AgfaPhoto Compact 104 User manual

Compact 104
User manual

AgfaPhoto Compact 104
1
Table of Contents
Preface................................................................................................................. 3
About this Manual .......................................................................................... 3
Safety and Handling Precautions................................................................... 3
Disposal of Waste Equipment by Users in Private Households in the
European Union............................................................................................. 4
Using this Menu ............................................................................................. 4
Introduction........................................................................................................... 5
System Requirements.................................................................................... 5
Main Features................................................................................................ 5
Package Contents.......................................................................................... 6
Camera Views................................................................................................ 7
Camera Buttons............................................................................................. 8
Navigation Control.......................................................................................... 9
Camera Memory .......................................................................................... 10
Getting Started.................................................................................................... 10
Attach the Camera Strap.............................................................................. 10
Inserting the Battery..................................................................................... 10
Inserting an SD/SDHC Memory Card............................................................11
Charging the Battery.....................................................................................11
Turning the Power On and Off...................................................................... 12
Initial Settings............................................................................................... 12
Modes .......................................................................................................... 12
Using the LCD monitor.......................................................................................13
LCD Monitor Layout.....................................................................................13
Changing the LCD Monitor Display.............................................................. 18
Recording Images, Videos and Voices............................................................... 18
Taking Images.............................................................................................. 18
Using the Stabilizer ...................................................................................... 19
Setting the Zoom Control .............................................................................19
Using Flash.................................................................................................. 20
Setting the Focus Mode ...............................................................................20
Using the Function Menu.............................................................................21
Using the Record Menu ...............................................................................25
Setting the Scene Mode...............................................................................25
Using Voices Recording............................................................................... 33
Recording Videos.........................................................................................37
Playback.............................................................................................................39
Viewing in Single Navigation........................................................................39
Viewing Thumbnails..................................................................................... 39
Zooming images........................................................................................... 40
Playing Videos ............................................................................................. 41
Playing Voice Recording..............................................................................41
Playing Voice Memo..................................................................................... 42
Deleting an Image/Video/Audio.................................................................... 42
Playback Menu............................................................................................. 43
Using the Setup Menu........................................................................................ 51
Setting Sounds............................................................................................. 51
Setting Power Save...................................................................................... 51
Setting LCD Save......................................................................................... 52
Setting Date & Time..................................................................................... 52

AgfaPhoto Compact 104
2
Setting Language......................................................................................... 52
Setting File Numbering................................................................................. 52
Setting TV Out.............................................................................................. 53
Setting LCD Brightness................................................................................ 53
Setting Battery Type..................................................................................... 53
Setting Memory Kit.......................................................................................53
Reset All....................................................................................................... 54
Making Connections...........................................................................................54
Connecting the Camera to a TV...................................................................54
Connecting the Camera to a PC .................................................................. 54
Setting the Print Mode Menu........................................................................56
Appendix ............................................................................................................ 57
About Folder and File Names....................................................................... 57
Troubleshooting..................................................................................................57
Specifications .....................................................................................................58
Customer care....................................................................................................59

AgfaPhoto Compact 104
3
Preface
About this Manual
This manual is designed to assist you in using your new AgfaPhoto digital camera. All information
presented is as accurate as possible but is subject to change without notice.
Copyright
This manual contains proprietary information protected by copyright. All rights are reserved. No part
of this manual may be reproduced by any mechanical, electronic or other means, in any form,
without prior written permission of the manufacturer.
© Copyright 2011 plawa-feinwerktechnik GmbH & Co. KG
Federal Communications Commission (FCC) Compliance
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the distance between the equipment and the receiver.
•Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Warning: A shielded-type power cord is required in order to meet FCC emission limits and to prevent
interference to radio and television reception. Use only shielded cable to connect I/O devices to this
equipment. Any changes or modifications not expressly approved by the manufacturer may void your
warranty and service agreement.
Declaration of Conformity
This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions:
•This device may not cause harmful interference.
•This device must accept any interference received, including interference that may cause
undesired operation.
Trademark Recognition
Windows 2000/XP/Vista/Win7 are registered trademarks of Microsoft Corporation in the United States
and/or other countries. Windows is an abbreviated term referring to the Microsoft Windows
Operation System. All other companies or product names are trademarks or registered trademarks of
their respective companies.
Safety and Handling Precautions
Camera Information
•Do not take apart or attempt to service the camera yourself.
•Do not expose the camera to moisture, or extreme temperatures.
•Allow the camera to warm up when moving from cold to warm temperatures.
•Do not touch the camera lens.
•Do not expose the lens to direct sunlight for extended periods.
•Do not use abrasive chemicals, cleaning solvents or strong detergents to clean the product.
Wipe the product with a slightly damp soft cloth.

AgfaPhoto Compact 104
4
Battery Information
•Turn off the camera before installing or removing the battery.
•Use only the provided batteries or type of battery and charger that came with your camera.
Using other types of battery or charger may damage the equipment and invalidate the
warranty.
•When the camera is used for an extended period of time, it is normal for the camera body to
feel warm.
•Download all pictures and don't remove the battery from the camera if you are going to store
the camera for a long period of time.
•The type of battery and the battery power level may cause the lens to be stuck up. Ensure you
use the correct battery type and use a fully charged battery.
• Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according
to the instructions.
Disposal of Waste Equipment by Users in Private Households in the
European Union
This symbol on the product or on its packaging indicates that this product must not be disposed
of with your other household waste. Instead, it is your responsibility to dispose of your waste
equipment by handing it over to a designated collection point for the recycling of waste electrical
and electronic equipment. The separate collection and recycling of your waste equipment at the
time of disposal will help to conserve natural resources and ensure that it is recycled in a manner
that protects human health and the environment. For more information about where you can drop
off your waste equipment for recycling, please contact your local city office, your household waste
disposal service or the shop where you purchased the product.
Using this Menu
Symbols used in this manual are explained below:
This indicates useful information when using your camera.
This indicates important message that should be read before using the function.

AgfaPhoto Compact 104
5
Introduction
Congratulations on your purchase of the new AgfaPhoto digital camera. Capturing high-quality digital
images is fast and easy with this state-of-the-art smart camera.
System Requirements
In order to get the most out of your camera, your computer must meet the following system
requirements:
For Windows:
•Windows 2000/XP/Vista/Win7
•Processor: Pentium II 450MHz or above
•Memory: 512MB or above
•HDD space: 200MB or above
•16bit color display monitor
•Microsoft DirectX 9.0C
•USB port and CD-ROM drive
For Macintosh:
•Power Mac G3 or later
•Mac OS 10.3X~10.6 <Mass storage>
•Memory: 512MB or above
•Q.Time player ver. 6.0.3 or above
•USB port and CD-ROM drive
Main Features
•14 mega pixels resolution
•Up to 3x optical zoom and 5x digital zoom
•2.7 inch color LCD monitor
•64MB internal flash memory with optional external SD/SDHC card
•Supports up to 4GB of SD card, and up to 32GB of SDHC card
•Easy-to-use button interface
•DCF, DPOF compatibility
•Slideshow to review still images
•A/V output to view your images, videos and audio on your TV
•USB port to transfer images, videos and audio to your PC

AgfaPhoto Compact 104
6
Package Contents
Please check the contents of your AgfaPhoto camera package. It should contain:
AgfaPhoto Compact 104 AA battery x 2 pcs
CD-Rom
Wrist strap USB cable Quick Start Guide/
User Manual (optional)

AgfaPhoto Compact 104
7
Camera Views
Front View
1. Flash
2. Self-timer LED/
AF Assist Lamp
3. Lens
4. Microphone
Back View
5. LCD monitor
6. Zoom buttons
7. Playback button
8. LED indicator
9. SET button/4-way
navigation control
10. Function/
Delete button
11. Menu button
Top View
12. Power button
13. Speaker
14. Stabilizer button
15. Shutter button

AgfaPhoto Compact 104
8
Bottom View
16. Battery
compartment
17. Tripod screw hole
18. Memory card
compartment
Left/Right View
19. Strap ring
20. USB/TV Out
Camera Buttons
Your camera is equipped with different buttons for ease of use.
Button Description
Power Press the Power button to turn the power on/off.
Stabilizer The stabilizer sets the optimal ISO value according to light levels to compensate for
camera shake. Press to set stabilizer on/off.
Shutter Press to capture an image or start/stop recording video or audio clip.
Zoom In Record mode, press the "W" button to zoom out, or "T" button to zoom in. In Playback mode, press to zoom in to magnify image or zoom out enter
9-image/calendar thumbnails.
Menu Press to enter or exit menu/submenu.
Function/Delete
In Record Mode, press to enter function menu.
In Playback mode, press to delete an image, video or audio clip.
Playback Press to enable Playback mode or return Record mode.

AgfaPhoto Compact 104
9
Navigation Control
The 4-way Navigation Control and the SET button allow you to access the various menus available
from the On Screen Display (OSD). You can configure a wide range of settings to ensure maximum
results from your images and videos. Further functions of these buttons are as follows:
No. Description
1 Face Tracking/Rotate Button
2 Macro Button
3 Display/Help Button
4 SET Button
5 Flash Button
Button Description
SET
1. Confirm a selection when using the OSD menus.
2. In Playback Movie/Audio mode, press to Start video or audio playback.
Flash/Right
1. In Photo Mode, press to scroll through the flash mode options.
(Auto, Anti Red-eye, Fill, Slow Sync and Off)
2. In Playback mode, press to view the next image, video or audio clip.
3. In playback Movie mode, press to Forward video playback.
4. In Menu, press to enter the submenu or to navigate through the menu
selections.
Macro/Left
1. In Photo Mode, press to scroll through Macro options. (Macro, Pan Focus,
Infinity and normal)
2. In Playback mode, press to view the previous image, video or audio clip.
3. In Playback movie mode, press to Rewind video playback.
4. In Menu, press to exit a submenu or to navigate through the menu selections.
Up/Face
Tracking/
Rotate
1. In Photo Mode, press to turn the face tracking function on and off.
2. Playing Video/Audio file, press to Pause/Start video or audio playback.
3. In Playback photo mode, press to rotate the image clockwise 90 degrees by
each press of the button. This feature is applicable for still images only.
4. In Menu, press to navigate through the menu and submenu selections.
Display/Down
1. The LCD monitor can be changed into 5 different types such as Basic, Full,
None, Guideline and Help screen.
2. In Playback Movie/Audio mode, press to stop video/audio playback.
3. In Menu, press to navigate through the menu and submenu selections.

AgfaPhoto Compact 104
10
Camera Memory
Internal memory
Your camera is equipped with 64MB of internal memory. Users can store images up to 14MB. If there
is no memory card inserted in the memory card slot, all images, videos and audio clips recorded are
automatically stored in the internal memory.
External storage
Your camera supports SD cards of up to 4GB in size. It also supports SDHC cards with a maximum
capacity of 32GB. If there is a storage card inserted in the memory slot, the camera automatically
saves all images, videos and audio clips in the external storage card. The icon indicates the
camera is using SD card.
Not all cards may be compatible with your camera. When purchasing a card,
please check the card's specifications and take the camera with you.
Getting Started
Attach the Camera Strap
Inserting the Battery
Follow these instructions to insert the battery into the battery compartment.
Please read "Battery Information" on page 4 before inserting/removing batteries.
1. Make sure the power is off before inserting the
batteries.
2. Unlock and open the battery compartment at the
bottom of the camera.
3. Insert the batteries into the compartment with the
terminal facing inside the camera with correct
orientation as shown.
4. Close and lock the battery compartment.

AgfaPhoto Compact 104
11
Inserting an SD/SDHC Memory Card
Expand your camera’s storage by using SD or SDHC memory
cards.
1. Unlock and open the memory card compartment at the
bottom of the camera.
2. Insert the SD/SDHC card into the memory card slot with
the metallic part facing the front side of the camera.
3. Push the SD/SDHC card into the memory slot until it
clicks into place.
4. Close and lock the memory card compartment.
To remove the SD/SDHC card
1. Unlock and open the memory card compartment.
2. Gently push the card until it pops out.
3. Pull out the card carefully.
Charging the Battery
The AA batteries that came with the camera are not rechargeable. Please replace new batteries
when they are exhausted. When charging the batteries, do not use batteries of different capacities or
brands. Failure to do so may damage the batteries.
1. Place the battery in the charger as shown.
2. Plug it into a power outlet.
•The light of the LED on the charger is orange when
charging is started and lights green when charging
is completed.
•It is recommended that you fully discharge the
battery before recharging.
•Charging time varies according to the ambient
temperature and the status of battery.
The battery may feel warm after it has been charged or immediately after being
used. This is normal and not a malfunction.
When using the camera in cold areas, keep the camera and battery warm by
holding them inside your outer clothes.

AgfaPhoto Compact 104
12
Turning the Power On and Off
There are two ways to turn on the camera:
• The startup image displays briefly and the startup sound plays if enabled. The zoom lens extends
and the camera is turned on in Record mode.
• The camera is turned on in Playback mode. The zoom lens is not extended.
To turn off the camera, press the Power button.
See "Modes" on page 12 to know more about Record and Playback mode.
Initial Settings
When you turn on your camera for the first time, you will be asked to do the initial settings of your
camera. First is the setup of language menu. Specify in which language menus and messages are to be
displayed on the LCD monitor.
Setting the Language
1. Press , , or to move through the selection.
2. Select a language, and then press SET to apply.
Setting the Date & Time
1. Press or to move through the selection.
2. Press or keys to change the value for the date and time.
3. Press SET to apply.
4. If necessary, press to close the menu.
Now, you are ready to start taking images and videos.
Holding down the or keys to change the values continuously.
Modes
Your camera has two modes:
Record Mode
This is the default mode while you turn on the camera every time. You are able to take images
and record video/audio clips in this mode.
Playback Mode
Press the Playback button after the camera is turned on to view and edit captured
images or playback videos and audio clips. The recording of voice memo attached to images is
available in this mode.

AgfaPhoto Compact 104
13
Using the LCD monitor
The LCD monitor shows all important information regarding camera settings as well as the visual
image of your image or video. The display on the LCD monitor is called the On Screen Display or
OSD.
LCD Monitor Layout
Photo Mode Screen Layout
No Item Description
1Record Mode Indicates the current mode.
2Flash Indicates flash settings.
3Self-timer/Burst Indicates drive mode settings.
4Zoom indicator Displays zoom.
5Shots remaining Indicates the remaining shots available.
6Battery Indicates battery level.
7 Storage media Indicates current storage media in use.
8Date stamp Indicates date stamp is enabled.
9AEB Indicates AEB function is enabled
10 Stabilizer Indicates stabilizer function is enabled.
11 Saturation Displays saturation settings.
12 Contrast Displays contrast settings.
13 Histogram Graphic display of Brightness.
14 ISO Displays ISO settings.
15 Focus area Use to frame subject to capture.
16 Shutter speed Displays shutter speed settings.
17 Aperture value Displays aperture settings.
18 Shake warning Indicates that the camera is shaking.
19 Macro Indicates macro is enabled.
20 Exposure Displays exposure settings.
21 Face tracking Indicates face tracking is enabled.
22 White balance Displays white balance settings.
23 Metering Displays metering settings.
24 Sharpness Displays sharpness settings.
25 Quality Displays quality settings.
26 Photo size Displays photo size settings.
27 AF lamp Indicates AF lamp is enabled.

AgfaPhoto Compact 104
14
Movie Mode Screen Layout
Standby layout Recording Layout
No Item Description
1 Record Mode Indicates the current mode.
2 Zoom indicator Displays zoom.
3 Time remaining Indicates the remaining time of video available.
4 Battery Indicates battery level.
5 Storage media Indicates current storage media in use.
6 Focus area Use to frame subject to record.
7 Macro Indicates macro is enabled.
8 White balance Displays white balance settings.
9 Metering Displays metering settings.
10 Movie size Displays movie size settings.
11 Key indicator Displays the commands on 4-way Navigation Control button
12 Recorded time Displays recorded time.
13 Recording status Indicates recording status.
14 Pre-record
Indicates pre-record is enable
The Pre-Record icon appears on the screen in red color as the same position as
zoom indicator.

AgfaPhoto Compact 104
15
Playback Mode Screen Layout
The Playback mode display varies depending on the type of image being viewed.
Playback mode display of still images:
No Item Description
1Playback mode Indicates playback mode.
2Protect Indicates file is protected.
3Voice memo Indicates voice memo is attached.
4Button intro
Indicates the button to press on the camera to play a video or audio
file.
5File no./Total no.
Indicates the file number over the total number of files in the storage
card.
6Battery Indicates battery level.
7Storage media Indicates used storage memory.
8Recording
information
Displays recording information of the file.
9DPOF Indicates the file is marked for printing.
10 Image Size Displays the image size settings.

AgfaPhoto Compact 104
16
Playback mode of videos:
No Item Description
1Playback mode Indicates playback mode.
2Protect Indicates file is protected.
3Video clip Indicates the file is a video.
4Button intro
Indicates the button to press on the camera to play a video or
audio file.
5File no./Total no.
Indicates the file number over the total number of files in the
storage card.
6Battery Indicates battery level.
7Storage media Indicates used storage memory.
8Recording date &
time
Displays the date and time of the video clip.
9Video size Indicates the size of the video clip.
10 Volume Indicates the volume while playing.
11 Video length Display the total length of the video clip.
12 Played time Indicates the played time of the video.
13 Playing status Displays playing status.
14 Capture image Capture the screenshot and save.

AgfaPhoto Compact 104
17
Playback mode of audio clips:
No Item Description
1Playback mode Indicates playback mode.
2Protect Indicates file is protected.
3Button intro
Indicates the button to press on the camera to play a video or audio
file.
4File no./Total no.
Indicates the file number over the total number of files in the storage
card.
5Battery Indicates battery level.
6Storage media Indicates used storage memory.
7Recording
information
Displays recording information of the file.
8Volume Indicates volume settings.
9Audio length Display the total length of the audio clip.
10 Played time Indicates played time.
11 Playing status Displays playing status.

AgfaPhoto Compact 104
18
Changing the LCD Monitor Display
The type of information displayed on the LCD monitor can be changed using the button. Press
the button repeatedly to change the LCD display from one type to another. In Photo/Movie
Mode, the LCD display can be changed into any of the following:
•Basic
•Full
•None
•Guideline
•Help screen
•The OSD information may vary depending on the record mode type.
•The following icons, if enabled, are still displayed on the LCD even when OSD
off or Guide lines on: AEB, Face tracking, AF lamp, Drive mode, and Macro.
•Use the "Guide lines" to properly set image for capture.
In Playback mode, the LCD display can be changed into any of the following:
•Basic
•Full
•None
•Help screen
LCD display cannot be changed in the following situations:
•Manual exposure mode
•Recording video or audio clips
•Playing video or audio clips
•Playing slideshow
Recording Images, Videos and Voices
Taking Images
Now that you are familiar with your camera, you are now ready to take your images. Taking images
with your camera is very simple.
1. Turn on the camera by pressing the Power button.
2. Frame the shot using the focus bracket on the LCD
monitor. See illustration on the right.
3. Pressing the Shutter button down halfway
automatically focuses and adjusts the exposure, and
pressing the Shutter button down fully captures the
images.
When the shake warning icon appears, hold the
camera steadily, with your arms at your side or use a tripod
to stabilize the camera to prevent blurred images.

AgfaPhoto Compact 104
19
Using the Stabilizer
The Stabilizer function works according to the luminance of the target object. This function uses
special image data processing for getting high sensitivity of CCD. High sensitivity can use higher
shutter speed compared with normal mode, so it reduces influence of hand shaking. Press the
stabilizer button before pressing the Shutter button.
Stabilizer button
Stabilizer
on
To activate Stabilizer
•Press the Stabilizer button on top of
your camera to enable/disable stabilizer.
If Stabilizer is enabled, the stabilizer icon is
displayed on the LCD monitor and the ISO
setting is automatically set to Auto. See "ISO"
on page 23 for more details.
Setting the Zoom Control
Using a combination of 3 times optical zoom and 5 times digital zoom permits zoom photography at
up to 15 times magnification. While the digital zoom can be a useful feature, the more an image is
enlarged (zoomed), the more pixelated (grainier) the image will appear. Please refer to "Setting the
Digital Zoom" on page 36 on how to setup digital zoom.
To adjusts the optical zoom:
1. Press the Zoom buttons to zoom in or zoom out an image.
2. The zoom indicator appears on the LCD monitor.
Zoom buttons
1. Press the "T" button to zoom in.
2. Press the "W" button to zoom out.
To adjusts the digital zoom:
1. Activate digital zoom. See "Setting the Digital Zoom" on page 36.
2. Press the T button to optically zoom in to the maximum until it stops.
3. Release the Zoom buttons.
Optical zoom 1X to 3X Digital zoom 1X to 5X
Digital zoom is not activated in recording videos
.
