lb
Assembly System Wall bracket
Safety
Safety class I
Insulation level Without transformer (TL)
Marking CE (50Hz only)
Safety and EMC Standards
EN62109-1, EN62109-2, AS/NZS3100, AS/NZS 60950, EN61000-6-2,
EN61000-6-3, EN61000-3-11, EN61000-3-12
Grid Standard
VDE 0126-1-1,
VDE-AR-N 4105,
G83/2, G59/3,
C10/11, EN 50438
(not for all natio-
nal appendices),
RD1699, AS 4777,
ABNT NBR 16149,
Not certied CEI
0-21
CEI 0-21, CEI 0-16,
VDE 0126-1-1,
VDE-AR-N 4105,
G83/2, G59/3,
C10/11, EN 50438
(not for all natio-
nal appendices),
RD1699, RD1565,
AS 4777, ABNT
NBR 16149
CEI 0-21, CEI 0-16,
VDE 0126-1-1,
VDE-AR-N 4105,
G59/3, C10/11,
EN 50438 (not for
all national appen-
dices), RD1699,
RD1565, AS 4777,
BDEW, ABNT NBR
16149, CLC/FprTS
50549, PEA, MEA
CEI 0-21, CEI 0-16,
VDE 0126-1-1,
VDE-AR-N 4105,
G59/3, C10/11,
EN 50438 (not for
all national appen-
dices), RD1699,
RD1565, AS 4777,
BDEW, ABNT NBR
16149, CLC/FprTS
50549
1. The output voltage range may vary according to the grid standard of the country of installation
2. The output frequency range may vary according to the grid standard of the country of installation
3. Check availability before to order
Note. Features not specically mentioned in this data sheet are not included in the product

- 19 -
000430BG
2 - Characteristics
Tightening torques
To maintain the IP65 protection of the system and for optimal installa-
tion, the following tightening torques must be used:
AC cable gland 11 M40 (ring nut xing) 5.0 Nm
AC cable gland 11 M40 (locknut xing) 8.0 Nm
Service cable glands 12 M20 (ring nut xing) 2.5 Nm
Service cable glands 12 M20 (locknut xing) 7.0 Nm
MC4 or Weidmuller quick t connectors 09 10 2.5 Nm
Front cover 03 1.5 Nm
AC output terminal block 15 - 16 mm² Max 1.5 Nm
Signal terminal block 18 - 1.5 mm² Max 0.25 Nm
Overall dimensions
The overall dimensions are expressed in millimetres and inches and in-
clude the wall installation bracket
645 mm
25.4”
224 mm
8.8”
716 mm
28.2”
TRIO

- 20 -
000430BG
2 - Characteristics
Bracket dimensions
The wall mounting bracket dimensions are expressed in mm and inches
50.0 mm
1.96 in
8.0 mm
0.31 in
25.0 mm
0.98 in
7.0 mm
0.28 in
8.0 mm
0.31 in
1.5 mm
0.06 in
64.0 mm
2.52 in
257.5 mm
10.14 in
459.5 mm
18.09 in
515.0 mm
20.28 in
100.0 mm
3.94 in
315.0 mm
12.40 in
90.5 mm
3.56 in
55.5 mm
2.19 in
