AG AG-WHP01K User manual

AG-WHP01K
Bluetooth Headphone
User's Manual
取扱説明書
使用说明书

2 3
EN Product OverviewPackage contents
AG-WHP01K Carrying Pouch User’s Manual
(Warranty Card Included)
USB Type-C
Charging Cable
Analog Audio Cable
with 3.5mm Plug
Volume - Button
Charging Indicator
ANC (Active Noise
Cancelling) Button
USB Charging Port
Bluetooth/ANC
Status Indicator
Power Button
Volume + Button
3.5mm Audio Jack

4 5
Powering ON
Press and hold the Power Button for 3 seconds and the headphones will turn ON with a "Power
ON" announcement.
When the power is ON, the Bluetooth/ANC Status Indicator flashes in blue at a regular interval.
When the power is ON with the ANC function is activated, the Bluetooth/ANC Status Indicator
flashes alternately in blue and green at a regular interval.
Powering OFF
Press and hold the Power Button for 5 seconds and the headphones will turn OFF with a "Power
OFF" announcement. When the power is turned OFF, the Bluetooth/ANC Status Indicator lights up
red and fades off.
*To fully turn OFF the power of the headphones, please make sure to turn OFF the ANC function
too to prevent extra power consumption. ANC function might remain ON even after turning OFF
the headphone power.
Charging the Headphones
Connect the USB Charging Port to a charging adaptor with the supplied USB Type-C Charging
Cable. The Charging Indicator flashes red while charging and turns green when the headphones
are fully charged.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.

67
WHP01K
To perform initial device pairing:
1. Press and hold the Power Button for 3 seconds and the headphones will turn ON with a "Power
ON" announcement. The headphones start device pairing mode automatically with the
Bluetooth/ ANC Status Indicator flashing alternately in red and blue.
2. With the Bluetooth function of the device being ON, choose "WHP01K" under the device list.
The device pairing is successful if "WHP01K Connected" is shown.
To reinitiate device pairing with another device:
1. While the headphone power is OFF, press and hold the Power Button for 5s and the
headphones will turn ON and start device pairing mode with "Power ON" & "Pairing"
announcements and the Bluetooth/ANC Status Indicator flashes alternately in red and blue.
2. With the Bluetooth function of the device is ON, choose "WHP01K" under the device list. The
device pairing is successful if "WHP01K Connected" is shown.
* It is necessary to unpair the current device pairing before reinitiating a new device pairing. This
can be done by removing the current connection or turning off the Bluetooth function of the
current paired device.
Performing Device Pairing
In order to use the WHP01K with your device, initial device pairing is necessary. Once the
headphone is paired to a device, it will connect to the device automatically next time the
power is turned ON.
Activating ANC (Active Noise Cancelling) Function
Press and hold the ANC Button for 2 seconds and the ANC function will be activated in 2 different
ways depending on the status of the headphone.
If headphone power is ON: Announcement "Noise Cancelling" will be emitted and the
Bluetooth/ANC Status Indicator flashes alternately in blue and green at a regular interval.
If the headphone power is OFF: The Bluetooth/ANC Status Indicator will light up green.
*The ANC function can be activated even when the power is OFF. As ANC function consumes
battery power, when the headphones are not in use, please make sure that the ANC function is
properly turned OFF.
Deactivating ANC (Active Noise Cancelling) Function
Press and hold the ANC Button for 2 seconds and the ANC function will be deactivated in 2
different ways depending on the status of the headphone.
If the headphone power is ON: Announcement "OFF" will be emitted and the alternately flashing
blue and green light of the Bluetooth/ANC Status Indicator fades off.
If the headphone power is OFF: The green light of the Bluetooth/ANC Status Indicator fades off.
*The status of the ANC function when the headphone power is OFF can be easily recognizable by
refering to the Bluetooth/ANC Status Indicator.
Green light: ANC function ON
No light: ANC function OFF
Setting
Device

8 9
Performing Factory Reset
If the headphone is having difficulty pairing to a device, please follow the simple steps below to
perform a factory reset.
1. While the headphone power is ON, press and hold the Volume + Button and the Volume -
Button simultenously for 2 seconds and the Bluetooth/ANC Status Indicator will flash twice in
purple together with 2 beeps.
2. The factory reset is completed. The headphones will start device pairing mode automatically
with the Bluetooth/ANC Status Indicator flashes alternately in red and blue.
Connecting the Headphones to a Device Using the Analog Audio Cable
The headphones can be used with any device through physical wired connection by connecting
the headphones' 3.5mm Audio Jack to the device with the supplied analog audio cable. Once the
3.5mm Audio Jack is plugged in, the headphones will turn OFF immediately with all media controls
being disabled. Please perform media controls via the connected device instead.
* It is possible to activate the ANC fuction when the headphone is used with physical wired
connection.
* As the headphone power is OFF, no announcement of "Noise Cancelling" or "OFF" will be made
when the ANC function is activated or deactivated. Please refer to the Bluetooth/ANC Status
Indicator for the status of ANC function.
Music Playback
Phone Call
Music Playback /
Phone Call
Siri/
Google Assistant
Press the Power Button once
Press the Power Button once
Press and hold the Volume + Button for 2 seconds
Press and hold the Volume
- Button for 2 seconds
Press the Power Button once
Press the Power Button once
Press and hold the Power Button for 1second
Press the Volume + Button
Press the Volume
- Button
Press the Power Button twice *1
Media Control
Play
Pause
Next
Previous
Receiving Call
End Call
Declining Call
Increasing Volume
Decreasing Volume
Activating
* 1: There is a possibility that this does not work for certain devices.
*Media controls on the headphones are disabled when the headphone is used with physical
wired connection.

10 11
Troubleshooting : When you think, “Is it broken?”
Important Safety Instruction
·There is a risk of permanent hearing loss from extended use at excessive sound volumes. Please
do not exceed 40 hours use per week at a sound volume of 80 dB(A) or 5 hours per week at a
volume of 89 dB(A).
· To avoid electromagnetic interference, please refrain from use in places in which the use of
electronic devices is prohibited.
· If you are using a pacemaker or other electronic medical devices, please consult your physician
before using this product.
· This product contains small parts that may be hazardous to children, so please store in a place
that is out of the reach of children.
· Please do not subject to strong shocks or apply excessive force. Damage from abnormal use is
not covered by the warranty. To prevent damage, please store the earphones inside the case in
an appropriate location.
· Causing damage to the circuits may result in fire or electrical shock, so please do not attempt to
disassemble this product.
· Please keep this product away from water or other liquids that may cause shorts or other damage.
· Please do not attempt to repair this product yourself as unauthorized attempts at repair may
void the product warranty.
· Never use headphones when operating a bicycle, automobile, motorcycle or other motor vehicle
as this is a cause of traffic accidents and there is a risk of serious consequences. Even when
not driving, please do not use at railroad crossings, traffic intersections and other environments
where there is a danger in the inability to hear surrounding sounds.
· This product may be damaged if it is placed in locations where the environment is subject to
excessive direct sunlight, humidity, dust.
· A drastic change of air pressure inside the earcup could cause severe damage not only to
headphones but also to the ears. Please do not press the earcups when having the headphones on.
· Using headphones with earrings, piercings, or other jewelry on ears may cause injury. In
addition, they might cause degradation to the headphone performance or cause scratches to the
body of the headphones.
Power Button has not
been pressed for
adequate time
ANC function has not
been deactivated and
caused battery level
depletion
(Immediately after
purchasing )
Battery charge is low
Headphones will
not turn ON
Please press and hold the Power Button long
enough for the headphones to turn ON. Please
refer to "Powering ON" on P.5 for the details of
the method.
Analog Audio Cable
with 3.5mm Plug is
connected
Please disconnect the Analog Audio Cable
since the power is automatically turned OFF
once the Analog Audio cable is connected.
Please make sure that the ANC function is
properly turned OFF when not in use since the
ANC function can be activated even when the
power is OFF. After using the headphones,
please turn OFF the ANC function on top of
powering OFF. Otherwise the battery may run out.
For safety of transportation from overseas, laws
and regulations do not allow the internal battery
to be fully charged at the time of shipping.
For that reason, voltage may fall below the level
required for operation at the time the customer
opens the package. Fully charging the battery
before use may relieve this inconvenience.
Please refer to “Charging the headphones” on
P. 4 regarding the method for charging.
Problem RemedyCause

12 13
Problem RemedyCause Problem RemedyCause
ANC function has not
been deactivated
Interferance from
external factors
Unstable music
playback
Bluetooth communicates using the 2.4GHz band
which might be interefered by other wireless
standards such as Wi-Fi, etc.
Moreover, the connection is sensitive against
liquid where humidity, rain, or even the size of
head could cause disruption to the connection.
The specifications of the device to be connected
could cause variation too.
For that reason, reducing the distance between
devices or switching OFF unused Wi-Fi/Bluetooth
of surrounding devices may improve the
connection.
Headphones will
not turn OFF
An error has occurred
due to improper
operation
Power Button has not
been pressed for
adequate time
Headphone power automatically turns OFF once
the analog audio cable is connected. Please try
to connect the cable and check if the
Bluetooth/ANC indicator is completely turned
OFF or turned into Green. Then please
disconnect the cable and check again if the
power can be turned ON/OFF. If the problem is
not solved, please perform the factory reset by
referring to "Performing Factory Reset" on P.8.
Please press and hold the Power Button long
enough for the headphones to turn OFF.
Please refer to "Powering OFF"on P.5 for the
details of the method
The output of the USB
adapter being used
for charging is low
In case it takes
time to charge
Please make sure that the ANC function is
properly turned OFF since the ANC function can
be activated even when the power is OFF. After
using the headphones, please turn OFF the ANC
function on top of powering OFF. Please refer to
"Deactivating ANC Function" on P.6 for the
details of the method.
In case you are using the USB port on a PC,
etc., there are cases in which the output is low
and it may take more time to charge than the
time stated on the specification. As such please
use a 5V/1A USB adapter for charging this product.
Headphones are not
in the pairing mode
In some cases, performing a reset operartion
may fix the problem. Please refer to "Performing
Factory Reset" on P.8 for the method to reset
the headphones.
Headphones
cannnot be
detected / paired
Please try performing the pairing operation
again after having deleted the pairing
information from a previously paired device.
(Once pairing has been
performed) Connection
automatically established
with the previously
connected device
Microphone
cannot be used
As the power automatically turned OFF and the
microphone is disabled once the analog audio
cable is connected. Please disconnect the
analog audio cable.
Analog Audio Cable
with 3.5mm Plug is
connected
Troubleshooting : When you think, “Is it broken?” Troubleshooting : When you think, “Is it broken?”

14 15
9
This card is necessary in the event that the warranty is utilized. Please store
this card along with a receipt or other documentation showing the date of purchase
in a safe place to be produced in the event that the warranty is utilized.
Please refer to the manual for the provisions of the warranty.
Regularly wipe the headband and earpads with a soft, dry cloth to keep the headphones clean.
The warranty for this product is valid for 1 year from the date of purchase. During the warranty
period, the product will be repaired based on the provisions below. The warranty is only valid
in the country in which the product was purchased. In the event that after-sales service or
support on the purchased product is needed, please contact and discuss with the store you
made the purchase from. 
1. During the warranty period, a malfunctioning product will be repaired free of charge if the
product is proven to fail even though it was used in accordance with the instructions in the
user's manual and the point of caution sections.
2. In the following cases, product repair will be subject to a fee even during the warranty period:
(1) The necessary documentation noted in the warranty card is not complete.
(2) The product is identified to be modified, disassembled, or repaired by a third party or
customer other than our company or our authorized organizations.
(3) The headphones were subjected to a strong impact or were allowed to get wet. Product
failure resulting from excessive use of force on the product.
(4) Failure of the product or damage caused as a result of fire, earthquake, storm or flood
damage, lightning strike, or other natural disasters.
(5) Repair of scratches on the surface of the housing or repair of the housing itself.
Regarding the earpads:
Earpads are considered as consumable parts which is not covered under warranty. If you wish
to purchase a new pair of earpads, kindly contact the store you made the purchase from.
Maintenance
Warranty and after service
* There is a possibility of a change in the specification, so please scan this QR code
for the latest user’s manual.
Manufacturer:
Shenzhen Victory Flag Technology Co.,Ltd
No.1 Xiangqian Lane Huangzhu Village,Pingdi Sub-district, Longgang district, Shenzhen,
Guangdong, China
