AG Neovo FS-24G User manual

FS-24G & FS-27G LED-Backlit Monitor
User Manual
displays.agneovo.com

TABLE OF CONTENTS
2
SAFETY INFORMATION
WEEE...........................................................................................................................................................3
PRECAUTIONS
Notice...........................................................................................................................................................4
Cautions When Setting Up...........................................................................................................................4
Cautions When Using...................................................................................................................................5
Cleaning and Maintenance...........................................................................................................................6
Notice for the LCD Monitor...........................................................................................................................6
CHAPTER 1: PRODUCT DESCRIPTION
1.1 Package Contents..................................................................................................................................7
1.2 Installation..............................................................................................................................................8
1.2.1 Installing the Stand......................................................................................................................8
1.2.2 Adjusting the ViewingAngle and Height......................................................................................9
1.2.3 Wall Mounting............................................................................................................................11
1.3 Overview ..............................................................................................................................................12
1.3.1 Front View.................................................................................................................................12
1.3.2 Control Buttons..........................................................................................................................13
1.3.3 Rear View..................................................................................................................................15
CHAPTER 2: MAK ING CONNECTIONS
2.1 Connecting the AC Power....................................................................................................................16
2.2 Connecting Input Source Signals.........................................................................................................17
2.3 Connecting Audio Devices ...................................................................................................................18
CHAPTER 3: ON SCREEN DISPLAY MENU
3.1 Using the OSD Menu ...........................................................................................................................19
3.2 OSD Menu Tree ...................................................................................................................................20
CHAPTER 4: ADJ USTING THE LCD MONITOR
4.1 Colour Setting.......................................................................................................................................22
4.2 Picture Setting......................................................................................................................................23
4.3 OSD Setting .........................................................................................................................................24
4.4 Other Setting........................................................................................................................................25
4.5 Reset Setting........................................................................................................................................26
CHAPTER 5: APPENDIX
5.1 Warning Messages...............................................................................................................................27
5.2 Troubleshooting....................................................................................................................................28
5.3 Transporting the LCD Monitor..............................................................................................................29
CHAPTER 6: SPECIFICATIONS
6.1 Monitor Specications ..........................................................................................................................31
6.2 Monitor Dimensions..............................................................................................................................32

3
SAFETY INFORMATION
Safety Information
WEEE
Information for users applicable in European Union countries
e so on te proct or its pacain sinies tat tis proct as to e ispose
separately from ordinary household wastes at its end of life. Please kindly be aware that
this is your responsibility to dispose electronic equipment at recycling centers so as to help
conserve natural resources. Each country in the European Union should have its collection
centers for electrical and electronic equipment recycling. For information about your recycling
rop o󰀨 area pease contact or oca reate eectrica an eectronic eipent aste
management authority or the retailer where you bought the product.

PRECAUTIONS
4
PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Symbols used in this manual
This icon indicates the existence of a potential hazard that could result in personal injury
or damage to the product.
This icon indicates important operating and servicing information.
Notice
• Read this User Manual carefully before using the LCD monitor and keep it for future reference.
• e proct specications an oter inoration proie in tis ser Mana are or reerence on. 
information is subject to change without notice. Updated content can be downloaded from our web site at
displays.agneovo.com.
• To register online, go to displays.agneovo.com.
• To protect your rights as a consumer, do not remove any stickers from the LCD monitor. Doing so may
a󰀨ect te eterination o te arrant perio.
Cautions When Setting Up
Do not place the LCD monitor near heat sources, such as a heater, exhaust vent, or in direct
sunlight.
Do not cover or block the ventilation holes in the housing.
Place the LCD monitor on a stable area. Do not place the LCD monitor where it may subject to
vibration or shock.
Place the LCD monitor in a well-ventilated area.
Do not place the LCD monitor outdoors.
Do not place the LCD monitor in a dusty or humid environment.
Do not spill liquid or insert sharp objects into the LCD monitor through the ventilation holes.
oin so a case accienta re eectric soc or aae te  onitor.
Precautions

5
PRECAUTIONS
Cautions When Using
Use only the power cord supplied with the LCD monitor.
The power outlet should be installed near the LCD monitor and be easily accessible.
If an extension cord is used with the LCD monitor, ensure that the total current consumption
plugged into the power outlet does not exceed the ampere rating.
Do not allow anything to rest on the power cord. Do not place the LCD monitor where the
power cord may be stepped on.
 te  onitor i not e se or an inenite perio o tie np te poer cor ro
the power outlet.
To disconnect the power cord, grasp and pull by the plug head. Do not tug on the cord; doing
so a case re or eectric soc.
Do not unplug or touch the power cord with wet hands.
WARNING:
np te poer cor ro te poer otet an reer to aie serice personne ner
the following conditions:
• When the power cord is damaged.
• If the LCD monitor has been dropped or the housing has been damaged.
• If the LCD monitor emits smoke or a distinct odor.
Ceiling mount or mount on any other horizontal surface overhead are not advisable.
WARNING:
Installation in contravention of the instructions may result in undesirable consequences,
particularly hurting people and damaging property. Users who have already mounted the
monitor on the ceiling or any other horizontal surface overhead are strongly advised to
contact  eoo or constations an sotions to ep ensre a ost peasrae an
in onitor eperience.

6
PRECAUTIONS
Cleaning and Maintenance
o not attept to serice te  onitor orse reer to aie serice personne.
Opening or removing the covers may expose you to dangerous voltage or other risks.
Notice for the LCD Monitor
In order to maintain the stable luminous performance, it is recommended to use low brightness setting.
Due to the lifespan of the lamp, it is normal that the brightness quality of the LCD monitor may decrease
with time.
When static images are displayed for long periods of time, the image may cause an imprint on the LCD
monitor. This is called image retention or burn-in.
To prevent image retention, do any of the following:
• Set te  onitor to trn o󰀨 ater a e intes o ein ie.
• Use a screen saver that has moving graphics or a blank white image.
• Switch desktop backgrounds regularly.
• st te  onitor to o ritness settins.
• rn o󰀨 te  onitor en te sste is not in se.
Things to do when the LCD monitor shows image retention:
• rn o󰀨 te  onitor or etene perios o tie. t can e seera ors or seera as.
• Use a screen saver and run it for extended periods of time.
• Use a black and white image and run it for extended periods of time.
There are millions of micro transistors inside the LCD monitor. It is normal for a few transistors to be
damaged and to produce spots. This is acceptable and is not considered a failure.

7
CHAPTER 1: PRODUCT DESCRIPTION
1.1 Package Contents
When unpacking, check if the following items are included in the package. If any of them is missing or
damaged, contact your dealer.
Chapter 1: Product Description
Note:
• Use only the supplied power cord.
• The above pictures are for reference only. Actual items may vary upon shipment.
LCD Monitor
Quick Start Guide
Stand
Power Cord
Warranty Card
Audio Cable
FS-24G/FS-27G_Quick Guide_V010
Quick Start Guide
FS-24G & FS-27G LED-Backlit Monitor
displays.agneovo.com
FS-24G FS-27G
HDMI Cable

8
PRODUCT DESCRIPTION
1.2 Installation
1.2.1 Installing the Stand
1. Place the LCD monitor with the screen side down on a cushioned surface.
2. Attach the stand to the LCD monitor.
a. Rotate the base mount 90° counter-clockwise.
b. Attach the stand to the base mount.
c. Fasten the screw to secure the stand. Then push the screw ring down to lock it in place.
FS-24G
FS-27G

9
PRODUCT DESCRIPTION
1.2.2 Adjusting the Viewing Angle and Height
For optimal viewing, it is recommended to look at the full face of the screen, then adjust the screen of the LCD monitor
angle and height according to your preference.
Hold the stand so that the screen does not topple when you make the adjustment.
You are able to adjust the screen angle and height as below:
• Tilt angle:
FS-24G
-5°~ +20°
FS-27G
-5°~ +22°
• Swivel angle:
FS-24G
40°
320°
FS-27G
40°
320°

10
PRODUCT DESCRIPTION
• Pivot angle:
90°
0°~ 90°
FS-24G
90°
0°~ 90°
FS-27G
Note: Before making the adjustment, make sure to adjust the height to the highest position, and then tilt the
screen 90˚.
• Height adjustment:
0 ~ 100 mm
10cm
FS-24G
0 ~ 130 mm
13cm
FS-27G

11
PRODUCT DESCRIPTION
1.2.3 Wall Mounting
To wall mount the LCD monitor, do the following steps:
1. Remove the base mount.
a. Remove the screws securing the base mount from the LCD monitor.
b. Remove the base mount (with the attached stand).
FS-24G
FS-27G
2. Wall mount the LCD monitor.
Screw the mounting bracket to the VESA holes at the rear of the LCD monitor.
DP HDMI
100 mm
10
0 mm
DP HDMI
100 mm
10
0 mm
FS-24G FS-27G
Note: Take measures to prevent the LCD monitor from falling down and lessen possible injury and damage
to the monitor in case of earthquakes or other disasters.
• Use only the 100 x 100 mm wall mount kit recommended by AG Neovo. All
AG Neovo wall mount kits comply with VESA standard.
• Secure the LCD monitor on a solid wall strong enough to bear its weight.
• It is suggested to wall mount the LCD monitor without tilting it facing
downward.

12
PRODUCT DESCRIPTION
1.3 Overview
1.3.1 Front View
1
2
1Monitor screen
2Control buttons
Press the button to perform its function. For more information about each button, refer to pages
13-14.

13
PRODUCT DESCRIPTION
1.3.2 Control Buttons
LED Indicator
FS-24G FS-27G
LED Indicator
Button Description
Menu Button
(MENU)On Screen Display (OSD) • Press to call out the OSD menu.
During OSD menu
• se to conr te seection or enter a sen.
Left / Right Button
(t/u)Volume Bar • Press the ubutton to call out the volume bar.
Audio Volume
50
Then press the t/ubutton to adjust the volume level.
Note: During volume or menu setting adjustment, press and hold the t/ ubutton
to change the values continuously.
Input Select Bar
• Press the tbutton to call out the Input Select bar.
VGA DPHDMI
Then press the t/ubutton to switch the input source and press the MENU
tton to conr.
During OSD menu
• Use to scroll through the menu options.
• Use to select an option and adjust the settings.

14
PRODUCT DESCRIPTION
Button Description
Auto Button
(AUTO)Auto Adjustment (available in VGA input only) Press to perform auto adjustment. This function automatically tunes the LCD
monitor to its optimal setting, including horizontal position, vertical position, clock,
and phase.
When auto adjustment is initiated, the below message is displayed on the screen.
Auto Adjust
When the message disappears, this indicates the auto adjustment is completed.
Note: • During auto adjustment, the screen will slightly shake for a few seconds.
• It is recommended to use the auto adjustment function when using the
LCD monitor for the rst time or after a resolution or frequency change.
During OSD menu
• Use to close the OSD menu or exit a submenu.
During volume adjustment
• Use to close the volume bar.
Power Button ( )Power ON/OFF
• Press once to turn the monitor ON.
• Press again to turn the monitor OFF.
LED Indicator LED lights green during normal operation and blinks green when on standby
mode.

15
PRODUCT DESCRIPTION
1.3.3 Rear View
HDMI VGA AUDIO
IN
DP
DP HDMI
AUDIO
IN
HDMI VGA
DP
FS-24G FS-27G
1 4 5
32 6
1
AC power input.
2DP(DisplayPort)
Connect DisplayPort signals input.
3HDMI
Connect HDMI signals input.
4VGA
Connect VGA signals input.
5AUDIO IN
Connect audio signals input (3.5 mm Stereo Audio Jack).
6
Connect a headphone (3.5mm Stereo Audio Jack).

CHAPTER 2: MAKING CONNECTIONS
16
CAUTION:
Make sure that the LCD monitor is not connected to the power outlet before making any
connections. Connecting cables while the power is ON may cause possible electric shock or
personal injury.
2.1 Connecting the AC Power
1. Connect the power cord to the AC power input at the rear of the LCD monitor.
2. Connect the plug to a power outlet or power supply.
AC IN
CAUTION:
When unplugging the power cord, hold the power cord by the plug head. Never pull by the
cord.
Chapter 2: Making Connections

17
MAKING CONNECTIONS
2.2 Connecting Input Source Signals
Input source signals can be connected with either of the following cables:
HDMI VGADP
HDMI VGA
DP • DisplayPort
Connect one end of a DisplayPort cable to the DisplayPort
connector of the LCD monitor and the other end to the
DisplayPort connector of the computer.
• HDMI
Connect one end of an HDMI cable to the HDMI connector of
the LCD monitor and the other end to the HDMI connector of
the computer.
• VGA
Connect one end of a D-sub 15-pin cable to the VGA connector
of the LCD monitor and the other end to the D-sub connector of
the computer.

18
MAKING CONNECTIONS
2.3 Connecting Audio Devices
• Audio Input
Connect one end of an audio cable to the audio port of the LCD monitor and the other end to the audio port
of the computer.
AUDIO
IN
Audio Out
• Audio Output
Connect a headphone to the headphone jack of the LCD monitor.

19
CHAPTER 3: ON SCREEN DISPLAY MENU
3.1 Using the OSD Menu
1. Press the MENU button to call out the OSD window.
Submenu
1920x1080 60Hz
Contrast 78
Brightness
Color Temp.
Auto Adjust
Color Adjust
90
M enu
option
During H DM I/DisplayP ort
input, Picture Setting is
disabled and grey out.
2. Press the tor ubutton to select a menu and press the MENU button to enter the selected
menu.
1920x1080 60Hz
H. Position 50
V. Position
Clock
Phase
50
50
78
1920x1080 60Hz
H. Position
V. Position
Clock
Phase
50
50
50
78
A selected menu is highlighted in grey and the text of the selected menu option turns yellow.
3. Press the tor ubutton to select an option and press the MENU button to enter its
submenu.
1920x1080 60Hz
H. Position
V. Position
Clock
Phase
50
50
50
78
1920x1080 60Hz
H. Position
V. Position
Clock
Phase
50
50
50
78
The text of the selected menu option or submenu turns yellow.
4. Press the tor ubutton to adjust the settings.
5. To exit the submenu, press the AUTO button.
6. To close the OSD window, press the AUTO button twice.
Note: W hen settings are moie all changes are sae hen the user oes the folloing
• rocees to another menu
• Exits the O SD menu
• aits for the O SD menu to disappear
Chapter 3: On Screen Display Menu

20
ON SCREEN DISPLAY MENU
3.2 OSD Menu Tree
Main Menu Submenu Reference
Colour Contrast Refer to page 22.
Brightness
Color Temp. 9300
6500
5500
USER
Auto Adjust
Color Adjust
Picture H. Position Refer to page 23.
V. Position
Clock
Phase
OSD Language English Refer to page 24.
Français
Deutsch
Italiano

Spanish
Portuguese
日本語
한국어
繁體中文
简体中文
Polski
OSD H. Pos.
OSD V. Pos.
OSD Timer
Transparency
